Airlinkplus AML001 User manual

PCI Modem Card
Quick Installation
Note：
：：
：If you encounter any problem during the installation
process, please refer to Manual in the provided CD.
For safety,
before installing and uninstalling your modem, please make sure
the telephone line is UNPLUGGED from your modem.
1. Hardware Installation
System Requirements
Before installation, please check the following requirements with
your equipment.
!Pentium®III or above
!32MB RAM or more
!One available PCI slot
!CD-ROM drive
!Windows 95®/ 98®/ Me®/ NT4.0®/ 2000® / XP®
Installing the Card
1. With the power to your PC disconnected, remove the PC's
casing.
2. Press the modem card firmly into the PCI slot, and secure it
with screws to your PC.
3. Reinstall the casing on your PC.
Connecting Your Modem
1. Plug one end of the phone cord into LINE jack and the other
end to the wall phone jack.
2. When you are not using the modem, you can use a telephone
on the modem’s phone line. Plug your telephone’s cord into
the modem’s PHONE jack.
The figure below illustrates the typical connection of internal
modem card.
2. Driver Installation
Once the hardware installation is finished, turn on your computer
and the system should detect the modem upon startup. Insert the
provided CD into your CD-ROM drive to start driver installation.
For Windows 95
1. Start Windows 95. When Update Device Driver Wizard
screen appears, click Next.
2. Click Other Locations.
3. Click Browse to locate the path of the driver:
X:\Driver\Win9x (where X is your CD-ROM drive letter) and
click OK.
4. Windows will find the location of driver; click Finish.
5. When Insert Disk window appears, click OK.
6. Click Browse to locate the path of the driver:
X:\Driver\Win9x (where X is your CD-ROM drive letter) and
click OK.
7. Windows will continue to detect another device. Click Next.
8. Repeat steps 2-4 to complete installation.
For Windows 98
1. Start Windows 98. When Add New Hardware Wizard screen
appears, click Next.
2. Select Search for the best driver for your device and click
Next.
3. Check Specify a location. Click Browse to locate the path of
the driver: X:\Driver\Win9x (where X is your CD-ROM
drive letter) and click OK. Click Next.
4. Windows will find the location of driver; click Next.
5. Click Finish.
6. Windows will continue to detect another device. Click Next.
7. Repeat steps 2-5 to complete installation.
For Windows Me
1. Start Windows Me. When Add New Hardware Wizard
screen appears, select Specify the location of the driver and
click Next.
2. Select Search for the best driver for your device and then
check only the Specify a location box. Click Browse to locate
the path of the driver: X:\Driver\WinME (where X is your
CD-ROM drive letter) and click Next.
3. Windows will find the driver file for the device. Click Next.
4. Click Finish.
5. Windows will continue to detect another device. Repeat Steps
1-4.
6. When New Hardware Found message appears, wait for
Windows to complete the installation.
For Windows NT4.0
1. Click Start menu and then click Run. Click Browse to open
the file Setup.exe from X:\Driver\NT40 where X is your CD-
ROM drive letter and click OK.
2. When confirm message appears, click OK.
3. When prompted to restart your computer, click OK.
For Windows 2000
1. Start Windows 2000. Windows will detect a new hardware
device, click Next to continue.
2. Select Search for a suitable driver… and click Next.
3. Check ONLY Specify a location and click Next.
4. Click Browse to locate the path of the driver: X:\Driver\W2K
(where X is your CD-ROM drive letter) and click OK.
5. When Windows finds the location of the driver, click Next.
6. If Digital Signature Not Found window appears, click Ye s to
continue.
7. Click Finish. When Found New Hardware window appears,
wait for Windows to complete the installation.

For Windows XP
1. When Found New Hardware Wizard screen appears, select
Install from a list or specific location (Advanced) and click
Next.
2. With Search for the best driver in these locations selected,
select ONLY Include this location in the search. Click
Browse to locate the path of the driver: X:\Driver\WinXP
( where X is your CD-ROM drive letter) and click Next.
3. If compatibility prompt message appears, click Continue
Anyway.
4. Click Finish. When Found New Hardware screen appears,
wait for completing the installation.
3. Country Selection
Before starting the modem for the first time, you may need to
specify the country where you locate upon different
telecommunication regulations/laws. If country selection is
finished during installation, just ignore this step.
For Windows 95/98/Me/NT4.0
1. Click Start | Settings | Control Panel | Modems.
2. In Modems Properties window, highlight Agere Systems
PCI Soft Modem and click Dialing Properties.
3. From the drop-down list of I am in (for Windows 95) or I am
in this country/region (for Windows 98/Me/NT4.0), select a
country where your modem is to be used and click Apply
(for Windows 98/Me/NT4.0) and then OK.
For Windows 2000/XP
1. Click Start | Settings | Control Panel | Phone and Modem
Options.
2. On the Dialing Rules tab, select the location from which you
are dialing and then click Edit.
3. On the General tab, from the drop-down list of
Country/region select the country where your modem is to be
used. Click Apply and then click OK.
4. Verify Modem Installation
For Windows 95/98/Me
1. Click Start | Settings | Control Panel | Modems.
2. Click the Diagnostics tab.
3. Highlight the COM port used by your modem and then click
More Info….
For Windows 2000/XP
1. Click Start | Settings | Control Panel | Phone and Modem
Options.
2. Click the Modems tab. Highlight Agere Systems PCI Soft
Modem and then click Properties.
3. Click the Diagnostics tab and then click Query Modem.
Final Verification
Wait for communication with your modem. If your modem is
properly installed, the command response (something like AT…)
should appear on the screen.
If your modem fails to respond, you will see an error message.
Make sure your modem is properly connected. Switch your
modem off and on, and try again. If your modem still fails to
respond, you may need to remove the driver and reinstall again.
5. Software Uninstallation
If you need to remove the modem card from your PC, you should
uninstall the software of your modem as follows. Then shut down
your computer to remove the modem card from the PCI slot.
If you need to reinstall/update driver, after uninstalling the
software and restarting your PC, follow the installation
procedures to install required driver.
For Windows 98/Me/NT4.0
1. Click Start | Settings | Control Panel | Add/Remove
Programs.
2. Select Agere Systems PCI Soft Modem (or Agere System
Soft Modem for NT4.0 ) from the list and click Add/Remove.
3. Click Ye s to remove the components.
4. When prompted to restart your computer, select Yes or No as
required.
For Windows 2000/XP
1. Click Start | Settings | Control Panel | Add/Remove
Programs (or Add or Remove Programs for Windows XP).
2. Highlight Agere Systems PCI Soft Modem and then click
Change/Remove.
3. Click Ye s to remove the components.
4. When prompted to restart your computer, select Yes or No as
required.
