Aico SmartLINK Ei3000MRF User manual

Ei3000MRF
SmartLINK Module
Instruction Manual
Read and retain carefully for as long as the product is being used. It contains vital
information on the operation and installation of your Alarm. The leaflet should be
regarded as part of the product.
If you are just installing the unit, the leaflet MUST be given to the householder. The
leaflet is to be given to any subsequent user.

2
Introduction ................................................................................
Installation and House Coding ...................................................
Additional Features ....................................................................
Indicator Summary .....................................................................
System Examples .......................................................................
Testing the system .....................................................................
Interconnected Carbon Monoxide Alarms and Smoke Alarms ...
SmartLINK Troubleshooting ......................................................
Technical Specifications .............................................................
Guarantee ..................................................................................
Limitations of Radio Communications ........................................
Table of Contents
3
4
10
12
13
15
16
17
18
19
19
page

3
The Ei3000MRF SmartLINK Module is the next generation RF module designed
to fit in the Ei160e and Ei2110e series, Easi-fit mains powered Alarms. The
Ei3000MRF RadioLINK Module effectively replaces the Ei168RC RadioLINK Base.
The primary function of the Ei3000MRF is to wirelessly interconnect all Ei
Electronics Alarms in a system by the means of an RF signal i.e. when one Alarm
senses a fire event, the Ei3000MRF module attached to that Alarm will transmit an
RF signal that will activate the sounders in all other Alarms in the system.
The Ei3000MRF module is plugged into the rear of the base of an Ei160e or
Ei2110e series Alarm. RF communication through this module eliminates the
need to install long interconnect wires between all the Alarms on different floors
in different rooms. The Ei3000MRF is powered from the Alarm it is connected to.
The module also has “multiple repeater” transmission – this provides multiple signal
paths to create a robust RF ‘mesh’ system and also increase the RF range.
Introduction

N.B Disconnect Mains Before Alarm Head Removal
After disconnecting the mains power supply, it is now safe to remove the Alarm from
its base. Using a screwdriver, insert into the removal slot on the side of the Alarm.
Push the lower half of the Alarm away from the screwdriver, in the direction of the
arrow on the cover (see Figure 1 below).
CAUTION: The existing hard-wired interconnection may need to be disconnected
at this point (refer to the Installation section in the Alarm instruction manual). If a
hard-wired connection and an RF connection exist between the SAME two Alarms,
a continuous Alarm loop signal may occur.
4
Installation and House Coding
Figure 1

Fitting the Ei3000MRF Module
To fit the Ei3000MRF Module, first hold the flexible antenna and guide it into its
designated hole in the rear of the unit until about 2/3 of its length is inserted (Fig.
2a). Then, hold the module housing (Fig. 2b) & plug it into the Alarm, being careful
to align the pins and keeping them perpendicular to the base as the module is
inserted (Fig. 2c). Ensure the module is fully home, by checking that it is flush with
the surrounding Alarm housing (Fig. 2d).
5
Pin
Alignment
Pin
Alignment
Pin
Alignment
Figure 2a Figure 2b Figure 2c

6
House Coding the Unit
Ensure that the Alarm is re-connected to the
base correctly by checking for the green LED
on the cover of the Alarm. Power supply to the
Ei3000MRF will be confirmed by an initial flash
of the red, blue and green LED on the side of
the unit (see Fig 3).
Using a screwdriver, press and hold the House
Code button on the side of the unit until the
blue light illuminates (see Fig 4).
Immediately release the button, the Blue light
will flash rapidly and then stop.
The flashing will repeat every 5 seconds
thereafter. Repeat this procedure for all alarms
in the system and any RF accessories such as
the Ei450 Alarm Controller.
Check to ensure all RF devices have been successfully House Coded. This can
be done by counting the number of blue flashes on each RF Module. The number
of flashes should correspond to the number of RF devices in the system. (i.e. 4
flashes if there are 4 devices in the system).
N.B. We recommend, for ease of installation and RF communication, that up
to 12 RF devices can be installed in any one RF coded system. Please contact
us for further advise if additional RF devices are required.
You can exit this mode by pressing the House Code button on one of the RF Alarms.
Keep the button pressed until the blue light comes on solid and then release.
Pin
Alignment
Figure 2d

7
Figure 4
blue, red & green LED
Figure 3

The Alarm will now send a signal to all the other RF devices in the system to exit
House Code. Alternatively, the RF Alarms will automatically exit the House Code
mode after 30 minutes. To check the system, press the test button on any Alarm.
After a few seconds all Alarms should now sound. All Alarms in the system should
be checked similarly. Caution: Do not House Code another group (e.g. adjacent
apartment) until the current House Code has been completed.
Factory Reset
Sometimes in order to resolve an RF communication issue it may be necessary
to reset (factory reset) and House Code the system again. To do so, press and
hold the House Code button until you see a flashing blue light on the Alarm cover
(approx. 7 seconds), release immediately. Repeat this procedure on all Alarms.
Removing the Ei3000MRF Module
If it is necessary to remove or replace
an RF Module already fitted to an Alarm,
it can be taken out by firstly using your
index finger to lift it by 5 to 6mm to release
the connection pins (Fig. 5a), repeat this
process on the opposite end to release
the antenna (Fig. 5b), after which the
module can be fully removed from the
Alarm by lifting it away while keeping the
pins perpendicular to the Alarm (Fig. 5c).
Pin
Alignment
Figure 5a
8

9
Pin
Alignment
Figure 5b
Pin
Alignment
Figure 5c

The Ei3000MRF SmartLINK Module provides additional features not available
with Ei Electronics RadioLINK products. The following features will only work with
SmartLINK devices.
1. Remote House Coding (required if you want to add an Alarm to an installed system)
2. Monitoring
3. Data Extraction
*Note these functions will not be available unless you have completed House Code Entry.
1. Remote House Coding
If it is necessary to extend an RF system or you find that you want to add an extra
Alarm to a system you can now do so quite simply via the ‘Remote House Coding’
feature. Firstly using a screwdriver, press and hold the House Code button of one of
the previously installed Alarms until you see all colours flashing (red, blue, green).
Immediately release the button. This Alarm will now send an RF message to all the
previously installed (compatible) devices to re-enter House Code mode. Similarly,
install and put the new Alarm you wish to add to the system into House Code mode
(see “Installation and House Coding” section). As before, allow sufficient time so
that all Alarms are now house coded correctly (this can be confirmed by counting
the number of flashes on each Alarm). You can then exit House Code mode
manually or let it exit automatically after 30 minutes. (N.B. for this feature to work
all devices in the system must be SmartLINK).
10
Additional Features

2. Monitoring
The Ei3000MRF SmartLINK Module has the ability to “Monitor” the RF signal path
and strength. This is an enhanced self-monitoring function that recognises system
tampering or alarm head removal. In monitoring mode each Alarm will check the
presence of its strongest received RF signal. If the signal is missing then the Alarm
will record a monitoring failure event. It will also signal the failure via a change in
the indicator light pattern.
For more information on using this feature, please visit www.eielectronics.com and
refer to the relevant section on the SmartLINK Monitoring feature.
3. Data Extraction
The Ei3000MRF SmartLINK Module is equipped with a feature that allows for the
extraction of information from an Ei Electronics Compatible Alarm, using an Ei
Electronics download device. Once the system has been set up, information can be
accessed securely from within or outside a property if access is an issue The event
log can contain very useful information about any recorded events in the history of
the Alarm such as: Fire Events, Alarm Head removals, Button Tests, and so on.
Event logs can be retrieved as many times as necessary.
For more information on using this feature, please visit www.eielectronics.com and
refer to the relevant section on the SmartLINK Data Extraction feature.
11

Blue LEDButton Action Red LEDGreen LEDSounder
House Code EnterPress & Release on Solid Blue
Press & Release on Flashing Blue
Flashes briefly & stops
In House code
Factory Reset
Mode-Enter / Exit
OffOff Off
(1 flash per unit) every 5 Sec *Off
*See ‘Installation and House Coding’ section for further details
OffOff
Rapid flashing followed by single flash OffOff Off
Press & Release on Solid Blue
House code Exit 3.5 Sec flash OffOff Off
Remote House Coding Press & Release on Multi- Colour Flashing Rapid flashing followed by 3.5 Sec flash OffOff Off
Power Up
Blue LED Red LEDGreen LEDSounder
Alarm
Head Removal
Full Sound
Normal Operation
Standby
1 flash1flash
3.5 Sec flash followed by flash every 10 Sec
3.5 Sec flash every 6 mins for 4 hrs
OffOff
Off
Off
1 flash
OffOff
Off
Off
Off
Off
Ei100MRF Indicator Summary
12

13
System Examples
RadioLINK+
Smoke Alarm
RadioLINK+
Heat Alarm
RadioLINK+
Smoke Alarm
RadioLINK+
Heat Alarm
RadioLINK+
Smoke Alarm
RFTool
Data Extraction
RadioLINK+System
Hardwired
Smoke Alarm
Hardwired
Heat Alarm
Hardwired
Smoke Alarm
RadioLINK+
Smoke Alarm
RadioLINK+
Ei2110e
MultiSensor Alarm *
RFTool
Data Extraction
RadioLINK+& Hardwired Hybrid System
RF System (RadioLINK & RadioLINK+)
RadioLINK
Smoke Alarm
RadioLINK
Heat Alarm
RadioLINK
Smoke Alarm
RadioLINK
Smoke Alarm
Note: Remote House Coding / Monitoring / Data Extraction only available on RadioLINK+Alarms
RadioLINK+
Smoke Alarm
RadioLINK+
Heat Alarm
RFTool
Data Extraction
* N.B. In Hybrid systems we recommend up to 6 Alarms on the hard-wire interconnection line
and the link Alarm be an Ei2110e MultiSensor Alarm

14
RadioLINK+
Smoke Alarm
RadioLINK+
Heat Alarm
RadioLINK+
Smoke Alarm
RadioLINK+
Heat Alarm
RadioLINK+
Smoke Alarm
RFTool
Data Extraction
RadioLINK+System
Hardwired
Smoke Alarm
Hardwired
Heat Alarm
Hardwired
Smoke Alarm
RadioLINK+
Smoke Alarm
RadioLINK+
Ei2110e
MultiSensor Alarm *
RFTool
Data Extraction
RadioLINK+& Hardwired Hybrid System
RF System (RadioLINK & RadioLINK+)
RadioLINK
Smoke Alarm
RadioLINK
Heat Alarm
RadioLINK
Smoke Alarm
RadioLINK
Smoke Alarm
Note: Remote House Coding / Monitoring / Data Extraction only available on RadioLINK+Alarms
RadioLINK+
Smoke Alarm
RadioLINK+
Heat Alarm
RFTool
Data Extraction
* N.B. In Hybrid systems we recommend up to 6 Alarms on the hard-wire interconnection line
and the link Alarm be an Ei2110e MultiSensor Alarm

Check that the green light is on continuously to
indicate that mains power is present and that the
red light flashes every 40 seconds.
Frequent testing of the system is a requirement to
ensure its continued and safe operation. Guidelines
and best practices for testing are as follows:
1. After the system is installed.
2. Regularly (monthly testing is recommended).
3. After prolonged absence from the dwelling (e.g.
after holiday period).
4. After repair or servicing of any of the systems
elements or household electrical works.
5. After renovations to the house.
To test an individual Alarm press and hold the test
button until the horn sounds and the red light flashes.
This will ensure that the sensor, electronics and sounder are working.
To test the SmartLINK system, press and hold the test button on one of the Alarms.
The blue LED from the Ei3000MRF will illuminate for approximately 3.5 seconds.
Continue to hold the test button until all the Alarms in the system are sounding. This
will take between 20 to 45 seconds depending on the number of Alarms and their
locations in the system, e.g. a system with 12 Alarms may take up to 45 seconds for
all to sound. Release the test button when the test is completed.
15
Testing the System

The local Alarm will stop sounding but you will hear the other Alarms still sounding
in the distance.
End of Life (EOL) Check
Check the ‘replace by date’ label on all Ei3000MRF modules and attached Alarms.
If the date has been exceeded then the module should be replaced.
Identifying source of Alarm
Ei Electronics Carbon Monoxide Alarms and Smoke Alarms can be interconnected
via RadioLINK or SmartLINK so that one Alarm sensing danger will cause all the
other units to sound, enabling the alarm to be heard throughout the residence.
When a system alarms, check to see which unit has its red light flashing rapidly - this
it the source of the alarm.
If it is a Carbon Monoxide Alarm, ventilate the residence and follow the instructions
in the Carbon Monoxide Alarm manual.
If it is a Smoke Alarm, evacuate the residence and follow the instructions in the
Smoke Alarm manual.
For added convenience we recommend that an Ei450 Alarm Controller is used
with these systems. When there is an alarm, an icon on the Ei450 Alarm Controller
shows if it is a CO or Fire incident and can be remotely controlled accordingly.
16
Interconnected Carbon Monoxide
Alarms and Smoke Alarms

It is important that all Alarms in your system communicate with each other. The number
of walls, ceilings and metal objects in the signal path will reduce the strength of the
SmartLINK signals between the Alarms. Accordingly, one or more Smoke/Heat/CO
Alarms may have difficulties in communicating to all the other Alarms in the system.
If, when checking the SmartLINK interconnection, some of the Alarms do not
respond to the button test, then you will need to either:
(i) Position another SmartLINK Alarm to act as a ‘repeater’ between the Alarms
which are not communicating and so shorten the path and/or by-pass an obstacle
which is blocking the signal. When the new Alarm is fitted, House Code all Alarms
again, as described above.
(ii) rotate / re-locate the Alarms (e.g. move them away from metal surfaces or wiring).
After making these changes to the RF signal path, the SmartLINK signals may still
not be reaching all the Alarms in your system, even though they have already been
House Coded successfully. (see Section on “Limitations of Radio Communications”).
It is important to check that all Alarms are communicating in their final installed
positions. If Alarms are rotated, have had their antennas extended and/or re-sited,
we would recommend that all the Alarms are returned to the factory settings and
then House Coded again in their final positions (see above). The SmartLINK
interconnection should then be checked again by button testing all units.
(NB. The SmartLINK module can be returned to the originally factory settings by
pressing and holding the House Code switch until the blue light turns on solidly and then
flashes rapidly. This will take about 7 seconds. This clears the learnt House Codes).
17
SmartLINK Troubleshooting

Supply Voltage: 9V from attached alarm
RF Range: A minimum of 100 metres in free space
RF Visual Indicator: Blue light flashes continuously for 0.5 to 3.5 seconds while
transmitting RF signal
RF Frequency: 868.499MHz (1% duty cycle)
Max RF Power: +10dBm
Dimensions: 80mm length x 19mm depth x 16mm height
Temperature Range: 0° to 40°C
Humidity Range: 15% to 95% Relative Humidity
Interconnect *: Up to 12 SmartLINK or RadioLINK modules
Optional Accessories: Ei407 Manual Call Point, Ei428 Relay Module ,Ei414 Fire /
CO Alarm Interface, Ei450 RadioLINK Alarm Controller
Approvals: RF performance to EN 300 220-1 in accordance
with EN 300 220-2
EMC performance to EN 301 489-1 in accordance
with EN 301 489-3
* We recommend, for ease of installation and RF communication, that up to 12 RF devices can be installed in
any one RF coded system. Please contact us for further advise if additional RF devices are required.
18
Technical Specifications

Ei Electronics guarantees this RF SmartLINK Module for five years from date of
purchase against any defects that are due to faulty materials or workmanship.
This guarantee only applies to normal conditions of use and service, and does not
include damage resulting from accident, neglect, misuse, unauthorised dismantling,
or contamination howsoever caused. This guarantee excludes incidental and
consequential damage. If this RF SmartLINK Module should become defective
within the guarantee period, it must be returned to Ei Electronics, with proof of
purchase, carefully packaged, with the problem clearly stated. We shall at our
discretion repair or replace the faulty unit.
Do not interfere with the Alarm or attempt to tamper with it. This will invalidate the
guarantee, but more importantly may expose the user to shock or fire hazards.
This guarantee is in addition to your statutory rights as a consumer.
Ei Electronics radio communication systems are very reliable and are tested to high
standards. However, due to their low transmitting power and limited range (required
by regulatory bodies) there are some limitations to be considered:
(i) Receivers may be blocked by radio signals occurring on or near their operating
frequencies, regardless of the House Coding.
(ii) Alarms with SmartLINK modules should be tested regularly, at least weekly. This
19
Limitations of Radio
Communications
Guarantee
