1. Product overview
TB-05 is a BLE5.0 low-power consumption Tmall Genie Mesh Bluetooth module based on
TLSR8250 chip. The Bluetooth module supports the direct control of Tmall Genie and has the
function of Bluetooth mesh networking. The devices communicate through peer-to-peer star
network and Bluetooth broadcast, which can ensure timely response in case of multiple devices.
It is mainly used in intelligent light control, which can meet the requirements of low power
consumption, low delay and short-range wireless data communication.
Figure 1 Main Chip Architecture Diagram

TB-05 Specification V1.0.0
Copyright©2022 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 5of 21
1.1. Characteristics
It can be directly controlled by the Tmall Genie without a gateway
1.1mm pitch SMD-20 package
6 PWM outputs
Onboard antenna, compatible with half-hole pad/through-hole pad
Brightness (duty cycle) adjustment range 5%-100%
Factory default cold color warm color duty cycle 50%
PWM output frequency 1KHz
With night light function
Color temperature switching function with wall switch

TB-05 Specification V1.0.0
Copyright©2022 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 6of 21
2. Main parameters
Table 1 Description of Main Parameters
Model
TB-05
Size
12.2*18.6*2.8(±0.2)MM
Package
SMD-20
Wireless standard
Bluetooth 5.0
Frequency
2400~2483.5MHz
Maximum Tx power
Maximum 10.5dBm
Receiving Sensitivity
-93dBm
Interface
GPIO/PWM/SPI/ADC
Operating temperature
-40 ℃ ~ 85 ℃
Storage environment
-40 ℃ ~ 125 ℃ , < 90%RH
Power supply
The power supply voltage is 2.7V ~ 3.6V, and the power
supply current is ≥ 50mA
Power consumption
Deep sleep pattern: 0.8 μA
Sleep mode: 1.8 μA
TX:21.56mA
Transmission distance
Outdoor open sight distance: ≥ 100 m
2.1. Static electricity requirements
TB-05 is an electrostatic sensitive equipment and requires special precautions during handling
Figure 2 ESD anti-static diagram

TB-05 Specification V1.0.0
Copyright©2022 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 7of 21
2.2. Electrical characteristics
Table 2 Table of Electrical Characteristics
Parameters
Condition
Min.
Typical value
Max.
Unit
Supply voltage
VDD
2.7
3.3
3.6
V
I/O supply voltage
VCCIO
-0.3
-
3.6
V
I /O
VIL
-
-
-
0.3*VDDIO
V
VIH
-
0.7*VDDIO
-
VDDIO
V
VOL
-
-
-
0.1*VDDIO
V
VOH
-
0.9*VDDIO
-
VDDIO
V
Operating
temperature
-40
-
+85
℃
Storage
temperature
-40
-
+125
℃

TB-05 Specification V1.0.0
Copyright©2022 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 8of 21
2.3. BLE RF performance
Table 3 BLE RF Performance Table
Description
Typical value
Unit
Spectrum range
2400~2483.5MHz
MHz
Output power
Rate mode
Min.
Typical value
Max.
Unit
1Mbps
7.1
8.5
10.5
dBm
Receiving sensitivity
Rate mode
Min.
Typical value
Max.
Unit
1Mbps sensitivity @ 30.8% PER
-
-93
-
dBm
2.4. Power consumption
The following power consumption data is based on a 3.3V power supply, ambient temperature
of 25°C, and measured using an internal voltage regulator.
All measurements are completed at the antenna interface with a filter.
All transmission data are measured in the continuous transmission mode based on the duty
cycle of the 100%.
Table 4 Power consumption table
Mode
Min.
Average
Max.
Unit
Tx power consumption (10.5dBm)
-
21.56
-
mA
Rx consumption
-
6.4
-
mA
Standby power consumption
-
3
-
mA
Superficial sleep
-
1.8
-
μA
Deep sleep
-
0.8
-
μA

TB-05 Specification V1.0.0
Copyright©2022 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 9of 21
3. Appearance dimensions
Figure 3 (for reference only)
Figure 4 dimension diagram (unit: mm)
Front
Back

TB-05 Specification V1.0.0
Copyright©2022 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 10 of 21
4. Pin definition
TB-05 module has a total of 20 interfaces. As shown in below pin diagram, the pin function
definition table is the interface definition.
Figure 5 Pin Top View
Front
Back

TB-05 Specification V1.0.0
Copyright©2022 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 11 of 21
Table 5 Pin Function Definition Table
No.
Name
Function
1
D2
SPI chip selection (active low)/PWM3 output/GPIO PD2
2
D3
PWM1 reverse output/GPIO PD3
3
D4
GPIO PD4/single-wire host/PWM2 reverse output
4
D7
GPIO PD7/SPI clock (I2C_SCK)
5
A1
GPIO PA1
6
SWS
Single-wire slave
7
TXD
PWM4 output/UART_TX/SAR ADC input/GPIO PB1
8
RXD
PWM0 reverse output/UART_RX/GPIO PA0
9
GND
Ground
10
3V3
3.3V power supply
11
B4
PWM4 output/SAR ADC input/GPIO PB4
12
B5
PWM5 output/SAR ADC input/GPIO PB5
13
B6
SPI data input (I2C_SDA)/UART_RTS/SAR ADC input/GPIO PB6
14
B7
SPI data output/UART_RX/SAR ADC input/GPIO PB7
15
C0
I2C serial data/PWM4 reverse output/UART_RTS / GPIO PC0
16
C1
I2C serial clock/PWM1 reverse output/pwm0 output/GPIO PC1
17
C4
PWM2 output/UART_CTS/PWM0 reverse output/SAR ADC input
/GPIO PC4
18
NC
NOT CONNECTED
19
RST
Reset pin
20
ANT
Antenna interface

TB-05 Specification V1.0.0
Copyright©2022 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 12 of 21
5. Schematic
Figure 6 Schematic diagram

TB-05 Specification V1.0.0
Copyright©2022 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 13 of 21
6. Antenna parameters
6.1. Schematic of Antenna Test Prototype
Figure 7 schematic diagram of antenna test prototype

TB-05 Specification V1.0.0
Copyright©2022 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 14 of 21
6.2. Antenna S parameter
Figure 8 Antenna S parameters
6.3. Antenna Gain and Efficiency
Table 6 Antenna Gain and Efficiency
Frequency ID
1
2
3
4
5
6
7
8
9
10
11
Frequency(MHz)
2400
2410
2420
2430
2440
2450
2460
2470
2480
2490
2500
Gain(dBi)
0.11
0.19
0.53
0.66
0.90
1.31
1.52
1.60
1.64
1.51
1.28
Efficiency(%)
27.64
28.55
31.13
32.06
33.47
36.26
36.85
37.13
36.93
36.74
35.69

TB-05 Specification V1.0.0
Copyright©2022 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 15 of 21
6.4. Antenna field type diagram
Figure 9 antenna field type diagram

TB-05 Specification V1.0.0
Copyright©2022 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 16 of 21
7. Design guidance
7.1. Application guidance circuit
Figure 10 Application Guidance Circuit
7.2. Recommended PCB package size
Figure 111 Recommended PCB Package Size (Unit: mm)

TB-05 Specification V1.0.0
Copyright©2022 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 17 of 21
7.3. Antenna layout requirements
In the installation position on the motherboard, the following 2 methods are recommended:
Scheme 1: Place the module on the edge of the main board, and the antenna area extends out of
the edge of the main board
Scheme 2: Place the module on the edge of the motherboard, and the edge of the motherboard
hollowed out an area at the antenna position
In order to meet the performance of the on-board antenna, it is forbidden to place metal
parts around the antenna, away from high-frequency devices
Figure 12 Antenna Layout
7.4. Power supply
Recommended 3.3V voltage, peak current above 50mA
LDO is recommended for power supply; If DC-DC is used, it is recommended that the
ripple be controlled within 30mV
The DC-DC power supply circuit suggests to reserve the position of the dynamic response
capacitor, which can optimize the output ripple when the load changes greatly
It is recommended to add ESD devices to the 3.3V power interface

TB-05 Specification V1.0.0
Copyright©2022 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 18 of 21
Figure 13 DC-DC Buck Circuit Diagram
7.5. GPIO
Some IO ports are led out from the periphery of the module. If you need to use a resistor of
10-100 ohms in series on the IO port. This can suppress overshoot and make the level on
both sides more stable. It is helpful for both EMI and ESD
For the up and down of the special IO port, please refer to the instructions in the
specification, which will affect the startup configuration of the module
The IO port of the module is 3.3V. If the level of the IO port of the main control and the
module does not match, a level conversion circuit needs to be added
If the IO port is directly connected to the peripheral interface or terminals such as pins, it is
recommended to reserve ESD devices at the IO port wiring close to the terminals
Figure 14 Level convert Circuit

TB-05 Specification V1.0.0
Copyright©2022 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 19 of 21
8. Storage conditions
The product sealed in the moisture-proof bag should be stored in a non-condensing
atmosphere of <40℃/90% RH.
The moisture sensitivity level MSL of the module is level 3.
After the vacuum bag is unpacked, it must be used within 168 hours at 25±5℃/60% RH,
otherwise it needs to be baked before it can be put on line again.
9. Reflow Welding Curve
Figure 15 reflow welding diagram

TB-05 Specification V1.0.0
Copyright©2022 Shenzhen Ai-Thinker Technology Co., Ltd All Rights Reserved
Page 20 of 21
10. Product packaging information
TB-05 module is packaged in a tape, 1350pcs/reel. As shown in the below image
Figure 16 Package and packing diagram
11. Contact us
Ai-Thinker offical website Office forum Develop DOCS
LinkedIn Tmall shop Taobao shop Alibaba shop
Technic support email：[e-mail]
Domestic business cooperation：[e-mail]
Overseas business cooperation：[e-mail]
Company Address：Room 403,408-410, Block C, Huafeng Smart Innovation Port, Gushu 2nd
Road, Xixiang, Baoan District, Shenzhen.
Tel: [phone]
Wechat mini program
WeChat offical account
