A/T SCANX ERASER
OPERATOR’S MANUAL

TABLE OF CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Cleaning Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Phosphor Storage Plate Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Phosphor Storage Plate Placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2

INTRODUCTION
Thank you for purchasing an Air Techniques A/T SCANX ERASER.
The A/T SCANX ERASER is designed to completely and efficiently erase all sizes of Phosphor Storage Plates (PSP).
We have designed and manufactured this A/T SCANX ERASER using the latest technology to give you many
years of dependable service. To ensure that your A/T SCANX ERASER gives you the highest level of service,
review and follow the guidelines outlined in this Operator’s Manual.
This Air Techniques equipment is warranteed to be free from defects in material and workmanship from the date
of installation for a period of twelve months.
Any item returned to our factory in Hicksville, New York, through an authorized dealer, will be repaired or replaced
at our option at no charge provided that our inspection shall indicate it to have been defective. Dealer, labor,
shipping and handling charges are not covered by this warranty.
This warranty does not apply to damage due to shipping, misuse, careless handling or repairs by other than
authorized service personnel. Air Techniques is not liable for indirect or consequential damage or loss of any
nature in connection with this equipment.
This warranty is in lieu of all other warranties expressed or implied. No representative or person is authorized to
assume for us any liability in connection with the sale of our equipment.
WARRANTY
3
DO NOT ATTEMPT INTERNAL SERVICE
The interior of the Main Assembly is only accessible by removing hardware with tools and
should only be opened and serviced by a Qualified Service Technician. Failure to heed this
warning may result in equipment damage or personal injury.
Please contact your local authorized Air Techniques dealer for service information.
WWAARRNNIINNGG::TToo
pprreevveenntt ffiirree oorr eelleeccttrriiccaall sshhoocckk,, ddoo nnoott eexxppoossee tthhiiss aapppplliiaannccee ttoo rraaiinn oorr mmooiissttuurree..
UUssee
ooff tthhee A/T SCANX ERASER nnoott iinn ccoonnffoorrmmaannccee wwiitthh tthhee iinnssttrruuccttiioonnss ssppeecciiffiieedd iinn tthhiiss
mmaannuuaallmmaayyrreessuullttiinnppeerrmmaanneennttffaaiilluurreeoofftthheeuunniitt..
SAFETY INSTRUCTIONS
This symbol alerts the
user that important
Operating and Main-
tenance instructions
have been included
with the unit. Read
carefully to avoid any
problems.
ATTENTION USERS:
Manufacturing date code on serial number label is in the format MMYY.
This symbol
represents
protective
Earth Ground

4
SPECIFICATIONS
MODELS: 73800, 73800C, 73800D & 73800J
Power Requirements: 108-265V AC, 50/60 Hz
0.75 A maximum
Environmental Conditions:
(Unit in Operation)
Temperature: 50°F to 105°F
Humidity: 5% to 95% Relative Humidity (Non-Condensing)
Installation Category: 2
Pollution Degree: 2
Erasing Surface Size: Erasing area 8” x 12”
Phosphor Storage Plate Capacity: All sizes, up to 21 Size 2 PSP’s.
See PHOSPHOR STORAGE PLATE PLACEMENT
for examples of more options.
Light Output: 25,000 lux minimum
Illumination Time: Approximately 35 seconds from last actuation of switch.
Bulb Rating: 24 Watt, two fluorescent bulbs.
Weight: 12 lbs.
CIRCUIT BREAKERS
REAR VIEW
MAGNETIC
LATCH
MAGNETIC
SWITCH
OPEN VIEW
ILLUMINATION
INDICATOR
FIG. 1

5
INSTALLATION
11-7/8”
5”
15-1/2”
TOP VIEW
FRONT VIEW SIDE VIEW
DIMENSIONS
The A/T SCANX ERASER may be located almost anywhere in the dental office.
Follow these guidelines for optimal performance.
- Place on a stable, flat counter top large enough to hold the Eraser and to provide a working area.
- Provide access to a standard grounded electric 115V AC outlet with supplied line cord.
220-240V, 50/60 Hz operation optional with corresponding line cord.
- The supplied line cord serves as the MAINS disconnection device.
FIG. 2

6
OPERATION
To operate A/T SCANX ERASER.
1. Open the A/T SCANX ERASER lid.
2. Place Phosphor Storage Plates (PSP’s) on A/T SCANX ERASER tray with blue or white side of PSP’s
facing up as suggested in FIG. 3 - 8.
3. Close the A/T SCANX ERASER lid.
4. The A/T SCANX ERASER will automatically start the erasing process and run for approximately 35
seconds to completely erase the PSP’s. The Illumination Indicator will be lit during the erasing process
and will turn off upon its completion.
Cleaning Instructions:
1. Disconnect the A/T SCANX ERASER by removing the supplied line cord from the unit.
2. Wipe the glass surface underneath the lid, and the grooves of the tray using a clean, damp cloth.
3. Wipe the surfaces again until they are dry with a dry cloth.
4. Once the cleaned surfaces have dried, reconnect the supplied line cord to the A/T SCANX ERASER.
PHOSPHOR STORAGE PLATE (PSP) HANDLING
Important: Completely erase Phosphor Storage Plates (PSP’s) prior to use.
Always allow the PSP’s to remain in Eraser until completion of cycle.
Use PSP’s within 24 hours of last ersasure. Repeat erasing process if PSP’s have been stored longer
than 24 hours.
Handle PSP’s with care.
- Avoid scratching or soiling PSP’s.
- Do not bend PSP’s or apply unnecessary pressure.
- Do not store PSP’s in a hot or moist area.
- Protect the PSP’s from direct sunlight and ultraviolet rays.
- Pick up the PSP’s using two fingers around the edges to avoid unnecessary contact with the plates.
Disposal of PSP’s.
Consult with your federal, national, state and local government, for rules and regulations on
disposal of PSP’s.

7
PHOSPHOR STORAGE PLATE (PSP) PLACEMENT
FIG. 4: ARRANGEMENT FOR 21 SIZE 2 PSP’s
FIG. 8: ONE 8” x 10” CEPH PSP
FIG. 5: ONE 5” x 12” PAN PSP
FIG. 7: ONE 15cm x 30cm PAN PSP
FIG. 6: ONE 5” x 12” PAN PSP & FOUR
SIZE 2 PSP’s
FIG. 3: SUGGESTED PSP ORIENTATION
Some Examples of PSP arrangements.

©Air Techniques, Inc. 2002
P/N 73961 Rev. C
