Aigo DPF882D User manual

aigo movie pad DPF882D
User anual
(Version 1.0)

Freedom in technology; Freedom in life aigo movie pad DPF882D
Important Notice
Congratulations on purchasing your aigo movie pad DPF882D. Please read
this user manual carefully before using your aigo product.
Warranty Registration
Register your aigo product online to enjoy warranty, member's perks and
more, please visit www.aigo.com.sg
Need Help Fast?
Read your User Manual first for quick tips. After you have read the instructions
and still need assistance, you may access our online help at www.aigo.com.sg
or call [phone] with your product’s model and serial number.
Obtaining Warranty Service
Please review the User’s Manual troubleshooting resources and online help
resources before seeking warranty service. If the product is still not
functioning properly after making use of these resources, access the online
website: www.aigo.com.sg for instructions on how to obtain warranty service.
Copyrights/ Trademarks Information
•aigo logo is registered trademark of Beijing Huaqi Information & Digital
Technology Co., Ltd.
•Microsoft, MS-DOS, Windows and the Windows logo are registered
trademarks of Microsoft Corporation.
•Intel and Pentium are registered trademarks of Intel Corporation.
•SRS WOW is the registered trademark of SRS Labs, Inc.
•All other products are trademarks or registered trademarks of their
respective owners and are hereby recognized as such.
•The information on this manual is prepared with the current player
specifications. aigo reserves the right to make design and specification
changes for product improvement without prior notice. Actual contents
may differ slightly from those pictured.
•Unauthorized duplication of any recordings downloaded from the internet
or made from audio CDs is a violation of copyright laws and international
treaties.
1

Freedom in technology; Freedom in life aigo movie pad DPF882D
Always Keep a Copy of Your Original Data
Before you deliver your product for warranty services please backup all data,
including all software programs. You will be responsible for reinstalling all data.
Data recovery is not included in the warranty service and aigo is not
responsible for data that may be lost or damaged during transit or a repair.
Safety Instructions
•Do not expose to extreme temperatures.
•Do not allow any liquid form into the device.
•Do not apply or subject the player to excessive pressure.
•Do not expose to direct sunlight or heat sources.
•Do not try to disassemble and repair the device yourself.
•Do not expose device to chemicals such as benzene or thinner.
•Do not store device in dusty or damp area.
•aigo will claim no responsibility for any damage on data loss due to
breakdown, repair or other causes.
2

Freedom in technology; Freedom in life aigo movie pad DPF882D
Contents
IMPORTANT NOTICE...................................................... 1
1. PRECUTIONS............................................................... 4
2. PRODUCT INTRODUCTION........................................ 5
2.1 FEATURE....................................................................5
2.2 SPECIFICATIONS .........................................................5
2.3 ACCESSORIES ............................................................6
2.5 TERMINAL ILLUSTRATION ............................................8
2.6 REMOTE CONTROL ILLUSTRATION...............................9
3. GETTING START....................................................... 10
3.1 STAND......................................................................10
3.2 CONNECTING ILLUSTRATION......................................10
4. OPERATING INSTRUCTION..................................... 11
4.1 TURN ON /OFF......................................................... 11
4.2 OSD AND MEMORY MEDIUM .....................................12
4.3 MY FAVORITE ...........................................................12
4.4 EXPLORER................................................................13
4.5 PHOTO .....................................................................13
4.6 VIDEO.......................................................................15
4.7 MUSIC ......................................................................16
4.8 E-BOOK....................................................................17
4.9 SETUP......................................................................19
5. TROUBLESHOOTING................................................ 21
3

Freedom in technology; Freedom in life aigo movie pad DPF882D
1. Precutions
Warming!!!
----Please read this manual carefully before operating and reserve it for
future reference. It will be helpful if any operating problem encountered.
Avoid exposing this device to water, moisture
or high temperature. Do not place it near
swimming pool, bathtub or kitchen where it
may come in contact with water.
Clean only with a damp cloth; do not use any
chemical liquid for cleaning.
To ensure reliable operation of the device
and to protect it from overheating, do not
block any ventilation openings.
Only use attachments/accessories specified
by the manufacturer.
Do not step on the power cable, plug or
adapter to avoid electronic shock.
Do not attempt to service this device yourself
as opening or removing covers may expose
you to dangerous voltages or other hazards.
Refer all servicing and repair to qualified
service personal.
Please unplug this device in the
thunderstorm weather or not in use for a long
time.
Do not press hard on the LCD screen in the
process of transportation or usage. Avoid
sharp objects.
4

Freedom in technology; Freedom in life aigo movie pad DPF882D
2. Product Introduction
2.1 Feature
¾Ultra slim and portable design;
¾8 inch high definition LCD: 1280X768 high resolution;
¾Decode and playback 1080P and 720P (RMVB) HD video;
¾Supports music playback in various formats;
¾Supports photo browsing in JPG, JPEG, BMP and PNG;
¾Ebook viewer in TXT format;
¾Supports 720P / 1080i video output to various display equipments;
¾Supports playing from the last stop;
¾Supports various storage medium, such as SD / SDHC (32GB max.) /
MMC / USB;
¾Built-in speaker, supports Hi-Fi stereo earphone output;
¾Built-in 2800 mAh li-polymer battery.
2.2 Specifications
Items Description
Video Decoder MPEG1 / 2 / 4, RealVideo, Divx&Xvid,
MJPEG, H.264
Video Formats TS, TP, RM, RMVB, AVI, MPEG, VOB, DAT,
M2TS, MTS, MP4
Video
Resolution
(Max)
MPEG2 / 4 / H.264 / Divx&Xvid: 1080i /1080P
RMVB:720P
Subtitle sub, srt, rt, txt, smi, ssa, aqt, idx, mks
Audio Decoder MP3, MPEG, PCM, COOKER (64, 1KBPS),
AAC, FLAC, APE, WMA, WAV
Decoding
Function
Image Formats JPG, JPEG, BMP, PNG
Multimedia
Input USB OTG Connect to USB flash drive or portable hard
disk (External power is required) by USB
HOST cable.
5

Freedom in technology; Freedom in life aigo movie pad DPF882D
Connect to PC for data transferring.
Memory Cards MMC, SD, SDHC (Max. 32GB)
File System FAT, FAT32, NTFS
Video Output YPbPr
Video Definition 720P, 1080i
HD Output
Audio Output Stereo output, headphone output (Impedance
32 ohm)
AC Input AC 100-240V~50/60Hz
DC Input DC5V, 2.0A
Power
Adapter Battery 2800 mAh li-polymer battery
Panel Size 8 inch 16:10
Resolution 1280 X 768 pixels
Effective
Viewing Area 173.76 (H) X 104.256 (V) mm
Brightness 200 cd/m2
LCD
screen
Contrast 400:1
Dimension 212.6 X 134.3 X14.3 mm
Others Weight
(Without
package) Approx. 380g
2.3 Accessories
Main unit------------------------------------------------------------------------------------1pc
Power adapter-----------------------------------------------------------------------------1pc
USB cable----------------------------------------------------------------------------------1pc
User manual--------------------------------------------------------------------------------1pc
6

Freedom in technology; Freedom in life aigo movie pad DPF882D
2.4 Button Illustration
7 9
4
3
8
2
10
6
1
5
1. Power Switch: Push to OFF position to power off; push to ON position to
power on and the indicator will light up.
2. On/Off: a. Power on: Press and hold; b. Power off: Press and hold;
c. Press to back to the main menu.
3. Return: Exit.
4. Up: a. Up; b. Previous; c. Rewind.
5. Down: a. Down; b. Next; c. Fast forward.
6. Left: a. Left; b. Volume down; c. Adjust down.
7. Right: a. Right; b. Volume up; c. Adjust up.
8. Play: a. Confirm / Enter; b. Play/Pause; c. Press and hold to pop
up the shortcut menu.
9. Menu: a. Press to pop up the shortcut menu.
b. Press and hold to turn on or off the HDTV out function.
10. Indicator: Green: a. Normal operation; b. Battery is fully charged.
Orange: Battery is charging.
Off: System OFF.
7

Freedom in technology; Freedom in life aigo movie pad DPF882D
2.5 Terminal Illustration
1
2
3
4
5
1. USB OTG: a. Connect to PC; b. Connect to USB flash drive or USB
hard disk by USB OTG cable.
2. SD/SDHC: SD/SDHC/MMC card slot.
3. HDTV Out: HDTV output jack, connect to video equipment such as TV
to enjoy HD video.
4. Headphone: a. Connect with a earphone; b. Audio output.
5. DC-IN: Connect with the power adapter, power input 5V DC 2.0A.
8

Freedom in technology; Freedom in life aigo movie pad DPF882D
2.6 Remote Control Illustration
1 2
4
3 7
6
5
9
8
1. Power: a. Press and hold for 3 seconds to turn off the device;
b. Press to back to the Main Menu when device is on.
2. Return: Exit.
3. Play: a. Confirm / Enter; b. Press and hold for 3 seconds to
pop up the shortcut menu; c. Play / Pause.
4. Up: a. Up; b. Fast forward; c. Previous.
5. Down: a. Down; b. Rewind; c. Next.
6. Left: a. Volume down; b. Left.
7. Right: a. Volume up; b. Right.
8. Mode: Press and hold for 3 seconds to turn on or off the
HDTV out function.
9. Shortcut Button: Press to pop up the shortcut menu.
9

Freedom in technology; Freedom in life aigo movie pad DPF882D
3. Getting Start
3.1 Stand
Tilt the stand as shown in the direction of the arrow in a 90 degree angle.
3.2 Connecting Illustration
10

Freedom in technology; Freedom in life aigo movie pad DPF882D
How to connect to TV (take YPbPr input for example)
1. Connect the video output cable to YPbPr IN jack on TV, connect the green
plug to the Y jack, blue to the PB jack, and red to the PR jack;
2. Connect the red and white audio cable to the Audio IN jack;
3. Set the video output mode to 720P in the device;
4. Set the video onput mode to YPbPr in the TV;
5. Press and hold “Menu” key on the device or press the “Mode” on the
remote control to switch the output mode to “TV OUT” or set “TV OUT” in
system setup, the screen will turn black, and the images will be displayed
on the TV screen.
6. In TV output mode, press and hold “Menu” key on the device or press the
“Mode” on the remote control, the image will be resumed.
4. Operating Instruction
4.1 Turn On / Off
¾Power on
Push the power switch to ON position, the device will be powered on.
Press and hold the On/Off button to power on the device when the power
switch is already in ON position.
¾Power off
Press and hold On/Off button to power off.
¾Return to the Main Menu
Press on/off button to return to the main menu when the device is powered
on.
11

Freedom in technology; Freedom in life aigo movie pad DPF882D
4.2 OSD and Memory Medium
¾Main Menu
The Main Menu is shown as below. Move the Left and Right buttons to
select an icon, and enter by ;
¾Memory Medium
This device is equipped with internal memory and external memory
interfaces that compatible with USB flash drive / USB hard disk and SD /
SDHC cards;
For refreshing the memory capacity, please press & hold the button
in the Memory Medium OSD.
4.3 My Favorite
In this category, user could self-define the contents by copying favorite from
PC or Memory Medium.
12

Freedom in technology; Freedom in life aigo movie pad DPF882D
4.4 Explorer
Move on the device to select “Explorer” in the Main Menu, and enter
by . The Explorer will list all the files saved in the Memory Mediums.
The files can be allowed to copy, delete and add to My Favorite.
¾Copy files: select a file or a folder in the list, press and hold or press
to pop up the setup menu, move to select “COPY”, and
confirm by .
File can only be copied from the external memory medium to the internal
memory.
¾Delete file: select a file or a folder in the list, press and hold or press
to pop up the setup menu, move to select “Delete”, and
confirm by .
¾Add to My Favorite: select a file in the list, press and hold or press
to pop up the setup menu, movie to select “Add to My
Favorite” and confirm by . Only picture and music files can be added
to My Favorite.
4.5 Photo
¾Picture Slideshow
Move to select “Photo” in the Main Menu, and enter by . In
the Photo Browser menu, select the picture and enter slideshow full-screen
by . During the slideshow, move for previous or next photo;
pause by and the picture information will be shown on the screen.
13

Freedom in technology; Freedom in life aigo movie pad DPF882D
¾Slideshow setup
During the slideshow, press and hold the or press to pop up
setup menu; move to select options, confirm by ; and exit
by .
•Source: select from Current Directory and Current Disk;
•Background Music: turn on or off the background music;
•Zoom: press repeatedly to zoom an image from 1 to 5 times;
•Rotate: press repeatedly to rotate an image by 0, 90, 180 or 270
degree;
•Brightness: move to change the brightness;
•Slideshow: there are 13 different transition effects such as random, Top to
Bottom and Left to Right, move to switch the transition effect;
•Interval: move to switch among Fast, Middle, Slow and Custom;
•Scale: move to switch among Auto, Original, Crop and Stretch.
14

Freedom in technology; Freedom in life aigo movie pad DPF882D
4.6 Video
Vodeo Playing back
¾Move Video Setup to select “Video” in the Main Menu, and enter
by .In the Video Browser menu, select a video file and press
to start full screen playing back. During video playing back, press to
pause, and the video information will be shown on the screen. Press
to fast forward or Rewind the video. It supports continue playing
from the last stop.
¾Video Setup
During video playing back, press and hold or press to pop up
setup menu, which includes Repeat, Skip, Previous, Next, Play / Pause,
Fast Forward, Rewind, Display Ratio, Caption, Stereo and Brightness.
15

Freedom in technology; Freedom in life aigo movie pad DPF882D
Previous: Go to the previous video;
Next: Go to the next video;
Play / Pause: Pause or resume playing video;
Rewind: Fast backward a video;
Fast Forwrad: Fast forward a video;
Jump:
Jump to the specified time for playing. Select Ship,
press to pop up a box shown on the left corner
of the screen, and then navigate to set the
accurate time;
Repeat: Press to switch among Repeat All, Once, Play
All and None;
Scale: Press to switch among Original, Stretch, Crop,
Auto and Actual;
Caption: Various external subtitle formats are supported. If no
subtiltle is present, this option will be disable;
Track: For track setting;
Brightness: Press to pop up the brightness bar, and move
to adjust the brightness level.
4.7 Music
¾Music Playback
Move to select “Music” in the Main Menu, and enter by . In
the Music Browser menu, select a music file and press for playing.
During the playing, move for previous or next song, confirm by
; adjust the volume by ; and pause by .
16

Freedom in technology; Freedom in life aigo movie pad DPF882D
¾Music Setup
During the playing, press and hold or press to pop up setup
menu; navigate to select options, confirm by ; and exit by
.
Origin file: Press to select from Current Disk and Current
Directory;
Repeat: Press to switch among Reapeat All, Repeat
One, Repeat Once and None;
Sequence: Select from Random and Order;
Previous: Go to the previous song;
Next: Go to the next song;
Play / Pause: Pause or resume playing music;
Rewind: Fast back forward a song;
Fastforward: Fastforward a song;
Background: Press to select preferred style;
EQ: Press to select from Normal, Classical, Jazz,
Pop and Rock;
Backlight: Press to select from OFF, 10s, 30s, 60s and
90s.
4.8 E-book
¾E-book browser
Move to select “E-book” in the Main Menu, and enter by . In
the E-book Browser menu, press for E-book reading; move
for page turning up or down; adjust the volume of background
music by .
17

Freedom in technology; Freedom in life aigo movie pad DPF882D
¾E-book Setup
During the reading, press and hold or press to pop up setup
menu; move to select options; to select sub-option; press
to exit and the setting will be activated.
BG music: Turn on or off the background music;
Auto scroll: Select from Fast, Middle, Slow and Off;
Font color: Move to select from White, Gray, Green and Pink;
Font size: Move to select from Big, medium and small;
Go to Page: Press to select “ Go to Page”, move to
change the value and confirm by ;
Background: Select the preferred style from Style 1 to Style 10.
18

Freedom in technology; Freedom in life aigo movie pad DPF882D
4.9 Setup
Move to select “Setup” in the Main Menu, and enter by .
¾1. Common
Language: Move to select preferred language;
Background: Move to select preferred style;
Product Information: Display product information;
Update: For software upgrade;
Factory Default: Resume to factory setting;
Boot Mode: Move to select from Phone, Video, Music, E-
book, Calendar and The last stop.
19
