HS3000A4 Room Air Purifier
Assembly and Installation Instructions
AIRFILTRONIX
CLEAN AIR FOR INDUSTRY, MEDICINE & RESEARCH
Before assembly please check the contents of your packages
following the enclosed instructions.
The HS3000A4 Room Ari Purifier comprises:
1. Combined blower unit and filter housing
2. Filters , ordered separately (see Appendix A)
3. AC line cord with medical grade plug
(inside blower housing)
No tools are required for assembly

HS3000A4 Room Air Purifier Installation Instructions
1. Unpack the HS3000A4 blower unit and check for shipping damage.
Place on table or portable cart approximately 32-34” high. (see Figure 1).
2. Unsnap latches on either side of the blower enclosure ( see figure 1) and lift the blower unit off its base (see figure 2).
Remove the line cord packaged inside the enclosure and loosen the wingnuts on either side of the compression bar
until the bar can be lifted approximately 4-5 inches above the filter frame (see figure 3). Place blower base on top of
enclosure allowing the two 8” openings in underside of blower base to sit over the two 8” collars with closed cell
gaskets on top of the enclosure.
Unpack the filters supplied with the unit (see appendix A) and lift the compression bar. Install filter(s) into the filter frame
with its gasketed side down (see figure 4).
Figure 2
Figure 1
Figure 3
Figure 4

3. Tighten down both sides of the compression bar evenly with the wingnuts until the bar bends upward approximately
1/4 inch in the middle (see figure 5).
4. Re-install the motor housing on top of the filter mounting (see figure 6) base and retighten latches on either side of the
enclosure (see figure 7). On/Off switch should be facing the front of the unit.
5. Attach the power cord to the input connector on the left side of each motor housing and connect to any suitable 110V
outlet (220V model is available to special order) (see figure 8).
6. Check for operation by turning power knob on (see figure 9).
7. Fill out the filter history card(s), one for each type filter, (see figure 10) and place in clear pouch on the front of the
blower unit(s).
Figure 5 Figure 6
Figure 7 Figure 8
Figure 9 Figure 10

Regular Maintenance
Cabinet Cleaning -The surfaces of the enclosure can be cleaned with a solution of mild soapy water or Windex™ type glass
cleaner.
Under normal use the blower unit, which has a sealed bearing, should provide many years of uninterrupted use. There are no user
serviceable parts in the blower unit housing. The filters should be checked for performance and replaced on a regular basis.
Safety Procedures
There is a risk that internal parts of model HS-3000 blower unit may be contaminated with whatever substance the filter is intend-
ed to remove. When replacing filters please follow appropriate guidelines for handling materials the enclosure is being used to con-
tain. Wear OSHA approved gloves, safety glasses and filtered breathing mask.
Used filters should be placed in impermeable bags for disposal in accordance with local regulations.
For further information, call or write the Occupational Safety and Health Administration. Department of Labor, Washington, DC
[phone] or your local health department.
Filter Maintenance and Replacement
Turn off blower unit and remove line cord from blower. Unsnap latches on either side of blower unit and lift blower unit from filter
base. Loosen wingnuts to allow filter removal.
Remove old filters and place in heavy plastic bag. Follow reverse order of these instructions when installing new filters. The gas-
keted side of the filter should always be facing downward. The filter replacement history should be maintained using the card sup-
plied in the clear pouch on front of the blower.
Warranty
Airfiltronix warrants this product for one year from data of purchase. We will repair without charge, or replace at our discretion, any
defects due to faulty material or workmanship. Please return the unit in original packaging or suitable equivalent, transportation
prepaid and insured directly to us. This warranty does not apply to filters, accessories or damage caused by improper repair or
unauthorized repairs attempted by anyone other than by manufacturer.
