AIGOSTAR 30KLR User manual

INSTRUCTION MANUAL
SMART KETTLE
MODEL: 8433325186470
PLEASE READ THE MANUAL CAREFULLY BEFORE OPERATING YOUR PRODUCT
AND RETAIN IT FOR FUTURE USE
The plastic material in contact with the food is PP (polypropylene), BPA FREE

CONTENT
--------------------------------------------- 08-14
ES
--------------------------------------------- 29-36
DE
--------------------------------------------- 37-43
NL
--------------------------------------------- 44-51
FR
--------------------------------------------- 52-58
PT
--------------------------------------------- 22-28
IT
--------------------------------------------- 15-21
PL
--------------------------------------------- 01-07
GB

1
When using your kettle, basic safety precautions should
always be followed, including the followings：
1．Read all instruction carefully and thoroughly, before any
operation of the kettle．
2．Close supervision is necessary when any appliance is used
by or near children.
3．Before connecting the kettle, check whether the voltage
indicated on the appliance(underside of kettle and base unit)
corresponds with the mains voltage in your home．If this is
not the case, contact your dealer and not use the kettle.
4．Switch off and unplug from the outlet before filling,
emptying or Cleaning, or when not in use．
5．Do not overfill as boiling water may be ejected, the
maximum level indicator．Fill with cold water only．
6．To avoid against fire, do not operated in the presence of
explosive and/or flammable fumes．Such as do not operate
or place any party of this appliance on or near gas and
electric burner or in a heated oven．
7．Do not let the cord hang over the edge of a table or a
counter．Do not let the cord touch hot surface．
8．Never yank on the cord as this may damage the cord and
eventually cause a risk of electric shock．
9．If the cord or plug is damaged, or after the appliance
malfunctions or is dropped or damaged in any way, return
the appliance completely to your nearest authorized service
agent for examination, repair or adjustment．
10．Avoid touching the surface of the hot kettle, use the handle
and knobs．
11．To avoid possible steam damage, not face the spout when
operating the kettle．
GB

2
12．If operated on wood furniture, use a protective pad to
prevent damage to delicate finishes．
13．To avoid scalding, always ensure the lid is correctly
positioned before operation．
14．Scalding may occur if the lid is removed while heating．
15．Remove and replace the lid carefully when hot．
16．Extreme caution must be used when moving the kettle
containing hot water．Never lift the kettle by its lid．Always
use the body handle.
17．Do not switch your kettle on if it is empty．
18．To protect from electrical hazard, do not immerse this
kettle, power base or cord set in any liquid．
19．Use the kettle only with the supplied base unit．Do not use
the base unit for other purposes．
20．To protect against fire, do not operated in the presence of
explosive and/or flammable fumes．
21．While the water boiling or in the short time after the water
boils, please be sure that don’t attempt to open the cover
for avoid the steam scalding your hand．
22．Please avoid the liquid sprinkling in the LCD board and the
pressed key place in the operating process. Because the
water possibly can plunge in the product, causes the
function to be unusual．
23．Please do not have to add surpasses the maximum water
volume the water, because this has the possibility to
damage the product, causes the product movement to
appear exceptionally．
24．Please regular clean descale or pot bottom residuum,
because this possibly can affect the normal use of the
product．
GB

3
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
25．This appliance should not be used by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have are supervised by the person who is responsible
for their safety.
Children should be supervised to ensure that they do not
play with the appliance
Instruction for use
1．Before use preparatory work：
(1).Before first use, fill the kettle with clean water to maximum
capacity and boil．Discard the water and repeat the process
twice．
Note : New bought kettle have a kind of light odor which caused by mould
opening during manufacturing. It is normal and not harmful to your
health.
(2).The kettle should always be unplugged when filling or adding
water．
(3).Fill the kettle with water to desired level．Do not overfill or there
will be a risk of spillage or spitting．The water level indicator will
assist you to measure the correct amount．You can fill the kettle via
the spout or after opening the lid．Do not forget to close the lid
after filling, otherwise the kettle will not automatically switch off
after use．
(4).Do not fill with less than 0.5 liters of water（to “min” indication）
to prevent the kettle running dry while operating．
(5).Do not fill with less than 1.7 liters of water（to “max”
GB

4
indication）．
(6).An automatic safety cut-out has been fitted for protection against
overheating, it will operate if the kettle is switched on
when containing insufficient water．Always ensure the water
inside the kettle covers the minimum mark on the water level
indicator gauge．If the automatic safety cut-out has operated,
switch the kettle off, disconnect from the power outlet and allow
the kettle to cool down for 5 to 10 minutes．The refill with and
switch on, the kettle will work as normal．
(7).After boiling, the kettle switches off automatically.
Disconnect the kettle from the mains electricity supply.
Do not open the lid when pouring. If the kettle is overfilled, boiling
water may be ejected. The kettle is only to be used with the stand
provided.
(8).This appliance is intended to be used in household and similar
applications such as:
- staff kitchen areas in shops, offices and other working
environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
2．Basal operation：
(1).Put the base on the dry , smooth and horizontal plane , insert the
plug to the socket .When the kettle is inserted into the base , the
power puts through automatically．
(2).Press the “ ” key shortly, with the sound “Di.”, it starts
running.
(3).After the water boils, indicator turns off and the buzzer sends out a
“di-”sound at the same time.
3．Advanced operation：
(1).Press the “ ” key shortly, with the sound “Di.”, it starts running.
GB

5
Then press “ ”key, with the sound “Di” from buzzer, start
dechlorination, after water boiling, the buzzer sends out
“Di” “Di” sound. It will stop heating automatically after boiling 3
minutes and heard sounds like “Di” “Di”, dechlorination finished.
4. (1).Press “ ”for 2 seconds, with the buzzer sends out “di” sound,
“”button indicator light is on, and the kettle is under heat
insulation function, with red LED light shining. The indicator light
is till shinning after water is boiled and the kettle automatically
turns into heat insulation function in 2 hours, which will go on
heating when water temperature arrives at 85℃till the 2
hours heat insulation time is completed .
(2).Press“ ”for 2 seconds, with the buzzer sends out “di”
sound, “”button indicator light is on, and the kettle is
under heat insulation function.
Press “ ”once, then the indicator light is under 60℃
condition with the green LED light shining. This means that
when water temperature arrives at 50℃,it will boil to 60℃,and
the heat insulation function works in 2 hours.
Press “ ”twice, then the indicator light is under 70℃
condition with the blue LED light shining. This means that when
water temperature arrives at 60℃,it will boil to 70℃,and the
heat insulation function works in 2 hours.
Press “ ”thrice, then the indicator light is under 80℃
condition with the yellow LED light shining. This means that
when water temperature arrives at 70℃,it will boil to 80℃,and
the heat insulation function works in 2 hours.
Press “ ”the fourth time, then the indicator light is under
90℃condition with the purple LED light shining. This means that
when water temperature arrives at 80℃,it will boil to
90℃,and the heat insulation function works in 2 hours.
GB

6
(Note: Only under such operation, will the kettle be with heat
insulation function. And this function will be invalid if the kettle
body is taken away from the base. Need to reset to start this
function.)
5. Press “ ”shortly, with the buzzer sends out “di” sound, the kettle is
under boiling water condition.
Press“ ”once, then the indicator light is under 60℃condition
with green LED light. This means that it will stop heating when the
water temperature is 60℃.
Press“ ”twice, then the indicator light is under 70℃condition
with blue LED light. This means that it will stop heating when the water
temperature is 70℃.
Press“ ”thrice, then the indicator light is under 80℃condition
with yellow LED light. This means that it will stop heating when the
water temperature is 80℃.
Press“ ”the fourth time, then the indicator light is under 90℃
condition with purple LED light. This means that it will stop heating
when the water temperature is 90℃.
6．After the use finished, please put plug off the power socket．
How to care for your kettle
Wipe the exterior of the kettle with a soft, damp cloth or sponge．
Remove stubborn spots with a cloth moistened with mild liquid
detergent．Do not use abrasive scouring pads or powers．Never immerse
the kettle in water or other liquids．From time to time, depended on the
nature of your water supply, a boiled scale deposit is naturally formed and
can be found mostly adhered to the heating element, thus reducing the
heating efficiency．The amount of boiled scale deposited（and
GB

7
subsequently the need to clean or rescale）largely depends on the water
hardness in your area the frequency with which the kettle is used．Boiled
scale is not harmful to your health．But if poured into your beverage, it
can give a powdery taste to your drink．
Therefore, the kettle should be descaled periodically as indicated below.
Descaling
Descale kettle regularly．With normal use：at least twice
a year
1．Fill the kettle up to “max” with a mixture of one part ordinary
vinegar and two parts water．Switch on and wait for the appliance to
switch off automatically．
2．Let the mixture remain inside the kettle overnight．
3．Discard the mixture the next morning．
4．Fill the kettle with clean water up to “max” mark and boil again．
5．Discard the boiled water to remove any remaining scale and
vinegar．
6．Rinse the inside of the kettle with clean water．
POWER: AC 220-240V 50/60Hz 1850-2200W
WARRANTY: 2 YEARS
