Afidus BN-230F1 User manual

Network Camera User’s Guide
2/100
Owner's Record
The model and serial numbers are located at the bottom of device. Record these numbers in the
spaces provided below. Refer to these numbers whenever you call upon your dealer regarding this
product.
Model No. BN-230F1
Serial No. ____________________
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
For AC Adaptor to avoid electrical shock, do not open the cabinet. Refer servicing
to qualified personnel only.
Notice: The changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.

Network Camera User’s Guide
3/100
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the installation manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference, in which case the user will be required to correct the interference at his own
expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this product may cause radio interference,
in which case the user may be required to take adequate measures.
NOTICE TO USERS
© 2006~13 All rights reserved. This manual or the software described herein, in whole or in part,
may not be reproduced, translated or reduced to any machine readable form without prior written
approval.
WE PROVIDES NO WARRANTY WITH REGARD TO THIS MANUAL, THE SOFTWARE
OR OTHER INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY
DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR
ANY PARTICULAR PURPOSE WITH REGARD TO THIS MANUAL, THE SOFTWARE OR
SUCH OTHER INFORMATION. IN NO EVENT SHALL WE BE LIABLE FOR ANY
INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES, WHETHER BASED ON
TORT, CONTRACT, OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH
THIS MANUAL, THE SOFTWARE OR OTHER INFORMATION CONTAINED HEREIN OR
THE USE THEREOF.
We reserve the right to make any modification to this manual or the information contained herein
at any time without notice. The software described herein may also be governed by the terms of a
separate user license agreement.

Network Camera User’s Guide
4/100
Table of Contents
Overview............................................................................................................................. 7
Introduction................................................................................................................. 7
Features....................................................................................................................... 7
Minimum System Requirements................................................................................. 8
Package Contents................................................................................................................ 9
Physical Description......................................................................................................... 10
Hardware Installation....................................................................................................... 13
Preparation....................................................................................................................... 14
Search and Set up by IPWizard II............................................................................. 14
Search................................................................................................................ 14
View .................................................................................................................. 16
LAN .................................................................................................................. 17
Wireless............................................................................................................. 19
UPnP of Windows®XP, Vista or 7............................................................................ 20
Install the Device behind a NAT Router................................................................... 21
Access the device from the Internet Explorer for the first time................................ 22
Logging in as an Viewer ........................................................................................... 23
Logging in as an Administrator ................................................................................ 23
Operating the Network Camera........................................................................................ 24
Monitor Image Section ............................................................................................. 24
Video Profile............................................................................................................. 24
Streaming Protocol.................................................................................................... 24
Language................................................................................................................... 25
2-WayAudio............................................................................................................. 25
Full Screen ................................................................................................................ 25
PTZ Control.............................................................................................................. 25
Volume.............................................................................................................. 27
About................................................................................................................. 27
Administrating the Device................................................................................................. 28
System Setting .......................................................................................................... 28
Network: Configure Network settings.............................................................. 28
Network..................................................................................................... 28
IPv6........................................................................................................... 30
HTTPS ...................................................................................................... 31
DDNS service ........................................................................................... 31
PPPoE ....................................................................................................... 33
Streaming.................................................................................................. 34
UPnP......................................................................................................... 35
Bonjour ..................................................................................................... 36
IP Filter ..................................................................................................... 37
IP Notification........................................................................................... 37
The message will be sent to HTTP server................................................................. 39
Camera: Adjust Camera parameters.................................................................. 40

Network Camera User’s Guide
5/100
Picture....................................................................................................... 40
Exposure Control...................................................................................... 42
Privacy Mask ............................................................................................ 43
PTZ Setting............................................................................................... 44
Preset Setting ............................................................................................ 44
Tour Setting............................................................................................... 45
System: Configure and maintain system........................................................... 47
System....................................................................................................... 47
Date & Time.............................................................................................. 48
Maintenance.............................................................................................. 49
Video: Configure OSD, Overlay, Profile, and ROI .......................................... 52
Common.................................................................................................... 52
Overlay Image........................................................................................... 52
Video Profile............................................................................................. 54
ONVIF Profile .......................................................................................... 55
AOI ........................................................................................................... 57
Audio: Audio parameters.................................................................................. 59
User: Manage user name, password and login privilege .................................. 60
Protocol: Parameter settings for different protocols......................................... 61
ONVIF ...................................................................................................... 61
SNMP........................................................................................................ 61
E-Mail: Setup E-Mail configuration................................................................. 63
Event Detection:................................................................................................ 65
Object Detection ....................................................................................... 65
Camera Tampering.................................................................................... 67
Audio Detection........................................................................................ 68
Face Detection .......................................................................................... 69
Cross Line Detection................................................................................. 70
Storage: Status and configuration of SD card and SAMBA Server.................. 73
SD Card..................................................................................................... 73
SAMBA Server......................................................................................... 73
Continuous Recording: ..................................................................................... 75
Recording List: Files list inside the SD card or SAMBA server ...................... 76
Recording List........................................................................................... 76
Continuous Recording List....................................................................... 76
Event Server: Setup FTP/TCP/HTTP/SAMBA server configuration............... 78
FTP Server ................................................................................................ 78
TCP Server................................................................................................ 79
HTTP Server ............................................................................................. 80
SAMBA Server......................................................................................... 81
Event Schedule: Configure the event schedule................................................. 82
Setting....................................................................................................... 82
Record....................................................................................................... 85
Port Status................................................................................................. 86
Appendix A: Alarm I/O Connector.................................................................................... 87
Appendix B: Troubleshooting & Frequently Asked Questions.......................................... 89

Network Camera User’s Guide
6/100
Appendix C: PING IP Address.......................................................................................... 94
Appendix D: Bandwidth Estimation.................................................................................. 95
Appendix E: Specifications............................................................................................... 96
Appendix F: Configure Port Forwarding Manually......................................................... 98
Appendix G: Power Line Frequency............................................................................... 100

Network Camera User’s Guide
7/100
Overview
The user’s guide explains how to operate this camera from a computer. User should
read this manual completely and carefully before you operate the device.
Introduction
This camera is a fully scalable surveillance device. Because the Network Cameras can
be plugged into your existing local area network (LAN), you will potentially save
thousands of dollars from unnecessary cabling.
The device is accessible via the LAN or Internet connection. Connect your device
directly to a local area network or xDSL modem, and with web browser you get instant,
on demand video streams. Within minutes you can set up the device to capture a video
sequence to a PC. The live video can be uploaded to a website for the world to see.
Features
2.4 Mega-pixel Sony Exmor™ image sensor
Support Full HD mode (1080p) up to 60fps
60fps mode or True WDR mode (30fps) selectable
ONVIF compliant
Intelligent Video Surveillance: object, face, and cross line detections
Camera tampering and audio detection
Gigabit 1000Base-T Ethernet
C/CS mount for camera lens
Built-in DC/P Iris and ICR
Easy installation with setup wizard (IP Wizard II)
UPnP device discovery and NAT router transversal for easy installation
Dynamic IP Service, DDNS®, to search your IP camera from Internet easily
H.264 and JPEG dual compression simultaneously
Dual stream simultaneously
UDP / TCP / HTTP / HTTPS protocols selectable
Smartphone or web pad accessible
Event and Continuous recording to SD card or SAMBA server
Built-in / external microphone input

Network Camera User’s Guide
8/100
Audio line out
Voice alerting while event triggered
Two-way audio
Micro SD slot
Privacy masks
3D noise reduction to improve picture quality at low lux.
True WDR to provide extremely clear images even under strong back light
Image transmission using an FTP or e-mail for event
Digital sensor input and alarm output
RS485 interface for P/T scanner control
Multi-channel control software for surveillance application
IEEE 802.3af PoE support
Minimum System Requirements
Microsoft Internet Explorer 9.0 or later
Microsoft Media Player 11.0 or later (to playback recorded file)
Full HD Monitor resolution 1920 x 1080 or higher
Intel Core 2 Duo E8600(3.33GHz) or faster
Memory Size: 2GB or more
Windows XP, Vista, 7, and 8

Network Camera User’s Guide
9/100
Package Contents
User can find the following items in the package:
Item
Descriptions
1. This camera
is the main element
of the product.
2. Camera Stand with
screws
(option)
3. User’s Manual CD provides
important information and
instructions for operating the
Network Camera..
4. Quick Start Guide provides
important information and
instructions for installing this device.
If any of the above items are missing, please contact your dealer immediately.
Note: Using a power supply with a different voltage than the one included with the
Network Camera will cause damage and void the warranty for this product.

Network Camera User’s Guide
10/100
Physical Description
Front View
Lens (option)
User could adjust the focus to get the best picture quality.
Internal Microphone
The Camera has built-in an internal microphone. This microphone is hidden in the
pinhole located on the front panel.
DC/P Iris
The Camera supports DC or P-Iris control.
Rear View
MIC In
Connect an external microphone to the network camera.
Audio Output
Connect a loud speaker to the network camera. This function is for alerting sound and
two-way audio.
DC Power
The input power is 12VDC.
Note that supply the power to the Camera with a 12VDC/1A power adapter. Otherwise,
the improper power adapter may damage the unit and result in danger.
Internal
Microphone
Lens
(Option)
DC/P
Iris

Network Camera User’s Guide
11/100
AC 24V Power
The input power is AC 24V.
Micro SD Card Slot
User can insert a micro SD card into this slot for recording.
LAN Socket
The LAN socket is a RJ-45 connector for connections to 100Base-TX, or 1000Base-TX
Ethernet cabling. This Ethernet port built N-Way protocol can detect or negotiate the
transmission speed of the network automatically. Please use Category 5 or better cable
to connect the Network Camera to an Ethernet network switch.
In the LAN socket, there are two LEDs embedded:
Power LED (orange color)
This LED is used to indicate whether DC power is on or not.
LAN LED (green color)
This LED will be flashing while network accessing via Ethernet.
Factory Default Reset
This button is hidden in the pinhole. It is used to restore the all factory default settings.
Sometimes restarting the device will make the system back to a normal state. However,
if the system still got problems after restart, user can restore the factory default settings
and install it again
Restore the device:
1. Make sure the Camera is ready first. Insert the paper clip or other suitable tool to
press and hold the button down continuously.
2. Hold it least 5 seconds and release the tool. Then the device has been restored
to default settings and reboot again.
Factory
Default Reset
Power
LED
LAN
LED

Network Camera User’s Guide
12/100
Note: Restoring the factory default setting will lose the all previous settings included
IP address forever. User needs to run the IPWizard II program to search the device
and configure it to let the device work properly again.
DI/DO/RS485 Connector
The Camera provides a terminal block with 6 pins of connectors for DI, DO, and RS485.
Please refer to the Appendix A in this manual for more information.

Network Camera User’s Guide
13/100
Hardware Installation
1. Fix a proper stand to desired location
2. Attach the Camera to the stand
3. Plug an Ethernet Cable into LAN port
Plug an Ethernet cable to the LAN socket located on the camera’s rear and connect it to
the network.
4. Connect an external power supply to Camera, if not powering by PoE
Connect the (option) power adapter to the DC power jack of the camera.
Note: Use a power adapter, 12VDC/1A and connect it to wall outlet for AC power.
5. Done
Once you have installed the camera well and powered it on, the Power LED (orange) will
turn on later. Once the Power LED turned on, it means the system is booting up
successfully. Furthermore, if you have a proper network connection, and access to the
camera, the LAN LED will flash green

Network Camera User’s Guide
14/100
Preparation
Search and Set up by IPWizard II
Once you installed the Camera on a LAN environment, you have two easy ways to
search your Cameras by IPWizard II or UPnP™ discovery. Here is the way to execute
IPWizard II to discover Camera’s IP address and set up related parameter in a Camera.
Search
When launch the IPWizard II, a searching window will pop up. IPWizard II is starting to
search Network Cameras on the LAN. The existed devices will be listed as below.

Network Camera User’s Guide
15/100

Network Camera User’s Guide
16/100
View
If IPWizard II finds network devices, View button will be available. Please select the
device you want to view and click the View button. Then you could see the video from
camera directly. Furthermore you could double click the left button of mouse to link to the
network device by web browser.

Network Camera User’s Guide
17/100
LAN
In case you want to change the IP related parameters of wired interface, please select
the device you want to configure and click the LAN button. Relative settings will be
carried out as below.
You could modify the relative settings of the selected device. Click “
<<
” button will
quit the LAN setting procedure and click “
>>
” button will move to next page as below.

Network Camera User’s Guide
18/100
In case, you do not want to change username and/or password, then just click
“
Submit
” button to perform your setting accordingly. Click “
<<
” button will go back
to previous page.
If you like to change username and/or password of the device, just click the check button.
Then, the related fields will show up as below.

Network Camera User’s Guide
19/100
After keying in new username and password, click “
Submit
” button to perform your
setting accordingly. Click “
<<
” button will go back to previous page.
Wireless
This model does not support wireless function. Therefore, IPWizard II disables this
function automatically.

Network Camera User’s Guide
20/100
UPnP of Windows®XP, Vista or 7
UPnP™ is short for Universal Plug and Play, which is a networking architecture that
provides compatibility among networking equipment, software, and peripherals. This
device is an UPnP enabled device. If the operating system, Windows XP, Vista or 7, of
your PC is UPnP enabled, the Network Camera will be very easy to be found.
Please make sure to enable UPnP settings first if your operating system of PC is running
Windows XP.
To discover your device, go to your Desktop and click My Network Places.
Click the targeted Device. Then Internet Explorer will connect to this Network Camera
automatically.
