PLANET ECLIPSE GTEK M170R User manual

01
GTEK M170R
PLANET ECLIPSE: GTEK M170R
USER MANUAL / ENGLISH

02 03
GTEK M170R GTEK M170R
!
Persons under 18 years of age must have adult supervision when
using or handling the M170R.
!
Only use professional paintball elds where codes of safety are
strictly enforced.
!
Only use compressed air/nitrogen. Do not use any other
compressed gas or pressurised liquid including CO2.
!
Always follow instructions, warnings and guidelines given with any
rst stage regulator you use with the M170R.
!
Use 0.68 inch calibre paintballs only.
!
Always measure your marker’s velocity before playing paintball,
using a suitable chronograph.
!
Never shoot at velocities in excess of 300 feet (91.44 metres) per
second, or at velocities greater than local or national laws allow.
!
Any installations, modications or repairs should be carried out by
a qualied individual at a licensed and insured paintball facility.
This Users Manual is in English.
It contains important safety guidelines and
instructions. Should you be unsure at any
stage, or unable to understand the contents
of this manual you must seek expert advice.
Le mode d’emploi est en Anglais.
Il contient des instructions et mesures de
sécurité importantes. En cas de doute, ou
s’il vous est impossible de comprendre le
contenu du monde d’emploi, demandez
conseil à un expert.
Este manual de usuarios (operarios)
Usarios está en Inglés.Contiene importantes
normas de seguridad e instrucciones. Si no
está seguro de algùn punto o no entiende los
contenidos de este manual debe consultar
con un experto.
Diese Bedienungs - und
Benutzeranleitung ist in Englisch.
Sie enthålt wichtige Sicherheitsrichtlinen und -
bestimmungen. Solten Sie sich in irgendeiner
Weise unsicher sein, oder den Inhalte dies
Heftes nicht verstehen, lassen Sie sich bitte
von einen Experten beraten.
!
THE PLANET ECLIPSE M170R IS NOT A TOY. PAINTBALL
SAFETY RULES MUST BE FOLLOWED AT ALL TIMES.
!
Careless or improper use of the M170R, including failure to follow
instructions and warnings within this User Manual could cause
serious injury or death.
!
Do not remove or deface any warnings attached to the M170R.
!
Paintball industry standard eye/face/ear and head protection
designed specically to stop paintballs and meeting ASTM standard
F1776 (USA) or CE standard (Europe) must be worn by the user and
any person within range. Proper protection must be worn during
assembly, cleaning and maintenance.
!
Hearing protection should be worn.
!
Never shoot at a person who is not wearing proper protection.
!
Never look directly into the barrel of the marker. Accidental discharge
into the eyes may cause permanent injury or death.
Never look into the barrel or breech area of the M170R whilst the
marker is switched on and able to re.
!
The push button safety is the marker’s disabling device, also known
as the ‘safety’. Always switch o the M170R when not
in use and only switch on when ready to shoot.
!
Treat every marker as if it is loaded and ready to re.
!
Always t a barrel blocking device to the M170R when not
in use.
!
Always remove paintballs from the M170R when not in use.
!
Do not eld strip or remove any parts while the marker is pressurised.
!
Do not pressurise the M170R without all the components of the
marker correctly installed, as high-pressure gas may be emitted.
!
Do not re the M170R without the bolt correctly installed.
!
Never put your nger or any foreign objects into the paintball feed
tube of the M170R.
!
Never allow pressurised gas to come into contact with any part of
your body.
!
Always remove the rst stage regulator and relieve all residual gas
pressure from the M170R before disassembly.
!
Always remove the rst stage regulator and relieve all residual gas
pressure from the M170R for transport and storage.
!
Always follow the guidelines given with your rst stage regulator for
safe transportation and storage.
!
Always store the M170R in a secure place.
!
Observe all local and national laws, regulations and guidelines.
WARNINGS
READ CAREFULLY BEFORE USE WARNINGS READ CAREFULLY BEFORE USE
WARNING!
This user manual must accompany the product in the event of resale or new
ownership. Should you be unsure at any stage you must seek expert advice.
WARNING
0302

04 05
GTEK M170R GTEK M170R
CONTENTS
GET READY
QUICK START (06 -14)
06 Setting up the M170R
08 Push button safety
10 Velocity adjustment
11 Trigger adjustment
12 Unloading the M170R
14 Storage and transportation
MAINTENANCE
15 Online maintenance videos
FAULT FINDING (16 -17)
16 Fault nding tables
TECHNICAL INFORMATION (18 - 27)
18 Parts list
20 Removing grips
21 Detent cover access
22 SL6 inline regulator
23 M170R bolt assembly
24 Three-way assembly
25 Push On Purge System (POPS) assembly
26 Trigger assembly
27 Low-rise feed assembly
SUPPORT (28-35)
28 Index
29 Our promise
30 Notes
31 Warranty card
33 Notes
FOLLOW OUR OFFICIAL PLANET ECLIPSE
SOCIAL MEDIA CHANNELS TO KEEP UP TO DATE
WITH OUR TECH SUPPORT EVENTS CALENDAR.
WE GOT
YOUR
BACK!!!
OUR ARMY OF PLANET ECLIPSE PRO
TECHS ATTEND PAINTBALL EVENTS ALL
OVER THE WORLD TO MAKE SURE THAT
YOU AND YOUR ECLIPSE MARKER ARE
FIRING ON ALL CYLINDERS, AT ALL TIMES,
IN ALL GAME SCENARIOS.

FIG-1
F
C B
E
D
H
I
A
J
G
K1
2 2
5
34
06 07
GTEK M170R GTEK M170R
QUICK START
SETTING UP THE M170R
FIG-1
A
PUSH SAFE before you begin.
This ensures the marker will not re when the trigger is pulled.
B
Screw both ends of the barrel together.
Screw the barrel tip counter-clockwise onto the barrel back.
C
Screw the complete barrel into the marker.
The barrel back screws clockwise into the marker body.
D
Fit a barrel blocking device for safety.
E
Ensure the marker is de-gassed.
Push in and hold the POPS button and pull the POPS bonnet away
from the POPS body.
F
Attach the pre-set air system.
Rotate the air system clockwise into the POPS body.
G
Loosen the clamping feedneck.
Open the feedneck lever away from the feedneck.
Rotate the feedneck lever screw counter-clockwise.
H
Attach the loader.
If the feedneck is too tight, loosen the clamping feedneck more.
I
Secure the loader.
Rotate the feedneck lever screw clockwise to tighten.
Close the feedneck lever to secure.
J
Gas the marker.
Push the POPS bonnet into the POPS body until it engages.
K
PUSH FIRE when you are ready to play.
The marker will now re when the trigger is pulled.
1
IMPORTANT! To operate the Safety Button see pages 8-9.
2
DO NOT over-tighten the barrel.
3
ALWAYS ensure the marker is de-gassed when setting up.
4
NEVER use CO2. Compressed air or Nitrogen only.
5
DO NOT over-tighten the feedneck. This may damage the marker.
QUICK START
SETTING UP THE M170R
WARNING!
Always ensure that the marker is o with a barrel blocking device installed and
that no paintballs are in the M170R or loader before installing an air system.
Compressed air and nitrogen systems can be extremely dangerous if handled
or used incorrectly.
Only attach an air system certied for use within the country of use.
Never add lubricants or grease into the ll adaptor of the air system regulator.
Ensure that all screws are tightened and no parts are loose before installing an
air system.
Do not pressurise the M170R without the bolt system correctly installed, as high
pressure gas will be emitted.
Do not install a compressed air system or load paintballs into the M170R until
you feel condent with your ability to handle the marker safely and responsibly.
WARNING

FIG-2 FIG-2
FIG-1 FIG-1
1
1
1
1
A
A
A
A
08 09
GTEK M170R GTEK M170R
FIG-1
The safety button
A
is located on the frame and is used to switch
between safe (PUSH SAFE) and re (PUSH FIRE). When the marker is
NOT safe the button will protrude from the left side of the frame.
FIG-2 - PUSH SAFE
Push the safety button
A
in from the left side of the frame to make
the M170R safe. The M170R trigger will be locked and the marker will
not re.
Firing the M170R
When the safety button is set to PUSH SAFE the M170R will not re.
1
IMPORTANT! If the safety button does not work, do not use the
marker. Either the button requires maintenance or the trigger has
been adjusted outside of its operating window and is blocking
the safety.
If you are not comfortable in performing either of these
operations then contact your nearest Eclipse Service Centre.
QUICK START
PUSH BUTTON SAFETY
PUSH SAFE
WARNING!
When the PUSH SAFE is enabled the M170R is still a live marker until the air
system has been fully removed.
Ensure that a barrel blocking device is attached when the marker is set to safe.
WARNING
FIG-1
The safety button
A
is located on the frame and is used to switch
between safe (PUSH SAFE) and re (PUSH FIRE). When the marker is
NOT set to re, the button will protrude from the right side of the frame.
FIG-2 - PUSH FIRE
Push the safety button
A
in from the right side of the frame. The
M170R will be live and ready to re.
Firing the M170R
When set to PUSH FIRE the M170R will re when the trigger is pulled.
1
IMPORTANT! If the safety button does not work, do not use the
marker. Either the button requires maintenance or the trigger has
been adjusted outside of its operating window and is blocking the
safety.
If you are not comfortable in performing either of these operations
then contact your nearest Eclipse Service Centre.
QUICK START
PUSH BUTTON SAFETY
PUSH FIRE
WARNING!
When PUSH FIRE is enabled the M170R is live and will re with every pull of the
trigger, if an air system is tted.
Ensure that the M170R is set to PUSH SAFE and a barrel blocking device is
attached until you are ready to use the marker.
WARNING

FIG-1
B
A
1
1/8
-+
FIG-1
A
B
C
1/16
5/64
1/16
+ -
-+
10 11
GTEK M170R GTEK M170R
QUICK START
VELOCITY ADJUSTMENT
FIG-1
Insert a 1/8 hex key
A
into the velocity adjuster screw
B
to alter the
velocity of the M170R.
1
Turn the hex key clockwise to reduce velocity.
2
Turn the hex key counter-clockwise to increase velocity.
3
Fire two clearing shots after each velocity adjustment for an
accurate velocity reading.
1
DO NOT turn the adjuster screw in too far. This will prevent the
M170R from ring.
WARNING!
DO NOT exceed 300FPS.
Always wear correct protective equipment when ring your marker.
NEVER point your marker in the direction of other people when not on the eld.
WARNING
QUICK START
TRIGGER ADJUSTMENT
FIG-1
The trigger spring screw
A
adjusts the spring strength of the trigger
return. Clockwise increases strength, counter-clockwise reduces it.
The activation point screw
B
sets the three-way actuation point.
Clockwise advances the actuation point in the trigger pull, counter-
clockwise delays the activation point in the trigger pull.
The post-travel screw
C
adjusts the distance the trigger travels once
the trigger has been actuated. Clockwise reduces the amount of
travel, counter-clockwise increases the amount of travel.
WARNING!
Always make sure the marker is OFF and de-gassed with a barrel blocking device installed and no paintballs are in the marker or loader before adjusting the trigger.
The M170R trigger has a large range of adjustability and must be adjusted with care. Adjustment of the trigger screws to the extremes of their range and incorrect adjustment may
prevent the safety switch from functioning correctly.
If the safety switch cannot be engaged or disengaged, adjust the pre-travel screw to allow more pre-travel in the trigger until the safety switch operates freely.
If the marker can be red while the switch is set to safe, the activation-point screw needs adjusting. Turn the screw counter-clockwise to delay the activation point in the trigger pull
until the marker does not re with set to safe.
WARNING

FIG-1
12 13
GTEK M170R GTEK M170R
QUICK START
UNLOADING THE M170R
FIG-1
A
Ensure that a barrel blocking device is tted for safety.
B
PUSH SAFE before you begin.
This ensures the marker will not re when the trigger is pulled.
C
De-gas the marker.
Push in and hold the POPS button and pull the POPS bonnet
away from the POPS body.
D
Remove the pre-set air system.
Rotate the air system counter-clockwise from the POPS body.
E
Loosen the clamping feedneck.
Open the feedneck lever away from the feedneck.
Rotate the feedneck lever screw counter-clockwise.
F
Remove the loader.
If the feedneck is too tight, loosen the clamping feedneck more.
G
Remove the barrel from the marker body.
Rotate the barrel counter-clockwise to remove.
H
Remove the barrel tip from barrel back.
Rotate the barrel tip clockwise to remove.
1
IMPORTANT! Extra precaution to avoid injury.
2
IMPORTANT! To operate Safety Button see pages 8-9.
3
IMPORTANT! Always de-gas before unloading.
4
IMPORTANT! Always remove air system before unloading.
5
IMPORTANT! Always remove any paintballs from the breech of the
marker once the loader has been removed.
6
IMPORTANT! Rotate the barrel tip CLOCKWISE to remove.
QUICK START
UNLOADING THE M170R
WARNING!
Always make sure the marker is o with a barrel blocking device installed and
that no paintballs are in the M170R or loader before unloading.
Compressed air and nitrogen systems can be extremely dangerous if handled
or used incorrectly.
NEVER leave the M170R gassed up when unloading.
NEVER point your marker in the direction of other people when not on the eld.
Remove any paintballs from the breech before storing your M170R.
WARNING
D
G H
C
A
F
E
1
6
5
34
B2

14 15
GTEK M170R GTEK M170R
QUICK START
STORAGE AND TRANSPORTATION
1
Your M170R must be clear of all paint and propellant during
transportation or storage.
2
Make sure the M170R marker is set to safe.
3
Remove the barrel from the marker.
4
Make sure the marker is clean of any paint residue, dirt
and moisture.
5
Store your M170R in a clean, cool, dry place.
6
Keep your M170R away from any unauthorized and
unsafe users.
7
Protect your M170R from excessive heat during transportation.
8
When transporting a paintball marker by air, check with the airline
regarding their policies on transporting paintball equipment as hold
luggage before arriving at the airport.
9
Observe and obey all local and national laws concerning the
transportation of paintball markers.
10
Use the box in which the marker was originally supplied to protect
the marker against rough handling during transport.
WARNING!
Never carry your M170R un-cased when not on a playing eld. The non-playing public and law enforcement personnel may not be able to distinguish between a paintball
marker and a real rearm. For your own safety and to protect the image of paintball, always carry the M170R (or any other paintball marker) in a suitable marker case
such as the one in which it was supplied.
WARNING
MAINTENANCE
ONLINE MAINTENANCE VIDEOS
To help demonstrate how to maintain and service essential parts
of the M170R we’ve created a collection of dedicated marker
maintenance videos to guide the user through each step.
From basic, to more advanced parts of the M170R, we got
your back!
Head over to our ocial Planet Eclipse YouTube channel and check
out our Eclipse Tech Hub playlist for more.
youtube.com/planeteclipse

16 17
GTEK M170R GTEK M170R
FAULT FINDING
FAULT FINDING TABLES
SYMPTOM POSSIBLE CAUSE SOLUTION
The M170R leaks from the three-way
and/or manifold.
The two o-rings under the solenoid body or the gasket
under the solenoid plate are damaged or dirty.
Ensure the gasket is seated correctly.
Replace the gasket if damaged using M170R parts kit.
Check condition of the 5x1 NBR70 and 3x1 NBR70 o-rings
under the solenoid body.
Solenoid valve and/or manifold are over-pressurised.
Check the output pressure of the inline regulator,
adjust accordingly. Clean and inspect the inline regulator
assembly especially the piston o-ring, piston tip and regulator
seal. Replace damaged components as necessary.
Damaged or incorrect seals on the solenoid spool. Replace and/or lubricate solenoid spool seals.
Damaged M170R SMC solenoid pilot valve. Replace M170R SMC pilot solenoid valve.
The M170R leaks down the barrel.
Dirty or damaged can o-rings. Clean and lubricate or replace 020 NBR70 and
017 NBR o-rings on the front of the can.
Dirty or damaged o-rings on the spool. Clean and lubricate or replace the 011 NBR70 and
012 NBR70 o-rings on the main spool.
Dirty or damaged bolt o-rings. Clean and lubricate or replace 14x2 NBR70 o-ring
on the back of the bolt.
Dirty or damaged rear bolt guide o-ring. Clean and lubricate or replace 014 NBR70 o-ring
on the back of the bolt guide.
The marker is breaking paintballs
in the barrel or breech.
The ball detents are damaged or missing. Replace the ball detents.
The force setting of the loader is too high. Reduce the loader force feed setting.
The paint is poor quality. Try a higher grade of paint.
The velocity is set too high. Check and adjust the velocity of the M170R.
The paint is too big for the barrel bore size. Invest in a range of barrels with different bore sizes.
FAULT FINDING
FAULT FINDING TABLES
SYMPTOM POSSIBLE CAUSE SOLUTION
The M170R does not re.
The POPS is not fully engaged. Push the POPS bonnet in until it engages.
The trigger is set-up incorrectly. Adjust trigger correctly.
The push-button safety is set to PUSH SAFE. Enable PUSH FIRE mode to disable the safety.
The three-way valve is damaged. Replace three-way valve.
Low constant velocity. The inline regulator output pressure is set too low. Increase the output pressure of the inline regulator.
High velocity rst shot. The inline regulator pressure is creeping. Strip and clean the inline regulator replacing the piston seal.
Velocity drop-off during rapid re.
Air system regulator does not have high enough ow. Try another air system.
Dirty/partially blocked inline regulator. Strip, clean, lubricate and rebuild the inline regulator.
The trigger is very “bouncy”. The trigger pull is too short and the
return strength is too low. See page 13 for trigger adjustment guidelines.
Two or more balls are being
fed into the breech.
Worn, damaged or missing ball detents. Change the rubber ball detent.
The feed force is too high from loader. Adjust loader settings/use a lower force loader.
M170R is inconsistent.
The inline regulator is supercharging. Strip and clean inline regulator, replace regulator seal.
Poor quality paintballs. Use better quality paintballs.
Poor paintball size to barrel bore match. Use a closer paintball to barrel bore size.
Inconsistent air supply from air system. Use a good quality air system.
M170R is inefcient. Poor paintball size to barrel bore match. Use a closer paintball to barrel bore size.
The safety button does not function.
The trigger is setup incorrectly. Adjust the trigger correctly.
The safety button is blocked or damaged. Clean and inspect the safety button assembly.
If an issue with the M170R cannot be solved using the fault nding guide,
contact your nearest Eclipse Service Centre for assistance.

FIG-1
768
45
2
14
9
10
1
13
12
11
3
18 19
GTEK M170R GTEK M170R
TECHNICAL
PARTS LIST TECHNICAL PARTS LIST
FIG-1
1
Clamping feed tube assembly
2
Marker body
3
Quick-release bonnet
4
Bolt assembly
5
Rubber detent
6
Three-way assembly
7
Rear frame screw
8
Front frame screw
9
Frame assembly
10
Trigger assembly
11
SL6 inline regulator assembly
12
Foregrip
13
POPS assembly
14
Push button safety

FIG-1
FIG-2
B
B
1
1
1
1
B
A
A
5/64
5/64
+
+
+
+
-
-
-
-B
FIG-1
B
D
C
A
20 21
GTEK M170R GTEK M170R
TECHNICAL
REMOVING GRIPS
FIG-1
Use a 5/64” (2mm) hex key
A
to remove the grip screws on the left hand
side of the grip
B
.
FIG-2
Use a 5/64” (2mm) hex key
A
to remove the grip screws on the right
hand side of the grip
B
.
Simply reverse the process to replace the rubber grips and screws.
1
DO NOT over-tighten the screws.
WARNING!
Always make sure the marker is o with a barrel blocking device installed and
that no paintballs are in the M170R or loader.
Compressed air and nitrogen systems can be extremely dangerous if handled
or used incorrectly.
WARNING
TECHNICAL
DETENT COVER ASSEMBLY
FIG-1
A
Detent cover
B
Rubber detent
C
Detent cover latch
D
Detent seat
The elements within this diagram apply to
both sides of the marker.

FIG-1 FIG-1
Adjuster bottom
Purge poppet spring
Purge poppet 3
Regulator seal
Adjuster top
Internal o-ring
#008 NBR70
Regulator spring 2
Regulator piston
Piston o-ring
14 x 2 NBR70
1 Reset the SL6 regulator to factory after re-assembly.
2 Only use the M170R SL6 spring with the SL6 inline regulator.
3 Failure to re-install the purge poppet assembly correctly could
seriously damage the M170R.
Adjuster o-ring
#011 NBR70
O-ring
#015 NBR70
Reg body
Quick-release bonnet #010 NBR70 #012 NBR70
Bolt guide
#014 NBR70 #015 NBR90
14 x 2 NBR70
#016 NBR70 #012 NBR70
#011 NBR70
Switch
#016 NBR70
#020 NBR70
#020 NBR70
#020 NBR70
Valve chamber
Bolt pin Plunger
Bolt
#013 NBR70
Can
#020 NBR70
Internal:
#017 NBR70
Spring guide
Spool spring
Spool
#008 NBR70
14 x 2 NBR70
#013 NBR70
#013 NBR70
#013 NBR70
22 23
GTEK M170R GTEK M170R
TECHNICAL
SL6 INLINE REGULATOR
1TECHNICAL
M170R BOLT ASSEMBLY

FIG-1 FIG-1
POPS bonnet
#004 NBR70
Latch spring
POPS button
#004 NBR70
Push rod
#007 NBR70
#005 NBR90
internal o-ring
POPS pin
POPS insert
POPS body
Three-way valve body
Three-way valve gasket
Transfer block
Three-way valve gasket
Three-way valve gasket
Three-way valve cap
Three-way valve spool
Three-way pin
#6 Seal (custom)
#6 Seal (custom)
4 x 1 NBR70
24 25
GTEK M170R GTEK M170R
TECHNICAL
THREE-WAY ASSEMBLY TECHNICAL PUSH ON PURGE SYSTEM (POPS) ASSEMBLY

Clamping feed nut o-ring
#006 NBR70
Clamping feed nut Feed lever
Feed swivel
Feed swivel o-ring
#004 NBR70
Short clamping feed screw
10-32 UNF x 1/2”
Feed tube
Machined
clamping
feed screw
Feed
insert
FIG-1
Trigger
Safety switch spring
Safety switch plunger
Threaded trigger pin
Push button safety
Bearing retainer screw
6-32 UNC x 1/8
socket set screw
Post-travel screw
6-32 UNC x 3/16
socket set screw
Activation point adjuster screw
custom socket set screw
Trigger spring screw
6-32 UNC x 3/16
socket set screw
Trigger return spring
Bearing carrier
Push pin bearing
Trigger spring holder screw
6-32 UNC x 3/16
socket set screw
Push pin
Bearing carrier screws
M2.5 x 5 cap head socket screws
Safety switch
housing screws
M2.5 x 5 cap head
socket screws
Safety switch housing
26 27
GTEK M170R GTEK M170R
TECHNICAL
TRIGGER ASSEMBLY TECHNICAL LOW-RISE FEED ASSEMBLY

28 29
GTEK M170R GTEK M170R
SUPPORT
OUR PROMISE
A
Activation point screw: 11
Adjuster bottom: 22
Astm standard: 02
B
Barrel: 02,07,08,09,11,13,14,16,17,20
Barrel blocking device: 02,07,08,09,11,13,20
Bearing carrier screws: 26
Bearing retainer screw: 26
Bolt: 19,23
Bolt pin: 23
C
Can: 23
Clamping feedneck: 07,13
Clamping feed tube: 19
D
Detent: 17,19,21
E
Eclipse service centre: 08,09,17
Eclipse Tech Hub: 15
F
Fault: 04,16,17
Feed lever: 27
Foregrip: 19
Frame: 19
Frame screw: 19
G
Grips: 04,20
Grip screws: 20
L
Loader: 07,11,13,16,17,20
P
Plunger: 23
POPS: 04,07,13,17,19,25
Post-travel screw: 11
Push button: 04,19,26
Push re: 07,08,09,17
Push pin: 26
Push safe: 07,08,09,13,17
Q
Quick-release bonnet: 19,23
R
Reg body: 22
Regulator: 02,03,04,07,16,17,19,22
Regulator piston: 22
Regulator spring: 22
S
Safety button: 07,08,09,13,17
Safety switch spring: 26
Spool: 23
Spring adjustment screw: 26
Spring guide: 23
Support: 05,29,32
T
Three-way: 04,19,24
Three-way valve body: 24
Three-way valve gasket: 24
Three-way valve spool: 24
Transportation: 02,04,14
Trigger: 07,08,09,11,13,17,26
Trigger return spring: 26
Trigger spring holder screw: 26
Trigger spring screw: 11
V
Velocity: 03,10,16,17
W
Warnings: 02,03,31
Warranty: 29,31,32
SUPPORT
INDEX
SUPPORT
As an Eclipse customer you will have access to
our worldwide technical support network that
will help you with any technical problems from
localised service centres to on-site* tech support.
WARRANTY
Our exceptional 12 month* manufacturers
warranty backed by our online warranty system
oers peace of mind and ensures your claim will
be repaired or replaced in a snap!
QUALITY
All Eclipse products undergo meticulous checks
by experienced specialists who care about the
product that arrives at your door. Stringent quality
control and the use of precision materials equals a
quality product.
STANDARD
Your Eclipse marker is awesome and requires no
aftermarket parts, however, for genuine Eclipse
accessories that complement your playing
preference or individual style consult your local
Eclipse Dealer for upgrade options.
* Conditions apply, see online policies for full details
at planeteclipse.com
For more information about our Planet Eclipse Approved Tech Centres, visit our
servicing page online:
PLANETECLIPSE.COM/SITE/SERVICE-CENTRES

30 31
GTEK M170R GTEK M170R
SUPPORT
NOTES
SUPPORT
NOTES
Full name: Price (e.g. $500.00):
Address: Colour:
Where did you hear about your Eclipse marker?
Magazines Internet Friends
Other (please specify):
City: Why buy Eclipse?
Postal/Zip Code:
WRITE SERIAL NUMBER HERE
Warranty card MUST be completed in full to be valid and bear the Eclipse marker serial number.
State:
Country:
Contact No:
Email:
Date of purchase (DD/MM/YY):
Purchased from:
YOUR WARRANTY REGISTRATION CARD.
Planet Eclipse offers a 12 month limited warranty period* on the Eclipse®paintball marker. The Eclipse®paintball marker is
warranted to be free from all manufacturing and production defects for a period of 12 months from the time of original purchase**.
Warranty cover is dependent on successful completion, and receipt by Planet Eclipse Limited, of warranty registration and proof
of purchase, either in electronic form at www.planeteclipse.com or vial mail using the warranty card included in every Eclipse®
paintball marker manual. Warranty exemptions include, but are not limited to, accidental damage, wear and tear, unreasonable
force, surface nish and perishable components such as o-rings, valves, screws, solenoids and break beam sensor units (at our
discretion). By completing and returning this warranty card you agree to our privacy policy***.
I verify that I am least 18 years of age and I have read
the manual supplied with my Eclipse®paintball marker
and I understand the safety cautions and warnings that
it contains. Contact your dealer or Planet Eclipse Limited
directly if you need a replacement set of instructions.
Please complete and return this form with proof of purchase, within 14 days so that
we may validate your 12 month limited warranty on your Eclipse®manufactured product.
Please return to the address on the reverse of this form.
* For full terms and conditions that apply to the limited warranty visit www.planeteclipse.com
** Limited warranty is valid for 12 months from the proof of purchase date, or 12 months from
the date of manufacture if no proof of purchase is provided.
*** Full details of the Planet Eclipse privacy policy can be found at www.planeteclipse.com

32 33
GTEK M170R GTEK M170R
GET MORE - PLANETECLIPSE.COM
PLANET ECLIPSE
130 FRANKLIN STREET
BUILDING L4 & L5
WARREN
RHODE ISLAND
02885
U.S.A.
LICK.
STICK.
SEND.
TO BENEFIT FROM OUR INDUSTRY-LEADING
GLOBAL TECH SUPPORT PLEASE REGISTER
YOUR MARKER ONLINE TODAY
WARRANTY.PLANETECLIPSE.COM
SUPPORT
NOTES

34 35
GTEK M170R GTEK M170R
SUPPORT
NOTES
SUPPORT
NOTES

36
GTEK M170R
GET MORE
PLANETECLIPSE.COM
THIS PRODUCT IS COVERED BY AND/OR LICENSED UNDER ONE OR MORE OF
THE FOLLOWING PATENTS:
G.B. PATENTS:
2,342,710; 2,345,953; 2,352,022; 2,391,292; 2,391,063;
U.S. PATENTS:
7,836,873; 7,603,995; 7,073,284; 8,104,463; 7,509,953; 7,921,839; 7,089,697; 7,866,307; 8,082,912;
7,076,906; 7,607,424; 7,980,238; 8,960,175; 8,528,877; 8,201,547; 8,397,706; 8,210,160; 7,073,284;
6,311,682; 6,748,938; 6,860,259; 6,941,693; 6,973,748; 5,881,707; 5,967,133; 6,035,843; 6,474,326;
6,637,421; 6,644,295; 6,810,871; 6,901,923; 7,121,272; 7,100,593; 7,610,908; 7,603,997; 7,946,285;
6,349,711; 7,044,119; 7,185,646; 7,461,646; 7,556,032; 7,591,262; 7,617,819; 7,617,820; 7,640,925;
7,640,926; 7,866,308;
APPLICATION NUMBERS:
12/256,832; 12/613,958; 12/493,777; 11/654,721; 11/747,107; 12/503,504; 11/781,821; 60/832,548;
11/965,886; 10/280,115
Additional U.S. and International Patents may be pending.
USA
130 Franklin Street
Building L4 & L5
Warren, RI, 02885, USA
Call: [phone]
[email protected] 2387_EN_PE_GtekM170R-Manual-v1
UK
Unit 14 Premier Park, Acheson Way
Trafford Park Road, Trafford Park
Manchester, M17 1GA, England
Call: [phone]
[email protected]
© Planet Eclipse Ltd.
EUROPE
Pe-Paintball.De Gmbh
Langenberger Str. 9 Tor 5 & 6
Düsseldorf 40233, Germany
Call [phone]
planeteclipse.com/contact
