AIMobile ATC63E Series Installation and operation manual

Tablet PC
ATC63E Series (AIM)
Startup Manual
ATC63E Appearance
Left: Front View Right: Rear
View
For more information on this and other AIM
products, please visit our website at:
https://www.aimobile.com.tw/
For technical support and service, please visit
our support website at:
https://www.aimobile.com.tw/contactUs.html
This manual is for ATC63E Series(AIM)
2nd Edition
Print in Taiwan May 2022
Description of Parts
A: Microphone
B: Camera LED
C: 5MP Front Camera
D: Light Sensor
E: Stereo Speaker (L)
F: Programable buttons Barcode
scanner)
G: System LED
H: Volume buttons
I: Power Button
J: Power LED
LED Status
K: Stereo Speaker (R)
L: Internet LAN Port,
HDMI output & USB-C 3.1 Port Door
M: USB 3.0 Type-A *2
& 3.5mmAudio Combo Jack Door
N: DC-in Door
O: Pogo Pin (USB3.0 )
P: 8MP Rear Camera
Q: Flash LED
A
M
N
E F G H I J K
O
B C D
L
PQ
Color
Status
Solid Green
Full charged (DC-in)
Solid Blue
Charging (DC-in)
Blinking Red
Battery lower than 10%
已註解 [SD1]: 要解釋什麼燈號什麼顏色的 LED 各是什麼
意思
已註解 [H黃A2R1]: 新增表格說明

Easy Setup
Power On Computer
1. Model: ATC63E power adaptor input Rating：AC
100-240V, 50-60Hz, 1.5A
Type-C output max: 5V/2A
USB3.0 type A output max: 5V/0.9A
RJ45:10/100/1000 Mbps
Audio Jack connection (no rating)
HDMI connection
2. This product is intended to be supplied by a UL
Listed Power Adapter( FSP ：FSP090-DBBN3&
FSP090-RBBM1) rated 19 Vdc, 4.74A MAX,90W.
for model ATC63E, and Tma 40-degree C. Please
contact AIMobile for further information and
assistance.
3. The product is equipped with shipping mode for
battery protected and power saving, please charge
the embedded battery of the computer: Connect
the adaptor on the ATC63E computer. (“N” on the
description of parts.) Please charge the device to
100% when you usethis computer for thefirst time.
4. Push the Power button (“I” on description of parts.)
to start the computer.
5. While the computer is running, push the power
button disable LCD backlight and initiate the power
saving mode. Push the power button again will
enable the backlight and exit the power saving
mode; press the power button for 4 seconds while
computer is running, the system will be shut down.
6. Contact time information where the case touch
(tablet PC, docking and adapter)
0-30°C contact time of the whole machine (more
than 1 minute)
31-40 °C contact time of the whole machine (less
than 10 second)
7. Expected tablet PC use handheld angle and
position:
The hand is parallel to the chest tilt angle of 30
degrees.
8. Environment Temperature:
Storage: -20°C ~ +60°C
Transport and storage:
Humidity up to 95 %, non-condensing
35 °C to 70 °C at a water vapour pressure up
to 50 hPa
An atmospheric pressure range of 700 hPa to
1060 hPa
Operating conditions
0°C~40 °C
0°C~40°C
Handheld: 0°C~30°C
Wall mount / Docking Station:
0°C~40°C
(Handheld: 0°C~30 °C/Wall mount / Docking
Station: 0°C~40°C)
Humidity up to 90 %, non-condensing, but not
requiring a water vapour partial pressure
greater than 50 hPa
An atmospheric pressure range of 700 hPa to
1060 hPa.
9. Temperature rise test with maximum normal
loading:
Intended use
The ATC63E is intended for integration with hospital
system. It is designed for general purpose for hospital
environment. For data collection and display for reference.
It shall not be used for life-supporting system.
Intended user group
The primary users for the ATC63E series are professional
healthcare personnel and general patient groups. It is
appropriate for users aged between 18 and 65 to use the
tablet and users’ weight and health are not relevant.
If encounter any of system failure or serious incident in
relation to device, please report to the manufacturer or
local agent.
Maintenance
1. Maintaining the Battery
•Do not expose heat or attempt to disassemble the
battery, and do not place the battery in water or in
a fire.
•Do not subject the battery to strong impact, such as
a blow from a hammer, or stepping on or dropping
it.
•Do not puncture or disassemble the battery.
•Do not attempt to open or service the battery.
•Replace only with batteries designed specifically
for this product.
•Keep the battery out of reach of children.
•Dispose of used batteries according to local
regulations.
2. Maintaining the LCD Display
1.Handheld mode
Play 1080p video with only AC-in for I/O port
connection
Battery: 10%/ Tablet placed at flat positioning /
Wifi on/BT on / ALS off
Brightness: 41% (150 cd/m2= 41%)/ Half of max
volume(50%)
Device I/O AC-in only
Contact time＞1 min
Temperature：0-30℃
2.Docking Station
Burn-in with full-installed Docking I/O
Battery: 10%/ Tablet on Docking Station/ Wifi
on/BT on / ALS ofF
Brightness: 100%/ Max volume(100%)
Docking I/O AC-in, DP monitor, HDMI monitor,
RJ45 device ping ip, USB type-A 5V/0.9A
10s＞Contact time＞1s
Temperature：0-40℃
3.Wall mount
Burn-in with full-installed Device I/O
Battery: 10%/ Tablet installed withWall mount /
Wifi on/BT on / ALS off
Brightness: 100%/ Max volume(100%)
Device I/O AC-in, HDMI monitor, RJ45 device
ping ip, audio jack, USB type-C 5V/2A, 2xUSB
type-A 5V/0.9A
10s＞Contact time＞1s
Temperature：0-40℃
已註解 [SD3]: Information provided for safe performance of
routine maintenance necessary to ensure continued safe use
of ME EQUIPMENT
任何維修或保養的需求
已註解 [H黃A4R3]: 已新增一個章節說明
已註解 [SD5]: Parts requiring preventive inspection and
maintenance to be performed by SERVICE PERSONNEL
identified including periods of application
任何部件有維修或保養的需求
已註解 [H黃A6R5]: 已新增一個章節說明

•Do not scratch the surface of the screen with any
hard objects.
•Do not spray liquid directly on the screen or allow
excess liquid to drip down inside the device.
•Do not place anything, such as food and drink, on
the screen at any time to prevent damage to the
screen.
•Clean the LCD display only with a soft cloth
dampened with 60% above isopropyl alcohol or
60% above ethyl alcohol each time after use.
3. Cleaning the ATC63E
•Turn off the ATC63E and unplug the power cord.
•Wipe the screen and exterior with a soft, damp
cloth moistened only with water. Do not use liquid
or aerosol cleaners on the screen, as these will
discolor the finish and damage the screen.
Safety Instructions
Please read these safety instructions carefully and follow
these instructions for use. Repair of the device may only
be carried by trained service personnel. AIMobile
recommends that a service contact be obtained with
AIMobile service and that all repairs also be carried out
by them; otherwise, the correct functioning of the device
may be compromised.
WARNING！Because of the danger of electrical shock,
never remove the cover of a device while it is
in operation or connected to a power outlet.
WARNING ！Do not modify this equipment without
authorization of the manufacturer.
WARNING ！To avoid risk of electric shock, this
equipment must only be connected to a
supply main with protective earth.
WARNING！Not to position the equipment so that it is
difficult to operate the disconnection device.
Disconnection device: Separate from
adaptor and power code.
WARNING ！When connecting with other peripheral
products, it must be a safety product that has
been evaluated by standards such as IEC. If
there is no product evaluated by standards
such as IEC, there may be product leakage
current when connecting.
WARNING！En raison du danger d'électrocution, ne
retirez jamais le couvercle d'un appareil
lorsqu'il est en marche ou branché à une
prise de courant.
WARNING ！Ne modifiez pas cet équipement sans
l'autorisation du fabricant.
WARNING！Pour éviter tout risque d'électrocution, cet
équipement ne doit être connecté qu'à une
alimentation secteur avec mise à la terre de
protection.
WARNING！Ne pas positionner l'équipement de sorte
qu'il soit difficile d'actionner le dispositif de
déconnexion. Dispositif de déconnexion :
séparé de l'adaptateur et du code
d'alimentation.
WARNING！Lors de laconnexion avec d'autres produits
périphériques, il doit s'agir d'un produit de
sécurité qui a été évalué par des normes
telles que CEI. S'il n'y a pas de produit
évalué par des normes telles que CEI, il peut
y avoir un courant de fuite du produit lors de
la connexion.
Accessories：Adaptor & power cord. Power cordsupports
the following three countries: Taiwan/US/Europe, please
use a power cord that matches the AC voltage of the
power outlet and has been approved by and complies
with the safety standard of your particular country.
If one of the following situations arises, have the
equipment checked by service personnel:
• The power cord or plug is damaged.
• Liquid has penetrated the equipment.
• The equipment has been exposed to moisture.
• The equipment does not work well, or you cannot get it
to work according to the user’s manual.
• The equipment has been dropped and damaged.
• The equipment has obvious signs of breakage.
Disconnect this equipment from any AC outlet before
cleaning. Use a damp cloth. Do not use liquid or spray
detergents for cleaning and keep this equipment away
from humidity.
•These two hooks are not for wall hanging instructions
CAUTION ！To avoid short-circuits and otherwise
damaging the device, do not allow fluids to
meet the device. If fluids are accidentally
spilled on the equipment, remove the affected
unit from service as soon as possible and
contact service personnel to verify that patient
safety is not compromised. Please check the
battery if your computer clock is unable to
keep accurate time or the BIOS configuration
is reset to default.
CAUTION ！Installation is only to be carried out by
manufacturer authorized and trained
personnel. Regarding calibrating the device,
we suggest sending back the tablet to the
supplier for annually check.
CAUTION！For disposing of your used product, please
follow the national requirement to dispose
waste products.
CAUTION！Pour éviter les courts-circuits et d'autres
dommages à l'appareil, ne laissez pas de
fluides entrer en contact avec l'appareil. Si
des liquides sont accidentellement renversés
sur l'équipement, mettez l'unité concernée
hors service dès que possible et contactez le
personnel de service pour vérifier que la
sécurité du patient n'est pas compromise.
Veuillez vérifier la batterie si l'horloge de votre
ordinateur n'est pas en mesure de conserver
une heure précise ou si la configuration du
BIOS est réinitialisée par défaut.
CAUTION！L'installation ne doit être effectuée que par
du personnel autorisé et formé par le fabricant.
En ce qui concerne le calibrage de l'appareil,
nous suggérons de renvoyer la tablette au
fournisseur pour un contrôle annuel.
CAUTION！Pour l'élimination de votre produit usagé,
veuillez suivre les exigences nationales en
已註解 [SD7]: Restrictions specified on other equipment or
NETWORK/DATA COUPLINGS, other than those forming part
of an ME SYSTEM, to which a SIGNAL INPUT/OUTPUT PART
may be connected
與其他產品連接時, 其他然產品必須經過 IEC 等標準評
估過之安全產品, 練結時也需要評估產品漏電流互相引響
的情形是否可以接受
已註解 [H黃A8R7]: 已增加文字說明

matière d'élimination des déchets.
Symbol Information
Button
Name
Functio
n
Mute Button
Press to
turn off
the
volume.
Brightness up Button
Press to
turn up
the
screen
brightne
ss.
Brightness down Button
Press to
turn
down
the
screen
brightne
ss.
Volume up Button
Press to
turn up
the
volume.
Volume down Button
Press to
turn
down
the
volume.
Power Button/Stand by
Press to
power
on/off.
ISO 7010-M002
Refer to
instructi
on
manual
CAUTION
Battery Caution
WARNING！
Remove the battery if the device is not likely to be used
for some time.
CAUTION！
Danger of explosion if battery is incorrectly replaced.
Replace only with the same type recommended by the
manufacturer, discard used batteries according to the
manufacturer's instructions.
CAUTION！
Danger d'explosion si la batterie est inexactement
remplacée. Remplacez seulement avec la même chose
ou le type recommandé par le fabricant, jettent les
batteries utilisées instructions de s selon fabricant des.
CAUTION！
Where providing safety devices or design in a battery or
equipment is not reasonably practical considering the
functional nature of the battery or equipment containing a
battery, instructional safeguards in accordance with
Clause F.5 shall be provided to protect the battery from
extreme conditions or user’s abuse. Examples that shall
be considered include:
–Replacement of a battery with an incorrect type
that can defect a safeguard (for example, in the
case of some lithium battery types).
–Disposal of a battery into fire or a hot oven, or
mechanically crushing or cutting of a battery, that
can result in an explosion.
–Leaving a battery in an extremely high
temperature surrounding environment that can
result in an explosion or the leakage of
flammable liquid or gas.
–Abattery subjected to extremely low air pressure
that may result in an explosion or the leakage of
flammable liquid or gas.
WARNING！
Retirez la batterie si l'appareil n'est pas susceptible d'être
utilisé pendant un certain temps.
CAUTION！
Lorsque la fourniture de dispositifs de sécurité ou la
conception d'une batterie ou d'un équipement n'est pas
raisonnablement pratique compte tenu de la nature
fonctionnelle de la batterie ou de l'équipement contenant
une batterie, des mesures de protection conformément à
l'article F.5 doivent être fournies pour protéger la batterie
des conditions extrêmes ou de l'abus de l'utilisateur. . Les
exemples qui doivent être pris en compte incluent :
–Remplacement d'une batterie par un type
incorrect qui peut faire défaut à une protection
(par exemple, dans le cas de certains types de
batteries au lithium).
–L'élimination d'une batterie dans le feu ou dans
un four chaud, ou l'écrasement ou le découpage
mécanique d'une batterie, pouvant entraîner une
explosion.
–Laisser une batterie dans un environnement à
已註解 [SD9]: 要有小藍人符號
附上以下網路找的做參考
...
已註解 [H黃A10R9]: 已加上小藍人符號
已註解 [SD11]: Stand by
已註解 [H黃A12R11]: 已加入
已註解 [SD13]: Where the RISK is unacceptable, the IFU
includes a warning to remove the battery if the ME
EQUIPMENT is not likely to be used for some time:
已註解 [H黃A14R13]: 已新增上去
已註解 [SD15]: A list of ACCESSORIES, detachable parts, and
materials for use with ME EQUIPMENT provided
已註解 [H黃A16R15]: 此產品配件只有 power cord and
power adaptor

température extrêmement élevée pouvant
entraîner une explosion ou une fuite de liquide ou
de gaz inflammable.
–Une batterie soumise à une pression d'air
extrêmement basse pouvant entraîner une
explosion ou une fuite de liquide ou de gaz
inflammable.
Mistreat the battery used in this device may present a risk
of fire or chemical burn.
Do not attempt to disassemble the computer or its
accessories.
Only qualified personal is allowed to replace the battery.
Do not dispose batteries in a fire and check with local
authorities for disposal instructions.
ATC63E can only be equipped with standard battery pack
with FUCO, ATC-63E-BAT,rating 10.8V 4660mAH
Polymer Lithium Ion Battery. Use of another battery may
present a risk of fire or explosion.
Battery Charge Notice
It is important to consider the environment temperature
whenever you are charging the Lithium-Ion battery pack.
The process is more efficient at normal room temperature
or slightly cooler. It is essential that you charge batteries
within the stated range of 0°C to 40C. Charging batteries
outside of the specified range could damage the batteries
and shorten their charging life cycle.
Storage and Safety Notice
Although charge Lithium-Ion batteries may be left unused
for several months, their capacity may be
depleted due to the buildup of internal resistance. If this
happens they will require recharging prior to use. Lithium
Ion batteries may be stored at temperatures between
-20°C to 60°C, however they may be depleted more
rapidly at the high end of this range. It is recommended
to store ATC63E within normal room temperature ranges.
Ensure that the voltage of the power source is correct
before connecting the equipment to a power outlet.
The power outlet socket should behave grounded
connection.
This Product is not intent for use by children. This product
is not suitable for use in locations where children are likely
to be present
The equipment power supply cord shall be connected to
a socket-outlet with earthing connection and the power
outlet socket should have grounded connection
Never open the equipment. For safety reasons, the
equipment should be opened only by qualified skilled
person.
This product is intended to be supplied by an UL certified
power supply or DC power source suitable for use at Tma:
40 degree C minimum, whose output meets ES1 and is
rated 5or 9Vdc,
minimum 3 A (minimum 45 W), if need further assistance,
please contact Advantech for further information.
Applicant：AIMobile Co., Ltd.
Address：6F., No. 166 Sec. 4. Chengde Rd., Shilin Dist.,
Taipei City 11167, Taiwan, R.O.C.
Tel：[phone]

Exploring the ATC63E
Before you can use your ATC63E, you must fully charge
the battery. Connect the power adapter as shown and
leave to charge for:
• A minimum of 10H 9m when using the internal battery.
Condition: The operation time is based on the LCD
brightness at 16%, Battery saver, Idle mode, Wi-
Fi/BT/camera/ALS off, Half of max volume (50%).
Installation Procedures:
Connect the male end of the power adapter to the DC-in
of ATC63E.
Connect the male end of the power cord to the DC power
adapter.
Connect the 3-pin male plug of the power cord to an
electrical outlet.
NOTE: Be sure always handle the power cords by holding
the plug ends only.
Connecting the Power
1. DC-in connection：Whenthe battery is low, connect
the adaptor and power cord to the socket, and the
device is charging.
NOTE: Unplug when fully charged.
2. Audio Jack connection: Support earphone only.
Connect the headphone cable to hear the sound.
3. USB3.0 type A: Data transfer only. When using the
USB-A cable, make sure to connect right cable to
the appropriate connector.
NOTE: Not support headset function.
4. HDMI connection: Audio and video transmission.
Please use a HDMI cable with a HDMI logo.
5. USB-C connection: Data transfer only. Use the
USB-C cable to connect the appropriate connector.
6. RJ-45 connection: Connect ethernet cable to the
appropriate socket in an environment without WIFI.
NOTE: Incorrect cable connections may result in irregular
operation, damage display quality/components and/or
shorten the module’s life.
System message
Root cause: HDD PWD incorrect 3 times
Solution: Please reboot and input the correct HDD PWD
Root Cause: try to boot by PXE but no bootable PXE
server
Solution: Please make sure LAN cable connected, or
please ignore PXE boot (by SSD boot)
Root cause: your bootable device(efi) without sign , and
SECURE BOOT is ON.
Solution: Turn off secure boot and use the bootable
device with signature(signed).
Root cause: once you try to boot by SECURE BOOT ON
but failed, you can’t back to turn off SECURE BOOT
directly.
Solution: Please turn off system then boot up and turn off
SECURE BOOT.
已註解 [SD17]: Information provided indicating where the
installation instructions may be found or information on
qualified personnel who can perform the installation
產品安裝資訊, 包含 VESA mount 安裝注意事項
已註解 [H黃A18R17]: 增加圖文說明

Root Cause: Your system is out of battery (main battery
+ RTC battery)
Solution: Please plug in adapter (DC in) for a while to
charge them (main battery + RTC battery)
Installation with Vesa Mount
Bracket
If you would like to use ATC63E with Vesa mount bracket,
you can follow the below steps.
1. Take off 4 screws in the corner.
2. Assembly VESA Mount Bracket with 4 screws
(Longer than original old screw)
SCREW, I,M4,15mm,MACH,8.5mm,2mm

Declaration of Conformity
CE Conformity Statement
Radio products with the CE alert marking comply with
the R&TTE Directive (1999/5/EC) issued by the
Commission of the European Community. Compliance
with this directive implies conformity to the following
European Norms (in brackets are the equivalent
international standards).
•EN55032/35 LOW VOLTAGE SWITCHGEAR AND
CONTROLGEAR FOR INDUSTRIAL USE
•EN300328 v.2.2.2 Technical requirement for
radio equipment
•EN301893 v2.1.1 WLAN - Spurious Emissions (5G)
•EN301489-1/-17 EMC radio/WLAN/BT
•EN50566 RF (SAR)
•IEC 62368-1 (CB+UL) Product Safety
•IEC/ EN 60601-1 AMMI/ ANSI ES 60601-1 Medical
Safety
Products that contain the radio transmitter are labeled
with CE alert marking and may also carry the CE logo.
Medical GENERAL EQUIPMENT AS TO ELECTRICAL
SHOCK, FIRE AND MECHANICAL HAZARD
ONLY IN ACCORDANCE WITH ANSI/AAMI ES 6060-1
Europe –EU Declaration of Conformity
This device complies with the essential requirements of
the Radio Equipment directive: 2014 / 53 / EU. The
following test methods have been applied in order to
prove presumption of conformity with the essential
requirements of the Radio Equipment directive: 2014 /
53 / EU:
EN300328 v2.2.2
Draft ETSI EN 301 893 V2.1.0
EN 301 489-1 V2.2.3
EN 301 489-17 V3.2.4
IEC 62368-1:2014
IEC 62368-1:2018
EN 62368-1:2014+A11:2017
EN IEC 62368-1:2020+A11:2020
UL 62368-1, 2nd Edition
UL 62368-1, 3rd Ed
RF exposure statement
SAR
This product complies with EU requirements regarding
restriction of exposure of persons to radio-frequency
energy (RF) emitted by telecommunication and radio
devices as it is designed and manufactured in such a
way as not to exceed the exposure limits indicated by
the European Union Commission. The permitted SAR
limit for the general population is 2.0 W/Kg. This limit
guarantees an ample safety margin that protects all
persons regardless of age and health condition.
5150 ~ 5350 MHz is limited to indoor used in below
countries.
FCC Compliance Statement
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one of the following measures:
•Increase the separation between the equipment
and receiver.
•Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
•Consult the dealer or an experienced
radio technician for help.
To assure continued compliance, any changes or
modifications not expressly approved by the party
responsible for compliance could void the user's
authority to operate this equipment. (Example: use only
shielded interface cables when connecting to computer
or peripheral devices).
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1) This device may not cause harmful interference,
and
2) This device must accept any interference
received, including interference that may cause
undesired operation.
15.21
Any changes or modifications not expressly approved
by the party responsible for compliance could void the
authority to operate equipment.
This device and its antenna must not be co-located or
operating in conjunction with any other antenna or
transmitter.
End-users and installers must be provided with antenna
installation instructions and transmitter operating
conditions for satisfying RF exposure compliance.
For product available in the USA/Canada market, only
channel 1~11 can be operated. Selection of other
channels is not possible.
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation
exposure limits set forth for an uncontrolled
environment for body-worn configuration in direct
contact to the phantom.
This device complies with FCC radiation exposure limits
set forth for an uncontrolled environment.
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. End
user must follow the specific operating instructions for
satisfying RF exposure compliance. This transmitter
must not be co-located or operating in conjunction
with any other antenna or transmitter.
The portable device is designed to meet the
requirements for

exposure to radio waves established by the Federal
Communications
Commission (USA). These requirements set a SAR limit
of 1.6 W/kg
averaged over one gram of tissue. The highest SAR
value reported under
this standard during product certification for use when
properly worn on the body
FCC 15.19 Statement
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment
and receiver.
•Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
•Consult the dealer or an experienced
radio technician for help.
FCC Caution: Any changes or modifications not
expressly approved by the party responsible for
compliance could void the user's authority to operate
this equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
IMPORTANT NOTE:
Radiation Exposure Statement:
The product comply with the US portable RF exposure
limit set forth for an uncontrolled environment and are
safe for intended operation as described in this
manual. The further RF exposure reduction can be
achieved if the product can be kept as far as possible
from the user body or set the device to lower output
power if such function is available.
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
Energy star Statement
ENERGY STAR qualified products save your money by
reducing energy cost and protecting the environment
without sacrificing features or performance. AIM is
proud to offer our customers products with the ENERGY
STAR mark.
About ENERGY STAR
Products that are ENERGY STAR qualified use less energy
and prevent greenhouse gas emissions by meeting strict
energy efficiency guidelines set by the U.S.
Environmental Protection Agency. AIM is committed to
offering products and services worldwide that help
customers save money, conserve energy, and improve
the quality of our environment. The more energy we can
save through higher energy efficiency, the more we
reduce greenhouse gases and the risks of climate change.
AIM products marked with the ENERGY STAR logo are
following the ENERGY STAR specification established by
the US Environmental Protection Agency, and the
product power management function has been turned
on. In addition, our equipment automatically goes into
"display sleep" within 10 minutes of inactivity
respectively. The user can wake up the computer by
pressing any key.
•Additional information about the energy and
cost savings that power management features
can provide can be found on the EPA ENERGY
STAR Power Management website at:
http://www.energystar.gov/powermanagement.
•Additional information about the ENERGY STAR
program and its environmental benefits can be
found on the EPA ENERGY STAR website at:
http://www.energystar.gov.
NCC：警語
取得審驗證明之低功率射頻器材，非經核准，公司、商號
或使用者均不得擅自變更頻率、加大功率或變更原設計之
特性及功能。低功率射頻器材之使用不得影響飛航安全及
干擾合法通信；經發現有干擾現象時，應立即停用，並改
善至無干擾時方得繼續使用。
前述合法通信，指依電信管理法規定作業之無線電通信。
低功率射頻器材須忍受合法通信或工業、科學及醫療用電
波輻射性電機設備之干擾。
無線資訊傳輸設備避免影響附近雷達系統之操作。
具備顯示器如手機，平板，NB….等3C 產品須標示警語：
【使用過度恐傷害視力】

A:警語 【使用過度恐傷害視力】(標示位置: 產品本體、說
明書及外包裝)
B: 說明書及外包裝須標示
（1）使用 30 分鐘請休息 10 分鐘。
（2）未滿 2歲幼兒不看螢幕，2歲以上每天看螢幕不要超
過1小時。
