Chapter 1
Getting Started
Congratulations on purchasing this rugged tablet PC.
This chapter first tells you step by step how to get the tablet PC up and
running. Then, you will find a section briefly introducing the external
components of the tablet PC.

Getting the Tablet PC Running
This section guides you through the procedures for getting the tablet PC
ready for operation.
Unpacking
After unpacking the shipping carton, you should find these standard items:
Notebook tablet PC
Accessories:
AC adapter
AC power cord
Hand strap
Screen protector film (already attached to the screen)
Touchscreen pen
Inspect all the items. If any item is damaged or missing, notify your dealer
immediately.
Keep the shipping carton and packing materials in case you need to ship or
store the tablet PC in the future.

Connecting to AC Power
The tablet PC operates either on the external AC power or internal battery
power. It is suggested that you use AC power when you start up the tablet
PC for the very first time.
1. Make sure that the tablet PC is turned off.
2. Place the tablet PC upside down.
3. Lift the latch handle of the battery cover and turn it counterclockwise to
the unlock position. Then, detach the cover from the tablet PC.
Unlock
position

4. Fit the battery pack into place (). Tightening the two screws () is
optional. The lack of the screws will not affect the rugged and
waterproof feature of the tablet PC.
5. Replace the battery cover and turn the latch clockwise to the lock
position.
Lock
position
