Aiphone JBW-M User manual

- INSTRUCTIONS -
The JBW-M adaptor converts a standard CCTV camera's signal to a 2-wire signal, compatible with the JF and JB
Open Voice Color Video systems. This allows the utilization of a color CCTV camera and a separate audio door
station (JF-D or JA-D) to be used in place of a JF/JB video door station. A motion detector or other activation
device can be connected to the Sensor input to trigger the system. The CCTV camera can also be connected to a
standard CCTV system for continual viewing and/or recording. The unit is equipped with a relay output to trigger
an external device, such as a DVR or video switcher whenever the audio and video to the Aiphone monitor is on.
Video Modulator with Audio Door Station and CCTV Interface
MASTER
A1
A2
AUDIO
1
2
VIDEO IN
VIDEO OUT
SENSOR
NC
NC
RELAY
NO
NO
JBW-M PS-1820UL
+
-
Pg. 1
WIRING DIAGRAM:
JBW-M Modulator for Standard CCTV camera and Audio-only door station (JF-2MED System)
OUT IN
VIDEO OFF ON
75 OHM
AIPHONE
SENSOR RELAY MASTER AUDIO
NC NC NO NO A1 A2 1 2
JF-D
(Optional, only if Sensor
input is not used)
1
2
CCTV Camera
75 Ohm, 1V Peak-to-peak
(Independently powered) Constant video output for
CCTV monitor, DVR, etc.
Normally Open contact for
remote device activation
(i.e. video switcher, DVR, etc.)
When VIDEO OUT is connected,
set 75ohm switch to OFF position.
Remote Activation*
(Optional, only with no JF-D
installed)
* Signaling device that provides a
Normally Closed momentary
contact.
NOTES:
1. When using the JF-2MED master,
use the JF-D audio door station.
2. Video Output is optional. If not
used, set 75 ohm switch to the
ON position.
3. SENSOR input can be used only
if there is no JF-D door station
connected. When used, the
camera will turn on when the
sensor device is activated.
JF-2MED
Door 1
JF-DA/DV/DVF A1
A2
+
A1
A2 B1 B2
A1
A2
DOOR 2
-
DOOR 1

Pg. 2
INTERNAL ADJUSTMENT WHEN JA-D/JF-D AUDIO DOOR STATION IS INCLUDED:
INSTRUCTIONS:
1. Open unit by removing 5 small
screws and lifting off cover.
2. Locate Jumper labeled JP1 on the
right side of the PC board, and JP3
on the top of the board.
3. Remove both jumpers completely,
or move them so they're on just
one of the posts.
4. Replace the cover and the 5
screws.
OPERATIONS
Activation of the camera from a Monitor:
1. The CCTV camera can be viewed on any of the JF/JB monitors in the system by pressing the MONITOR button.
This will turn on the video, but not the audio. To initiate 2-way audio with the outdoor location, press and release
the TALK button momentarily.
2. To turn the monitor off, press the MONITOR button again. Otherwise, it will automatically time out after
approximately 1 minute.
Activation of a camera by the Audio Door Station:
1. When the call button is pressed on the JF-D/JA-D door station, the monitor will turn on with the image from the
CCTV camera, and the chime will sound. The monitor will stay on approximately 30 seconds unless answered.
2. Press TALK momentarily to answer, then speak hands free. Press TALK again to conclude, or unit will turn off
automatically in approximately 1 minute.
A1
A2
B1
B2
+
-
JB-2MD
MASTER
A1
A2
AUDIO
1
2
VIDEO IN
VIDEO OUT
SENSOR
NC
NC
RELAY
NO
NO
JBW-M
PS-1820UL
+
-
JA-D
(Optional, only if Sensor
input is not used)
1
2
CCTV Camera
75 Ohm, 1V Peak-to-peak
(Independently powered) Constant video output for
CCTV monitor, DVR, etc.
Normally Open contact for
remote device activation
(i.e. video switcher, DVR, etc.)
When VIDEO OUT is connected,
set 75ohm switch to OFF position.
Remote Activation*
(Optional, only with no JA-D
installed)
* Signaling device that provides a
Normally Closed momentary
contact.
NOTES:
1. When using the JB-2MD master,
use the JA-D audio door.
2. Video Output is optional. If not
used, set 75 ohm switch to ON
position.
3. SENSOR input can be used only
if there is no JA-D door station
connected. When used, the camera
will turn on when the sensor device
is activated.
WIRING DIAGRAM (cont): JBW-M with JB-2MD master

NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device , pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try and correct the interference by one or more of the following measures:
— Reorient or locate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help.
FCC Class B Verification
Aiphone Communication Systems
1700 130th Ave. N.E.
Bellevue, WA 98005
[phone]
FAX [phone]
Toll Free Technical Support:
1-800-692-0200
FAX: [phone]
E-mail [email protected]
Pg. 3
JBW-M Instr.
0307JD
Note:
Only information pertaining to the connection and operation of the JBW-M and devices interfacing
with it are included here. For complete installation, wiring, and operational information about the
JF-2MED or JB-2MD system, please refer to the Installation Manual included with the system.
SPECIFICATIONS:
Power: Supplied by JF/JB Monitor
Video Input & Output: Composite 1V Peak-to-Peak, NTSC
Connector: BNC
Audio Door input: Use JF-D/JA-D surface mount door station only
Relay: Normally open output, 24VDC, 1Amp
Wire: 18AWG, 2-conductor, non-shielded, solid or stranded
Wiring distance: Max. 330' from JBW-M to Monitor
Dimensions: 1-5/8"H x 7"W x 4"D
OPERATIONS (CONT):
Interfacing Video with Other Systems:
1. VIDEO OUT connection simply passes the composite video signal on to a standard CCTV system, such as a
monitor, input on a switcher, or DVR. This video signal is live as long as the camera is powered. When using this
feature, set the 75 OHM switch to the OFF position.
2. SENSOR input allows a motion detector or other activation device to remotely turn on the camera. Use any device
with a Normally Closed contact. If an audio door station (JF-D/JA-D) is included, the sensor input cannot be used.
3. RELAY connection provides a normally open contact closure that can be connected to an external system. This
can be wired into a record input on a DVR or any other external device that needs to be notified when the video
and audio is activated to the Aiphone monitor.
