Agilent technologies Microscan 610-0002 User manual

AGILENT TECHNOLOGIES

AGILENT 5DX SERIES II/2L/3

AUTOMATIC BARCODE READER

INSTALLATION AND OPERATION

PROCEDURES FOR THE MICROSCAN

IN-LINE BARCODE READER SUBSYSTEM

November 2000

OVERVIEW The Microscan BCR (Bar Code Reader) scanner (FIS 610-0018) can be

configured to work in Stand-Alone mode (Single Read Head) as well as

Multidrop mode (Multiple Read Head.) Most of the current bar code readers

have been shipped to accommodate both single read head and multiple read

head, with the addition of the Multidrop Series 5000 concentrator. This manual

provides a description of the installation and operation of the Microscan 600

series Bar Code Reader and Multidrop 5000 concentrator for single or multiple

read head applications on the AGILENT 5DX Automatic Inspection System.

Section One (1) discusses the configuration of the single read head BCR.

Section Two (2) discusses the configuration of the multiple read head BCR and

concentrator.

While many of the installation and operation parameters associated with this

system are specific to the 5DX/BCR interface implementation, this manual has

not been designed to serve as a theory of operation or software implementation

specification. This manual has been designed to assist personnel in the

installation and operation of the BCR subsystem for the AGILENT 5DX

product line. Agilent Technologies provides the bar code reader, cables,

connectors, power supplies and other accessories.

Please verify that the following items are included with the specific product as

shown below.

MICROSCAN SERIES 600 (Agilent Technologies E7241A)

MICROSCAN 610-0002 BAR CODE READER E7200-67977

RS232 ADP JUNCTION BOX E7200-67978

BCR POWER SUPPLY E7200-66409

BCR TO MASTER CPU INTERFACE CABLE E7200-61709

BCR TO ADP CABLE 1150-2046

MICROSCAN SERIES 5000 (Agilent Technologies E7242A)

MICROSCAN MUTIDROP CONCENTRATOR 0960-0938

RS485 ADP JUNCTION BOX 0960-0939

MICROSCAN 610-0018 BCR HEAD 0960-1262

BCR TO ADP CABLE 1150-2046

T-CONN 9PIN 3-WAY 1252-7535

T-CONN TO CONCENTRATOR LAN CBL 8120-6956

ADP TO T-CONN CBL 8120-6957

CONCENTRATOR TO CPU CBL E7200-61709

BCR POWER SUPPLY E7200-66409

In addition to the bar code reader you will need the following to perform the

installation and verify the operation.

• Flat blade screwdriver

• 20 gage buss wire - 2”

• Standard barcode labels

MICROSCAN

SERIES 600

INSTALLATION

AND

CONFIGURATION

The 610-0002 BCR scanner will only work in Stand-alone mode. If you have a

Series 600 BCR then continue with Step 1. If not skip to “MICROSCAN

SERIES 5000 INSTALLATION AND CONFIGURATION” on page 12.

Figure 1 Microscan 610 and ADP-232

Model 5DX Stand-alone BCR Configuration

1 Connect the BCR components as shown in the diagram. The AC power

connection for the Power Supply is provide at the J Box mounted on the left

rear corner of the AGILENT 5DX Main Cabinet on Series I through Series

2L. AC power outlets are not currently provided on a Series 3 5DX. If the

customer has a Series 3 5DX, a local power supply will have to be accessed.

Connect the DC output power connector to J2 on the ADP-232 unit.

Assemble the BCR as in Figure 2.

610-0018

BCR

SCANNER ADP

RS-232

UNIT

POWER

SUPPLY

J4 TO J05051 CABLE

BCR/ADP CABLE

SYSTEM CONTROLLER

EXPAN.CHASSIS

Figure 2 Microscan 610 and ADP-232

2 Power on the BCR ADP-232. The Scan Head should generate a

continuous series of raster scan lines. Position the scan head towards the

standard bar code label at a distance of about 2.0" (50mm) and verify that

the raster scans across the length of the bar code label. Also check the

power status “green” indicator light is lit. If the code can be read from the

default settings, the "red" good read indicator light will also be lit. In

addition, the BCR read head will beep continuously while reading the bar

code label. Reference Figure 3

Figure 3 Microscan 610 BCR successfully reading a bar code label

ADVICE

The Microscan box has a standard bar code label on the outside. The Microscan

will not read all labels. Use this label to check the BCR operation. Then use a

sample of the customer’s label to see if the reader will read the label. Distance

between the scanner and the label is important. In order to read the label it may

be necessary to adjust the distance several times

If this step fails, the red light does not come on, try these fixes:

•Try scanning alternative barcode labels. The first barcode sample

may have been bad.

•If still fails, repeat Step 1 to ensure that all cable connections are

good.

•If still failing, try resetting the BCR head (procedure on next page)

and test again.

If the BCR still cannot successfully scan any barcode, you should replace the

unit.

3 To confirm the BCR unit is in a known state, we will reset it. Remove the

connector at J4 on the ADP-232 unit CPU Interface cable (E7200-61709).

Use a piece of bus wire and jumper pin 7 to pin 11 on the ADP unit

momentarily. A series of beeps should be heard. As soon as the beeps start

sounding, release the connection, then quickly jumper pin 7 to pin 11 again.

When correctly executed, a single long higher pitched beep will be

heard after the short beeps. This long beep confirms the unit has been

reset. If a long beep is not generated, reconnect the jumper and repeat

the procedure. When successful, reconnect the cable connector to J4 on the

ADP-232 unit. Reference Figure 4

Figure 4 Reset the Microscan 610 through the ADP-232 J4 connector

4 Configure the scanner (Optional). DO THIS STEP ONLY IF YOU

KNOW IT IS NECESSARY BECAUSE CONFIGURATION CHANGES

HAVE BEEN MADE TO THE PROGRAM. Usually this step is not

required for the stand-alone configuration because Step 3 resets the BCR

610 to the default configuration. Usually you will go to Step 5.

Configuring and testing the scanner must be executed from the AGILENT

5DX User Interface command window.

From the 5DX User Interface window select SYSTEM > Quit from 5DX.

The stand-alone configuration file should already be set for a Microscan

600 series scanner. However, if it is necessary to change the baud rate or

the number of read heads, then CFGSCNR.EXE will do it. Configurable

parameters are located in:C:\5DX\Release Root\CALIB\SCNR.CFG and

are shown in Figure 5.

Figure 5 Configurable parameters in SCNR.CFG

5 Running CFGSCNR (Optional). Return to the Master folder. At the Dos

command window prompt, type “cfgscnr 0” (0 is for identifying a single

read head). When CFGSCNR is executed, the current configuration settings

will be displayed to inform the user how the scanner is being programmed.

Figure 6 shows the usage and results.

Figure 6 CFGSNCR.EXE Usage and Output

If the configuration is set for stand-alone and the unit address is greater than

zero, the system generates the error shown in Figure 7.

Figure 7 Error Message for Invalid Stand-Alone Unit Address

If no error message is generated, then proceed to the next step. If an error mes-

sage is displayed, re-check the “scnr.cfg” file for the correct setup.

6 Verify BCR operation and alignment. Position the scanner head towards

the standard barcode label. Power on the ADP unit if not already powered

on. From the Dos command prompt, type “alignbcr –a”. The bar code

reader will automatically start reading the bar code label and displaying the

value it read on the screen. Distance between the reader and the barcode

will affect success. Two inches is a good starting point. See Figure 8.

Figure 8 ALIGNBCR Usage and Output for Automatic Mode

7 There is a second way to run ALIGNBCR.EXE. The user can specify an

“-m” parameter to operate the executable in manual mode. In this mode a

read cycle can only be generated by pressing the SPACE BAR. This will

allow the user to slowly control the alignment process. Once a read cycle

has been generated, the output will be displayed. Hit ESC to quit. Figure 9

shows the usage and output for manual alignment.

Figure 9 ALIGNBCR Usage and Output for Manual Mode

8 Configure the Bar Code Reader from the Agilent 5DX User Interface.

Select System > Sytem Access > Configure >5DX Options.

Figure 10 Screen shot of Result of Step 8.

9 Use the arrow key and select “In-Line Bar Code Reader”.

Figure 11 Screen shot of result of Step 9.

10 Configure the menu to use the barcode reader and make sure the number of

heads reads “1,” Save changes.

Figure 12 Screen shot of Step 10 action.

NOTE

This setup will only work in STAND-ALONE mode.

ADVICE

This is usually as far as a Customer Engineer can go without the help of the

customer. The customer must provide the Serial Numbers for their boards/panels

to continue with the next step.

11 Serial Numbers for loading CAD. The customer must configure the Serial

Number option to match the bar code label numbers for the correct

applications to be inspected. Refer to the Agilent 5DX Online Reference

Guide for the procedure to set up the serial number recognition files.

MICROSCAN

SERIES 5000

INSTALLATION

AND

CONFIGURATION

You can configure the Microscan BCR scanner (610-0018) to work in either

Stand-Alone mode, or Multidrop mode. To configure in the multidrop mode,

refer to Figure 13 and follow the procedure below. To configure in the

standalone mode, refer to “MICROSCAN SERIES 600 INSTALLATION

AND CONFIGURATION” on page 3

Figure 13 Model 5DX Multidrop BCR Configuration

Figure 14 Cable connections for dualhead, multidrop automatic barcode reader

1 Configure the Scanner cables in the Stand-Alone configuration first to

program the Microscan 610 BCR heads. Refer to Figure 15. Label the

ADP-232 / BCR Scanners sets as number 1, number 2, ect. Connect the

CPU Interface cable (E7200-61709) from the Com Port 3 (Port 1 on Series

3) on the 5DX to the first ADP-232 J4 connector.

Figure 15 Model 5DX Stand-alone BCR Configuration
