AIPTEK PenCam Ultra User manual

@n IP Company
Digital Camera
Installation Guide

Rechargeable Batteries
1. The batteries haven't contained any electricity before you recharge the
batteries. When using your camera for the first time, please connect the USB
cable with your camera and your PC and the batteries will be recharged via
you PC. The first recharging hours shall be over 8 hours.
2.After using your camera for two or three hours, you'll see the LCD starts
blinking, which indicates there is no sufficient electricity. Meanwhile, you
should connect the USB cable with your camera and your PC. Your PC is
recharging the batteries in your camera while you are transferring photos to
your PC. The rechargeable batteries led shows green light while full of
electricity; it shows red light while still recharging.
3.When batteries are removed, all of the stored pictures are cleared.
( Battery Capacity: continuous snapshot for 2 hours, stand by works for
approximately 1 weeks.)
..1..
How to Use Your Digital Camera
Introduction
The built-in memory of your camera is 64 Mbit memory. It supports two kinds
of resolution- high resolution ( 640x480 VGA) pictures and low resolution (
320x240 QVGA ) pictures. Besides, your camera offers several functions on
the LCD, showing the remaining number of pictures as well. With a USB
cable, you can transfer all the pictures to your PC.
English

Your Camera
View Finder
Lens
Shutter Switch
()Sw1
USB Port
LCD
Mode
()SW2
Power up/ down Switch
Strap Ring
..2..
Rechargeable
Battery Led

..3..
Selecting Functions
Your camera has two switches - the shutter switch(SW1) and the mode
switch ( Sw2 ). As you keep pressing the mode switch, the LCD indicates "
Hr, 26, Ct, St, CL, and Lr" icons in order. To select the icon you want,
press the shutter switch. Note! If an icon is not selected within 5 seconds,
the LCD goes back to the picture remaining number. The following chart
shows the function of each icon.
Press SW2 to change features
Features are displayed
Press SW1 to select mode
High resolution ( 26 images at most )
Picture remaining number
Continuous snapshot
10-second self-timer
Clear all images
Low resolution ( 107 images at most )
English

Power up/down your camera
Power up/ down your camera:
Turn on/ off the LCD:
There is a switch on the upper side of your
camera. To power up your camera, move up the switch; to power down
your camera, move down the switch. Note! You can't power down the
camera before transferring the taken photos to your PC. Once the camera
is powered down, all the stored photos will be lost. Therefore, the taken
photos should be transferred to your PC as soon as possible.
Keep pressing SW2 until the LCD is activated, and
the camera turns off after 30 seconds of inactivity. The LCD indicates "Lr"
for low resolution (QVGA images) and "Hr" for high resolution(VGA images).
The LCD then displays the number of the remaining pictures.
( Note! Though the camera is turned off, it still consumes electricity. Only by
powering down the camera can stop power consumption. You can power
down the camera after transferring photos to your PC. If your camera is
improperly shut down, power down your camera and then power it up again.)
..4..
Taking a picture
Press the shutter switch to take a picture. A high pitched beep indicates that a
picture is taken successfully and the counter decreases as well. A low beep
indicates insufficient light to . A series of beeps suggest that the camera is full.
(Picture remaining number)
ON
OFF

..5..
Self Timer
Press the mode switch until "St" appears on the LCD. Then
press the shutter switch and a 10 second self-timer starts.
Every 10 second the camera issues a short beep. When
completing the self-timer, a longer beep sounds, which
indicates that a picture is taken.
Note: The self-timer can't work when the memory of your
camera is full.
Change mode to "St"
"St" is displayed
Press SW1 to initiate the self-timer mode
Change mode to "Ct"
"Ct" is displayed
Press SW1 to select Continuous mode
Continuous mode
Press the mode switch until "Ct" appears on the LCD. You
can take a series of pictures in quick succession by holding
down the shutter switch. The function stops as you release
the shutter switch. If the "Ct" icon is not selected within 5
seconds, the LCD reverts back to the remaining number of
the pictures .
Note: Even if the light is insufficient, the continuous mode
still works. However, the pictures you take will be too dark
or too vague.
English

..6..
Changing the picture resolution
Picture resolution may only be changed when the camera
memory is empty. If there are any pictures stored in your
camera, the memory must be cleared first. To change
resolution, press the mode switch until the resolution icon is
displayed. To select "Hr" or " Lr", press SW1. Then the
LCD shows the number of remaining pictures at the current
setting.
Change mode to "Hr" or "Lr"
"Hr" or "Lr" is displayed
Press SW1 to change resolution
Clearing all the stored
Press the mode switch until CL appears on the LCD. Press
SW1 and after a beep the LCD starts to flash . Press SW1
again within 5 seconds and all and
the pictures are cleared.
the camera memory
Change mode to "CL"
"CL" is displayed
Press SW1 to select clear mode
LCD starts to flash
Press SW1 to clear the memory

Digital Camera Manager
After the welcome screen appears, click "Next".
..7..
How to Download Photo and Video to PC
Thank you for purchasing the Digital Camera. This guide will help you install
your camera onto your computer system.
Digital Camera Manager Installation
Place the CD into your CD-ROM and click on the Digital Camera
Manager Icon to begin the installation. If the CD does not automatically
display, simply go to "Start" then "Run" and select the path"D:\Setup.
exe". You may need to replace "D" with the letter that corresponds to
your CD-ROM drive.Now your computer is initializing the Wise Install-
ation Wizard. Please wait.
English

The dialog box that appears asks if you would like to restart your computer
now or later. Press "OK" to complete installation.
..8..
The CD begins installing the driver to the proper location.

USB
..9..
Start Digital Camera Manager
The digital pictures can be transferred at all times, even if you take only one
image. To connect your camera with your PC, you need a USB cable and
USB port. Your camera double beeps when successfully connected with
your PC. Don't worry! All of the stored images in your camera are still alive.
Your PC offers power for your camera. When disconnecting the USB cable,
your camera turns off automatically.
Connect the smaller end of the USB cable to
the USB port of your camera.
Plug the larger end of the USB cable to
the USB port of your PC.
Note: When plugged into a USB port,
your camera is powered by the PC. You
may remove the batteries. However, all
pictures are cleared when the USB cable is
unplugged.
=
=
English

.. 10 ..
Mode Selecting
=
=
Press the "Live View" button to change the camera to PC Camera mode.
Press the "DSC Function" button to change the camera to DSC &
Camcorder mode.
=
=
Live View (PC Camera Mode)
DSC Function (DSC Mode)
To start using the Digital Camera Manager, simply click on the "Start"
menu and go up to "Programs" Then go to the folder named "Digital
Camera Manager" and select it. This is the program where you can begin
to use your camera.

.. 11 ..
PC Camera Mode
It is easy to attach your camera to your system. our camera
is used as a standard PC camera.
In this mode, y
The current view is displayed in the "preview" window.
=
=
=
=
Press "Video Source" button to adjust
advanced settings.
Press "Video Format" button to set image
size.
Press "Snap Shot" button to capture an
image to the album window.
Press "Record button" to record a video clip
to album window.
PC Camera Mode
Live preview
=
=
English

.. 12 ..
DSC Mode
Transferring Photos:
This allows you to transfer photos in your camera.
Press the "Link" button to connect the camera and transfer photos.
Press the "Album" button to open the album window.
<
=
>Press the "Transfer all" or "Transfer selected" button to transfer photos
to the album window.
=
=
=
=
Transfer pictures in your camera
to your PC
Open or close album window
Transfer selected photos to
album window
Transfer all photos to album
window
Enhanced Resolution Mode:
The Largest Resolution : XGA( 800K pixels )
Optical Resolution: VGA ( 300K pixels)
Your camera has particular enhanced image skills, which make images
sharper by enhancing the original VGA image to XGA image.
How to operate:
=
=
=
=
Click the setting button.
Click " picture ".
Choose " Enhanced resolution ".
You can download your images again.

.. 13 ..
Playing picture:
You can play any picture file you want in the album
window by double clicking the picture icon to execute your default media
application.
browser or in the
Editing Photos:
It is easy to edit any photo you want in the album window. Double click the
photo icon to execute your default image application (such as Imaging,
Paint....etc.) to edit your image file.
Browerser
Album
Picture icon
English

.. 14 ..
Transferring Video:
After transferring images to the preview window, click AVI Creator and all
images are combined in one AVI file. This AVI file is saved in your album
folder.
Note: Pictures in AVI files can be placed forward or backward.
AVI Creator:
<
=
Select Images you want.
Press "Setting" button to adjust frame rate.
>Press "AVI Creator" button to create an AVI file.
AVI Creator
(Reverse)
AVI Creator

Playing Video:
You can play any video clip file (AVI format) you want in album window by
double clicking the AVI file icon to execute your default media application.
Image processing:
Click the" Image Process" button to choose image settings.
.. 15 ..
AVI Creator
Image Process
English

Album window:
Delete
Select All
Making Your Album Folders
Transferring Image and Sound Files
Click the button. All the files you select in the album window are cleared forever.
Therefore, you should be very careful with the delete button.
Click the button. You select all the files in the album window.
Click the button and key in your file name. Then you'll have a new album folder, which
can store lots of images or video files. If you want to cancel any of the album folders,
just select the album and click the delete button below.
Click the button. You transfer all the images and sounds in your camera to your PC.
Mail Function:
Click the "Mail" button to attach selected image to a new email document. it
is easy to send images to your family and friends!
.. 16 ..
Mail

Wiederaufladbare Batterie
1. Die Batterien waren ladungsfrei, bevor Sie geladen werden. Bevor Sie die
Kamera das erste Mal benutzen, verbinden Sie Kamera und PC mit dem
USB-Kabel, so dass die Batterien er den PC wiederaufgeladen werden.
Ein erstes Laden dauert mindestens 8 Stunden.
2.Nachdem die Kamera zwei oder drei Stunden benutzt wurde, fängt das
LCD an zu blinken, wodurch ein zu niedriger Ladezustand angezeigt wird.
Verbinden Sie Kamera und PC mit dem USB-Kabel. Die Batterien in der
Kamera werden über den PC aufgeladen, während Sie Fotos in den PC
laden. Die LED der wiederaufladbaren Batterien leuchtet grün, wenn die
Batterie voll aufgeladen ist; während des Aufladens leuchtet sie rot.
3.Werden die Batterien entnommen, gehen alle gespeicherten Bilder
verloren.
üb
..1..
Handhabung der Kamera
Einführung
Der eingebaute Speicher der Kamera ist beträgt 64 MBit. Es werden zwei
Auflösungsarten, High Resolution ( 640x480 VGA) für 26 Aufnahmen und
Low Resolution ( 320x240 QVGA ) für 107 Aufnahmen unterstützt. Außerdem
bietet die Kamera eine Reihe LCD-Funktionen, so wird etwa die noch
verbleibende Anzahl von Bildern angezeigt. Mit Hilfe eines USB-Kabels
können alle diese Bilder in den PC übertragen werden.
Deutsch

Ihrer Kamera
Ein/Aus-Schalter
Riemen Ring
..2..
LED der
wiederaufladbaren
Batterie
Linse
LCD-Anzeige
Sucher
Auslöser
(Sw1)
Modus-Wahlschalter
(Sw2)
USB-Anschluß

..3..
Funktionsauswahl
Die Kamera operiert mit zwei Knöpfe- den Modusknopf und den
Blendenknopf. Bei fortgesetztem Drücken des Modusknopfes zeigt das
LCD ”Hr, 26, Ct, St, CL, und Lr” Symbole, in dieser Reihenfolge. Mit dem
Blendenknopf wird das gewünschte Symbol ausgewählt. Hinweis! Wird
innerhalb von 5 Sekunden kein Symbol ausgewählt, kehrt das LCD wieder
zur Anzeige der noch verbleibenden Anzahl von Bildern zurück. Die
folgende Darstellung zeigt die Funktion eines jeden Symbols.
Drücken Sie die Taste SW2,
um zwischen den Funktionen umzuschalten.
Die jeweils ausgewählte Funktion erscheint in der Anzeige.
Drücken Sie die Taste SW1,
um den angezeigten Modus auszuwählen.
High Resolution ( für max. 26 Aufnahmen )
Verbleibende Anzahl von Bildern
Serien-Schnappschuss
10-Sekunden Selbstauslöser
Löschen aller Bilder
Low Resolution ( für max. 107 Aufnahmen )
Deutsch
