The AETHRA ISDN S0-EXTENDER SYSTEM allows for
connection of two user terminals using the S/T
interface with standard ISO8877 connector in
compliance with ETS300 012 by means of two-wire
leased line.
The system is composed of a MASTER (SX1080S2U)
and a SLAVE (SX1080U2S) device.
8The system allows for connecting two user PBXs or NT1
and the ISDN terminal, up to 8 Km (the maximum lenght
depends on the characteristics of the cable used).
8It enables the remotization of devices using any
communication protocol (EDSS1, Q-SIG, 1TR6…) with
ISDN 2B+D frame (ETSI 300 012).
8No remote power supply over the BUS-S/T is
necessary.
8Immediate use thanks to compact dimensions and
easy installation feature (plug-and-play).
PABX / NT1
MASTER
MASTER
PABX / TE
SLAVE
S/ T
Sx1080S2U
SLAVE
Sx1080U2S
S/ T
M10M9
M2
S1 S4
S2

Mechanical specifications
MASTER
Internally screened ABS plastic enclosure
8Dimensions (LxDxH): 121x252x50 mm
8Weight: 0.86 kg
!A33/A power supply adapter
8Dimensions (LxDxH): 74x100x60 mm
8Weight: 0.5 kg
SLAVE
ABS plastic enclosure
8Dimensions (LxDxH): 102x39x127 mm
8Weight: 0.4 kg
PS-65 power supply adapter
8Dimensions (LxDxH): 82x63x50 mm
8Weight: 0.2 kg
Power supply by means of external adapter
MASTER
8Mains voltage: 207 - 254 Vac @ 50 Hz
8Power supply: 10 Vdc 10%
8“LINE“ interface voltage (optional): 48 Vdc 10%
SLAVE
8Mains voltage: 207 - 254 Vac @ 50 Hz
8Power supply: 40 Vdc 10%
Interface
MASTER
8“S/T” INTERFACE: ETS 300 012 compliant - Ending
with a standard ISO8877 connector
8“LINE“ INTERFACE: ETS 300 012 compliant Ending
with a ISO8877 connector
8“LINE“ POWER SUPPLY (optional): Ending with a
MINI-DIN 4-pole connector
SLAVE
8“S/T” INTERFACE: ETS 300 012 compliant - Ending
with a standard ISO8877 connector
8“LINE“ INTERFACE: ETS 300 012 compliant - Ending
with a standard ISO8877 connector
