AeroWorks ULTIMATE 20-300 ARF-QB User manual

1
100cc-120cc ULTIMATE 20-300
ARF-QB
(Quick Build)
ASSEMBLY MANUAL
AEROWORKS
4903 Nome St.– Denver, CO. 80239
www.aero-works.net

2
TABLE OF CONTENTS
Page
Aeroworks Contact Information …………………………………………………………………………. 3
Introduction / Warranty…………………………………………………………………………. ………. 4
Kit Contents………………………………………………………………………………………………… 5
Items Needed To Complete ……………………………………………………………………………….. 8
Tightening and Re-shrinking The Covering ………………………………………………………………13
Ultracote™ Colors…………………………………………………………………………………………. 14
Checking Seams and Color Overlaps for Good Seal / Sealing Hinge Gaps ………..………………….. 15
Checking Hinges for proper throw ……………………………………………………………………….. 16
Checking Glue Joints …………………………………………………………………………………….… 17
Canopy/Front Hatch Warp Prevention…………………………………………………………………… 18
Wing Assembly………………………………………………………………….…………………………. 19
Stab and Elevator Assembly………………………………………………………………………………. 23
Rudder and Rudder Servos Installation ………………………………………………………. ……….. 25
Tail Wheel Installation ………………………………………………………………………….. ………. 33
Main Landing Gear and Wheel Pant Installation …………………………………………….. ……….. 36
Engine Installation ……………..…………………………………………………………………………. 39
Throttle Servo Installation ……………………………………………...………………………………… 41
Standard Muffler Installation ……………………………………………………………………………. 46
Canister Muffler Installation …………...………………………………………………………. ………. 47
Tuned Pipe Installation …………………………………………………………………………. ………. 50
Ignition Module Installation ……………………………………………………………………. ………. 53
Inner Cabane Installation …………………………………………………………………………………. 57
Fuel Tank Assembly and Installation ………………………………………………………….. ………. 59
Receiver/Battery Installation …………………………………..…………………………………………. 64
Cowl Installation for Standard Mufflers ………………………………………………………………... 68
Cowl Installation for Canister/Tuned Pipes …………………………………………...………………... 72
Manual Choke Installation ……………………………………………………………………... ………. 73
Preflight Preparation …………………………………………………………………………….. …..... .. 74
Center Cabane Fairing Installation …………………………………………………………………….. 79
Decal installation ………………………………………………………………………………………… 81
Center of Gravity / Control Throws ……………………………………………………………. ……… 85
Preflight Check List ……………………………………………………………………………………… 89
Optional Accessories……………………………………………………………………………………… 91

3
4903 Nome Street
Denver, CO 80239
Phone: [phone]
Fax: [phone]
Website: www.aero-works.net
E-mail: [email protected]
Tech Support: [email protected]
Thank you for choosing the Aeroworks 100cc-120cc Ultimate 20-300 ARF-QB. We put
great effort into making this plane the best model you will ever build and fly. We have
provided you with the highest quality kit and performance possible. We wish you great
success in the assembly and flying of your new Aeroworks 100cc-120cc Ultimate 20-
300 ARF-QB.
!WARNING!
An R/C aircraft is not a toy! If misused, it can cause serious bodily harm and property
damage. Fly only in open areas, and AMA (Academy of Model Aeronautics) approved
flying sites. Follow all instructions included with your plane, radio, and engine.
Aeroworks manufacturing guarantees this kit to be free from defects in both material
and workmanship at the date of purchase. This limited warranty does not cover any
component parts damaged by use or modification. In no case shall Aeroworks liability
exceed the original cost of the purchased kit. Further, Aeroworks reserves the right to
change or modify this limited warranty without notice.
In that Aeroworks has no control over the final assembly or materials used for final as-
sembly, No liability shall be assumed nor accepted for any damage resulting from the
use by the user of the final user-assembled product. By the act of using the user-
assembled product, the user accepts all resulting liability.
We, as the kit manufacturer, have provided you with a top quality, thoroughly tested kit
and instructions, but ultimately the quality and fly ability of your finished model
depends on how you build it; therefore, we cannot in any way guarantee the
performance of your completed model, and no representations are expressed or
implied as to the performance or safety of your completed model.

4
INTRODUCTION
Your new 100cc-120cc Ultimate 20-300 ARF-QB is a highly aerobatic airplane. It is ca-
pable of both precision and 3-D maneuvers. The aircraft builds easily, quickly, and precisely
due to its state of the art CAD design, LASER cut technology, and high quality included
hardware. We hope you enjoy building and flying your 100cc-120cc Ultimate 20-300
ARF-QB.
Great care has been taken in both the design and manufacturing of the 100cc-120cc Ulti-
mate 20-300 ARF QB to allow for the strongest and lightest construction possible. Only
the highest quality materials from the covering, paint, wood and hardware have been used in
the construction of this model.
The 100cc-120cc Ultimate 20-300 ARF-QB has been individually hand built, covered and
painted by trained and experienced craftsmen with over 25 years of manufacturing experi-
ence. Using CAD design, laser cut technology and jig-built assures accuracy in all stages of
production.
The 100cc-120cc Ultimate 20-300 ARF-QB is designed for gas engines in the 100cc-
120cc category. The DA-120cc engine is shown in the assembly instructions. The aircraft
was tested with the DA-120cc and has outstanding performance. The final choice of engine
is left up to the builder. A computer radio is recommended to allow the pilot to take advan-
tage of the full capabilities of this aerobatic aircraft.
IMPORTANT Please read through this assembly manual carefully, before starting the as-
sembly of your new model. Inventory and inspect all parts and hardware for any imperfec-
tions or damage. Notify Aeroworks immediately if there are missing or damaged parts
and do not proceed with the assembly.
INTENDED USE
This plane should not be regarded as a toy. This is an aerobatic plane and is recommended for pilots
who are beyond the trainer-stage and are comfortable with flying an aerobatic sport plane.
READ! LIMITED WARRANTY READ!
It is important to notify Aeroworks of any damage or problems with the model within 30
days of receiving your airplane to be covered under warranty. If you wish to return this air-
craft for any reason a 15% restock fee will be charged to the customer. In addition the cus-
tomer is responsible for all return shipping cost and all prior shipping cost will not be re-
funded. Parts will be exchanged or replaced once the original item is returned at the owner’s
expense. If you have any problems or questions, please contact Aeroworks.
Aeroworks cannot insure the skill of the modeler and cannot influence the builder during the
construction or use of this aircraft, and therefore, will not be accountable for any property
damage, bodily injury or death caused by this aircraft.
Aeroworks cannot insure the skill of the modeler and cannot influence the builder during the
construction or use of this aircraft, and therefore,

5
KIT CONTENTS
100cc-120cc Ultimate Parts List
BASIC AIRCRAFT PARTS:
Fuselage – covered, firewall fuel-proofed:
(16) 8-32 blind nuts installed for the main landing
gear mounting (8) and center cabane mounting (8)
(6) 4-40 blind nuts installed for the bottom cowling
(2) and stabilizer (4)
(4) Plastic vacuumed hatch covers for the center
cabane holes pre-glued
(2) 1000mm Antenna Tube installed
(2) 1200mm Elevator servo string installed
(2) 120mm Pull-Pull cable exist tubes installed
(1) Pilot holes pre-drilled for tail wheel assembly
(1) Top hatch cover for the engine box with AW
logo installed by (4) T2.6x10mm PWA screws
Bottom hatch cover for the engine box installed by
(4) 4-40x14mm hex style head bolts and
(4) 3mm flat washers
(1) Front Fuse bottom hatch cover with pre cut air
exit slots pre installed with (4) T2.6x10mm PWA
screws
(1) Rear Canister fuse bottom hatch cover with pre
cut air exit slots pre installed with (4)
T2.6x10mm PWA screws
(1) Rear Long Pipe fuse bottom hatch cover with
pre cut slots for stinger exit
(2) Bottom wing fillet installed – Left and Right,
painted
(1) Center Cabane assembly installed
(1) Front hatch cover – covered and installed on the
fuse by (4) 4-40x20mm hex style head bolts and
4-40 blind nuts
(1) Tinted Canopy installed on fuse by
(6) 4-40x20mm hex style head bolts and 4-40 blind
nuts and
(6) 6# bonded washers
Left Top Wing with Aileron – covered:
(2) 8-32 blind nuts installed for the Outer strut
mounting.
(2) 2mm steel L bracket – outer struts fitting pre-
installed at the root of the wing
(8) pin point hinges glued
(1) Aileron servo string installed
(1) Pilot holes pre drilled for control horn mounting

6
Right Top Wing with Aileron – covered:
(2) 8-32 blind nuts installed for the Outer struts
mounting.
(2) 2mm steel L bracket – outer struts fitting prein
stalled at the root of the wing
(8) pin point hinges glued
(1) Aileron servo string installed
(1) Pilot holes pre drilled for control horn mounting
Left Bottom Wing with Aileron–covered:
(2) 8-32 blind nuts installed for the Outer strut
mounting.
(8) pin point hinges glued
(1) Locater pin glued
(1) Aileron servo string installed
(1) Pilot holes pre drilled for control horns mounting
(2) Pre drilled holes for the wing retainer bolts
Right Bottom Wing with Aileron–covered:
(2) 8-32 blind nuts installed for the Outer strut
mounting.
(8) pin point hinges glued
(1) Locater pin glued
(1) Aileron servo string installed
(1) Pilot holes pre drilled for control horns mounting
(2) Pre drilled holes for the wing retainer bolts
Horizontal Stabilizer with elevator assembly with (12)
pin point hinges (glued)---covered
(2) Pilot holes pre drilled for control horns mounting
Rudder with (9) pin point hinges (not glued) – covered
(2) Pilot holes pre drilled for control horns mounting
SUB ASSEMBLIES:
#1:
(1) Fiberglass Cowling, - painted
(2) 6-32 blind nuts – pre installed for the top cowling
Mounting
(2) 4-40x16mm hex style head bolts for the bottom
cowling mounting
(2) 6-32 hex head bolts for top cowling mounting
(4) #6 bonded washers
(2) 3mm split ring lock washers
(2) 3.5mm split ring lock washers
#2: If center cabane fairing will be used
(1) Plastic vacuumed fairing for center cabane
(2) 8-32x40mm for fairing mounting
(4) 9mm (long) Metal Spacers
(4) #8 Bonded Washers
(2) 8-32 Lock Nuts
OR: If No center cabane fairing will be used
(2) 8-32x15mm bolt
(2) 8-32 Lock Nuts
#3:
(2) Aluminum Main Landing Gear, 1 left and 1 right,
painted
(2) 5mm dia. x 48mm AL Axle
(2) M8 lock nuts
(4) 5mm Wheel Collars with set-screws
(2) 8mm flat washers
(2) 4” Dia. Main Wheels
(4) 4-40x14mm hex style bolts for mounting wheel
pants
(4) 3mm flat washer for mounting wheel pants
(4) 3mm split ring lock washer for mounting wheel
pants
(8) 8-32x25mm hex head bolts for mounting main
landing gear
(8) 4mm flat washers for mounting main landing gear
(8) 4mm split ring lock washer for mounting main
landing gear
#4:
(2) Wheel Pants—1 Left and 1 Right---Painted
(4) 4-40 blind nuts installed in the wheel pants
#5:
(1) Aluminum Tail Wheel Assembly - Large
#6:
(2) Outer struts – Left and Right, covered, marked with
BL, BR
(8) 8-32x10mm hex head bolts for the Outer strut
mounting
(8) 8-32 lock nuts for the Outer strut mounting
(8) 2mm L steel Outer strut fittings
(8) 8-32x15mm hex head bolts for the steel L bracket
for Outer strut mounting
#7:
(6) 4-40 3” left hand and right hand threaded pushrod
with nuts and carbon tubes for elevators and ailerons
(1) Wrench for the left hand and right hand threaded
pushrod
(2) 4-40 x 300mm Threaded pushrod
(2) 4-40 solder couplers
(8) Brass spacers – 4 for ailerons; 2 for elevators; 1 for
throttle; 1 for choke
(10) 3mm flat washers – 4 for ailerons; 2 for elevators; 2
for throttle; 2 for choke
(16) 4-40 Ball Link – 8 for ailerons; 4 for elevators; 2
for throttle; 2 for choke
(16) 4-40x16mm hex style bolts
(16) 4-40 lock nuts
#8:
(2) 1.0x1100mm plastic coated pull-pull steel cable.
(4) 4-40 Metal R/C links with nuts
(4) 3.5x5mm brass pull-pull swaging tubes
(8) AL double control horns
(48) T2.6x16mm Phillips head mounting screws for the
control horns

7
(2) 4-40x36mm left hand and right hand threaded
pushrod for connecting rudder servo
(4) 4-40 ball links for connecting rudder servo
(2) 4-40x20mm hex head bolts for connecting rudder
servo
(4) 3mm flat washers
(4) Brass spacers
(2) 4-40 lock nuts
(4) 4-40 Ball Link for rudder servo
(4) 4-40x16mm hex style bolts for rudder control horns
(4) 4-40 lock nuts
(2) Brass spacers
(2) 3mm flat washers
#9:
(1) 1000cc Gas Fuel Tank assembly
(1) 750cc Gas Fuel Tank assembly-Smoke
(4) Brass barbs for fuel tank
(2) Fuel filler dot - 1 male and 1 female
#10:
(1) Choke servo mounting trays
(1) Pipe mounting bracket with silicon tube
(1) Canister mounting bracket with silicon tube
(2) Engine mounting templates
(1) 180x120x6mm foam for the Fuel tank
(1) 160x120x6mm foam for the Fuel tank
(2) 300x80x6mm sponge for the receiver and battery
(8) 8x450mm Nylon Ties for the fuel tank mounting
(10) 3x150mm Small Nylon ties for the fuel line
(6) 356x12.5mm Velcro
(6) Rubber grommets –each 2 for 6mm, 8mm,
10mm-fuel line and wire guide
(1) 16mm dia. aluminum insert
(1) Paper degree meter for the rudder - Large
(1) Card Stock (8-1/2”x12”) for making of the
template for cutting of cowling
(1) Pre Cut Template for cutting air exit slots in
bottom of cowling
(1) Custom Throw Meter
#11:
(24) 6.35mm aluminum engine stand offs.
(2) 4mm flat washers for top wing mounting
(4) 6-32x20mm hex head bolts for bottom wing
Mounting
(4) 3.5mm flat washers for bottom wing mounting
(4) 4-40x16mm hex style head bolts for stab mounting
(4) #6 bonded washers for stab mounting
(4) 3mm split ring lock washers for stab mounting
#12: (1) 23x740mm Carbon Compound top wing tube
(1) 23x740mm Carbon Compound bottom wing
tube with hard wood rod inside and pre-drilled
for mounting
bolts and marked L/R
(2) 10x140mm Aluminum Located Pins for Top
wing
(1) 12.5x456mm C/F Compound bottom wing tube
with hard wood rod inside and pre-drilled for
mounting bolts and marked L/R
(2) 12.5mm Carbon/Fiber Compound stabilizer tubes
– 440mm; 220mm
(2) 8-32x20mm hex head bolts for top wing
mounting
(2) 8-32 lock nuts for top wing mounting
(2) 4mm flat washers for top wing mounting
(4) 6-32x20mm hex head bolts for bottom wing
mounting
(4) 3.5mm flat washers for bottom wing mounting
(4) 4-40x16mm hex style head bolts for stab
mounting
(4) #6 bonded washers for stab mounting
(4) 3mm split ring lock washers for stab mounting
#13:
(1) 300x300mm True Red Covering
(1) 300x300mm Bright Yellow Covering
(1) 300x300mm Black Covering
OR:
(1) 300x300mm Pearl Blue Covering
(1) 300x300mm Cub Yellow Covering
(1) 300x300mm White Covering
(2) 20x1800mm Transparent Covering for the
sealing of the hinge gap
#14: Vinyl Decal Set
#15: Manual CD

8
Engine Option 1 : DA 120
HARDEWARE NEEDED TO COMPLETE
◊ 1 - DA 120
◊ 1 - Ignition Module
◊ 4 - 1/4-20 x 2 1/4” Mounting Bolts
◊ 8 - Fender Washers
◊ 4 - 1/4” Lock Nuts for engine mounting
◊ 3’ - Large Gas Fuel Line
◊ 1 - 27x12-28x12 2 Blade Propeller
Note: DA 120 can be purchased through
Aeroworks.
Engine Option 2: DA 100-L
◊ 1 - DA 100-L
◊ 1 - Ignition Module
◊ 4 - 1/4-20 x 2 1/4” Mounting Bolts
◊ 8 - Fender Washers
◊ 4 - 1/4” Lock Nuts for engine mounting
◊ 3’ - Large Gas Fuel Line
◊ 1 - 26x12-28x10 2 Blade Propeller
Note: DA 100-L can be purchased through
Aeroworks.
Engine Option 3: DLE 111
◊ 1 - DLE 111
◊ 1 - Ignition Module
◊ 4 - 1/4-20 x 2 1/4” Mounting Bolts
◊ 8 - Fender Washers
◊ 4 - 1/4” Lock Nuts for engine mounting
◊ 3’ - Large Gas Fuel Line
◊ 1 - 26x12-28x10 2 Blade Propeller
Note: DLE 111 can be purchased through
Aeroworks.

9
Exhaust Option 1: Compact Mufflers
HARDEWARE NEEDED TO COMPLETE
◊ 1 - Left Compact Muffler
◊ 1 - Right Compact Muffler
◊ 4 - Muffler Mounting bolts
◊ 4 - Lock Washers
◊ 2 - Smoke inlets
◊ 2 - Smoke inlet plugs
Exhaust Option 2: Canister Mufflers
◊ 2 - MTW TDH 75 Rear Exit Canisters
◊ 2 - 70mm Drop Headers
◊ 2 - 3” Teflon Couplers
◊ 2 - Header Gaskets
◊ 4 - Header Clamps
◊ 4 - Header Mounting Bolts
Exhaust Option 3: Tuned Pipes
◊ 2 - MTW RE-2 Tuned Pipes
◊ 2 - 70mm Drop Headers
◊ 2 - 3” Teflon Couplers
◊ 2 - Header Gaskets
◊ 4 - Header Clamps
◊ 4 - Header Mounting Bolts

10
Servo Option 1 : Sport Performance
HARDEWARE NEEDED TO COMPLETE
Hitec 7940TG Servos may be used for sport flying.
If flying more aggressive aerobatics please see servo
option two below.
Note: Servos available through Aeroworks
◊ 8 - Hitec 7940TG Servos for flight surfaces
◊ 1 - Hitec 5625MG Servo for throttle
Servo Option 2: Unlimited Performance
Hitec 7955TG Servos are recommended for unlim-
ited flying. These servos will provide the best per-
formance possible.
Note: Servos available through Aeroworks
◊ 7 - Hitec 7955TG Servos for flight surfaces
◊ 1 - Hitec 5625MG Servo for throttle
Recommended Spinner:
◊ 1 - 4” Spinner- Carbon Fiber Recommended
Note: Spinner available from Aeroworks
Electronic Accessories : Receiver
A 12 or 14 channel receiver is recommended, using a
receiver with 12-14 channels will allow the builder to
mix both the aileron and elevator servos together in the
radio. Mixing these functions will result in a great flying,
well trimmed airplane.
◊ 1 - 12-14 Channel 2.4 GHz or PCM Receiver
◊ 4 - Aileron
◊ 2 - Elevator
◊ 2 - Rudder
◊ 4 - Aileron
◊ 2 - Elevator
◊ 1 - Rudder

11
Receiver Power System :
HARDEWARE NEEDED TO COMPLETE
The Aeroworks 100-120cc Power package is
recommended. The package consists of the
following items:
◊ 2 - Fromeco Sahara Regulator Deans in 2 JR out
◊ 2 - Fromeco 2600mah Li-Ion Battery w/ Deans
◊ 2 - Smart-Fly Super Switch HD w/ Deans
Ignition Power System :
If using the DA 120 or any other gas engine the
Aeroworks Ignition Power System is recommended
◊ 1 - Fromeco 2600mah Li-Ion Battery w/
Universal Connector
◊ 1 - Smart-Fly Ignition Regulator
◊ 1 - MPI charge switch
Recommended Extensions:
22 AWG extensions are recommended through out
the 100cc Ultimate. The following sizes will be
used:
◊ 4 - 12” Extensions For Top and Bottom Wings
◊ 2 - 12” Extensions For Bottom Wing In Fuse
◊ 2 - 18” Extensions For Center Cabanes
◊ 1 - 18” Extension For Throttle Servo
◊ 2 - 48” Extensions For Elevators
Note: Extensions available from Aeroworks

12
BUILDINGACCESSORIES NEEDED TO COMPLETE
Tools:
• Allen wrenches US and Metric.
• Dremel cutting disc and sanding drum tool
• Electric drill and selection of bits
• Razor saw
• Flat head screwdriver
• Hobby heat gun
• Hobby iron and covering sock
• Masking tape
• Modeling knife
• Needle nose pliers or crimping tool
• Paper towels
• Pen, pencil or felt tipped marker
• Phillips screwdriver
• Rubbing alcohol
• Ruler and tape measure
• Scissors
• T pins
• Waxed paper
• Wire Cutters
Adhesives:
• 15-30 Minute epoxy
• Blue Loctite
• Epoxy mixing cups, mixing sticks, brushes
• CA kicker (optional)
• Thick, Thin and Medium CA
• Rubbing alcohol
• Wipes
WARNING
Some rubbing alcohols
may attack painted parts.

13
1. Open your kit slowly and take care not to dam-
age any parts of the kit. Remove all parts from
their plastic protective covers for inspection.
Before doing any assembly or installation of any
decals it is very important to re-shrink or re-
tighten the already applied covering. Due to the
shipping process, heat and humidity changes
from different climates, the covering may be-
come lose and wrinkle in the sun. If you take the
time to re-tighten the covering, you will be re-
warded with a long lasting beautifully covered
model.
TIGHTENINGAND RE-SHRINKING THE COVERING
2. Using your covering iron with a soft sock, gently
apply pressure and rub in the covering. If any
bubbles occur, your iron may be to hot. Reduce
heat and work slowly.
3. If bubbles persist, use a small pin to punch holes
in the bubble to relieve trapped air and reheat.
4. Use your heat gun with extreme caution. Take
care not to apply too much heat to one area for
long periods of time. This may cause the trim
colors to over shrink and pull away leaving un-
sightly gaps on the color lines. The trim stripes
are especially vulnerable to over shrinking.

14
1. Your model is covered with Ultracote™ covering.
In case of repairs, the colors are:
Red/Yellow/Black Scheme
Black #874
Silver #881
True Red #866
Bright Yellow #872
Ultracote™ Colors
Yellow/Silver/Blue Scheme
Pearl Blue #845
Silver #881
Cub Yellow #884
White #870

15
1. Go over all seams and color overlaps with your
sealing iron.
Note: Even if your models covering has no wrin-
kles out of the box it is still very important to
go over all seams and overlaps to make certain
they are sealed securely. This is especially
important at the leading edges of the wings and
stabs. We recommend checking the covering
after each flying session.
CHECKING SEAMS AND COLOR OVERLAPS FOR GOOD SEAL
SEALING HINGE GAPS
2. Use covering iron to ensure all edges, seams,
and color overlaps are securely sealed.
3. Sealing hinge gaps. This is an optional step
but is recommended.
Cut strips of the supplied clear covering to fit
the hinge gaps. Use covering iron to seal the
clear covering snugly into the bottom of the
hinge lines as shown for air tight hinge seals.
Note: The clear covering does have a transparent
protective backing. This must be removed
prior to applying heat and to the surface.
IMPORTANT:
It is the responsibility of the purchaser /
operator to check the covering seams and
overlaps for security and a good seal.
Aeroworks is not responsible for failure of
covering seams or overlaps during flight.
Note: If covering continues to lift apply a small
amount of thin CA underneath the covering.
Then using a clean rag apply pressure to secure.
One of the most important tools in your
flight box is a roll of clear tape. This can be
used at the field for fast and easy repairs of
the covering. Then once you have finished
flying the covering can be permanently
repaired.

16
CHECKING HINGES FOR PROPER THROW
2. Evenly heat each hinge along the entire length of
the wing. This will allow the hinge glue to soften
and the hinge to move into it proper position.
Hold the surface at full deflection until the
hinges have cooled down and the glue has re-
hardened.
3. If the elevator hinges are tight follow the
same process as described for the wings.
Note: Once these steps have been completed
the hinges will throw to their full deflect-
tion.
IMPORTANT
1. If control surfaces will not throw to full deflec-
tion it may be necessary using a heat gun to
apply heat to the knuckle of each hinge. This
will allow the hinges to move freely.

17
1. Go over all seams and glue joints with thin CA,
this will ensure your model lasts for many sea-
sons to come.
Note: Even if you can visibly see glue on all glue
joints it is still recommended that the joints be
reglued. Due to changes in humidity during the
life of the aircraft glue joints can separate, it is
always recommended that the glue joints be
checked before each flying session.
CHECKING GLUE JOINTS
2. Use thin CA to reglue any accessible glue joint
as shown below.

18
1. Leave the canopy bolted to the airframe at all
times unless working on the inside of the fuse.
Due to high humidity levels during the building
and shipping process the canopy may warp when
not bolted to the airframe.
CANOPY/FRONT HATCH WARP PREVENTION
2. The front hatch should also be bolted to the air-
frame whenever possible.

19
Aileron Servo Installation
1. The ailerons have been pre-hinged and glued to
the wing panels and are ready for flight. No
other steps are necessary for hinging. Clear
Covering is supplied for sealing the hinge gaps if
desired. However, due to the precisely aligned
and minimal hinge gap this step is optional.
◊ 1 - Wing panel
◊ 1 - Aileron servo
◊ 1 - 1 1/4” Servo Arm
◊ 4 - Servo Mounting Screws (Micro Fastener
Part number STW0209 recommended)
◊ 1 - 12” servo extension
◊ 1 - Aeroworks Safety Clip
WINGASSEMBLY
2. Attach the 12” servo extension to the servo wire
and secure using an Aeroworks Safety Clip.
Minimum recommended servo:
181 in. oz. / Metal Geared / Digital
3. Remove the balsa stick with the pull string from
the servo well and tie the pull string to the servo
lead as shown.
4. Pull the servo lead through the root end of the
wing.

20
5. Install servo in servo well with the output shaft
toward the leading edge of the wing.
Aileron Control Linkage Installation
1. Gather the aileron control linkage parts as shown
below.
◊ 4 - 4-40 x 3” Pushrods-With carbon reinforce-
ment sleeves
◊ 8 - 4-40 Ball Link Assemblies
◊ 4 - Flat Washers
◊ 4 - Brass Spacers
◊ 4 - Left Side Control Horns
◊ 4 - Right Side Control Horns
◊ 24 - Wood Screws
◊ 1 - Adjustment Wrench
3. Correct installation of ball link, flat washer and
brass spacer to servo arm shown below.
2. Assemble pushrod and control horn
assembly as shown. The ball link goes
between the left and right sides of the control horn
sides and is secured with a nylon lock nut.
Improperly installed servo linkages can cause ser-
vos to strip and ailerons to flutter. Aileron flutter
can and will destroy your model instantly!
Note: Flat washer prevents ball link from
coming off brass ball.
Leading
Edge
