Aim CR1009W User manual
1
ALARM
CLOCK RADIO
• BLUETOOTH
• USB FOR CHARGE
• WIRELESS CHARGE
• MULTI ALARM
USER MANUAL
INTELLI SET
WITH WIRELESS AND
USB CHARGE PAD
INDEX
• OPERATING INSTRUCTIONS
• FRONT DISPLAY INTERFACE
• BACK DISPLAY INTERFACE
• 1 YEAR LIMITED WARRANTY
• REPAIRS PROCEDURE
3
8
9
10
11
3 |
USER INSTRUCTIONS
OPERATING INSTRUCTIONS
BOOT:
1. After unpacking and accessing (output is QC3.0 quick charge
DC 5V 3A, 9V 2A, 12V 1.5a) adapter, long press the power button to
enter the startup program. At this point, the LED on the front display
interface is all lit for 5 seconds for self-check, so as to ensure the normal
use of the display screen. After normal display, the power indicator lights
up.
CLOCK SETTINGS:
1. Press the power button to enter the clock setting program when the LED
self-check on the display screen displays 00:00 (the default clock of the
machine is 24H). At this point, the number of hours (00:) icker, through
the “+” or “-” key set to the correct number of hours (00: -23:), then
short press M key to switch to the minute setting area, at this time the
minute (00) icker, through.
2. After setting the “+” or “-” key to the correct number of minutes
(: 00- : 59), press the M key to conrm or pause for 3 seconds, the
machine will automatically complete the default setting and return to the
home screen display interface.
ALARM SETTINGS:
1. After conrming that the clock time is displayed correctly, press M to
switch to the setting of alarm 1 (press M again to switch to the setting of
alarm 2). At this time, the logo of alarm clock 1 or alarm clock 2 lights
up and ashes. Press the power button to enter the setting program
(the same as alarm clock 1 and 2).
2. Timing alarm settings: Hours (00) when ashing, debug to the
correct number of hours (00: -23) through the “+” or “-” key, then switch
to the minute setting area by pressing the M key. At this time, the minute
(00) ashes.
Please read this instruction manual carefully before using for
the rst time and always keep these instructions.
| 4
OPERATING INSTRUCTIONS - CONTINUED
3. Alarm type selection: This machine preset has 5 kinds of chord
sound alarm and timing FM function (alarm 6) to choose from, through
the “+” or “-” key in order or reverse order to choose, when the
selection of the corresponding ringtone horn will have a pre-listening
effect, the default program is 01. Select OK and press M to enter the
next setting.
4. Alarm ON/OFF: “ON” or “OFF” of the alarm can be selected by “+”
or “-” key. When “ON” is selected, the pattern of the corresponding
alarm clock 1 or 2 will light up after exiting the setting to show that the
alarm clock is set successfully. When selecting “OFF”, the corresponding
alarm clock icon is not lit. After setting OK, press M to enter the
next setting.
5. Alarm cycle setting: the “+” or “-” key can be used to select the
cycle of the alarm to ring for ONE day (ONE) or ALL day (ALL).
When “ONE” is selected, the alarm will ring for 30 seconds when
the clock reaches the time of the timer alarm, and the alarm will
automatically exit after 30 seconds when there is no operation. When
you choose “ALL”, ring a bell at a certain time each day.
6. After the above steps are performed in sequence, press the M key
to conrm or pause for 3 seconds, and the default setting will be
automatically completed and returned to the home screen.
APPLICATION OF SNOOZE BUTTON:
1. One-button SNOOZE setting: When the alarm goes off, press
SNOOZE to enter SNOOZE mode for one time (or press any other
button to end the SNOOZE mode). Five minutes later, the alarm will
ring again.
2. Brightness adjustment of the display: In any picture, press the
“SNOOZE” button to highlight the rst time, highlight the second time,
highlight the third time and so on. When there is no key operation for
15 seconds, the machine will enter automatically and keep the
general display.
3. Set the clock alarm clock to zero: when the time is displayed on the
main interface, press the “SNOOZE” button for a long time for
5 seconds to enter the restore factory setting program, and everything
is set to zero.
5 |
OPERATING INSTRUCTIONS - CONTINUED
FM PLAYING FUNCTION AND TIMING FM PLAYING FUNCTION:
(during playing FM, please use the MIC charging cable of the machine to
connect to the USB interface)
1. In the clock display the main interface, long press the M key after
entering FM broadcast program (FM icon bright) long, short press the
switch on the power key can automatically search FM radio, search
until after all can search to the FM radio, broadcast program will
automatically enter the rst FM radio, long press the M key to exit the
FM broadcast function again and return to the clock display the
main interface.
2. When FM is playing, press the “+” button for the next station; Long
press “+” to increase the volume; Press the “-” key to the previous
station; Long press “-” to reduce the volume. Press M to play/pause,
and press start to search the platform.
3. When setting alarm 1 or 2, switch to “6” in the alarm selection to
automatically wake up the FM playing function. The timing time and
playing operation are the same as the alarm setting and FM
playing operation.
USB POWER FUNCTION:
1. When using the local type-c power cord, use the FM antenna (MIC
charging cable) on the USB interface to provide DC 5V power for
other devices.
POWER FUNCTION:
1. This machine supplies power to the external adapter. Please use the
standard type-c (DC 5V 2A) charging line of this machine and the DC
power supply output for quick charging of QC3.0 (DC 5V 3A, 9V 2A,
12V 1.5a) for charging.
2. When the machine is charging, the brightness of the display screen
switches between brightness modes such as highlighting, general
brightness and dark light (keep dark light display state when there is no
operation, press any key to activate the bright display).
| 6
WIRELESS CHARGING FUNCTION SETTING:
1. When the wireless charging of the machine works normally, the power
supply supplies the external power supply. Please use the adapter with
output QC3.0 quick charging (DC 5V 3A,9V 2A, 12V 1.5a) to power
the type-c interface of the machine.
2. When charging wireless power, the power cord must be the standard
type-c charging cable (DC 5V 2A) of the machine, otherwise the
charging effect of wireless charging will be affected.
3. After the external power supply is successful, the device with wireless
charging function (such as mobile phone) shall be placed on the center
area of the wireless charging transmitter (net cloth) at the top of the
machine smoothly, so as to ensure the good docking between the
wireless charging transmitter and the receiver
4. Connect to the standard type-c charging line of the machine, and when
waiting for charging, there will be a red light on the upper right corner
of the cloth, a green light will be on when charging, and the green light
will remind you to re-access the type-c charging line.
5. When wireless charging works, the output power of DC 5V can be
provided for the USB interface of the machine at the same time, which
can be used for charging mobile devices without wireless
charging function.
LOCAL WARNING:
1. If the machine is not used for a long time, please press the power button
to enter the background operation mode to ensure the normal service
life of the product.
2. Matters needing attention when the machine is used or used: anti-
insolation, anti-moisture, anti-corrosion, anti-drop, anti-pressure.
3. Automatic repair function of the machine software: in the process of
use, if abnormal operation mode or operation jam occurs (the machine
freezes), please long press the power button for about 8 seconds (at this
time, the power cannot be disconnected), the machine will automatically
enter the program repair mode until the normal boot.
OPERATING INSTRUCTIONS - CONTINUED
7 |
LOCAL INFORMATION:
1. Product specication: 137*131.5*93 mm
2. Product material: ABS shell material + hd PC display lens +EVA
non-slip pad + high-elastic wear-resistant cloth net
3. Display size: 5 “LED display clock alarm clock
4. No charging power: DC 5-9v / 850-1000mah for single wireless
charging, DC 5-9v / 400-650mah for simultaneous FM function and
wireless charging
5. The speaker specication: ø66 mm 3 w
6. Sensitivity: 85%
7. Frequency width: 800MHZ - 20000MHZ
8. Chip version: V 5.0
9. Wireless charging standard: WPC+QI wireless charging standard
OPERATING INSTRUCTIONS - CONTINUED
| 8
FRONT DISPLAY INTERFACE
1. Top wireless charging area.
2. Wireless trafc light indicator hole.
1
2
9 |
BACK DISPLAY INTERFACE
1. Charging light hole.
2. Short press when alarm: enter snooze mode for 5 minutes.
Other modes short press: cycle adjust light brightness.
3. Type-c charging port.
4. The FM mode Short press: next channel long press: increase volume.
Clock mode short press: add one long press: increment.
5. The FM mode short press: last channel long press: to reduce the volume.
Clock mode short press: minus one long press: decreasing
6. Long press: enter/exit FM mode.
Clock mode short press: sets the alarm/ toggle settings long press: enter/exit FM.
7. The FM mode short press: automatic search table long press:
enter the background.
Time mode short press: set the time long press: enter the background.
Press “boot” for the rst time.
8. The DC 5V power supply.
FM antenna (MIC charging line).
1
2
3 4 5 6 7 8
| 10
1
The Manufacturer hereby provides a warranty to the original purchaser of this product (the
consumer) that this product will be free of manufacturing defects in materials and workmanship
which under normal, personal, family or household use (commercial use expressly excluded)
manifest themselves within the 1 year from the date of purchase.
EXCLUSIONS
• The warranty does not include and will not be construed to cover products damaged as a
result of disaster, misuse, commercial use, not in accordance within the written instructions
included with the product, abuse and/or any non-authorised modication of the product,
incorrect installation of the product or normal wear and tear.
• Insect infestation of the electrical or motor makes the claim invalid.
• Customer abuse do not fall under warranty.
WAIVER
The warranty and the obligations of the Manufacturer provided herein are in lieu of, and the
consumer, waives all other warranties, guarantees, conditions or liabilities, express or implied,
arising by law or otherwise, including without limitation, any obligation of the manufacturer in
respect of any injury, loss or damage (direct, indirect or consequential) arising out of the use of,
or inability to use this product and whether or not occasioned by the manufacturer’s negligence
or any act or omission on its part.
PROOF OF PURCHASE
Any claim in terms of the warranty must be supported by a proof of purchase. If such proof
is not available, then not withstanding anything to the contrary herein, the service agent’s
prevailing charges for services/repairs and/or spares will be payable by the Consumer upon
collection of the repaired product. The Consumer should call the Pick n Pay CUSTOMER
CARE number on 0860 30 30 30 (only in South Africa). Customers residing outside South
Africa may return the product back to a Pick n Pay store. During the warranty period the
product may only be serviced and/or repaired by the Manufacturer’s duly authorised agent(s).
1 YEAR LIMITED WARRANTY
If this product proves to
be faulty during normal
use due to defective
materials or workmanship.
Refer to our website for
terms and conditions.
11 |
REPAIRS PROCEDURE
Should you experience any faults on your Aim product, please adhere to the following
procedure to have the fault rectied speedily and professionally.
You can return the product to the store.
Call the Pick n Pay CUSTOMER CARE number on 0860 30 30 30 (only in South Africa) to
report the fault and make arrangements for the next steps.
Note: Should you live in an outlying area or outside South Africa, it may be necessary to
return the product to the store nearest to you.
COST OF REPAIRS
UNDER WARRANTY
Any items still under warranty will be repaired free of charge, as long as it complies with the
terms and conditions of the warranty (refer to “warranties” section in this manual). Any items
that need to be repaired that are NOT covered in the warranty will be for the consumer’s
expense. A quote for the repair/replacement of these items will be provided to the consumer
for approval prior to repairs being conducted.
OUT OF WARRANTY
Any items that need to be repaired once the warranty has expired will be for the consumer’s
expense including call out fees. A quote for the repair/replacement of these items will be
provided to the consumer for approval prior to repairs being conducted.
Raymond Ackerman
Founder of Pick nPay
Product of China
CUSTOMER CARE
Sharecall: 0860 30 30 30
ONLY IN SOUTH AFRICA
customercare@pnp.co.za
MODEL NUMBER:
CR1009W
Specially packed for
Pick n Pay Retailers (Pty) Ltd.
Pick n Pay Oce Park,
101 Rosmead Avenue,
Kenilworth, Cape Town, 7708
www.picknpay.co.za
Table of contents
