Aetechron 2100 series User manual

Multi-Amp Configuration Guide
Step-by-Step Guide to Multi-Amp Systems
using AE Techron 2100 and 7000-Series Amplifiers
574.295.9495 | www.AETechron.com
2507 Warren Street, Elkhart, IN 46516

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
2Information subject to change 97-8002465_09-19-14
1Multi-Amp Systems Using 2100 or 7000 Series Amplifiers ................................................................. 4
1.1 Safety First ...................................................................................................................................................4
1.2 Overview.......................................................................................................................................................4
1.3 Multi-Amp Configuration Accessories ..........................................................................................................4
1.4 Accessory Recommendations by System Type ............................................................................................5
2Multi-amp System Principles .............................................................................................................. 6
2.1 One Master Amplifier for Series Systems ....................................................................................................6
2.2 All Master Amplifiers for Parallel Systems ...................................................................................................6
2.3 Use only 7000-Series Amplifiers of the same Model Number ....................................................................6
2.4 Use Correct Wiring........................................................................................................................................6
2.5 When Constructing Output Wiring, Use These Basic Criteria ......................................................................6
2.6 Operate with Safety in Mind.........................................................................................................................6
3Series Systems Configuration and Wiring............................................................................................ 7
3.1 Choosing Single-Ended or Differential Configuration for Two-amplifier Systems........................................7
3.2 Configure SIM-BNC-OPTOC Input Cards.......................................................................................................7
3.3 Install SIM-BNC-OPTOC Input Cards in Amplifiers........................................................................................8
3.4 Configure Amplifiers’ Main Boards for Slave Operation ..............................................................................8
3.5 Remove Output Terminal Resistor ...............................................................................................................9
3.6 Attach Master/Slave Labels (optional) ........................................................................................................9
3.7 Series System Wiring ................................................................................................................................ 10
3.8 Two in Series –Differential....................................................................................................................... 10
3.9 Two or Three in Series –Single Ended ..................................................................................................... 13
4Parallel Systems Configuration, Wiring and Balancing ....................................................................... 17
4.1 Install Ballast Resistors ............................................................................................................................ 17
4.2 Main Board Access.................................................................................................................................... 18
4.3 Disable Gain Controls (7224 amplifiers only)........................................................................................... 18
4.4 Parallel System Balancing......................................................................................................................... 19
4.5 Connect for Balancing............................................................................................................................... 19
4.6 Verify Interlock Operation.......................................................................................................................... 20
4.7 Adjust DC Offset ........................................................................................................................................ 20
4.8 Wire and Connect Parallel Inputs ............................................................................................................. 20
4.9 Verify and Adjust Amplifier Gain................................................................................................................ 21
4.10 Amplifier Gain Matching............................................................................................................................ 22
4.11 Verify Minimal Circulating Currents .......................................................................................................... 24
4.12 Verify Current Sharing ............................................................................................................................... 24
Appendix A Wire Current-Carrying Capacity ............................................................................................... 17
Appendix B Critical Wire Lengths in Parallel Systems................................................................................. 17
Appendix C Building Parallel System Output Cables................................................................................... 17
Appendix D Building the DB-25 Interlock Cable ......................................................................................... 30
Appendix E Returning Slave Amplifiers to Stand-Alone Use ........................................................................ 31
Table of Contents

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
97-8002465_09-19-14 Information subject to change 3
List of Figures
Figure 1.1 –Maximum Continuous Output in 7000-Series Multi-amp Systems.................................................. 4
Figure 3.1 –Two in Series: Single-Ended vs. Differential........................................................................................ 7
Figure 3.2 –SIM-BNC-OPTOC card jumper locations............................................................................................... 7
Figure 3.3 –7224 Amplifier Access Panel Screw Locations ................................................................................. 9
Figure 3.4 –Master/Slave Jumper Locations.......................................................................................................... 9
Figure 3.5 –7224 Output Terminal Resistor ........................................................................................................... 9
Figure 3.6 –7548/7796 Output Terminal Resistor................................................................................................ 9
Figure 3.7 –Terminating the Amplifier Input .........................................................................................................10
Figure 3.8 –Verifying DC Offset ..............................................................................................................................11
Figure 3.9 –Verifying Amp Gain ..............................................................................................................................11
Figure 3.10 –Verifying System Gain.......................................................................................................................12
Figure 3.11 –Two Amplifiers in Series –Differential Configuration ....................................................................12
Figure 3.12 –Terminating the Amplifier Input .......................................................................................................13
Figure 3.14 –Verifying Amp Gain............................................................................................................................14
Figure 3.13 –Verifying DC Offset ............................................................................................................................14
Figure 3.15 –Verifying System Gain.......................................................................................................................15
Figure 3.16 –Two Amplifiers in Series –Single-Ended Configuration.................................................................15
Figure 3.17 –Three Amplifiers in Series –Single-Ended Configuration..............................................................16
Figure 4.1 –7224 Ballast Resistor Mounting........................................................................................................17
Figure 4.2 –7796 Ballast Resistor Mounting........................................................................................................17
Figure 4.3 –7224 Ballast Resistor Connected to Output Terminal.....................................................................17
Figure 4.4 –7796 Ballast Resistors Connected to Output Terminal...................................................................17
Figure 4.5 –Access Panel Screw Locations...........................................................................................................18
Figure 4.6 –Gain Control Connection on Main Board..........................................................................................18
Figure 4.7 –Gain Control Pin Settings....................................................................................................................19
Figure 4.8 –Connecting for Balancing (Four in Parallel shown)...........................................................................19
Figure 4.9 –Terminating the Amplifier Input .........................................................................................................20
Figure 4.10 –Main Board Balancing Control Locations........................................................................................20
Figure 4.11 –Wiring and Test Points for DC Offset...............................................................................................21
Figure 4.12 –Wiring the Paralleled Input Wire ......................................................................................................21
Figure 4.13 –Optional BNC Parallel Input Wiring (Three in Parallel shown)......................................................21
Figure 4.14 –Wiring and Test Points for Amp Gain...............................................................................................22
Figure 4.15 –Wiring and Test Points for Gain Matching ......................................................................................23
Figure 4.16 –Two Amplifiers Paralleled .................................................................................................................24
Figure 4.17 –Three Amplifiers Paralleled ..............................................................................................................25
Figure 4.18 –Four Amplifiers Paralleled ................................................................................................................26
Figure A-1 –Wire Current-Carrying Capacity Chart ................................................................................................27
Figure B-1 –Critical Wire Lengths in Parallel Systems..........................................................................................28
Figure C-1 –Output Cables constructed for use in a Two-in-Parallel System......................................................29
Figure D-1 –DB-25 Cable Wiring for a Four-in-Parallel System............................................................................30
Figure E-1 –7224 Access Panel Screw Locations.................................................................................................31
Figure E-2 –Master/Slave Jumper Locations ........................................................................................................31
Figure E-3 –Output Terminal Resistor....................................................................................................................31
Figure E-4 –7548/7796 Output Terminal Resistor ..............................................................................................31
Figure E-5 –SIM-BNC-OPTOC, Factory Default Settings........................................................................................32

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
4Information subject to change 97-8002465_09-19-14
1.1 Safety First
Throughout these instructions special emphasis is placed on good safety practices. The WARNING and
CAUTION graphics are used to highlight certain topics that require extra precaution.
1.2 Overview
A single AE Techron amplifier can provide continuous output current or voltage only up to a certain level. If
you need increased output above those levels, you can combine multiple amplifiers into a system that can
provide increased voltage or current. Because the internal circuitry of a 2100 or 7000-Series amplifier is not
connected to chassis ground, these
amplifiers are well suited for use in
series or parallel with other like-
model amplifiers within the Series.
Each amplifier added to a Series
multi-amp system will increase the
continuous voltage output, while
each amplifier added to a Parallel
multi-amp system will increase the
continuous current output. See
Figure 1.1 for the approximate
output levels you can expect from
each multi-amp system.
While it is possible to operate a
multi-amp system in either
Controlled Voltage or Controlled
Current modes of operation, multi-
amp operation in Controlled
Current mode requires additional
equipment configuration, and so is
beyond the scope of this Guide.
Please contact AE Techron Tech Support for assistance with configuring a multi-amp system for
Controlled Current operation.
For assistance in determining the best multi-amp configuration to meet your requirements, please contact AE
Techron.
This Guide will provide step-by-step instructions for setting up a Series or Parallel controlled-voltage multi-
amp system using AE Techron 2100 or 7000-Series amplifiers.
1.3 Multi-Amp Configuration Accessories
The following accessories are available from AE Techron. They are recommended for use in the configuration
of AE Techron multi-amp systems. For a listing of recommended accessories by multi-amp system type,
please refer to Section 1.4.
SIM-OPTOC –Specialized input card required for all Series configurations. Includes input card and BNC
connector safety cover.
1Multi-Amp Systems Using 2100 or 7000 Series Amplifiers
Amplifier
Model
Configuration
Continuous Output
(100% Duty Cycle)
2105 or
7224
Two amps in Series
Up to 316 Vpk
Three amps in Series
Up to 474 Vpk
Two amps in Parallel
Up to 90 Apk
Three amps in Parallel
Up to 135 Apk
Four amps in Parallel
Up to 180 Apk
2110 or
7548
Two amps in Series
Up to 390 Vpk
Three amps in Series
Up to 585 Vpk
Two amps in Parallel
Up to 86 Apk
Three amps in Parallel
Up to 129 Apk
Four amps in Parallel
Up to 172 Apk
2120 or
7796
Two amps in Series
Up to 318 Vpk
Three amps in Series
Up to 477 Vpk
Two amps in Parallel
Up to 254 Apk
Three amps in Parallel
Up to 381 Apk
Four amps in Parallel
Up to 508 Apk
Figure 1.1 –Maximum Continuous Output in
2100 or 7000-Series Multi-amp Systems

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
97-8002465_09-19-14 Information subject to change 5
BALLAST RESISTOR KIT (BAL RES KIT) –Three types available: 2105/7224 BAL RES KIT, 2110/7548 BAL
RES KIT and 2120/7796 BAL RES KIT. Ballast resistors are required for all Parallel configurations. These
ballast resistor kits include one ballast resistor (two in the 2120/7796 kit) with connection terminals and
mounting hardware. The2105/7224 BAL RES KIT also contains the shunt required to defeat the amplifier’s
external level control.
NOTE: AE Techron Ballast Resistor Kits are sold as parts kits only. Buyers are responsible for
installing the Ballast Resistor Kit in a way that meets local Safety requirements.
Alternatively, ballast resistor installation, which will meet generic safety requirements, can be
ordered from AE Techron at the time of purchase or is available through AE Techron Service.
DB9M CABLE –High-voltage Interlock cable required for all Series configurations.
PARALLEL WIRING KITS –Six types available: 2105/7224 2-AMP, 2110/2120/7548/7796 2-AMP,
2105/7224 3-AMP, 2110/2120/7548/7796 3-AMP, 2105/7224-AMP, and 2110/2120/7548/7796 4-
AMP. Parallel wiring kits include the DB-25 Interlock cable for system communication, and the output wiring
for connecting system amplifiers to the load. The kits also include the wire(s) required for wiring the parallel
inputs through the Removable Barrier Block (WECO) connectors, BNC patch cable(s) and T-connector(s) for
wiring parallel inputs through the BNC input connectors, and the terminated Removable Barrier Block
connectors used to terminate the amplifier inputs during system setup. Parallel wiring kits are recommended
for all Parallel configurations.
1.4 Accessory Recommendations by System Type
Series Systems
2105 or 7224 Two in Series: (2) SIM-BNC-OPTOC input cards, (1) DB9M OPTOC cable
2105 or 7224 Three in Series: (3) SIM-BNC-OPTOC input cards, (2) DB9M OPTOC cables
2110 or 7548 Two in Series: (2) SIM-BNC-OPTOC input cards, (1) DB9M OPTOC cable
2110 or 7548 Three in Series: (3) SIM-BNC-OPTOC input cards, (2) DB9M OPTOC cables
2120 or 7796 Two in Series: (2) SIM-BNC-OPTOC input cards, (1) DB9M OPTOC cable
2120 or 7796 Three in Series: (3) SIM-BNC-OPTOC input cards, (2) DB9M OPTOC cables
Parallel Systems
2105 or 7224 Two in Parallel: (2) 2105/7224 BAL RES kits, (1) 2105/7224 2-AMP Parallel Wiring kit
2105 or 7224 Three in Parallel: (3) 2105/7224 BAL RES kits, (1) 2105/7224 3-AMP Parallel Wiring kit
2105 or 7224 Four in Parallel: (4) 2105/7224 BAL RES kits, (1) 2105/7224 4-AMP Parallel Wiring kit
2110 or 7548 Two in Parallel: (2) 2110/7548 BAL RES kits, (1) 2110/2120/7548/7796 2-AMP Parallel Wiring kit
2110 or 7548 Three in Parallel: (3) 2110/7548 BAL RES kits, (1) 2110/2120/7548/7796 3-AMP Parallel Wiring kit
2110 or 7548 Four in Parallel: (4) 2110/7548 BAL RES kits, (1) 2110/2120/7548/7796 4-AMP Parallel Wiring kit
2120 or 7796 Two in Parallel: (2) 2120/7796 BAL RES kits, (1) 2110/2120/7548/7796 2-AMP Parallel Wiring kit
2120 or 7796 Three in Parallel: (3) 2120/7796 BAL RES kits, (1) 2110/2120/7548/7796 3-AMP Parallel Wiring kit
2120 or 7796 Four in Parallel: (4) 2120/7796 BAL RES kits, (1) 2110/2120/7548/7796 4-AMP Parallel Wiring kit

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
6Information subject to change 97-8002465_09-19-14
2Multi-amp System Principles
The following configuration and operating principles apply to 2100 or 7000-Series multi-amp systems.
Following these basic principles will help to ensure the safety of your equipment and personnel.
2.1 One Master Amplifier for Series Systems
Series multi-amp systems are configured with one amplifier configured as the Master amplifier, and all other
amplifiers in the system configured as Slave amplifiers. DO NOT operate with more than one Master in your
Series multi-amp system.
2.2 All Master Amplifiers for Parallel Systems
Parallel multi-amp systems are configured with all amplifiers configured as Master amplifiers. To avoid
problems that might occur with signal latency, the input signal is sent through a parallel input cable that
delivers the signal simultaneously to all amplifiers in the system.
2.3 Use only 2100 or 7000-Series Amplifiers of the same Model Number
Use only AE Techron 2100 or 7000-Series amplifiers of the same model to construct these multiple amplifier
systems. You CANNOT combine different models of 2100 or 7000-Series amplifiers in the same system,
such as combining 7224 amplifiers with 7548 amplifiers. All amplifiers must be in good working order. Never
use other model AE Techron amplifiers or amplifiers made by another manufacturer in a 2100/7000-Series
multi-amp system. Such improper connections could damage the amplifiers.
2.4 Use Correct Wiring
Never directly connect one amplifier’s OUTPUT terminal (on the output terminal block) to another amplifier’s
OUTPUT terminal. The resulting circulating currents will waste power and may damage the amplifiers.
Depending on the configuration to be used, the OUTPUT terminal of one amplifier should only be directly
connected to the next amplifier’s COM or SAMPLED COMMON terminal, to the load, or to a ballast resistor.
2.5 When Constructing Output Wiring, Use These Basic Criteria
In multi-amplifier systems, the quality, gauge, length and rating of the output wiring leading to the load can
affect system performance. Wire gauge refers to the diameter of solid wire and is an important factor in the
wire’s current-carrying capacity. For Parallel system output wiring, we recommend a wire gauge from 4 AWG
(2120/7796 systems) to 10 AWG (2105/7224 systems), and a length of 2.5 to 4 feet. Refer to the Wire
Current-Carrying Capacity chart in Appendix A for more information.
Wire length is also an important factor. Particularly in Parallel multi-amp systems, the output wire branches
to each amplifier must be carefully matched in length to within ¼-inch to ensure system operation. To assist
with output wiring requirements in Parallel systems, AE Techron offers Parallel System Wiring Kits that
contain pre-built output wiring. See Section 1.3 for a description of these and other multi-amp accessories.
See Appendix B for more information on critical wire lengths in a Parallel system.
Wire rating refers to the allowable voltage handled by the wire. In configuring Series systems for increased
voltage, make sure that the wire insulation on output wiring is appropriate for the expected output voltage.
Wire length should also be limited to 3 to 4 feet to minimize voltage drop.
2.6 Operate with Safety in Mind
Potentially lethal voltages and currents are present within the 2100/7000-Series amplifiers. While the
amplifiers’chassis are earth grounded, all internal grounds are floating. Particularly in systems assembled
for increased voltage (Series configurations), all internal grounds of Slave amplifiers could carry lethal
voltage levels.

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
97-8002465_09-19-14 Information subject to change 7
Figure 3.2 –SIM-BNC-OPTOC card jumper locations
Figure 3.1 –Two in Series: Single-Ended vs. Differential
3.1 Choosing Single-Ended or Differential Configuration for Two-amplifier Systems
Series amplifier systems can be configured with the load
ground-reference (single-ended output) or floating
(differential output). Refer to Figure 3.1 and use the
following guidelines to select a Single-Ended or a
Differential configuration.
For Series configurations requiring only two1.
amplifiers, the Two in Series - Differential
configuration is safer and is easier to build than
Single-Ended output.
Series configurations requiring more than two2.
amplifiers should be wired using a Single-Ended
configuration.
Regardless of the number of amplifiers in the system,3.
if the load will ever be ground referenced, a Single-
Ended configuration must be used.
3.2 Configure SIM-BNC-OPTOC Input Cards
Each amplifier in a Series multi-amp system uses a
specialized input card that functions to synchronize the
operation of all amps in the system and provides for
optical isolation. The input card allows you to designate
(via jumpers located on the card), that the input card will
function as a Master (sending synchronization
information), or will function as a Slave (receiving synchronization information). Other options for system
configuration and operation can also be selected via jumpers located on the input card. Refer to Figure 3.2
for the jumper locations.
Master/Slave (jumper J6 & J7):
When J6 and J7 are Open, the
input card will be operating in an
amplifier that will act as a Slave in
a multi-amplifier system. When
Shorted, the input card will be
operating in an amplifier that will
act as a Single amplifier, or as a
Master amplifier in a multi-
amplifier system. Factory default:
Shorted for individual amplifiers
and Master amplifiers sold as a
part of a multi-amplifier system.
Removable Barrier Block Input Connector, Balanced/Unbalanced (jumper J4): When Open, this option
lifts the ground for the Removable Barrier Block connector, allowing it to be used as an unbalanced
input. When Shorted, the ground leg is enabled on the Removable Barrier Block connector. Factory
default: Open.
3Series Systems Configuration and Wiring

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
8Information subject to change 97-8002465_09-19-14
After turning the amplifier off, let the unit sit for 3-
5 minutes before removing the input card or
access panel. This will allow the electrical charge
in the power supply capacitors to discharge.
Slave Phase Inversion (jumpers J12 & J13): When the Upper two pins are shorted, this option inverts
the input signal, allowing a Slave amplifier to operate in the Two in Series –Differential configuration.
When the lower two pins are shorted, the input signal is not inverted, and the amplifier can operate as a
Master amplifier or as a Slave for any Series –Single Ended configuration. Factory default: Lower pins
shorted.
3.2.1 Configure for Use in a Series –Single Ended configuration
If you will be using a Series –Single Ended configuration for your system, complete the following:
For all except one SIM-BNC-OPTOC input cards for your system, remove the shunts from the1.
Master/Slave jumpers (J6 and J7) to configure the card to operate as a Slave. For the remaining card,
verify that the shunts are in place to configure the card to operate as a Master.
If desired, configure the Removable Barrier Block input connector option on the Master input card to2.
allow the connector to be used as an unbalanced input.
3.2.2 Configure for Use in a Two in Series –Differential configuration
If you will be using the Two in Series - Differential configuration for your system, complete the following:
For one SIM-BNC-OPTOC input card for your system, remove the shunts from the Master/Slave jumpers1.
(J6 and J7) to configure the card to operate as a Slave. For the remaining card, verify that the shunts are
in place to configure the card to operate as a Master.
On the SIM-BNC-OPTOC input card that is now configured for Slave operation, move the shunts2.
positioned on the lower two pins of jumpers J12 and J13 and place them on the UPPER two pins of
jumpers J12 and J13. This will allow the input signal received by the Slave amplifier to be inverted.
If desired, configure the Removable Barrier Block input connector option on the Master input card to3.
allow the connector to be used as an unbalanced input.
3.3 Install SIM-BNC-OPTOC Input Cards in Amplifiers
Before preparing the amplifiers, make sure the amplifier is
turned off for at least 3-5 minutes and the AC mains are
disconnected.
Locate the standard SIM-BNC Input Card on the right side of the rear panel of each amplifier.1. Use a #2 Phillips screwdriver to remove and retain the two (2) screws located at the edges of the input2.
card.
Unplug the ribbon cable from the back of the input card; remove the card from the amplifier card bay.3. For each amplifier, plug the ribbon cable into the ribbon connector on the SIM-BNC-OPTOC card. Reinstall4.
the card into the card bay on the amplifier back panel and secure in place using the retained screws.
(optional) We recommend labeling each SIM-BNC-OPTOC card as “Master” or “Slave” to identify the
5.
configuration of the installed input card.
3.4 Configure Amplifiers’ Main Boards for Slave Operation
2100/7000-Series amplifiers are configured by default for use as
stand-alone (or Master) amplifiers. When creating a Series multiple
amplifier system, you must also configure each amplifier’s main board
for Slave operation on the amplifiers to be used as a Slave(s) in the
system. Note that the main boards installed in the 2100 and 7000
Series models are identical, but the method for accessing the main
board varies between models.
Do not attempt to access the Main Board
while the amplifier is running. Turn the
amplifier off and disconnect the AC Mains
before removing the input card or amplifier
access panel.

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
97-8002465_09-19-14 Information subject to change 9
Figure 3.6 –7548/7796 Output Terminal Resistor
3.4.1 Accessing the Main Board on 2105/7224 Amplifiers
2105 and 7224 amplifiers contain an Access Panel built into the
top cover to allow easy access to the amplifier main board for
configuration of the Master/Slave setting.
IMPORTANT: Before removing the Access Panel, make sure the
amplifier is turned off for at least 3-5 minutes and the AC mains
are disconnected.
On each Slave amplifier, locate the Access Panel as shown in1.
Figure 3.3. Make sure that all 8 screws are accessible.
Remove the unit from its rack, if necessary.
Using a #2 Phillips screwdriver, remove the 8 screws located2.
on the top and side of the amplifier.
Remove the Access Panel and set it aside.3.
3.4.2 Accessing the Main Board on 2110, 2120, 7548 or
7796 Amplifiers
The 2110, 2120, 7548 or 7796 amplifier Main Board can be
accessed by removing the amplifier front panel.
IMPORTANT: Before removing the Front Panel, make sure the
amplifier is turned off for at least 3-5 minutes and the AC mains
are disconnected.
Turn the power to the amplifier “OFF”.1. Remove the four hex-head screws, located along the left and2.
right edges of the amplifier front panel.
Remove the front cover by pulling straight towards you.3.
3.4.3 Set Master/Slave Jumpers
On the main board, locate the jumpers P1 and P21.
(Master/Slave). For Slave operation, set both jumpers to the
DOWN position (lower two pins shorted). See Figure 3.4 for
jumper locations.
3.5 Remove Output Terminal Resistor
For all Series –Single Ended Output configurations, it is
important to remove the output terminal resistor from all Slave
amplifiers in the system.
On each Slave amplifier back panel, locate and remove the1.
resistor connecting the terminals labeled COM (2105/7224
amplifier) or SAMPLED COMMON (2110/2120/7548/7796
amplifiers) and CHASSIS GROUND on the output connector.
See Figures 3.5 and 3.6.
Retain the resistor for later use.
2.
3.6 Attach Master/Slave Labels (optional)
We recommended labeling each amplifier front panel as “Master” or “Slave to identify the configuration of
the amplifier.
Figure 3.3 –7224 Amplifier Access Panel
Screw Locations
Figure 3.4 –Master/Slave Jumper Locations
Figure 3.5 –7224 Output Terminal Resistor

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
10 Information subject to change 97-8002465_09-19-14
Figure 3.7 –Terminating the Amplifier Input
3.7 Series System Wiring
Locate the Series configuration that you have selected to meet your application requirements: Section 3.8
for a Two-in-Series –Differential configuration or Section 3.9 for a Two-in-Series –Open-Ended
configuration. Then follow the steps provided to wire and test your 7000-Series Multi-amp System.
3.8 Two in Series –Differential
Complete the following procedures to connect your amplifiers for Two in Series - Differential operation.
3.8.1 Connect and Test DC Offset and Interlock
Using a DB-9 high-voltage interlock cable, connect from the1.
MASTER OUTPUT connector on the SIM-BNC-OPTOC card of the
Master amplifier to the SLAVE INPUT connector on the SIM-BNC-
OPTOC card of the Slave amplifier.
Using wiring appropriate for your application, load and expected2.
output, connect from the MASTER amplifier’s back-panel output
connector labeled COM (2105/7224) or SAMPLED COMMON
(2110/2120/7548/7796) to the SLAVE amplifier’s
COM/SAMPLED COMMON connector.
On the MASTER amplifier, connect the output wiring to the back-3.
panel output connector labeled OUTPUT. On the SLAVE amplifier,
connect the output wiring to the back-panel output connector
labeled OUTPUT. IMPORTANT: DO NOT connect the load at this
time.
Terminate the input of the Master amplifier using the resistor-4.
terminated barrier block connector (see Figure 3.7) or similar
device.
Power up each amplifier by switching to ON the front-panel ON/OFF switch (2105/7224 amplifiers) or5.
moving the back-panel AC Mains Switch/Circuit Breaker to the ON (up) position
(2110/2120/7548/7796 amplifiers). Allow the amplifiers to come to the Ready state. When Ready, the
amplifier Ready and Run LEDs will be lit. Note: Some amplifiers that have been custom-configured may
require that you press the Enable button to bring the amplifier to the Ready state. Let the amplifiers run
for several minutes in Ready state to allow DC offsets to stabilize.
Using a digital voltmeter set to DC, measure across each amplifier’s back-panel output connector6.
terminals (OUTPUT to COM or SAMPLED COMMON) to verify that the DC offset of each amplifier is less
than 10 mVdc. See Figure 3.8. NOTE: If any amplifier’s DC offset is greater than 10 mVdc, the amplifier
may require servicing. Contact AE Techron Technical Support.
On the Master amplifier only, press the Stop button to place the amplifier in Standby mode.7. Verify that both Master and Slave amplifier enter Standby mode (Standby LED is lit).8.
3.8.2 Test Amplifier Gain
With the amplifiers in Standby mode, remove the input signal terminator and connect a signal generator1.
to the BNC or Removable Barrier Block connector on the SIM-BNC-OPTOC card of the MASTER amplifier
ONLY.
Apply a sine wave of 5 Vrms at 100 Hz at the Master amplifier input. Using a voltmeter measure across2.
each amplifier’s back-panel output connector terminals (OUTPUT to COM or SAMPLED COMMON) to
verify an output from each amplifier of approximately 100 Vrms (gain of 20). See Figure 3.9. NOTE: If
any amplifier’s gain varies significantly from the set gain of 20, the amplifier may require servicing.
Contact AE Techron Technical Support.
ELECTRIC SHOCK HAZARD. Output potentials
from the amplifiers can be lethal. Make
connections only with amplifiers’ AC power
OFF and input signals removed.

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
97-8002465_09-19-14 Information subject to change 11
Figure 3.8 –Verifying DC Offset
Figure 3.9 –Verifying Amp Gain
3.8.3 Connect Load and Test System Output
Power down the amplifiers.1. Connect the two output wires leading from the MASTER and SLAVE OUTPUT connectors to your load.2. Power up both amplifiers and allow them to come to the Ready state.3. Apply a sine wave of 5 Vrms at 100 Hz at the Master amplifier input. Using a voltmeter, measure across4.
the system load to verify an output from the system of approximately 200 Vrms. See Figure 3.10.
Check the completed system diagram in Figure 3.11 to verify proper system setup.5. Turn input signal up to the level required for your application.6.
‘

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
12 Information subject to change 97-8002465_09-19-14
Figure 3.10 –Verifying System Gain
Figure 3.11 –Two Amplifiers in Series –Differential Configuration

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
97-8002465_09-19-14 Information subject to change 13
Figure 3.12 –Terminating the Amplifier Input
3.9 Two or Three in Series –Single Ended
Complete the following procedures to connect your amplifiers for Series –Single-Ended operation.
3.9.1 Connect and Test Amplifier Interlock
Using a DB-9 high-voltage interlock cable, connect from1.
the MASTER OUTPUT connector on the SIM-BNC-OPTOC
card of the Master amplifier to the SLAVE INPUT
connector on the SIM-BNC-OPTOC card of the first Slave
amplifier. If configuring for a three amp system, use an
additional DB-9 cable to connect from the MASTER
OUTPUT of the first Slave amplifier to SLAVE INPUT on a
second Slave amplifier.
Using wiring appropriate for your application, load and2.
expected output, connect from the MASTER amplifier’s
back-panel output connector labeled OUTPUT to the first
SLAVE amplifier’s COM (2105/7224) or SAMPLED
COMMON (2110/2120/7548/7796) connector. For an
additional SLAVE amplifier in the system, connect from
the first SLAVE amplifier’s OUTPUT connector to the
second SLAVE amplifier’s COM or SAMPLED COMMON
connector.
On the MASTER amplifier, connect the output wiring to the back-panel output connector labeled COM3.
(2105/7224) or SAMPLED COMMON (2110/2120/7548/7796). On the last SLAVE amplifier, connect
the output wiring to the back-panel output connector labeled OUTPUT. IMPORTANT: DO NOT connect the
load at this time.
Terminate the input of the Master amplifier using a resistor-terminated barrier block connector (see4.
Figure 3.12) or similar device.
Power up each amplifier by switching to ON the front-panel ON/OFF switch (2105/7224 amplifiers) or5.
moving the back-panel AC Mains Switch/Circuit Breaker to the ON (up) position
(2110/2120/7548/7796 amplifiers). Allow the amplifiers to come to the Ready state. When Ready, the
amplifier Ready and Run LEDs will be lit. Note: Some amplifiers that have been custom-configured may
require that you press the Enable button to bring the amplifier to the Ready state. Let the amplifiers run
for several minutes in Ready state to allow DC offsets to stabilize.
Using a digital voltmeter set to DC, measure across each amplifier’s back-panel output connector6.
terminals (OUTPUT to COM or SAMPLED COMMON) to verify that the DC offset of each amplifier is less
than 10 mVdc. See Figure 3.13. NOTE: If any amplifier’s DC offset is greater than 10 mVdc, the amplifier
may require servicing. Contact AE Techron Technical Support.
On the Master amplifier only, press the Stop button to place the amplifier in Standby mode.7. Verify that both Master and Slave amplifier enter Standby mode (Standby LED is lit).8.
3.9.2 Test Amplifier Gain
With the amplifiers in Standby mode, remove the input signal termination and connect a signal generator1.
to the BNC or Removable Barrier Block connector on the SIM-BNC-OPTOC card of the MASTER amplifier
ONLY.
Apply a sine wave of 5Vrms at 100 Hz at the Master amplifier input. Using a voltmeter measure across
2.
each amplifier’s back-panel output connector terminals (OUTPUT to COM or SAMPLED COMMON) to
verify an output from each amplifier of approximately 100Vrms (gain of 20). See Figure 3.14. NOTE: If
any amplifier’s gain varies significantly from the set gain of 20, the amplifier may require servicing.
Contact AE Techron Technical Support.
ELECTRIC SHOCK HAZARD. Output potentials
from the amplifiers can be lethal. Make
connections only with amplifiers’ AC power
OFF and input signals removed.

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
14 Information subject to change 97-8002465_09-19-14
Figure 3.13 –Verifying DC Offset
Figure 3.14 –Verifying Amp Gain
3.9.3 Connect Amplifiers and Load
Power down the amplifiers.1. Connect the two output wires leading from the MASTER amplifier’s COM/SAMPLED COMMON connector2.
and last SLAVE amplifier’s OUTPUT connector to your load.
Power up all amplifiers and allow them to come to the Ready state.3. Apply a sine wave of 5Vrms at 100 Hz at the Master amplifier input. Using a voltmeter, measure across4.
the system load to verify an output from the system of approximately 200Vrms. See Figure 3.15.
Check the completed system diagrams in Figure 3.16 or 3.17 to verify proper system setup.5. Turn input signal up to the level required for your application.6.

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
97-8002465_09-19-14 Information subject to change 15
Figure 3.15 –Verifying System Gain
Figure 3.16 –Two Amplifiers in Series –Single-Ended Configuration

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
16 Information subject to change 97-8002465_09-19-14
Figure 3.17 –Three Amplifiers in Series –Single-Ended Configuration

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
97-8002465_09-19-14 Information subject to change 17
Before preparing the amplifiers, make sure the
amplifier is turned off and the AC mains are
disconnected. Let the unit sit for 3-5 minutes to
allow the electrical charge in the power supply
capacitors to discharge.
Figure 4.1 –2105/7224 Ballast Resistor Mounting
Figure 4.2 –2120/7796 Ballast Resistor Mounting
Figure 4.3 –2105/7224 Ballast Resistor Connected to Output Terminal
Figure 4.4 –2120/7796 Ballast Resistors Connected to Output Terminal
(Note: Kits for 2110/7548 amplifiers contain one ballast resistor)
4Parallel Systems Configuration, Wiring and Balancing
Parallel multi-amp configurations require a ballast resistor
(two resistors for 2120 and 7796 models) to be mounted on
each amplifier’s back panel and connected to the amplifier’s
OUTPUT connector. Complete the following steps for each
amplifier in your system to install the ballast resistors for
Parallel System setup.
Before preparing the amplifiers, make sure the amplifier is
turned off for at least 3-5 minutes and the AC mains are
disconnected.
4.1 Install Ballast Resistors
4.1.1 Mount and Connect Ballast Resistor
Locate the bracket-mounted ballast resistor(s) in the1.
Ballast Resistor Kit. Position the bracket on the amplifier
back-panel grill as shown in Figures 4.1 and 4.2.
Use the provided plastic ratchet fasteners to secure the2.
resistor mounting bracket to the grill of the amplifier by
pushing each fastener through the bracket mounting hole and into a slot on the grill.
Connect the resistor’s terminal lead(s) to the output connector labeled OUTPUT as shown in Figures 4.33.
and 4.4.Tighten the screw to secure.
SHOCK/BURN HAZARD. DO NOT TOUCH
BALLAST RESISTORS while the system is
operating. The ballast resistors are not
protected against electrical or heat transfer.
Touching the ballast resistors during operation
can result in severe shock or burn.

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
18 Information subject to change 97-8002465_09-19-14
4.2 Main Board Access
Before operating a paralleled amplifier system, the system first
must be “balanced” to ensure system stability. The balancing
process seeks to calibrate the amplifiers so they operate as
similar as possible. To prevent unwanted current and dissipation
in the amplifiers, each amplifier must have as little offset DC as
possible at no signal. In addition, the gains of the amplifiers must
be as closely matched as possible to keep the outputs from
driving each other when a signal is present.
Balancing of 2100/7000-Series amplifiers requires access to
the amplifier main boards. Note that the main boards installed
in 2100 and 7000 Series models are identical, but the method
for accessing the main board varies between models.
4.2.1 Accessing the Main Board on 2105/7224
Amplifiers
2105 and 7224 amplifiers contain an Access Panel built into
the top cover to allow easy access to the amplifier main board.
IMPORTANT: Before removing the Access Panel, make sure
the amplifier is turned off for at least 3-5 minutes and the AC
mains are disconnected.
On each amplifier, locate the Access Panel as shown in1.
Figure 4.5. Make sure that all 8 screws are accessible.
Remove the unit from its rack, if necessary.
Using a #2 Phillips screwdriver, remove the 8 screws located2.
on the top and side of the amplifier.
Remove the Access Panel and set it aside.3.
4.2.2 Accessing the Main Board on
2110/2120/7548/7796 Amplifiers
The 2110, 2120, 7548 and 7796 amplifier’s main board can be
accessed by removing the amplifier front panel.
IMPORTANT: Before removing the Front Panel, make sure the
amplifier is turned off for at least 3-5 minutes and the AC mains
are disconnected.
1Turn the power to the amplifier “OFF”.
2Remove the four hex-head screws, located along the left and
right edges of the amplifier front panel.
3Remove the front cover by pulling straight towards you.
4.3 Disable Gain Controls (2105 and 7224 models only)
In order to ensure the amplifiers in 2105 and7224 Parallel systems
maintain a matched gain while operating, the variable gain controls
located on the amplifier front panels must be disabled. Once
disabled, each amplifier will have a fixed gain of 20. If preferred, the
gain for each amplifier can be fixed at a lower level.
Figure 4.5 –Access Panel Screw Locations
Do not attempt to access the Main Board while
the amplifier is running. Turn the amplifier off
and disconnect the AC Mains before removing
the amplifier access panel. After turning the
amplifier off, let the unit sit for 3-5 minutes to
allow the electrical charge in the power supply
capacitors to discharge.
Figure 4.6 –Gain Control Connection
on Main Board
Do not attempt to access the Main Board while
the amplifier is running. Turn the amplifier off
and disconnect the AC Mains before removing
the amplifier front panel. After turning the
amplifier off, let the unit sit for 3-5 minutes to
allow the electrical charge in the power supply
capacitors to discharge.

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
97-8002465_09-19-14 Information subject to change 19
ELECTRIC SHOCK HAZARD. Output potentials
from the amplifier can be lethal. Make
connections only with amplifier AC power OFF
and input signals removed.
On the amplifier main board, locate the1.
connector that connects the external
gain control to the main board by
following the wire leading from the gain
control (see Figure 4.6).
Pull gently upward to remove the 3-pin2.
connector from the main board. Secure
the gain-control cable within the
amplifier cabinet.
To set a fixed gain of 20, place a shunt3.
(supplied) across pins 1 and 2 as
shown in Figure 4.7.
If preferred, a fixed gain can be set at4.
another level; place two resistors (not
supplied) across pins 1 and 2 (resistor
1) and pins 2 and 3 (resistor 2) as
shown in Figure 4.7. Note: these resistors
can be mounted to a header or soldered
directly to the pins.
4.4 Parallel System Balancing
Complete the following procedures to balance
your parallel amplifier system.
4.5 Connect for Balancing
For each amplifier in your system, connect1.
a leg of the black output cable found in the
Parallel Wiring Kit to one of the amplifier’s
output connectors labeled COM
(2105/7224) or SAMPLED COMMON
(2110/2120/7548/7796) on the amplifier
back panel. Important: Do not connect this
cable to the LOAD and do not connect the
red cable at this time. See Figure 4.8.
Starting with either end of the DB-252.
Interlock cable found in the Parallel Wiring
Kit, connect the DB-25 connector to the
INTERLOCK –I/O CONNECTOR on the SIM-
BNC input card of the first amplifier in your system. Connect additional connectors on the DB-25 cable to
the INTERLOCK –I/O CONNECTOR on the SIM-BNC input card of additional amplifiers in your system.
See Figure 4.8.
Figure 4.7 –Gain Control Pin Settings
Figure 4.8 –Connecting for Balancing (Four in Parallel shown)

AE TECHRON MULTI-AMP CONFIGURATION GUIDE
20 Information subject to change 97-8002465_09-19-14
Figure 4.9 –Terminating the Amplifier Input
Ensure that the inputs of all of the amplifiers are terminated3.
by using a resistor-terminated barrier block connector (see
Figure 4.9) or similar device.
4.6 Verify Interlock Operation
Power up each amplifier by switching to ON the front-panel1.
ON/OFF switch (2105/7224) or the back-panel AC Mains
Switch/Circuit Breaker to the ON (up) position
(2110/2120/7548/7796 amplifiers).
Allow each amplifier to power up and come to Ready state. When Ready, the amplifier Ready and Run2.
LEDs will be lit. Note: Some amplifiers that have been custom-configured may require that you press the
Enable button to bring the amplifier to the Ready state.
On the first amplifier only, press the Stop button to place the amplifier in Standby mode.3. Verify that all amplifiers in the system enter Standby mode (Standby LED is lit).4.
4.7 Adjust DC Offset
Power down all amplifiers.1. Remove the amplifiers’ Access Panels (2105/7224) or2.
front panel (2110/2120/7548/7796) to access the main
board for each amplifier (see Sections 4.2.1 and 4.2.2).
On each amplifier main board, locate the Amp Offset3.
(R65) (see Figure 4.10).
Power up all amplifiers in the system and run the4.
amplifiers for several minutes in Ready state to allow
DC offsets to stabilize.
Using a digital voltmeter set to DC, measure across5.
the amplifier’s back-panel output connector terminals (OUTPUT to COM or SAMPLED COMMON) to verify
that the DC offset of each amplifier is less than 5 mVdc. See Figure 4.11.
If the DC offset for any amplifier is greater than 5 mVdc, adjust each amplifier using the Amp Offset (R65)6.
on the amplifier main board. Adjust each amplifier’s DC offset to read as closely as possible to zero.
4.8 Wire and Connect Parallel Inputs
IMPORTANT FOR 2105 and 7224 PARALLEL SYSTEMS: In order to ensure the amplifiers used in a 2105 or
7224 Parallel system maintain a matched gain while operating, the variable gain controls located on each
amplifier’s front panel must be disabled. Refer to Section 4.3 to complete this process before connecting
the inputs to your system.
Power down the amplifiers.1. Remove all amplifier input terminations.2. Use the jump wires included in the Parallel Wiring Kit and the Removable Barrier Block connectors that3.
ship with each amplifier to create a paralleled input signal wire as shown in Figure 4.12. Wire one input
connector for each amplifier in your system.
You can use balanced wiring (shown), or you can build the wire for unbalanced input. If using unbalanced4.
wiring, switch the INPUT SELECT switch located on the SIM-BNC input card on each amplifier to the LEFT
position (unbalanced setting).
Alternately, you can connect an unbalanced input signal to the SIM-BNC’s BNC input connector using the 5.
optional BNC PARALLEL INPUT KIT as shown in Figure 4.13. Set the INPUT SELECT switch located on the
SIM-BNC input card on each amplifier to the LEFT position (unbalanced setting).
Connect the input wire to a signal generator and to each amplifier in your system.6.
Figure 4.10 –Main Board Balancing Control Locations
