air Diverter Solutions Air Velocity Reducer Manual

Air Velocity Reducer Set-Up
Assemble on a at, clean surface for greater stability
No tools are required. Approximate assembly me: 15-20 min
Parts Provided:
 1 front panel with Air Diverter Soluons logo
 2 side panels (A, B)
 1 back panel with aached white inlet ange
 1 boom piece with 2 casters and 2 support legs installed
 1 top piece with handle
 1 lter tray
 2 baes
 1 lter
 16 gray boom assembly and front/back assembly thumb screws
with lock washers
 8 black top assembly service access thumb screws
8 – black thumb-
screws for top
Overview
12
34
SIDE
PANEL
slots
Stand the front panel (with logo) lengthwise, on its side with the
slots facing you and arrow poinng le . Add the boom panel to
the right side, with the wheels away from you, not down. Secure
with two gray thumbscrews.
Add the top panel to the le side, make sure the handle is towards
the back (in line with the wheels). Secure the top with 2 black
thumbscrews
Rotate the enre piece so the front panel is lying at on the ground
or clean surface.
Align arrows and insert the side panel into the long groove, slots
facing you. Secure to the bottom with two gray thumbscrews.
Secure to the top with two black thumbscrews. Insert filter tray
into filter tray slot near the top (left side). Insert one baffle into the
slot next to the filter tray. Tip: make sure the side panel is pushed
all the way into the groove, if not the screws will not line up/go in.
Filter Tray
Bae
Insert
gray
thumb-
screws
and
washers
Flange
Handle
A
BACK
PANEL

56
9
87
Insert the second side panel into the long groove so the slots are
facing inside and arrow is poinng to top panel. Tip: All arrows
should face the same direcon
Secure to the boom with 2 gray thumbscrews. Secure to the top
with 2 black thumbscrews. Note: Remove all the sckers from the
inside of the unit before proceeding to the next step.
Drop in the lter into the support tray.
NOTE: The airow direcon arrow on the side of the lter must
point up.
Slide the second bae into the last remaining slot.
Filter
Bae
Place the back panel, with the inlet ange facing up, on top of the
side panels and push gently to insert into the grooves.
Secure to the boom with 2 gray thumbscrews.
Flange
Secure to the top with 2 black thumbscrews.
Screw 4 gray thumbscrews in the back panel.
Black
Gray
Black
Gray
Stand the unit up. Add four gray thumbscrews on the front panel.
Make sure all thumbscrews are ghtened
The unit is now fully assembled. Tilt the handle towards you to
maneuver the unit.
Before connecng, make sure your HEPA scrubber is o. Fit the ex-
ible exhaust pipe over the Air Velocity Reducer inlet collar and se-
cure it ghtly using a clamp or a large zip e.
Cauon: The unit is heavy, do not use on uneven surfaces. Make
sure the unit is level before use.
Maintenance:
The 8 black service access thumb screws allow for easy access dur-
ing lter changes (recommended semiannually, depending on use)
Clean with a moist paper towel. The material is stain resistant.
However, for spill or stains a small amount of liquid dish soap can be
used.
Quesons? Comments?
For a step-by-step video, visit us at airdivertersoluons.com or
reach out to us at info@airdivertersoluons.com.
Congratulaons!
Your Air Velocity Reducer is ready to use.
Filter direcon arrow
B
A
