Armotech WG47 & WG47s User Manual
Revision 1 printed 8/4/2005
Mail: [email protected]
1
Armotech WG47 Manual
–poweredbyWarsensor
ARMOTECH and WARSENSOR are trademarks owned by AI-MOK Paintball Ltd.;
All ARMOTECH and WARSENSOR products are manufactured by ARMOTECH Taiwan Co., Ltd. only.
© 2004 - 2005 AI-MOK Paintball Ltd. All rights reserved
WWW.ARMOTECH.NET
Armotech WG47 & WG47s User Manual
Revision 1 printed 8/4/2005
Mail: [email protected]
2
Safety First!
WARNING
WARSENSOR PAINTBALL MARKERS ARE NOT A TOY. ANY MISUSE MAY CAUSE SERIOUS
INJURY OR DEATH. THE USER AND ANY PERSON WITHIN RANGE MUST WEAR EYE
PROTECTION DESIGNED FOR PAINTBALL USE. READ THIS OWNERS’S MANUAL
COMPLETELY BEFORE LOADING, PRESSURIZING, OR OPERATING YOUR WARSENSOR
PAINTBALL MARKER.
•Always wear protective goggles & headgear designed for paintball when shooting this marker
•Everyone within range of an area where this paintball marker is used should wear protective goggles
and headgear specifically designed for paintball
•Operate this paintball marker only in areas where it is safe and lawful to do so
•Misuse of this marker may result in criminal charges or imprisonment
•This marker is intended for sale to adults. Adult supervision is recommended at all times whenever a
minor is handling this marker
•READ THIS OWNER’S MANUAL COMPLETELY BEFORE LOADING, PRESSURIZING, OR
OPERATING THE WARSENSOR MARS SERIES PAINTBALL MARKER!
•Never aim or shoot this paintball marker towards anybody who is not wearing protective goggles or
headgear specifically designed for paintball
•During game play, follow referee’s instructions and all field safety rules. Avoid shooting at another
player’s head, neck or groin area
•Play paintball only where the rules of safety for paintball are followed
•All paintball markers must be chronographed regularly. Adjust the marker to shoot paintballs at a
velocity this is 300feet per second (fps) or less and that does not exceed the velocity limit set by the
Paintball Park or field where the marker is in use. Chronograph the marker at regular intervals during
the day, as well as any time the power source is refilled or changed, any time the barrel or any part of
the power system is changed, and upon request of any player or game official
•This paintball marker operates using compressed gas or air at specified pressure ranges. Follow
safety procedures when handling compressed gas or air. All filling of compressed gas or air cylinders
must be done by qualified persons
WWW.ARMOTECH.NET
Armotech WG47 & WG47s User Manual
Revision 1 printed 8/4/2005
Mail: [email protected]
3
•Follow the rules of safe marker handling: keep finger off the trigger until ready to shoot. Keep muzzle
pointed in a safe direction. In addition, firmly insert a barrel plug into the muzzle and push the
mechanical or electronic safety to “ON” or “SAFE” when the marker is not in use and when in any
non-shooting area
•Never shoot at domestic animals or wildlife
•Never mark objects outside the confines of the game or authorized shooting areas
•Never look down the barrel of a marker
•Before disassembly, storage, or transport of this marker, remove ALL paintballs from the marker,
barrel, and loader: remove power source: and remove all gas or air from the power system. Insert a
barrel plug and put the safety “ON”
•Carry your marker in a case or sturdy bag when transporting it in public
•Safely and securely store marker to prevent access to it by unauthorized persons or minors.
WWW.ARMOTECH.NET
Armotech WG47 & WG47s User Manual
Revision 1 printed 8/4/2005
Mail: [email protected]
4
Welcome to Armotech. The Armotech line of scenario paintball markers are designed to extremely high quality standards
because we realize that only the best will do. Our markers all undergo extensive testing, prototyping and are constantly
improved based on customer feedback. Why? Simply because Armotech wants to bring you the Newest Innovations in
Scenario Paintball Markers.
Always exercise caution when handling a paintball marker.
Remember this is not a toy. Misuse of this product can cause physical harm.
Protective eyewear – made specifically for paintball should always be used when operating the marker.
Adult supervision should be exercised when minors are operating the marker.
Install the Fixed Stock
Removethestrippintoreleasethestockbase.
Tightenthefixedstockbyusingthe4screws
foundinsparepartskit.Donotovertightenthe
screws.
(WG47comeswiththestockdetached)
WWW.ARMOTECH.NET
Armotech WG47 & WG47s User Manual
Revision 1 printed 8/4/2005
Mail: [email protected]
5
Velocity Adjustment
Usewrenchtoadjustthevelocity:
Clockwise–raisethevelocity
CounterClockwise–reducethevelocity
NOTE: Do not cock and fire the marker prior to performing initial lubrication of internal bolt and
striker o-rings. Some dealers perform this task for you prior to delivery as an added service.
However, the marker is shipped w/o internals lubed.
WWW.ARMOTECH.NET
Armotech WG47 & WG47s User Manual
Revision 1 printed 8/4/2005
Mail: [email protected]
6
Cleaning inside
Toremovetheinternalsturntheplugcounter
clockwise.
Pulloutthebolt,hammer,andspring.
(Carefullyremovethestrikerspringguide,striker
springandthecircularspringbuffer.Youmay
havetousetheendofaflatscrewdriverorother
bluntobjecttoaidinremovingthecircularrubber
buffersectionoftheinternals.)
Once the internals are out – note their assembly orientation.Also note the lubrication points as
illustrated. These should all be properly lubricated using either 3-in-1 gun oil, paintball marker
lubricant, Teflon grease, or Silicon grease – whichever is most readily available to you.
Bottle o-rings fit perfect on both bolt and striker.
Do not be afraid to lubricate these parts.
Do not use excessive lube or thick lube – this may create a resistance effect and inhibit marker
recocking.
Sometimes o-rings may look good to the naked eye, but can be damaged.
If the ureathane orings on the bolt are discolored – change them.
WWW.ARMOTECH.NET
Armotech WG47 & WG47s User Manual
Revision 1 printed 8/4/2005
Mail: [email protected]
7
Release the barrel
Removethemuzzlefirst.
Pullofftheparts.
Turnthebarrelcounterclockwisetoremove.The
barrelandforegripremoveasonepiece.
ThebarrelandforegripmoveTOGETHER,DO
NOTremovethegripfrombarrel.
WWW.ARMOTECH.NET
Armotech WG47 & WG47s User Manual
Revision 1 printed 8/4/2005
Mail: [email protected]
8
Cocking
PushtheSafeswitchtofiringposition.
Firingposition.
(Guncanbecockedonlyatthisposition)
PullCOCKINGHANDLEbackwardtocockthe
gun.
WWW.ARMOTECH.NET
Armotech WG47 & WG47s User Manual
Revision 1 printed 8/4/2005
Mail: [email protected]
9
The power system used on the Armotech WG47 Marker contains compressed gas or air. NEVER
work on, disassemble the marker with the compressed air source connected. The marker has a
volumizer chamber which will retain air pressure. Please ensure your air source is properly
turned off, and the marker is cleared of all compression before disassembly. If working with CO2
avoid CO2 gas or escaping liquid to contact the skin – it can cause freezer burn. Always ensure
your power source bottle is firmly screwed in to avoid accidental release which could cause
bodily harm.
Thestandardoptionforplayerswhopreferto
playwithoutaremoteistoattachthebottom
lineadapterontothemarker‐Itcomescomplete
withthenecessaryadaptertosnapontothe
quickreleasenipple,andthescrewstofastenit
tothebottomofthetriggerframe.
Withthisoptioninstalledasstandard
configuration,youcanscrewthecompressed
gas/airpowersourcedirectlyontothe
marker…orusearemotelinewithscrewinASA
nipple
TheWG47iscapableofoperatingatinput
pressuresrangingfrom350psito1200psi.
Itisnotrecommendedtooperatethe
markerbeloworbeyondtheselimitsas
thiswillseverelyhampertheperformance
andcoulddamagethemarker.
WWW.ARMOTECH.NET
Armotech WG47 & WG47s User Manual
Revision 1 printed 8/4/2005
Mail: [email protected]
10
Neverleaveapressurized
markerorairsourceindirect
sunlight–inparticularif
usingCO2asanairsource.
Excessiveheatcancause
internalpressurestobuild
beyondsafelevelsandcould
causesafetyburstdisksto
ruptureifthebottleissitting
erect.
Ifthebottleislyingonits
side–theexcessivepressure
couldcauseaburstwhich
coulddamagethemarker,or
theairbottlesvalvesystem.
Cylindervalve(thecopper
neckontheairbottle)
shouldbefirmly,andfully
connectedtotheairbottle.
Makeamarkonyour
bottleandinspectthis
regularlytoseeifithas
moved.
Aloosecylindervalve
underpressurecanbe
extremelydangerous–the
airbottlewouldbecomea
highspeedprojectile
whichcouldcauseserious
damageordeath.
During filling, if any leaks are detected, immediately stop the filling process and examine
the power source for the location of the leak. If it is leaking from the fill adapter’s ASA it
could be that the o-ring on the bottle is worn and needs replacement –bleed off ALL
excess pressure, remove bottle, change o-ring and resume filling.
If the leak is coming from the connection between the Cylinder valve and the bottle
body – cease filling, use a hard tool such as a screwdriver or other item to depress the
pin valve and release ALL pressure from the bottle . If you have an on/off valve open it to
release the pressure. Have the bottle inspected by a US – DOT certified air-smith or
compressed air specialist to get it repaired. DO NOT ATTEMPT TO REPAIR THE BOTTLE
YOURSELF!
WWW.ARMOTECH.NET
Armotech WG47 & WG47s User Manual
Revision 1 printed 8/4/2005
Mail: [email protected]
11
Afteryouhaveconnectedtheremotelinetothe
ASACylindervalveheadofyourpowersource.
DONOTACTIVATETHEAIRSOURCE.
Firstconnectthequickreleaseportionofthe
remotelinetothenippleonthemarker.Ensure
thatitsnap‐locksintoplace.Onlyafteryou
havedonethisshouldyouconsideractivating
theairsourcewewillgettothatinjustabit,for
now,letsjustmakecertaintheairsourceis
properlysetupandconnectedtotheWG47.
Ifyouaredepressuringthemarker–
firstturnofftheremotelineairsourceat
thebottle–thenfirethemarkerafew
timestodepleteanyexcesscompressed
gas/airbeforeremovingthequickrelease.
Usingthebottomlinesetupisjustassimple
Yourairsourcecanscrewdirectlyintothe
optionalbottomlineattachmentonceproperly
affixedtothemarker.
Lineupyourairsourceandwithaclockwise
motion,screwthebottleontotheASAuntilyou
NOTE–ifyourairsourcedoesnothave
anon/offvalve,pleaseremembertohold
markerupsidedown,whileslowly
unscrewingthebottle,andfiringthe
markeratthesametimetorelease
pressurebuildup.Atacertainpointthe
pin‐valvewilldisengageallowingyouto
WWW.ARMOTECH.NET
Armotech WG47 & WG47s User Manual
Revision 1 printed 8/4/2005
Mail: [email protected]
12
getatightfitandthebottleSTOPS.
Forbottleswithanon/offvalve–ensureitis
OFFwhendoingthis.Ifthebottleispin‐valve
driven,remembertoCOCKthemarkerfirst.
Screwingonapin‐valvedrivenbottlewill
immediatelyengagethecompressedgas/airand
readythemarker.
totallyde‐pressurethemarkerand
makingremovalofthebottlebotheasier
andSAFE!
Holdingthemarkerupsidedown,ensures
thatnopaintballscanenterthebreach
accidentally(inparticularifusinga
gravityhopper)
Onceyourairsourceisproperlyinstalled,ifyouhaven’talreadydoneso,COCKTHE
MARKERbypullingbackonthetoprearcockinghandleasillustrated.Atthispointyou
mayactivatetheairsource(unlessitisadirectlyscrewedonpin‐valvedrivenbottleonthe
bottomlineASA).
YOURMARKERISNOWCOCKEDANDREADYFORFIRING.Pleaseobserveallnecessary
safetyprecautionswhenfiringthemarker.
To fire the marker – depress the trigger safety to the DOWN. The safety is now OFF. This
puts the trigger in active mode and makes the marker ready-to-fire.
DRY FIRE the marker a few times to get used to the feel of the trigger, and the marker
under pressure. Practice firing the marker with air on –observe the reaction of the
marker. Turn your air source OFF (either by the on/off valve of the remote, bottle, or by
slightly unscrewing the bottle from the ASA bottomline, and fire the marker a few times
to familiarize yourself with the entire process of running out of power on the marker –
see how it reacts. Practice proper removal of the air source a few times.
WWW.ARMOTECH.NET
Armotech WG47 & WG47s User Manual
Revision 1 printed 8/4/2005
Mail: [email protected]
13
Warranty Information
LIMITED 1 YEAR WARRANTY
This product is warranted to the retail consumer for one year from date of retail purchase against defects in material and
workmanship and is transferable. To register the serial number of your paintball marker, please return the Product
Registration form found in your owner’s manual packet. The warranty is not conditioned on the return of the card.
WHAT IS COVERED
Replacement parts and labor. Transportation charges to consumer for repaired product.
WHAT IS NOT COVERED
Transportation charges to ARMOTECH for defective product. Damages caused by abuse or failure to perform normal
maintenance. (See Step 9) Any other expense. CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, OR
INCIDENTAL EXPENSES, INCLUDING DAMAGE TO PROPERTY. SOME STATES DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR
EXCLUSION MAY NOT APPLY TO YOU.
WARRANTY CLAIMS
USA customers: Attach your name, address, description of problem, phone number and copy of sales receipt to product.
Package and return to Armotech. International Customers: Please return product to your nearest distributor. If you do not
know your distributor, please call 1-856-753-2662 and ask for our International Department for assistance.
IMPLIED WARRANTIES
ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY ANDFITNESS FOR
A PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO ONE YEAR FROM DATE OF RETAIL PURCHASE.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE
LIMITATIONS MAY NOT APPLY TO YOU. To the extent any provision of this warranty is prohibited by federal, state, or
municipal law which cannot be preempted, it shall not be applicable. This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state and country to country.
WWW.ARMOTECH.NET
Armotech WG47 & WG47s User Manual
Revision 1 printed 8/4/2005
Mail: [email protected]
14
SUGGESTED UPGRADE KITS
16” Hop-UP Barrel
Sight Rail
Sight Mount
Barrel Extension
WS Red Dot
WS Scope
WS RD Scope
Warsensor Laser Kits
This manual suits for next models
1
Table of contents
