Meru LED Flood Light
Part number breakdown
Part number: AA BBB CC D E F G
AA
BBB
CC
D
E
F
G
FL Flood light
Wattage
S6
-
Series 6
LED
colour
Lens
Mounting type
Number of banks
25w, 50w, 75w,
100w, 150w
C
-
Cool white 5000K
N-Neutral white 4000K
W-Warm white 3000K
S
-
155
°
x 85°
U
U
-
Bracket
1
Technical information
Operating voltage
IP Rating
Front cover
Operating
temperature (°C)
Standards
Mounting hight (m)
200
240VAC
50/60hz
IP 65
Polycarbonate
Diffused front cover-
Ultra High Impact
-
20 to 40
SANS 60598
2
-
6
Operating position Universal
Series 5
25w 50w 75w 100w 150w
A (mm) 120 200 280 350 500
B (mm) 175 175 175 175 175
C (mm) 100 100 100 100 100
Max
projected
area (m°)
0.033 0.055 0.077 0.079 0.113
Weight
(kg)
1.6 2.4 3 3.4 3.8
U- Bracket mounting holes

*AFRISON TERMS & CONDITIONS
DUE TO ONGOING R&D AFRISON RESERVES THE CATALOGUE AT ITS OWN DISCRETION AND AT ANY TIME
WITHOUT PRIOR NOTICE 1, 2 , 3 OR 5 YEAR WARRANTY (REPLACE OR REPAIR) - PLEASE SEE FULL TERMS AND CONDITIONS AT WWW.AFRISON.CO.ZA - PICTURES
SHOWN ARE FOR ILLUSTRATION PURPOSES ONLY, ACTUAL PRODUCT MAY VARY DUE TO TECHNICAL DEVELOPMENT. E & OE. © 2022 AFRISON LED. ALL RIGHTS RESERVED.
Protection Unit
Meru LED
Flood Light
Installation instruction
The installation must be carried out by a Qualified Electrician.
Tools required:
- Flat head screwdriver (to open connection box.)
- 13 hex spanner (to adjust u-bracket) tools not included
1. To install the Meru Flood Light, special attention needs to be given to the mounting holes on the U-bracket for alignment.
a. Use correct size (calculated on hight and weight) Bolts / Rawle bolts to correspond with your mounting surface.
b. Once U-bracket adjusted to required angle fasten U-bracket bolts. (M8 25N.m)
2. To connect to the mains 220VAC confirm main power is switched off.
3. The Meru Flood Lights require mains voltage of between 200 to 240VAC 50 Hz. Connect the mains cable to the protection unit via the
20mm Cable Gland. Always use round cable and not flex or flat cables for sealing purposes with the Cable Gland. Open the protection
unit by unscrewing the 4 screws that keep the lid closed. Connect the corresponding wires, Brown (L), Blue (N), and Yellow/Green (E)
in the connector on the PC board. Always read the label on the protection unit to make sure the voltage is correct. When powering
the light, the light should come on immediately.
4. Connection Diagram:
5. Picture of Protection Unit:
