A reliable and affordable 22”
surveillance display with Full HD
resolution and versatile video inputs
ideal for security and control centre
environments.
e SC-22 features an LED backlight 22” widescreen display with
a full HD 1920 x 1080 resolution, delivering high picture clarity.
Quick signal-switching and rapid response time guarantees
surveillance eciency. With Analogue, HDMI, and looping
BNC I/O, the SC-22 is easily integrated into any security system.
Auto NTSC/PAL detection and auto settings adjustment reduce
maintenance eort. Coming with built-in speakers and stylish
slim prole, the SC-22 is the ideal value display choice for security
and surveillance environments.
> FHD 1920 × 1080 resolution
> Anti-Burn-inTM technology
> Built-in Image Enhancer: 3D Comb Filter/Deinterlace/Noise Reduction
> Versatile connectivity (BNC in/out, S-Video, VGA, HDMI, Audio in/out)
> Looping BNC video inputs for multiple connections
> Quick signal-switching time ( ≤ 0.8 sec. )
> NTSC/PAL auto-detection
> Selectable signal source
> PC compatible
> Built-in speakers
> Auto-adjustment for optimal setting
> Security socket
> VESA standard wall mount
> Tilt capacity from -6° ~ 13°
SC-22

All specications are subject to change without prior notice.
Copyright © 2014 AG Neovo. All rights reserved. e name AG Neovo is a trademark of AIC.
All other trademarks are the property of their respective owners.
P/C: SC2200 Version 1.1, 20140414
SC-22
Stylish and slim design ideal for
professional security environments
Video versatility, including VGA, HDMI, S-Video
and BNC In/Out
Looping BNC video inputs allow multiple display
connections
Built-in speakers enable more rigorous
security monitoring
Specications SC-22
Panel Panel Type
Panel Size
Max. Resolution
Pixel Pitch
Brightness
Contrast Ratio
Viewing Angle (H/V)
Display Colour
Response Time
LED-Backlit TFT LCD
21.5” (546.86mm)
FHD 1920 x 1080
0.248 mm
250 cd/m2 (Typical)
1000:1 (Typical)
170°/160° (Typical)
16.7M
3 ms (GTG)
Horizontal
Resolution
TV Lines 600TVL (NTSC), 600TVL (PAL)
Frequency (H/V) H: 31.5 kHz - 80 kHz
V: 50 Hz - 75 Hz
Input Analogue
HDMI
CVBS
S-Video
15-Pin D-Sub
HDMI
BNC x 1
4-Pin mini DIN
Out CVBS BNC x 1
Audio Audio In
Audio Out
Speaker
3.5ø mm audio jack
3.5ø mm audio jack
1W x 2
Power Power Supply
Power Requirements
Consumption
Internal
100 ~ 240V, 50 - 60Hz
< 25 W (On)
< 0.5 W (Off)
Plug & Play VESA EDID
Operating
Conditions
Temperature
Humidity
0 °C ~ 40 °C
10% ~ 85%
Storage
Conditions
Temperature
Humidity
-20 °C ~ 60 °C
10% ~ 95%
Mounting VESA FPMPMI Yes (100 x 100mm)
Tilt Tilt -6° ~ 13°
Dimensions Product
(W x H x D)
Packaging
(W x H x D)
516.5 x 376 x 185mm
(20.3” x 14.8” x 7.3”)
565 x 420 x 116mm
(22.2” x 16.5” x 4.6”)
Weight Product Weight
Packaged Weight
3.4 kg (7.5 lbs)
4.5 kg (9.9 lbs)
Regulation
Approval
Certications &
Compliance
CB, FCC, CE, GOST-R, WEEE,
RoHS
Accessories Supplied User manual, power cord,
15-Pin D-Sub cable, audio
cable, warranty card
