AGU Baby Brainy AGU SHE7 User manual

1
agu–baby.com
RU РУКОВОДСТВО
ПО ЭКСПЛУАТАЦИИ
SMART THERMOMETER
INFRARED
AGU SHE7
EN USER MANUAL

2
CONTENTS
1 Introduction ........................................................................................................................3
2 List of symbols..................................................................................................................5
3 Scope of application.........................................................................................................6
4 Complete set......................................................................................................................6
5 Specications.....................................................................................................................6
6 Device description........................................................................................................... 8
7 Safety instructions.........................................................................................................10
8 Preparation for use....................................................................................................... 12
9 Operating principles and procedures......................................................................14
10 Device cleaning..............................................................................................................18
11 Troubleshooting ............................................................................................................. 19
12 Storage, transportation and operation terms....................................................... 20
13 Disposal............................................................................................................................20
14 Certication.......................................................................................................................21
15 Manufacturer’s warranty ............................................................................................24
SMART INFRARED THERMOMETER AGU SHE7 EN

3
EN
INTRODUCTION
Dear friends, thank you for choosing our products!
Smart infrared thermometer AGU SHE7 is an advanced high-quality product that
is compliant with international standards.
Smart infrared thermometer AGU SHE7 has been designed for body tempera-
ture measurement .
It performs high-precision temperature measurements through the use of
unique technology. Power-on self-test of the system ensures the required mea-
suring accuracy.
This device is suitable for people of all ages.
Benets of smart infrared thermometer
AGU SHE7 :
Multiple purpose (wide measurement range).
The device has a wide measurement range from 1 °С to 100 °С, which allows it to
be used as a forehead or ear thermometer, as well as for measuring:
•liquid surface temperature in a baby bottle (for instance, milk);
•water surface temperature in a baby bath;
•ambient temperature and solid object surface temperature.
Measuring temperature in a just few seconds.
Innovative technology with the use of infrared sensor allows measuring tempera-
ture in the external ear canal in just a 1 second.
Accuracy and reliability.
The unique design of the device with built-in infrared sensor provides accurate
and reliable measurement results.
Ease of use.
Smart infrared thermometer AGU SHE7 allows conducting temperature mea-
surements easily and simply.
The temperature can be measured even in a sleeping child without disturbing.
The measurement is fast, which is very convenient when taking a child’s tem-
perature.
Automatic display of readings in the device memory.
The device automatically displays the last measurement for 2 seconds aer
switching on.
1

4
Reproduction of the last few results.
You can recall the last 10 measurement results, which makes it possible to more
eectively monitor temperature changes.
Data storage and viewing in the application due to wireless transmission.
Having installed the AGU application on your smartphone, you can save and view
temperature measurement statistics.
Please read this manual carefully before using the device.

5
EN
LIST OF SYMBOLS
Symbol Meaning
The CE marking with the Registration Number of the Notied Body.
This denotes the compliance of European Medical Device Directive
93/42/EEC.
The product complies with the basic requirements of TR CU 020/2011
«Electromagnetic compatibility of technical means».
WEEE (Waste Electrical and Electronic Equipment Directive). The
symbol on the product or its package means that this product
does not fall under the category of domestic waste. To avoid pos-
sible damage to the environment and human health, separate such
wastes from others and dispose of them in accordance with accept-
ed standards.
Device classication type BF.
Ingress protection rating.
Leading digit (protection against ingress of solid foreign objects): 2 –
protection against ingress of solid objects more than 12 mm in size; n-
gers or other objects with a maximum length of 80 mm, or solid objects.
Second digit (protection against ingress of foreign liquids): 2 – pro-
tection against vertically falling water drops and objects when enclo-
sure tiled up to 15° (normally positioned equipment).
Warning/Attention.
Read the instruction manual before use.
2

6
SCOPE OF APPLICATION
Smart infrared thermometer AGU SHE7 is intended for measuring body
temperature on the forehead and in the external ear canal in the home
environment. Do not use the device for purposes other than intended. This
thermometer can be used for children and adults
.
COMPLETE SET
1. Smart non-contact digital infrared thermometer AGU SHE7 - 1 pc.
2. Batteries 1.5 V ААА - 2 pcs.
3. Storage case - 1 pc.
4. Instruction manual - 1 pc.
SPECIFICATIONS
Type Smart infrared thermometer
Model
AGU SHE7
Temperature measurement
range
Human body: 34°C – 43°C (93.2°F – 109.4°F).
Objects: 1°C – 100°C (35°F – 212°F)
Measuring accuracy Human body: 35°C – 42°C (95°F – 107,6°F) - ±0,2°C (0,4°F).
Objects: ±2°C (±4°F) или ±5%
Operating environment
temperature
15°C – 35°C (59°F – 95°F).
Relative humidity: up to 95% (non-condensing)
Storage conditions -25°C – +55°C (-13°F ~+131°F).
Relative humidity: up to 95% (non-condensing)
Transport conditions 25°C – +55°C (-13°F ~+131°F).
Relative humidity: up to 85% (non-condensing)
Operating conditions 15°C – 35°C (59°F – 95°F).
Relative humidity: up to 95% (non-condensing)
Display resolution 0.1°C or 0.1°F
Power source 2 batteries 1.5 V AAA

7
EN
Memory 10 records
Weight 69 g (without batteries)
Dimensions 134.3×42.4×47.6 mm (LWH)
Housing material ABS plastic
Measurement time 1 second (in the external ear canal)
Display segment
Auto power-o in 30 seconds

8
DEVICE DESCRIPTION
Сover cap
Measure button
«HEAD» mode
Measure
button «EAR»
mode
Fever indicator
LCD
Memory
button
Setting
button
Speaker
hole
Infrared sensor
Battery lid
Battery lid screw

9
EN
DESCRIPTION OF THE DISPLAY ELEMENTS
Date Time
Foreheade
measurement
mode
Ear
measurement
mode
Measurement
in Progress
Object
measurement
mode
Celsius Scale
Fahrenheit Scale
Temperature
value
Memory
Symbol
Memory
number Low battery
Warning
Sound
indication

10
SAFETY INSTRUCTIONS
The device must be used for its intended purpose, in accordance with this manual.
The manufacturer is not responsible for any damages caused by improper use.
•Any modication of the device is prohibited.
•The device is not waterproof! Under no circumstances should you im-
merse it in water or other liquids. When cleaning, follow the instructions
contained in «Device cleaning» section.
•Aer cleaning the measuring sensor, take a ve-minute break before
the next measurement so that the sensor gains the initial operating
temperature.
•Do not use the device if you think it is damaged or notice anything un-
usual in its operation.
•Never disassemble the thermometer.
•It is important to clean the ear canal before measurement as the ear
wax can aect the measurement results (usually too low).
•During early stages of illness with a rapid rise in temperature to high val-
ues, the eect of «white hyperthermia» can be observed – a condition
which can be characterized by the peripheral vessel constriction, when
the skin becomes pale and remains cold. In such cases, temperature
measurements on the forehead should not be carried out, because the
skin temperature will be low. THEREFORE, YOU SHOULD SELECT «EAR»
MODE TO MEASURE THE TEMPERATURE IN THE EXTERNAL EAR CANAL.
•If the measurement results are contrary to the patient’s general state or
suspiciously low, repeat the measurements every 15 minutes or mea-
sure the body temperature with another thermometer in the mouth or in
the rectum.
•The device includes parts that require careful handling.
•Please refer to «Basic specications» section for storage and operation
conditions.
•Ensure that children do not use the device unsupervised: some parts are
small enough to be swallowed. Do not allow children to play with the
thermometer.
•Remove the batteries from the device if it will not be used for extended
period of time.
•Do not use the device near strong electromagnetic eld sources, includ-
ing cellular phones and radio installations. Maintain the required dis-
tance from these sources during operation of the device.
•Every time before starting measurement, please make sure that the
measuring sensor lens is not contaminated. In case of contamination,

11
EN
clean the measuring sensor lens, wait for a few minutes before tak-
ing the next measurement so that the sensor gains the initial operat-
ing temperature.
•Do not pocket the thermometer before use as it can be heated.
•Do not measure temperature during or straight aer nursing.
•When measuring temperature in babies, it is ideal to place the baby on
a at surface and turn the head on one side so that the ear is directed
upward.
•Keep your thermometer out of the reach of children! The device should
not be used by physically, nervously or mentally disordered people (in-
cluding children), or by the people who have insucient experience and
knowledge, unless they are supervised or instructed by the persons re-
sponsible for their safety. You should supervise the children and not al-
low them to play with the thermometer.
•The user should not take food, drink or do physical exercises immediate-
ly prior to or during temperature measurement.
•Before starting measurement, please remove any dirt, hair or sweat
from the measuring area.
•The environmental temperature in the apartment may dier in various
rooms. Before measuring temperature, the user and the thermometer
should stay in the same room (premises) with constant environmental
conditions for at least 30 minutes.
•Always measure the temperature in the same area, as the readings may
vary in dierent areas.
•Wait for at least 30 seconds aer 3-5 consecutive measurements to en-
sure accuracy of readings.
Protect the device from:
•extreme temperatures;
•shocks;
•contamination and dust;
•direct sunlight.
This device is not intended to be a substitute for professional medical advice.

12
PREPARATION FOR USE
Remove the device from the package. Check the battery charge level.
When the batteries get weak, the battery warning symbol
appears.
It is still possible to make measurements, but the batter-
ies should be replaced as soon as possible. If the batteries
are completely discharged, the display shows «Lo» and a
low battery indicator.
In this case, the batteries must be replaced.
NOTE
•It is recommended to remove the batteries if the thermometer will not
be used for extended period of time.
•Keep the batteries out of the reach of children and do not expose them
to heat.
•Batteries must be disposed of in accordance with local environmental
and organization policies.
•Do not use rechargeable batteries.
Battery replacement
1. Loosen the battery lid screw with a Phillips screwdriver. Remove the lid.
2. Insert 2 new batteries 1.5 V AAA into the battery compartment, observing
polarity. Always use only new batteries.
3. Reinstall the battery lid and tighten the screw.
Dispose of the used batteries in accordance with the applicable legal regu-
lations. It is prohibited to dispose of the batteries in the normal household
waste.

13
EN
DEVICE SETTINGS
Date and time settings
Before the rst use of the device and aer each replacement of batteries, date
and time are displayed in the format 1-1 00:00. Set the following parameters in
turn: temperature measurement unit, date and time.
Make settings in steps
:
measurement unit – year – month – day – hours – minutes
1. Press «EAR» button.
2. Press and hold «SET» button for 5 seconds to activate the setting mode.
3. «C» or «F» measurement unit will be displayed.
•Press «SET» button to change the parameter.
•Press «MEMORY» button to conrm the entry.
4. The year indicator will be displayed, set the current date using «SET»
and «MEM» buttons.
5. Set in turn the month, day, hours and minutes using «SET» and «MEM»
buttons.
6. Aer setting all the parameters, the «OFF» indicator will be displayed
and the device will switch o automatically.
Reproduction of the previous readings
You can recall up to 10 measurement values stored in the
device memory.
1. Press «EAR» button to switch on the thermometer.
2. Press «MEMORY» button. The last measurement
value stored in memory is displayed rst.
3. Press «MEMORY» button one
more time to view the previ-
ously stored value.
•When recording new mea-
surement values (aer the
10th value), old values are
deleted automatically.

14
Enable / disable sound
Press the «EAR» button to turn on the device. Then press the «SET» button to
enable or disable the sound alert.
OPERATING PRINCIPLES AND PROCEDURES
There are 2 options for the device operation:
Option 1: without mobile application.
Option 2: via mobile application.
OPERATION WITHOUT MOBILE APPLICATION
Smart infrared thermometer AGU SHE7 is intended for measuring tempera-
ture on the forehead and in external ear canal.
1. MEASURING BODY TEMPERATURE ON THE FOREHEAD
The thermometer takes temperature by measuring infrared heat generated in the
eyebrow area and surrounding tissues.
1. Remove any dirt, hair or sweat before placing the temperature sensor in
the measurement area.
2. Press «EAR» button to switch on the
device.
3. Put the sensor tip with the cap to the
temple and, holding «HEAD» button,
swipe it smoothly across the fore-
head to the other temple.
4. Release head button
«HEAD». You will hear
a beep, and the result
of the body tempera-
ture will appear on
the display.

15
EN
2. MEASURING BODY TEMPERATURE IN THE EAR
ATTENTION
•Some people produce dierent readings in their le and right ear. To
avoid temperature variations, always perform measurements in the
same ear.
•The measurement must not be taken in an ear aected by inammato-
ry diseases, aer possible ear injuries or in the healing period. In all of
these cases, please consult your doctor.
•If you have been lying on one ear for some time, the temperature is
slightly raised. Wait a little while or measure in the other ear.
•Accumulation of ear wax on the sensor can aect the measuring ac-
curacy and result in the spread of infection among the thermometer
users. It is extremely important for each measurement to observe the
rules of hygiene and keep the sensor clean. To clean the sensor, fol-
low the instructions contained in the «Device cleaning» section. Every
time before starting measurement, please make sure that the mea-
suring sensor lens is not contaminated.
•Aer cleaning the measuring sensor lens with a disinfectant solution,
wait for a few minutes before taking the next measurement so that
the sensor gains the initial operating temperature.
The thermometer takes temperature by measuring infrared heat generated by
ear drum and surrounding tissues. Energy is captured with a lens and convert-
ed to a temperature value. Temperature measurement should be carried out
by placing the sensor tip in the external ear canal above the ear drum, and not
over the surface of nearby anatomical areas. Otherwise, the measurement val-
ues may be too high.
Body temperature measurement in the external ear canal ensures accurate
readings due to the same temperature of blood owing towards the ear drum
and the brain's temperature regulation center – hypothalamus. Therefore,
changes in body temperature are faster and more accurately recorded in the
external ear canal than in any other body area.

16
1. Press «EAR» button to switch on the device.
2. Remove the cap.
3. Make sure the ear canal is clean. As the ear canal is slightly curved,
you have to pull the ear slightly up and backwards before inserting the
sensor tip.
The correct position of the thermometer sensor in the ear canal:
•Children under 1 year of age.
Lay the child in a horizontal position and turn the head on one side so
that the ear is directed upward. Slightly pull the ear back.
•Children over 1 year of age.
Slightly pull the ear up and back to align the ear canal.
4. Carefully insert the sensor tip into the ear canal and press «EAR» button .
If the temperature reaches 37.5°C or above,
the backlight turns on and the red LED light
is on for 3 seconds.
2
1

17
EN
3. OBJECT TEMPERATURE MEASUREMENT
1. Press «EAR» button to switch on the device.
2. Remove the cap.
3. Simultaneously press and
hold for 3 seconds «SET»
and «MEM»
buttons icon
will appear on the display.
4. Bring the thermometer to
the measurement object so
that there is a distance of
3-5 cm between the sensor
and the object.
5. Press «EAR» button.
When the measurement is completed, you will hear a beep sound, and the
measured value will appear on the display.
OPERATION VIA MOBILE APPLICATION
NOTE
Mobile application provides opportunity to:
•save the temperature measurement history;
•save the temperature measurement history for dierent users;
•take notes on symptoms and general state;
•take notes on medicines taken.
NOTE
The object temperature measurement history is not stored in the application.
2
1

18
Install the application: Android 5.0 and higher, iOS 10.0 and higher.
Option A:Open the PlayMarket or AppStore, enter «AGU» in the
search box and download the application.
Option B:For direct link to download the application, scan this
QR code.
1. Download and run the application.
2. Register and log in with social media site.
3. Select device to connect.
4. Enter the required user data.
5. Switch on the device and press «Connect» button.
6. Follow the application instructions.
DEVICE CLEANING
ATTENTION
Do not use chemically active detergents.
to clean the device
Disinfecting agents can be used in
the home.
Lens/measuring sensor: In case of contamination of the infrared thermometer
sensor lens, the readings begin to change immediately as something interferes
with the measurement (usually the readings are too low). To eliminate this prob-
lem, it is enough to wipe the sensor with a so lint-free cloth (or cotton swab)
moistened with disinfectant solution. Then it is necessary to wipe the lens with
a dry so lint-free cloth. Aer the cleaning procedure, the lens surface should be
ab
12 3 4 5
TheAG USmart Infrared Thermometer
TheAGU Smart Baby Formula Maker
Ido not have a device yet.
Device selection
The AGU Smart Infrared
Thermometer
Youare in control any time without
disturbing the baby

19
EN
crystal clear. As the lens surface gets cool when the disinfectant solution evapo-
rates, the thermometer should be le for several minutes at room temperature
before use aer cleaning.
Thermometer: Clean the thermometer housing with a so, dry cloth. Never use
abrasive cleaners, thinners or benzene. Do not scratch the surface of the sensor
lens or display. Avoid dropping your device and do not expose it to extreme tem-
peratures, moisture and direct sunlight.
Store the device in a dry, clean and dust-free place in accordance with the
operating conditions.
TROUBLESHOOTING
If a problem occurs during operation, rst of all, refer to the list of possible failures
given below.
LCD display Cause Solution
1. The human body temperature mea-
sured is higher than 42°С (107.6°F).
2. The object temperature measured is
higher than 100°C (212°F)
Operate the thermom-
eter only between the
specied temperature
ranges. If necessary,
clean the sensor tip. In
the event of a repeated
error message, contact
your retailer or Custom-
er Service
1. The human body temperature mea-
sured is lower than 35°С (95°F).
2. The object temperature measured is
lower than 10°С (50°F) 10°C (50°F)
The operating temperature is out of range
between 15°С and 35°С (59°F ~95°F) Operate the thermom- eter only between the
specied temperature
ranges

20
STORAGE, TRANSPORTATION AND OPERATION
TERMS
•The device should be stored within the temperature range from -25°C to
+55°C (-13°F ~ +131°F) with relative humidity up to 95% (non-condensing).
•The device should be operated within the temperature range from +15°C
to +35°C (59°F~95°F) with relative humidity up to 95% (non-condensing).
•The device should be transported within the temperature range from
-25°C to +55°C (-13°F ~ +131°F) with relative humidity up to 85% (non-
condensing).
•Do not expose the device to thermal shock.
ATTENTION
Aer transportation or storage at low temperatures, it is necessary to keep
the device at room temperature for at least 2 hours before switching on.
DISPOSAL
This symbol on the product or its package means that this product does
not fall under the category of domestic waste.
•Proper disposal of the device will prevent adverse environmental and
human health eects.
•In order to protect the environment, the device must not be disposed of
together with domestic (household) waste. Disposal shall be provided in
accordance with local regulations.
•The device must be disposed of in accordance with the EU Directive
2012/19/EU WEEE (Waste Electrical and Electronic Equipment).
If you have any questions, please contact the local public utility responsible for
waste disposal.
