Aervoe® Solar Strobe/Signal Light
#1197 Red or #1198 Yellow
IMPORTANT SAFEGUARDS
Read all instructions before operatings
Do not operate at temperatures above 149°F or below -4°Fs
To reduce the risk of electric shock, do not submerge the unit in any liquid. Unit is weatherproofs
but not submersible.
Do not use in flammable or explosive environmentss
For better light quality, protect the globe from scratchings
For maximum battery efficiency, never completely deplete stored powers
Use appropriate safeguards when mounting the light to any surfaces
PARTS IDENTIFICATION
CHARGING
Place unit in a sunny location, with the solar panel facing the sun to charge. Unit will not charge as quickly
on a cloudy day and not at all in complete darkness.
OPERATION
The unit will operate when the ON/OFF1. BUTTON is in the ON position, but charging is still possible.
When in the2. OFF position the unit will not flash and stored battery power will not be depleted.
Once the unit is charged it is operational. To activate the strobe, press the ON/OFF3. BUTTON and it will
start flashing when the ambient light is low enough.
The strobe will continue to flash as long as there is battery power and darkness. Once daylight4.
returns the flashing will stop and if kept in a sunny location, it will recharge.
You can test to make sure the ON/OFF BUTTON is either on or off by placing your hand over the solar5.
panel. If the light starts flashing it is in the ON position. If it does not flash, it is either in the OFF
position or battery power has been depleted.
BRACKET MOUNTING
Unit may be mounted vertically or horizontally to surfaces such as metal, concrete, wood, or asphalt; and to
plastic barricades and rubber safety cones. NOTE: Mounting hardware is not included. User is responsible
for ensuring proper selection of hardware, depending on location.
Remove unit from the MOUNTING BRACKET1.
Place the bracket in the desired location and mark either the horizontal (4-holes) or vertical (2-holes)2.
mounting holes.
Once bracket is securely mounted, slide unit into the bracket and operate as stated above.3.
SAFETY CONES
Unit may be used with rubber traffic safety cones that include a top inside hole diameter of at least 1 5/16”
to accommodate the shaft.
Vertical Mounting
(2-holes)
Horizontal Mounting
(4-holes)
Solar Panel 4 LED
Light Globe
Reflective Stripe
On/Off Button
(not visible) MOUNTING BRACKET
SOLAR STROBE/
SIGNAL LIGHT
Shaft
REPLACING THE BATTERY
The rechargeable battery may be replaced when the battery life has been
exceeded.
Remove the plastic seal cap on the SHAFT1.
Carefully pull out the battery and circuit plug from the unit2.
Unplug the battery and replace with the same size and capacity battery3.
Replace the plastic seal cap4.
