AG Neovo RX-22 User manual

www.agneovo.com
NeoV™ Optical Glass - e most
trusted hard glass protection available.
Only on AG Neovo displays
Given its hard glass protection and
metal casing, the RX-22 promises
to excel in all sorts of modern
surveillance environments, however
demanding they may be.
Specically design and tested for commercial video security
applications, the RX-22 comes with AG Neovo’s AIP technology
that reproduces contrast, colours and details with an extraordinary
faithfulness. Armed with EcoSmart Sensor and Anti-Burn-in™
technologies, the energy ecient RX-22 runs on less than
0.5W at stand-by mode, a feature that ensures its performing
nonstop service immaculately. More versatile capabilities allow
multiple RX-22 displays to be easily installed in any surveillance
conguration for security environments.
> LED-backlit technology with high FHD 1920 x 1080 resolution
> NeoV™ Optical Glass
> Anti-Burn-in™ technology
> AIP technology: PIP and PBP functions; 3D Comb Filter/ Deinterlace/ Noise
Reduction; Image rotation function / Freeze
> Horizontal resolution up to 620TVL(NTSC), 625TVL(PAL)
> Quick signal-switching time ( ≤ 0.8 sec.)
> Selectable aspect ratio for ultimate image
> EcoSmart Sensor for low watt power consumption
> Black-level alignment
> Versatile inputs: VGA, DVI, HDMI, S-Video, CVBS in/out (BNC x 2), Audio in/out
> Built-in speakers (2W x2)
> BNC video out passive looping
> Power DC-out design to power connected peripherals
> Durable metal housing
> Rigorous screening of the components for mission-critical 24/7 applications
RX-22

REACH
All specications are subject to change without prior notice.
Copyright © 2012 AG Neovo. All rights reserved. e name AG Neovo is a trademark of AIC.
All other trademarks are the property of their respective owners.
P/C: RX2200, Version 1.1, 20120701
Specifications RX-22
Panel Panel Type
Panel Size
Max. Resolution
Pixel Pitch
Brightness
Contrast Ratio
Viewing Angle (H/V)
Display Colour
Response Time
LED-backlit TFT LCD
21.5”
FHD 1920 x 1080
0.2482 mm
250 cd/m2 (Typical)
1,000 : 1 (Typical)
170°/160° (Typical)
16.7M
3 ms (GTG)
Horizontal
Resolution
TV Lines 620TVL (NTSC), 625TVL (PAL)
Frequency (H/V) H: 24 kHz - 83 kHz
V: 50 Hz - 85 Hz
Input VGA
DVI
CVBS
S-Video
HDMI
15-Pin D-Sub
24-Pin DVI-D
BNC x 2
4-Pin mini DIN
HDMI x 1
Output CVBS
DC Output
BNC x 2
12V/500mA, DC jack 2.5Ø
Audio Audio In
Audio Out
Speaker
1 x stereo audio in for PC (audio
jack, 3.5 Ø)
RCA L+R for video
RCA L+R
2W x 2
Power AC-DC Adaptor
Power
Consumption
External
100 – 240V, 50 – 60Hz
<25W (On)
<0.5W (Active Off)
<0.5W (Off)
Sync Format Video System NTSC/PAL/SECAM
NeoV™
Optical Glass
Thickness
Reflection Rate
Coating Hardness
3.0 mm (0.18”)
< 1%
> 9H
Operating
Conditions
Temperature
Humidity
0°C ~ 40°C (32°F~104°F)
10%~90% (No condensation)
Storage
Conditions
Temperature
Humidity
-20°C ~ 60°C (-4°F~140°F)
5%~95% (No condensation)
Mounting VESA FPMPMI Yes (100mm x 100mm & 75mm x
75 mm)
Dimensions Product
(W x H x D)
Packaging
(W x H x D)
513 x 369 x 155 mm
(20.2” x 14.5” x 6.1”)
633 x 497 x 213 mm
(24.9” x 19.6” x 8.4”)
Weight (net) Product Weight
Packaging Weight
6.9 kg (15.2 lbs)
9.5 kg (20.9 lbs)
Regulation
Approval
Certifications &
Compliance
FCC, CB, CE, BSMI, RoHs, WEEE,
REACH
Accessories Supplied Quick Guide, CD ROM(user manual),
power cord, power adapter,
15-Pin D-Sub cable, audio cable
RX-22
NeoV™ Optical Glass protects against scratches,
impacts and other physical damage
On top of PIP and PBP, Smart Omni Viewer oers selectable
aspect ratios and the option of 180° image rotation
EcoSmart Sensor and versatile capabilities ensure
round-the-clock operations
Available in black or white
Multiple video inputs (HDMI, DVI, VGA, CVBS, S-Video)
make possible eortless system integration
