Plum Z708 User manual
USER MANUAL
FCC ID:Y7WPLUMZ708
Tablet PC
This manual includes security measures and correct operating methods. For personal safety, please
make sure to read this manual before using. Thank you!
The Machine uses a capacitive touch screen. You can operate the device by touching the screen
with your finger or with a capacitive pen. (Never use the sharp objects to click the screen, or the
touch screen may be damaged).
Do not expose the device to high temperature, high humidity, or dust.
Protect the device from drops or sudden impacts. Accidental damage may not be included as part
of your warranty.
Please note that the maximum volume of the device can damage your hearing.
Please charge your phone in the event of the following situations:
AǃLow battery on the battery icon. BǃThe system turns off automatically.
CǃThe keys do not work.
Dǃ“ ” is battery charging. ǏNoteǐ:Please use the included charger for your phone, as using
incompatible chargers may result in damages. We assume no liability for the damage. Plase contact
our customer service should you need a new adapter.
During charging, it is normal for the charger to feel warm to the touch. This does not affect the
functionality of the charger
Do not disconnect the device while formatting, downloading or uploading.
Do not attempt to dismantle the device, nor polish it using chemical abrasives or solvents.
Do not use this device where electronics are forbidden, such as on airplanes..
Take extra precautions if using the device while walking or driving. Please note that operating the
device while driving a vehicle is against the law in many places.
USB is for transferring data.
For technical support, please contact our customer service or the authorized distributor.
Key points˖
1
Packing List:
Please check box for the following items
1. Tablet Device
2. User Manual
3. Earphone
4. Power Adaptor
5. USB Cable
ǏTIPS ǐ˖1. When the battery is low, it will power off automatically.
2. In the event of an unexpected shutdown, the device will scan and repair the disk.
This will result in an extended loading delay.
1
2
3
11
456
7
8
9
12
10
Device description
1 Touch screen:You can click and drag in the touch screen.
2 Front Camera:You can take photos and videos etc..
3:Earphone jack: 3.5mm standard earphone jack.
4 :Micro USB 5 pin connector: For battery charging and data
transfer.
5 Rear Camera:You can take photos and videos etc..
6 Flash: Camera flash.
7 Speaker
8 Micro SD/TF card
9 POWER˖Keep pressing button over 2 seconds
for power on/ off, press button once to turn on
screen from sleep mode .
10 Volume +:Turn up the volume
Volume -:Turn down the volume
11 SIM Card:Insert/Pull out SIM Card
12 MIC:Voice Recording
3
Setting up for the first time
Charging your device˖
Prior to using your phone, allow the battery to charge for a full
ten hours. After that you can recharge the device as needed.
Connect the DC-in jack to your device and plug the AC
adapter into any AC outlet.
ǏTIPSǐ:
1. This device uses a built in polymer battery. Please only use
authorized chargers.
2. It is normal for the device’s surface to become warm during
charging or long
periods of use. All devices are factory tested before release.
3. To ensure long battery life, you should completely charge and then
discharge the device battery once a month.
Battery Saving
To increase the device's operation time per charge, please follow the
key points below˖
1. When device is not in use, press power button once to go to sleep mode.
2. Shut down the applications when not in use.
3. Turn off WLAN when not in use
4. Shut off application sync selection
5. Set a shorter time for display backlight
6. Reduce brightness of display
4
Connecting to a PC:
<RXFDQFRQQHFWZLWKD3&XVLQJWKH86%FDEOH
that comes with your device.
You can transfer your personal data to the PC.
&RQQHFWWKH3&DQGWKHGHYLFHLWZLOOFKDQJHWR
the USB mode,in this state, realize the files transfer
function between the PC and the device.
Connecting a USB device:
86%GHYLFHVDUHVXSSRUWHGVXFKDVDNH\ERDUGPRXVH
through the USB port.
9LHZPHGLDILOHVRQ86%VWRUDJHZLWKLQVWDOOHGSKRWR
music or video applications.
ǏCautionǐ: Before removing this USB storage,make sure
your device is not accessing data from the USB storage
5
Inserting the MicroSD card :
You may install a Micro SD card to expand your device’s
storage space.
1. This device supports Micro SD card up to 32GB capacity.
2. Insert the Micro SD card as shown.
ǏNoteǐ: Ensure that the Micro SD card is inserted all the
way into the card slot.
ǏCautionǐ: Before removing this card, make sure your device
is not accessing data on the card.
Connecting to the Network:
Wi-Fi wireless setup:
Enter the setting interface, and turn on the Wi-Fi item.
The device will automatically search any accessible
nearby wireless networks.
6
Power On
Keep pressing power button over 2 seconds, device will start up opening screen, Android system is
activating and enter the main screen.
Sleep Mode
After device is on, press power button once and it goes to sleep mode. The screen is now on standby
and under low battery consumption. To wake up device, press one more time power button.
Power off and Forced Shut down
When you are not using the device, keep pressing power button over 2 seconds,the screen will
display “shut down” , select “Yes” to power off unit completely. If device is hanging, use a small pin to
press Reset hole, it will forced shut down and the device will power on again.
Operation of Touch Panel
Click -- Use finger or capacity panel pen to touch once, so as to select or activate function, or select
menu or turn on applications.
7
Tap and hold -- Tap over 2 seconds, it will turn on option list
Slide -- Slide up, down, left or right for fast scrolling browsing page and display screen
Drag – drag an icon and relocate the position
8
Double Click – Double click to enlarge or shrink the display size of picture or under browsing
webpage.
Shut --Use two fingers at same time on touch panel, to enlarge or to shrink the display scale.
9
ķGoogle Search
ĸClick to turn on voice search, it will search according to voice input ( Make sure Wireless is on )
ĹList of last running applications
ĺBack to Home screen
ĻBack to previous screen
ļDisplay of icons and device status, click to turn on notification screen
ĽShortcut to application
ľEnter applications page
Home Screen
1
6
8
7
2
5
3
4
10
Home screen with a set of 5 screens, slide left/ right to view individual screen
Change of Wallpaper
1. Long press an open area of the home screen. A Wall paper selection pop-up will appear.
2. Select preloaded wallpapers or picture as wallpaper.
3. Click "Set Wallpaper" to confirm.
Add shortcut on Home screen
1. Enter the application page, and long hold the app you wish to make a shortcut of.
2. Drag the app to the desired location on your home screen.
Add Widget in Home Screen
1. Enter application page and slide to Widget page
2. Long hold widget you want, then drag it to your home screen
Remark˖Some widgets are linked to internet services, and may incur data charges
Some widgets are restricted by region or service provider
Relocate the shortcut on Home screen
1. Tag the application icon and move
2. Long hold the application icon and drag it to the desired location
Cancel shortcut on Home screen
1. Long hold the application icon, recycle bin displays on upper screen
2. Drag the icon to the recycle bin icon located at the top of your screen
3. When icon changes to red, let go
11
Notification screen
While in home screen or when running applications, press the notification bar on the bottom right
hand side of your screen, then click the settings icon next to your power indicator˖
Icon Icon Description
Wireless signal Wireless connection, icon is full under strong signal
Battery Status of battery or if device is being charged
USB Connection To show if USB port is connected
Soft keyboard Turn on soft keyboard, for word typing
Screen shot After taking screen shot, show picture saved
Applications
Internet Browsing
Browse internet and bookmark the website
Remark :Web browser and bookmark might be different in different countries or different service
providers
ǏAttentionǐ:The icons here do not match the device.
12
Browsing webpage
1. Enter application page, select ”Browser” Icon
2. To brows certain webpage, select URL and input website address, and select “confirm”
3. See below browsing options˖
ķOpen new window
ĸShut down current webpage
ĹGo to Next or Previous webpage
ĺAccessing webpage, icon becomes “X” when webpage shows
ĻDetail message of webpage
ļEnter webpage address or related words
ĽBookmark current page
ľSearch message
ĿOpen bookmark and current visited webpage
ŀOption list of browser
1
7
8
10
9
2
5
3
4
13
Browser setting
When browsing webpageˈclick upper right corner“ ”ˈadjust setting in the option menu
Current visited webpage
1. Enter application page, click ”Browser”
2. Select bookmark current visited history
3. Select webpage
Email
Send and Receive email
Setting of email account
1. Enter application page and click ”Email”
2. Enter email address and password
3. Select next step ( for personal email account) or manual setting (for commercial email account)
4. Follow and input the requested setting
5. For setting more than one email account, select setting add email account, repeat steps
2-4.
After email account setting, message will be received in device. For more than one email account,
switch email account for operation,to receive and send out message.
14
Sending outgoing message
1.Enter application page and select ”Email”
2.Type in Recipients ;Manual input email addressˈuse ” ;” or ” ,” to separate more than one
recipients
3.Type in Subject
4.Type in message in content
5.Select for attachments
6.Select and send out message
Remark ˖If user is offlineˈmessage cannot be sent out
Check email message
In email account, user can check downloaded message, go online to check new messages.
15
Audio player
Click “Play Music”in application page.
Music will be categorized by artists, album, and play list. It will display all music inside“Songs”.
Click the song and it will play automatically.
Video player
Click “Video”in application page.
Video player will search for all supported video files in the device, click the designated video
file to play.
16
Camera
The built-in front camera can take picture and video file.
Take picture
1. Click“Camera”in application page, device is default at picture taking, icon is“ ”
2. To take pictureˈclick “ ”
3.When take the photos, it can be zoom
option by two finger freely
Video shooting
1. Select recording in video fileˈclick“ ”
2. Click “ ” to record video file.
3. Click “ ” again to stop recording.
Camera Setting
In camera modeˈclick“ ” for set upˈclick“ ” to select set up options.
1-3X
17
File Manager
File manager will copy, cut, delete, rename the documents or the folder in the TF card, it also will
share the files, install apk etc.In the main menu or desktop, click the document manager icon
to enter into documents manager.
A.Copy, cut, delete, rename the files and folder: choose the file or folder, long pressthe file or folder
to enter into the interface as Picture 9.4, you can operate the file or folder.
B.Paste the file or folder you copy or cut: in the catalogue you want to paste, choose icon
in right top, as Picture
C.Share file: choose any file, long click this file, choose icon in right top, it willl show
A
BC
18
FM Radio
Click in the main interface or desktop to enter into FM radio interface:
[Note]: Use FM radio, you need to insert earphone, if no antenna, you can’t search radio frequency
2
3
4
5
6
7
8
1
1.Open outer voice
2.Channel list
3.Menu
4.Save button
5.Current frequency
6.Next channel
7.Play/pause
8.Previous channel
Click search to scan FM frequency
19
