NeoV™ Optical Glass - e most
trusted hard glass protection available.
Only on AG Neovo displays
www.agneovo.com
RX-W22
A smart 22” widescreen surveillance
display with hard glass protection
and Anti-Burn-in™technology
designed specifically for advanced
security environments.
e RX-W22 redenes the security display with the convenience
and cost-competitiveness of the widescreen format. Features
include NeoV™ Optical Glass protection, image burn-in prevention,
swi 0.8 second switching time, Mask Mode and automatic
recovery of video settings aer a power interruption. e VESA
compatible mounts and thin prole allow for multiple displays to
be installed in any surveillance conguration. Expressly designed
and tested for commercial video security applications, the RX-W22
delivers the performance expected of a high-end security display.
> 22” widescreen format
> High 900:1 contrast ratio
> NeoV™ Optical Glass
> Distinctive bezel design and durable metal casing
> Anti-Burn-in™ technology to prevent image sticking
> Mask Mode to eliminate image distortion
> Quick signal-switching time (≤ 0.8 sec.)
> Real-time image display with no time lag
> Automatic recovery of video settings aer power interruptions
> Video looping output supports auto termination
> Supports NTSC/PAL/SECAM video systems
> Auto-adjustment when VGA input is selected
> Kensington® security socket
> VESA standard wall mount

Specifications RX-W22
Panel Panel Type
Panel Size
Max. Resolution
Pixel Pitch
Brightness
Contrast Ratio
Viewing Angle (H/V)
Display Colour
Response Time
Panel Life Time
TFT LCD
22.0” (559 mm)
WSXGA+1680 x 1050
0.282 mm
300 cd/m
2(Typical)
900:1 (Typical)
170°/160° (Typical)
16.2M
5 ms (GTG)
30,000 hrs (Minimum)
Frequency (H/V) H: 24 kHz – 83 kHz
V: 50 Hz - 76 Hz
Max. Pixel Clock 160 MHz
Input Analogue
Digital
BNC Security
15-Pin D-Sub
24-Pin DVI-D
BNC Connector
Input Signal Analogue
Digital
Composite
RGB H.V Sync
TMDS
NTSC/PAL/SECAM
Output Connector BNC Security BNC Connector
Power AC-DC Adaptor
Power
Consumption
External
AC 100 - 240 V, 50 - 60 Hz
< 50 W (On)
< 2 W (Off)
NeoV™
Optical Glass
Thickness
Reflection Rate
Transmission Rate
Hardness
3.0 mm (0.18”)
< 1%
> 96%
> 6H (MOH’s Rating)
Plug & Play VESA DDC 1/2B, DDC-CI
Operating
Conditions
Temperature
Humidity
0 °C ~ 40 °C
10% ~ 90%
Storage
Conditions
Temperature
Humidity
-20 °C ~ 60 °C
5% ~ 95%
Mounting VESA FPMPMI Yes (100 mm)
Tilt Tilt 0° ~ +20°
Dimensions Product
(W x H x D)
Packaging
(W x H x D)
512 x 392 x 155 mm
(20.2” x 15.4” x 6.1”)
586 x 508 x 195 mm
(23.1” x 20.0” x 7.7”)
Weight Product Weight
Packaged Product Weight
6.9 kg (15.2 lbs)
10.5 kg (23.1 lbs)
Regulation
Approval
Certifications &
Compliance
FCC-B, UL/CUL, NOM, CB, CE,
TUV/Baurt, BSMI, Nordic,
GOST, WEEE, RoHS
Accessories Supplied Quick Guide, CD ROM (user
manual and drivers), power
cord, power adaptor, 15-Pin
D-Sub cable, 24-Pin DVI-D
cable, S-Video cable, CVBS
cable, BNC connector cable
All specications are subject to change without prior notice.
Copyright © 2008 AG Neovo. All rights reserved. e name AG Neovo is a trademark of AIC.
All other trademarks are the property of their respective owners.
P/C: RXW200_RXW201 Version 2.0, 20080530
RX-W22
NeoV™ Optical Glass for hard glass protection
and strong metal casing for secure mounting
Looping BNC video connector for multiple
display connections
Specially designed and tested for commercial
video security applications
Anti-Burn-in™ technology prevents image sticking
