AG Neovo DF-55 User manual

•Important Safety Instructions ..........................................1
–Safety precautions and maintenance………………………..1
–Use………………………………………………………………4
–Installation Notes……………………………………………….6
•Package Content .................................................................8
–Unpacking………………………………………………………8
–Accessories……………………………………………………10
–DF-55 Option Accessories…………..……………………….11
–Overview……………………………………………………….12
•Setting Up the Display ......................................................14
–Step1 : Tear down the downside covers……………………14
–Step2 : Place the upside part into downside part………….15
–Step3 : Connect the LVDS and 24V………………………...16
–Step4 : Reinstall the downside covers……………………...17
–Step5 : Open the user door, Connect by HDMI connector.18
–DF-55 Full Size Stand installation………….……………….19
–Using the Remote Control……………………………………21
–OSD Setting Menu……………………………………………22
•Trouble shooting ................................................................26
•Specifications ................................................................ 27
•Product Dimensions ........................................................28
Table of contents

Safety precautions and maintenance
WARNING: Use of control, adjustments or
procedures other than those specified in this
documentation may result in exposure to shock,
electrical hazards and/or mechanical hazards.
Important Safety Instructions
Read and follow these instructions when connecting and
using your display:
Operation:
•Keep the display out of direct sunlight and away from stoves or any
other heat sources.
•Remove any object that could fall into ventilation holes of power box
or prevent proper cooling of the display’s electronics.
•Don’t block the ventilation holes on the power box.
•When positioning the display, make sure the power plug and outlet
are easily accessible.
•When turning off the display by detaching the power cord, wait 6
seconds before re-attaching the power cord for normal operation.
•Ensure the use of an approved power cord provided byAG Neovo at
all times. If your power cord is missing, please contact your local
service center.
•Don’t subject the display to severe vibration or high impact conditions
during operation.
•Don’t knock or drop the display during operation or transportation.
•Provide an earthing connection before the mains plug is connected to
the mains.And, when disconnecting the earthing connection, be sure to
disconnect after pulling out the mains plug from the mains.
1

Safety precautions and maintenance
Maintenance:
•To protect your display from possible damage, do not put excessive
pressure on the display.
•Unplug the display if you are not going to use it for an extensive
period of time.
•Unplug the display if you need to clean it with a slightly damp cloth.
The screen may be wiped with a dry cloth when the power is off.
However, never use organic solvent, such as, alcohol, or ammonia-
based liquids to clean your display.
•To avoid the risk of shock or permanent damage to the set, do not
expose the display to dust, rain, water or an excessively moist
environment.
•If your display becomes wet, wipe it with dry cloth as soon as possible.
•If a foreign substance or water gets in your display, turn the power off
immediately and disconnect the power cord. Then remove the foreign
substance or water.
•Don’t store or use the display in locations exposed to heat, direct
sunlight or extreme cold.
2

Safety precautions and maintenance
Read and follow these instructions when connecting and using
your display:
•Unplug the display if you are not going to use it for an extensive
period of time.
•Unplug the display if you need to clean it with a slightly damp cloth.
The screen may be wiped with a dry cloth when the power is
off. However, never use alcohol, solvents or ammonia-based liquids.
•Consult a service technician if the display does not operate normally
after having followed the instructions in this manual.
•Keep the display out of direct sunlight and away from stoves or any
other heat sources.
•Remove any object that could fall into the vents or prevent proper
cooling of the display’s electronics.
•Don’t block the ventilation holes on the power box.
•Keep the display dry. To avoid electric shock, do not expose it to rain
or excessive moisture.
•When turning off the display by detaching the power cable or DC
power cord, wait for 6 seconds before re-attaching the power
cable or DC power cord for normal operation.
•To avoid the risk of shock or permanent damage to the set do not
expose the display to rain or excessive moisture.
•When positioning the display, make sure the power plug and outlet
are easily accessible.
3

Use
Remote Controller Precautions：
•This product requires remote switch (ON/OFF) from Front Side ; the
Back Side only has OSD function operated by remote controller.
4
Front Side Back Side
The Front Side have a user
door.

Use
Disconnect devices:
•For pluggable equipment, the socket-outlet shall be installed near the
equipment and shall be easily accessible.
5

Installation Notes
Please make sure you
have a solid installation.
(Locks on the ground)
As shown in the picture.
You can install Dual
side display by screws
x10(M6x20mm)
Ground
6

Installation Notes
IPC installation:
•Dual side display (DF-55) contains a plate metal, it is used to fix your
IPC.
•The relative position of the screw holes is shown below. You can choose
the fit screw holes to use.
7

Package Content
Unpacking
•This product is packed in a carton, together with the standard
accessories.
•Due to the size and weight of this display it is recommended for two
people to move it.
•After opening the carton, ensure that the contents are complete and in
good condition.
8
Package 1
BOTTOM CARTON
BOTTOM CUSHION
DF-55 DUAL SET
PACKING BAG
TOP CUSHION
UPPER CARTON
PLASTIC GRIP

Package 2
9

Accessories
Dual Side Display (upside
part : DF-55 dual set)
Power Cord x1
Remote Controller x1
(Battery : CR 2025 3V)
Dual Side Display
(downside part :
Bottom housing)
M5x30mm screw x4
10
M6x20mm screw x10
Key x1

Full Size Stand
(with wheels)
11
M10x100mm screw x4
Accessories

Overview
Front View Back View
Top View
Side View
12

Overview
1. Display (Dual side)
2. Display Set
3. Remote control sensor(Dual side)
4. Stand (with use hole x 10)
5. Use Door (with locker)
1
2
4
5
3
13

Setting Up The Display
Step1 : Tear down the downside covers
Putting the down half part upside ,
and tear down the downside covers.
screws x 20 (M3x6mm)
14

Step2 : Place the upside part into downside part
Place the upside part
into downside part
screws x 4 (M5x30mm)
15

Step3 : Connect the LVDS and 24V
LVDS 24V LVDS
LVDS
Connector
12pin 14pin
12pin 14pin
16
24V
Connector

Step4 : Reinstall the downside covers
Reinstall the downside covers
screws x 20 (M3x6mm)
17

HDMI*2
AC Switch
HDMI
Step5 : Open the user door, Connect by HDMI
connector & AC switch (power cord)
18
