Aervoe® LED Road Flares #1183, 1184 & 1185
IMPORTANT SAFEGUARDS
Read all instructions before operating•
Do not look directly at the light; may cause injury to your eyes•
Turn off all lights before charging•
Do not use alcohol, flammable solutions, or other solvents on or near this unit. Only clean with•
warm water and a soft cloth.
Administer close supervision when using around children•
Waterproof only when used in accordance with manufacturer’s instructions•
PARTS IDENTIFICATION
CHARGING
The Flare may be charged using either a 12V car charger, 120V wall charger, or USB adapter (included).
Plug the1. USB PLUG into the appropriate 12V or 120V CHARGING ADAPTER, depending on your
application, or directly into your computer or other USB charging device.
Plug the male end of the2. USB CABLE into the female port of the MAGNETIC CONNECTOR HUB.
Connect the MAGNETIC CONNECTOR3. HUB to the FLARE aligning the (+) and (-) terminal symbols on
each. The MAGNET in the center will keep the two items connected.
Plug the 12V or 120V C4. HARGING ADAPTER into either a 12V power receptacle or 120V wall outlet.
Green LED = charge in process•
Red LED = fully charged OR the Flare and Hub are misaligned and need to be adjusted•
NOTE: Stand-by charging feature allows flares to be kept plugged in when not in use without damage to the
battery or unit. Ensures the flares will be charged and ready for use when needed.
OPERATION
Press the ON/OFF BUTTON to rotate through the following 9 light patterns:
#1 - Rotate
#2 - Quad Flash
#3 - Single Blink
#4 - Alternating Blinks
#5 - SOS Rescue (Morse Code)
#6 - Steady on - high
#7 - Steady on - low
#8 - 2 LED Flashlight
#9 - 4 LED Flashlight
#10 - Off
Alternate Operation:
To turn off the flare without cycling through the 9 light pattern, press and hold the ON/OFF BUTTON for 2
seconds. Two LEDs will flash five times and then turn off. When ready to operate again, press the ON/OFF
BUTTON and it will return to the last flash pattern that was selected before turning off.
RANGE OF USE
Safer and ecologically better for our environment than flame style emergency road flares. No spark,1.
open flame, fumes or toxic chemicals are produced when using the LED Road Flare.
Shock resistant construction makes the Flare very durable and can withstand the impact of roadside2.
traffic. Can even be run over by a truck and still operate. Used by fire, police, and other emergency
responders.
Lie flat or on its edge depending on your reference. Place on the road, at construction sites, vehicle3.
bumper or other surface, and anywhere needing emergency signaling.
The LED Road Flare is waterproof so it may be used for marine applications and safely in wet4.
environments, including submerged to a depth of 33 feet. Will float unless secured.
Using the magnet on the back, attach to any magnetic metal surface. Place on a vehicle, fence, or5.
other metal surface.
Flares will keep a full charge for 90 days.6.
NOTE: It is not recommended that you disassemble the Flare. If it is not reassembled correctly it may result
in failure of the waterproof seal and damage to the unit.
FRONT
BACK

OPERATING INSTRUCTIONS
TECHNICAL INFORMATION
SPECIFICATIONS
INTERNAL RECHARGEABLE BATTERY Lithium Ion 700 mAh ~ 3.7V
5+ year life
CHARGING SPECIFICATIONS
120V AC/DC CHARGER:
(UL Listed)
12V DC CHARGER:
(CE)
Input: 100-240V AC, 50-60 Hz 0.15A
Output: 5.0 V DC 1000 mAh
Input: 12-24V DC
Output: 5.0V 850 mAh
TEMPERATURE RANGE -32ºF TO 240ºF (-36ºC - 116ºC)
DOT & TRAFFIC SAFETY COMPLIANCE U.S. DOT (FMCSA) 49 CFR1. § 392.25 & 393.95 (g)
(prohibits the carrying of any flame-producing flare
on any Commercial Motor Vehicle (CMV) transporting
explosives; any cargo of flammable liquid or flammable
compressed gas, whether loaded or empty; or any CMV
using compressed gas as a motor fuel).
MUTCD Type A (flashing) and Type C (solid on)2.
NFPA 1901 Standards for Traffic Safety; Section 6.7.33.
Miscellaneous Equipment
WEIGHT 10 oz.
DIMENSIONS 4.25” L x 4.375” W x 1.375” H
POWER DURATION RUN TIME
The battery will be fully charged with either charger
within 2-3 hours. When fully charged you may expect
these run times*:
#1 - Rotate 7 hours
#2 - Quad Flash 7 hours
#3 - Single Blink 50 hours
#4 - Alternating Blinks 7 hours
#5 - SOS Rescue (Morse Code) 12 hours
#6 - Steady on - high 4 hours
#7 - Steady on - low 30 hours
#8 - 2 LED Flashlight 7 hours
#9 - 4 LED Flashlight 5 hours
* #1183 Blue LED Road Flare realizes 25% less operating time.
AERVOE INDUSTRIES INCORPORATED
Gardnerville, NV 89410 • 1-800-227-0196
www.aervoe.com • [email protected]
1185inst; cs5/10
