AGA Ludlow Instruction Manual

Ludlow
Standard Model
Electric Stove
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CUSTOMER: PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE.
For use in GB & IE (United Kingdom and Ireland)
Document No. : RH/ELEC/LUD/AS/AM –Iss 02/01/2020
File: Ludlow Electric ECE-AS Standard_User_Man.doc

Page 2
AGA Ludlow Electric Standard Stove
Installation & User Manual
TABLE OF CONTENTS
Please read and carefully follow all of the instructions found in this manual. Please pay
special attention to the safety instructions provided in this manual. The instructions included
here will assure that you have many years of dependable and enjoyable service from your
AGA Electric Stove.
PURCHASE, INSTALLATION INFORMATION & HEALTH & SAFETY
3
ELECTRICAL SAFETY TEST CERTIFICATE
6
IMPORTANT INSTRUCTIONS
7
THE DO’S & DON’Ts
8
STOVE DIMENSIONS
9
INSTALLATION ONTO A NON-COMBUSTIBLE HEARTH
10
UNPACKING AND TESTING APPLIANCE
12
WHAT COMES WITH THE STOVE
13
FITTING THE REAR WALL FIXING BRACKET
14
SETTING UP THE LOG SET & MEDIA
17
LOG SET - SAMPLE LAYOUT
18
OPERATING YOUR STOVE –UNDERSTANDING THE ICONS
20
MANUALLY OPERATING THE STOVE –INSTRUCTIONS
22
REMOTE CONTROL OPERATION –INSTRUCTIONS
23
STOVE RESET SEQUENCE
27
CARE AND MAINTENANCE
27
EXPLODED VIEW & PARTS LISTS
29
TROUBLE SHOOTING
30
SERVICE HISTORY
31
WARRANTY
32
SAFETY INFORMATION
WARNING
If the information in these
instructions is not followed exactly, a
fire or explosion may result causing
property damage, personal injury or
loss of life.
Do not store or use Petrol or any
other flammable vapors and liquids in
the vicinity of this or any other
appliance.

Page 3
AGA Ludlow Electric Standard Stove
Installation & User Manual
PURCHASE & INSTALLATION INFORMATION
Please complete the following form for reference when required:
Ref.
Description
Please Complete
1
Which retailer did you purchase the
stove from?
Name & Address of Retailer:
2
What date did you purchase your new
stove?
Purchase Date:
3
What was the name of the person
who installed your stove?
Full Name:
Contact Number:
5
What is the serial Number of your
stove?
This can we found inside the front
door above the bottom hinge
Serial Number:
6
What date was your stove Installed?
Installation Date:
7.
The AGA Name, Model & Type
reference for this stove is
Name - Ludlow Standard
Model –LUD/ELEC/A5S
Type –Electric
Technical Data Summary:
Reference
Description
Data
1
Maximum Heat Output
1.9 kW - (Equivalent to approx. 6,500 BTU's)
2
Minimum Heat Output
950 Watts
3
Flame Only Effect - LED Lights
25 watts - (Power Consumption)
4
Fuse Size inside 3 Pin Plug
10 Amp Rating
AGA Reference Code:
Model Code Reference - LUD/ELEC/A5S

Page 4
AGA Ludlow Electric Standard Stove
Installation & User Manual
HEALTH & SAFETY REQUIREMENTS –PLEASE READ
1. If the electricity supply cable is damaged do not use the appliance until it has been replaced.
For safety reasons the replacement has to be carried out by a service agent or a similarly
competent electrician.
2. Caution: in order to avoid a hazard due to inadvertent resetting of the thermal cut out, this
appliance must not be supplied through an external switching device, such as a timer, or
connected to a circuit that is regularly switched on and off by the utility
3. Do not operate the appliance if it is damaged.
4. Repairs of electrical appliances must only be performed by a suitably qualified electrical
engineer. Should the appliance fail to operate, or in case of any damage, please contact the
retailer from whom the appliance was purchased.
5. Caution: some parts of this product can become very hot and cause burns. Particular
attention must be given where children and vulnerable people are present.
6. This appliance can only be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision and/or instruction concerning
use of the appliance in a safe way and understand the hazards involved. However if
you do not deem the child or person competent only allow them to operate the stove
when a competent adult is in the room to supervise
7. CHILDREN OF LESS THAN 8 YEARS SHOULD BE KEPT AWAY UNLESS
CONTINUOUSLY SUPERVISED BY A COMPETENT ADULT.
If you are installing your appliance in to an existing chimney cavity
This stove MUST be installed on a Non Combustible Hearth - Ensure the floor area the
stove will sit on is flat and free from any loose materials
If applicable - if being fitted into a chimney opening ensure the flue has been
fully swept out, the chimney cavity should be sealed but an air vent must be
fitted so there can be a free flow air into the flue
To provide power to the appliance instruct a qualified electrician to install an earthed
power socket behind the stove unless one is already there. Ensure this socket can be
electrically isolated with a switch which is accessible, this must be connected to the
13 amp ring main of the house and covered by a RCB breaker
Must not be installed into a room with steam and water ingress such as a Kitchen or
Bathroom or a Wet Room
When installing & operating this stove there must be a free flow of air all around the
complete stove so a free flow of air can enter the rear air vent of the stove without any
restriction

Page 5
AGA Ludlow Electric Standard Stove
Installation & User Manual
HEALTH & SAFETY REQUIREMENTS –PLEASE READ
Never leave children unsupervised with an unguarded heater.
Never obstruct or cover the Stove or the heater Air Inlet and Outlet.
Never install or use this product where it may come in contact with water, moisture or
Steam i.e. Kitchen, Bathroom or Wet Room.
Never use aerosols or steam cleaners near this product.
Never route the electric cable near the heater outlet.
Never route the electric cable under carpets or floor coverings.
Never install this product close to curtains or any combustible materials.
Never use the heater to dry clothes or other objects.
Never remove the stove from the fireplace without isolating the electric supply, ensure
this stove is EARTHED

Page 6
AGA Ludlow Electric Standard Stove
Installation & User Manual
This AGA Electric Stove has been fully tested and CE Approved in the UK by KIWA
Blackwood Compliance Laboratories, a leading European Test Agency
Electrical Safety Test Certificate
Manufacturer:
AGA Rangemaster
Product Name/Model:
Ludlow Standard Electric Stove LUD/ELEC/A5S
Description:
Room heater
Certificate Number:
C 19-4649B
Test Standards:
EN 60335-2-30:2009 + A11:2012
EN 60335-1:2012 + A11:2014 + A13:2017
Tested at:
Kiwa Blackwood Compliance Laboratories
Blackwood, NP12 2DG,
United Kingdom
CONFORMITY WITH DIRECTIVES
This stove conforms to all relevant European Directives and is fully CE Compliant

Page 7
AGA Ludlow Electric Standard Stove
Installation & User Manual
IMPORTANT INSTRUCTIONS
1. Read all instructions before installing or using this heater.
2. DO NOT COVER THIS STOVE IN ANY WAY WHAT SO EVER
3. THIS STOVE MUST BE FITTED ONTO A NON COMBUSTIBLE HEARTH, WHICH
EXTENDS 225MM PAST THE FRONT OF THE STOVE &100MM TO THE REAR.
4. DO NOT BLOCK THE COOL AIR INLET AT THE REAR OR THE HOT AIR OUTLET
AT THE FRONT
5. ENSURE NO FOREIGN BODIES BLOCK THE COOL AIR INLET AT THE REAR
OR THE HOT AIR OUTLET AT THE FRONT OF THIS STOVE (SUCH AS PET
HAIRS CARPET FLUFF ETC) REGULARLY CLEAN ANY DUST, FIBRES OR
DEBRIS FROM THESE VENTS AT THE FRONT AND BACK OF THE STOVE
6. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains
at least 1000mm (39 inches) from the front, sides and rear of the heater.
7. Ensure the rear mounting bracket is fitted before opening the door, otherwise the stove could
tip forward
8. Always unplug (3 pin plug) heater when not in use.
9. Do not operate the fireplace if it has a damaged cord or plug, after it has malfunctioned, or if
the unit has been dropped or damaged in any way.
10. Do not use the heater outdoors.
11. Do not run the cord under carpeting. Do not cover the cord with throw rugs, runners or
anything else. Arrange the cord away from traffic areas where it could cause a tripping
hazard.
12. To disconnect the heater, turn the controls to "OFF" before removing the plug from the outlet.
13. Do not insert or allow foreign objects to enter any ventilation or exhaust opening, as this may
cause an electric shock, fire or damage to the heater.
14. To prevent a possible fire, do not block air intakes in any way.
15. A heater has hot and arcing or sparking parts inside. Do not use it in areas where
petrol/gasoline, paint or flammable liquids are used or stored.
16. Use this heater only as described in this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock or injury.
17. Avoid the use of an extension cord, the extension cord could overheat and cause a fire. This
heater is not to be used with an extension cord.
18. Always use properly grounded fused and polarized outlets.
19. Always use ground fault protection where it is required by electrical codes.
20. Always disconnect the power before performing any cleaning, maintenance or relocation of
the heater.
21. To prevent a possible fire, do not burn wood or other materials in this heater.
22. To prevent electric shock or fire, always use a certified electrician, should new circuits or
outlets be required.
23. When transporting or storing the heater, keep it in a dry place, free from excessive vibration.
24. This appliance should not be modified under any circumstances.
25. Packaging material should be kept away from children and be disposed of in a safe manner.
Plastic bags are not toys and should be kept away from children and infants.

Page 8
AGA Ludlow Electric Standard Stove
Installation & User Manual
26. Do not use this heater in small rooms when they are occupied by persons not capable of
leaving the room on their own, unless constant supervision is provided.
27. If the glass is damaged, do not use the heater in order to avoid a hazard.
28. Do not leave children unsupervised when heater is turned on.
29. CAUTION Some parts of this product can become very hot and cause burns. Particular
attention has to be given where children and vulnerable people are present.
30. This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children should not play with the appliance. Cleaning and
user maintenance shall not be made by children without supervision.
The DO’s & DON’Ts
DO’s
DO INSTALL THIS STOVE ONTO A NON COMBUSTIBLE HEARTH, WHICH EXTENDS
225MM PAST THE FRONT OF THE STOVE.
CLEAN THE INLET & OUTLET VENTS REGULARLY AT LEAST ONCE A WEEK
DEPENDING ON OPERATING CONDITIONS TO REMOVE ANY DUST, FIBRES OR
DEBRIS (SUCH AS PET HAIRS & CARPET FLUFF ETC)
Always install the heater in accordance with this guide. If in doubt obtain expert advice
Always make sure the electrical socket is accessible and located adjacent to, but not
above the heater.
Always disconnect the heater from the electrical supply before moving it, or carrying out
cleaning, maintenance.
Always make sure the heater is firmly secured to prevent it from being tipped over,
using the rear fixing bracket
Always use a fireguard when young children and infirm persons can come into contact
with the heater.
DON’Ts
NEVER COVER THIS STOVE IN ANY WAY WHAT SO EVER
DON’Ts
NEVER BLOCK THE COOL AIR INLET AT THE REAR OR THE HOT AIR OUTLET
AT THE FRONT
DON’Ts
NEVER ALLOW FOREIGN OBJECTS TO BLOCK THE COOL AIR INLET AT THE
REAR OR THE HOT AIR OUTLET AT THE FRONT OF THIS STOVE (SUCH AS PET
HAIRS & CARPET FLUFF ETC)
DON’Ts
Never leave children unsupervised in a room where the heater is ON and unguarded.
Never obstruct or cover the fan outlet or force items into heater openings.
Never install or use the heater anywhere where water is in use, i.e. Bathroom, Kitchens,
Shower Rooms, Swimming Pool etc.
Never use aerosols or steam cleaners on or around the heater.
Never route the mains supply cable under carpet etc.
Never install the heater close to curtains or combustible materials.
Never use the heater to dry clothes etc.
Never sit or stand on the heater.
Never use with a timer or any other device that switches the fire on automatically.

Page 9
AGA Ludlow Electric Standard Stove
Installation & User Manual
STOVE DIMENSIONS
Manual Controls and the ON/OFF Switch
Front View Right Hand Side View
Rear View Top View
Drawings are Not to Scale

Page 10
AGA Ludlow Electric Standard Stove
Installation & User Manual
INSTALLATION MUST BE ONTO A NON-COMBUSTIBLE HEARTH
(Hearth is shown as thick Black Line below)
Drawing Not to Scale
============== ====
225mm 100mm
This stove must be fitted on to a Non Combustible Hearth with a minimum
thickness of 12mm, which extends:
225mm from the front of the door of the stove
Minimum of 100mm from the rear of the stove
Minimum of 75mm either side of the stove
Hearth Must
Extend
225mm to
the front of
the Stove
Hearth
Must Extend
100mm to
the rear of
the Stove
Must be
Installed onto a
Non-
Combustible
12mm thick
Hearth

Page 11
AGA Ludlow Electric Standard Stove
Installation & User Manual
DO NOT COVER THIS STOVE –this will void the warranty
Above Front View - Hot Air Output Grill must be kept clear–shown in white box above
Rear View - Cool Air Intake Grill shown in white box above, this must be kept clear of any foreign objects
such as Pet Hairs & Carpet Fluff, this must be regularly cleaned so the vents are clear of foreign objects,
such as dust, debris & fibres.
Mains
Socket
Plugs in
Here
Rear Cool Air
Inlet Vent
KEEP CLEAR
Hot Air
Output
Vent
KEEP
CLEAR
Must be Installed
onto a
Non-Combustible
12mm thick
Hearth
Rear Wall
Fixing Bracket
Must be
Installed

Page 12
AGA Ludlow Electric Standard Stove
Installation & User Manual
UNPACKING AND TESTING APPLIANCE
Carefully remove the appliance from the box.
Prior to installing the appliance, test to make sure the appliance operates properly by
plugging the power supply cord in the socket on the back of the stove and then directly into a
240 Volt wall socket (not an extension lead or a multi-plug in a wall socket)
Test all aspects of its operation (manual switches, remote and heater) to make sure all
components are operating correctly.
As with most electronic devices, your new electric stove has been designed to operate at
temperatures between 5℃(41℉) and 35℃(95℉). During the cold winter months, allow the
stove to reach a minimum room temperature of 5℃before turning it on.
NOTE: There may be a trace of odour during the first time you use this stove. This is
caused from the paint finish curing, if the smell is strong open the windows and
operate the stove on the full heat setting for 30 to 45 minutes to allow the paint to cure,
children, the elderly or pets should not be allowed into the room during this period
WARNING –ELECTRIC SHOCK HAZARD
It is the customers responsibility to contact a qualified
electrical installer to make sure the electrical installation
is adequate and in conformance with the regulations.
Take special care when cutting holes in walls or floor.
Electrical wires may be behind the wall or floor covering
and could cause an electrical shock if you touch them.
Locate any electrical circuits that could be affected by the
installation of this product and disconnect power circuit
WARNING: THIS APPLIANCE MUST BE EARTHED.
DO NOT use an extension lead with this appliance.
The appliance is designed for the voltage stated on the
CE data plate.
Recommended but not mandatory to fit an individual Residual
Current Device (RCD) to the ring main supply circuit to this stove.
Please Hand this Manual to the customer/User for retention and
future instructions in the safe operation of the appliance.

Page 13
AGA Ludlow Electric Standard Stove
Installation & User Manual
WHAT COMES WITH THE STOVE
1 - Media Pack consisting of Logs and Embers –please refer to the Media Section
2 - Remote Control
3 - 2 xAAA Batteries - packed separately
4 - Power Cord with 3 pin sealed plug fitted –10 AMP fuse fitted
5 - Wall Fixing Bracket –please note this is already fitted to the rear of the stove
Item 2 –Remote Control
Item 3 –Power Code
Item 1 - Log Media Pack includes the following:
11 x Piece Log set –various sizes
Large bag of Glass Amber Bead Embers
Small bag of White Vermiculite Chippings
Small bag of Black Vermiculite Chippings
All of the items are packed into this cardboard box
In the box is
Item 1 - Log Media Pack
Item 2 - Remote Control
Item 3 - 2 x AAA Batteries
Item 4 - Power Cable
Item 3 - Batteries

Page 14
AGA Ludlow Electric Standard Stove
Installation & User Manual
Step 1 - Drill x 3 holes - 7mm diameter x 40mm deep to suit brown masonry
wall plug. - 65mm centres 450mm from base level into the rear wall
Step 2 - Insert 3 X 30mm Long Brown Rawplugs into the 3 drilled holes in
the back wall (marked as item 1)
FITTING THE REAR WALL FIXING BRACKET
This bracket must be fitted to the rear of the stove to ensure that the stove will not tip forward
when the stove door is opened
12mm thick
Non-Combustible
Hearth
Back Wall,
which the
Stove
Bracket will
be Mounted
onto

Page 15
AGA Ludlow Electric Standard Stove
Installation & User Manual
Step 3 - Fix wall bracket (item 3) with 3 x no. M5 x 25mm long posi drive
screws (item 4) as shown Note orientation of the bracket
Step 4 - Offer up the fire to the wall bracket so the two brackets align fit the
2x no. M5 x 20mm long cap screw supplied into bracket adjust distance to
wall to suit (max 102.5mm, min 65mm) tighten screws

Page 16
AGA Ludlow Electric Standard Stove
Installation & User Manual
Congratulations the rear fixing bracket is now complete and the stove is securely fixed to the rear
wall. Now you can open the door without the possibility of the stove tipping forward and lay your log
arrangement
Please note the arrows on the drawing so COOL air enters at the rear of the stove then HOT air
comes out from the front of the stove below the door
Please ensure the stove is fitted onto a non-combustible hearth as described earlier in this manual
Please ensure there is 100 mill gap at the rear so COOL air from the room can enter into the rear of
the stove without any restriction
IMPORTANT - Please make sure the front Hot Air outlet and the rear Cool Air inlet are regularly
cleaned so no foreign matters such as pet hairs and carpet fluff can block these 2 vents
NEVER COVER THIS STOVE –THIS COULD CAUSE A FIRE
Now just plug in your stove using the 3 pin plug lead provided into the female plug socket at the
rear of the stove. Please note the 3 pin Plug must be plugged into a wall mounted three pin
socket (which is part of your 13 amp ring main) not an extension lead or a multi plug in the wall
socket.
HOT Air Out
COOL Air In

Page 17
AGA Ludlow Electric Standard Stove
Installation & User Manual
Amber Glass Bead Embers
Black & White Vermiculite Chippings
11 –Piece Log Set
SETTING UP THE LOG SET & MEDIA
Your Stove is supplied with 11-piece-log, Amber Glass beads and Black and White
Vermiculite chippings.
Large Bag of Amber Glass Bead Embers
to be placed onto LED light base of the
stove
Small bag of White and Black Vermiculite chippings to
place over the logs and Amber glass beads to enhance
the real log burning feature

Page 18
AGA Ludlow Electric Standard Stove
Installation & User Manual
LOG SET - SAMPLE LAYOUT
Stove with the base lights and the rear flame effect turned
on - only using the Yellow light option
Step 1 - Now you are ready to place the media and logs into your stove
Firstly pour the bag of amber glass beads onto the glass base plate which will
allow the light from the base lights to diffuse and glow

Page 19
AGA Ludlow Electric Standard Stove
Installation & User Manual
Step 2 - You can lay the logs in what ever pattern or design you wish, there
are 11 x logs of various sizes (length and thickness) so from the 11 x logs
select the ones you wish to assemble into the stove and arrange them in a
manner that suits you.
Also included are the black and white vermiculite chippings you can just
sprinkle these over the top of the logs for that final log burner effect
Now just clean the door glass inside and out with a damp cloth, then close
the door. The door only needs to be reopened if you wish to change the
log arrangement. So for safety reasons keep the door closed
You probably won’t want to use all 11 x logs in the fire bed at the same time
but keep the extra ones safe as this gives you the option to change the log
bed design when you wish
Now sit back and enjoy

Page 20
AGA Ludlow Electric Standard Stove
Installation & User Manual
ICON
DESCRIPTION OF THE FUNCTION –FULLY DETAILED OVERLEAF
Red in Colour –this is the Main ON/OFF button for the stove, this will turn on the LED lights and
the Heater
This button operates the LED lights in the base and the rear flame effect turning them on or off, so
you can have the heater on, but the lights off
This Flame icon appears on the remote screen to show the flame effect is working
This operates the RED coloured LEDs in the base and the red colour in the flame effect in the
back of the stove, there are 3 x levels of brightness, High, Medium and Low –each time you
press the button the brightness will adjust on the 4th press of the button this light colour will turn
off. You can operate all 3 lights together or just one colour or 2 colours together.
This operates the YELLOW coloured LEDs in the base and the red colour in the flame effect in
the back of the stove, there are 3 x levels of brightness, High, Medium and Low –each time you
press the button the brightness will adjust on the 4th press of the button this light colour will turn
off. You can operate all 3 lights together or just one colour or 2 colours together.
This operates the BLUE coloured LEDs in the base and the red colour in the flame effect in the
back of the stove, there are 3 x levels of brightness, High, Medium and Low –each time you
press the button the brightness will adjust on the 4th press of the button this light colour will turn
off. You can operate all 3 lights together or just one colour or 2 colours together.
This button operates the top light colours. There are 16 shades of colour varying from red,
green, blue, violet, purple & yellow. If you want you can just have the down lights on without the
flame effect
This is the Fan Heater Button and operates the Heater unit turning it ON/OFF and between the
high and low settings
The Remote control screen displays this icon which means the stove is operating on its High heat
setting which is 1900W
The Remote control screen displays this icon which means the stove is operating on its Low heat
setting which is 950W
Press this button to adjust the temperature setting between 7℃and 30 ℃The buzzer beeps
when the remote key is pressed;
This is the Shift Key button to adjust the settings
OPERATING YOUR STOVE
Understanding the Icons on the Remote Control
