AirLive WT-2000 USB User manual

WT
-2000 USB
Turbo-G Wireless LAN Card
Use
r
’s Manual

Declaration of Conformity
We, Manufacturer/Importer
Declare that the product
Turbo-G USB Adapter
is in conformity with
In accordance with 89/336 EEC-EMC Directive and 999/5 EC-R & TTE Directive
Clause Description
Electromagnetic compatibility and Radio spectrum Matters (ERM);
Essential requirements under article 3.2 of the R&TTE Directive
Electromagnetic compatibility and Radio spectrum Matters (ERM);
(2 4-11) Electromagnetic compatibility(EMC) standard for radio equipment and
HIPERLAN equipment
Generic standard to demonstrate the compliance of low power
Electronic and electrical apparatus with the basic restrictions related
to human exposure to electromagnetic field ( 0MHz – 300GHz)
-General public
Safety for information technology equipment including electrical
Business equipment
Manufacturer/Importer
Position/ Title : Vice President
OvisLink Corp.
5F., NO.6, Lane 13 , Min-Chuan Rd.,
Hsin-Tien City, Taipei County, Taiwan
AirLive WT-2 USB
■ EN 3 328 V1.6.1
(2 4-11)
Wideband transmission equipment operating in the 2.4GHz ISM band
And using spread spectrum modulation techniques; Part ：technical
Characteristics and test conditions Part2：Harmonized EN covering
■ EN 3 1 489-1 V1.5.1
■ EN 3 1 489-17 V1.2.1
Services; Part 7：Specific conditions for wideband data and
(2 2- 8)
■ EN 5 371:2 2
■ EN 6 95 -1: 2 1/A11
:2 4
■ CE marking
Signature：
Name ：
Albert Yeh
Date： 2 7/1/4
(Stamp)

AirLive WT-2000USB CE Declaration Statement
Country Declaration Country Declaration
cs
Česky [Czech]
OvisLink Corp. tímto prohlašuje, že tento irLive
WT-2000USB je ve shodě se základními
požadavky a dalšími příslušnými ustanoveními
směrnice 1999/5/ES.
lt
Lietuvių
[Lithuanian]
Šiuo OvisLink Corp. deklaruoja, kad šis irLive WT-
2000USB atitinka esminius reikalavimus ir kitas
1999/5/EB Direktyvos nuostatas.
da
Dansk [Danish]
Undertegnede OvisLink Corp. erklærer herved,
at følgende udstyr irLive WT-2000USB
overholder de væsentlige krav og øvrige
relevante krav i direktiv 1999/5/EF.
nl
Nederlands [Dutch
Hierbij verklaart OvisLink Corp. dat het toestel irLive
WT-2000USB in overeenstemming is met de
essentiële eisen en de andere relevante bepalingen
van richtlijn 1999/5/EG.
de
Deutsch
[German]
Hiermit erklärt OvisLink Corp., dass sich das
Gerät irLive WT-2000USB in Übereinstimmung
mit den grundlegenden nforderungen und den
übrigen einschlägigen Bestimmungen der
Richtlinie 1999/5/EG befindet.
mt
Malti [Maltese]
Hawnhekk, OvisLink Corp, jiddikjara li dan irLive
WT-2000USB jikkonforma mal-ħtiġijiet essenzjali u
ma provvedimenti oħrajn relevanti li hemm fid-
Dirrettiva 1999/5/EC.
et
Eesti [Estonian]
Käesolevaga kinnitab OvisLink Corp. seadme
irLive WT-2000USB vastavust direktiivi
1999/5/EÜ põhinõuetele ja nimetatud direktiivist
tulenevatele teistele asjakohastele sätetele.
hu
Magyar
[Hungarian]
z OvisLink Corporation kijelenti, hogy az irLive
WT-2000USB megfelel az 1999/05/CE irányelv
alapvető követelményeinek és egyéb vonatkozó
rendelkezéseinek.
en
English
Hereby, OvisLink Corp., declares that this irLive
WT-2000USB is in compliance with the essential
requirements and other relevant provisions of
Directive 1999/5/EC.
pl
Polski [Polish]
Niniejszym OvisLink Corp oświadcza, że irLive WT-
2000USB jest zgodny z zasadniczymi wymogami
oraz pozostałymi stosownymi postanowieniami
Dyrektywy 1999/5/EC.
es
Español
[Spanish]
Por medio de la presente OvisLink Corp. declara
que el irLive WT-2000USB cumple con los
requisitos esenciales y cualesquiera otras
disposiciones aplicables o exigibles de la
Directiva 1999/5/CE.
pt
Português
[Portuguese]
OvisLink Corp declara que este irLive WT-2000USB
está conforme com os requisitos essenciais e outras
disposições da Directiva 1999/5/CE.
el
Ελληνική [Greek]
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ OvisLink Corp. ΔΗΛΩΝΕΙ
ΟΤΙ irLive WT-2000USB ΣΥΜΜΟΡΦΩΝΕΤΑΙ
ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ
ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ
1999/5/ΕΚ.
sl
Slovensko
[Slovenian]
OvisLink Corp izjavlja, da je ta irLive WT-2000USB
v skladu z bistvenimi zahtevami in ostalimi
relevantnimi določili direktive 1999/5/ES.
fr
Français [French]
Par la présente OvisLink Corp. déclare que
l'appareil irLive WT-2000USB est conforme aux
exigences essentielles et aux autres dispositions
pertinentes de la directive 1999/5/CE
sk
Slovensky [Slovak]
OvisLink Corp týmto vyhlasuje, že irLive WT-
2000USB spĺňa základné požiadavky a všetky
príslušné ustanovenia Smernice 1999/5/ES.
it
Italiano [Italian]
Con la presente OvisLink Corp. dichiara che
questo irLive WT-2000USB è conforme ai
requisiti essenziali ed alle altre disposizioni
pertinenti stabilite dalla direttiva 1999/5/CE.
fi
Suomi [Finnish]
OvisLink Corp vakuuttaa täten että irLive WT-
2000USB tyyppinen laite on direktiivin 1999/5/EY
oleellisten vaatimusten ja sitä koskevien direktiivin
muiden ehtojen mukainen
lv
Latviski [Latvian]
r šo OvisLink Corp. deklarē, ka irLive WT-
2000USB atbilst Direktīvas 1999/5/EK
būtiskajām prasībām un citiem ar to saistītajiem
noteikumiem.
Íslenska [Icelandic]
Hér með lýsir OvisLink Corp yfir því að irLive WT-
2000USB er í samræmi við grunnkröfur og aðrar
kröfur, sem gerðar eru í tilskipun 1999/5/EC.
sv
Svenska
[Swedish]
Härmed intygar OvisLink Corp. att denna irLive
WT-2000USB står I överensstämmelse med de
väsentliga egenskapskrav och övriga relevanta
bestämmelser som framgår av direktiv
1999/5/EG.
no
Norsk [Norwegian]
OvisLink Corp erklærer herved at utstyret irLive WT-
2000USB er i samsvar med de grunnleggende krav
og øvrige relevante krav i direktiv 1999/5/EF.
copy of the full CE report can be obtained from the following address:
OvisLink Corp.
5F, No.6 Lane 1 0,
Min-Chuan Rd, Hsin-Tien City,
Taipei, Taiwan, R.O.C.
This equipment may be used in T, BE, CY, CZ, DK, EE, FI, FR, DE, GR, HU, IE, IT, LV, LT, LU, MT, NL, PL, PT, SK,
SI, ES, SE, GB, IS, LI, NO, CH, BG, RO, TR

AirLive WT-2000USB User’s Manual
1
COPYRIGHT
Copyright ©2005/2006 by this company. All rights reserved. No part of this
publication may be reproduced, transmitted, transcribed, stored in a retrieval system,
or translated into any language or computer language, in any form or by any means,
electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the
prior written permission of this company
This company makes no representations or warranties, either expressed or implied,
with respect to the contents hereof and specifically disclaims any warranties,
merchantability or fitness for any particular purpose. Any software described in this
manual is sold or licensed "as is". Should the programs prove defective following their
purchase, the buyer (and not this company, its distributor, or its dealer) assumes the
entire cost of all necessary servicing, repair, and any incidental or consequential
damages resulting from any defect in the software. Further, this company reserves the
right to revise this publication and to make changes from time to time in the contents
hereof without obligation to notify any person of such revision or changes.
All brand and product names mentioned in this manual are trademarks and/or
registered trademarks of their respective holders.
Federal Communication Commission
Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution
This equipment must be installed and operated in accordance with provided
instructions and a minimum 20 cm spacing must be provided between computer
mounted antenna and person’s body (excluding extremities of hands, wrist and feet)

AirLive WT-2000USB User’s Manual
2
during wireless modes of operation.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the authority to operate equipment.
Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled
environment. In order to avoid the possibility of exceeding the FCC radio frequency
exposure limits, human proximity to the antenna shall not be less than 20cm (8 inches)
during normal operation.
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
R&TTE Compliance Statement
This equipment complies with all the requirements of DIRECTIVE 1999/5/EC OF THE
EUROPEAN PARLIAMENT AND THE COUNCIL of March 9, 1999 on radio
equipment and telecommunication terminal Equipment and the mutual recognition of
their conformity (R&TTE)
The R&TTE Directive repeals and replaces in the directive 98/13/EEC
(Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As
of April 8, 2000.
Safety
This equipment is designed with the utmost care for the safety of those who install and
use it. However, special attention must be paid to the dangers of electric shock and
static electricity when working with electrical equipment. All guidelines of this and of
the computer manufacture must therefore be allowed at all times to ensure the safe
use of the equipment.
EU Countries Intended for Use
The ETSI version of this device is intended for home and office use in Austria,
Belgium, Denmark, Finland, France, Germany, Greece, Ireland, Italy, Luxembourg,
the Netherlands, Portugal, Spain, Sweden, and the United Kingdom.
The ETSI version of this device is also authorized for use in EFTA member states:
Iceland, Liechtenstein, Norway, and Switzerland.
EU Countries Not intended for use
None.

AirLive WT-2000USB User’s Manual
3
CONTENTS
CHAPTER I: INTRODUCTION ..................................................................... 4
1.1 Features ......................................................................................................... 5
1.2 Specifications ................................................................................................. 5
1.3 Package Contents .......................................................................................... 5
CHAPTER II: INSTALLATION PROCEDURE ............................................... 7
2.1 Install the Hardware .......................................................................................... 7
2.2 Install the Driver and Utility ............................................................................... 7
CHAPTER III: CONFIGURATION UTILITY ................................................. 10
3.1 Site Survey ................................................................................................... 13
3.2 Profile ........................................................................................................... 14
3.2.1 Configure the Profile ............................................................... 15
3.2.1.1 Configuration............................................................................ 16
3.2.1.2 Authentication and Security...................................................... 18
3.2.1.3 802.1x Setting-Certification ...................................................... 21
3.2.1.4 802.1x Setting-CA Server......................................................... 23
3.3 Link Status .................................................................................................... 24
3.4 Advance........................................................................................................ 25
3.5 About ............................................................................................................ 28
3.6 Turbo Mode................................................................................................... 28
3.7 WMM Function ............................................................................................. 29
CHAPTER IV: TROUBLESHOOTING ......................................................... 31

Chapter I: Introduction
Thank you for purchasing the 802.11g Wireless LAN PCI Card. This card complies with IEEE 802.11g
standard, which supports up to 54Mbps high-speed wireless network connections. It can also work with
IEEE 802.11b devices. When the card connects to 11b devices, the link speed will be up to 11Mbps.
This card enables higher data throughput than the IEEE 802.11g standard (up to 54Mbps). It supports
specific ways to increase the data transfer rate at a time; compress the data and decrease the waiting
time to send the next data to the Routers or APs. This feature is called Turbo Mode. When the card is
connecting to the Routers or APs with the proprietary Turbo Mode feature, the wireless network will be
more effective.
For WLAN security issues, this card supports 64/128-bit WEP data encryption that protects your
wireless network from eavesdropping. It also supports WPA (Wi-Fi Protected Access) feature that
combines IEEE 802.1x and TKIP (Temporal Key Integrity Protocol) technologies. Client users are
required to authorize before accessing to APs or AP Routers, and the data transmitted in the network is
encrypted/decrypted by a dynamically changed secret key. Furthermore, this card supports WPA2
function, WPA2 provides a stronger encryption mechanism through AES (Advanced Encryption
Standard), which is a requirement for some corporate and government users.
When you use the devices such as Voice over Internet Protocol (VoIP) phones, televisions, VCRs and
MP3 players, how can you speed up the audio, video and voice data to pass through the wireless
network? IEEE 802.11e Quality of Service (QoS) (The Wi-Fi Alliance defined WMM as a profile of the
IEEE 802.11e) extensions for 802.11 networks will help to define the priorities of the data traffics by the
data categories to provide enhanced multimedia support. This card supports the advanced technology
for sure.
The power consumption of the card is also very low. This card provides several levels of power saving
modes allowing user customizes the way of saving the power from his/her portable or handheld
devices.
This card is cost-effective, together with the versatile features; it is the best solution for you to build your
wireless network.

AirLive WL-1000CAM User’s Manual
5
1.1 Features
•Works with both IEEE 802.11b and IEEE 802.11g products.
•High-speed transfer data rate - up to 54Mbps.
•Supports Turbo Mode to enhance the data transfer speed within the specific wireless
network.
•Supports WMM function to meet the multi-media data bandwidth requirement.
•Supports 64/128-bit WEP, WPA (TKIP with IEEE 802.1x), WPA2 (AES with IEEE 802.1x)
functions for high level of security.
•Detachable antenna with long length cable provides convenience to locate the antenna.
•Automatic fallback increases data security and reliability.
•Supports the most popular operating system: Windows 98SE/Me/2000/XP.
•Supports 32-bit PCI interface.
1.2 Specifications
•Standard: IEEE 802.11b/g
•Interface: 32-bit PCI
•Frequency Band: 2.4000 ~ 2.4835GHz (Industrial Scientific Medical Band)
•Modulation: OFDM with BPSK, QPSK, 16QAM, 64QAM (11g)
BPSK, QPSK, CCK (11b)
•Data Rate: 54/48/36/24/18/12/11/9/6/5.5/2/1Mbps auto fallback
•Security: 64/128-bit WEP Data Encryption, WPA (TKIP with IEEE 802.1x), WPA2 (AES with
IEEE 802.1x)
Note: WPA2 is enabled in Windows 2000/XP.
•Antenna: External detachable dipole antenna (Connector: RP-SMA connector, Cable Length:
94 cm)
•Drivers: Windows 98SE/Me/2000/XP
•LEDs: Link, TX/RXTransmit Power: 16dBm~18dBm
•Dimension: 19(H) x 130(W) x 121(D) mm
•Weight: 46g
•Temperature: 32~131°F (0 ~ 55°C)
•Humidity: Max. 95% (NonCondensing)
•Certification: FCC, CE
1.3 Package Contents
Before you begin the installation, please check the items of your package. The package should include
the following items:

AirLive WT-2000USB User’s Manual
6
•One PCI Card
•One CD (Driver/Utility/User’s Manual.)
•One Quick Guide
If any of the above items is missing, contact your supplier as soon as possible.

AirLive WL-1000CAM User’s Manual
7
Chapter II: Installation Procedure
Before you proceed with the installation, please notice following descriptions.
Note1: The following installation was operated under Windows XP. (Procedures are similar for
Windows 98SE/Me/2000.)
Note2: If you have installed the Wireless PCI Card driver & utility before, please uninstall the old
version first.
2.1 Install the Hardware
A. Turn off your computer and remove its cover.
B. Insert the PCI card to an available PCI slot firmly.
C. Secure this card to the rear of the computer chassis and put back the cover.
D. Secure the antenna to the antenna connector of the card.
E. Turn on the computer.
2.2 Install the Driver and Utility
A. “Found New Hardware Wizard” is displayed after the PCI card is installed and the computer
is restarted. Click “Cancel”.

AirLive WT-2000USB User’s Manual
8
B. Insert the Installation CD to your CD-ROM Drive. Execute the “setup” program.
C. Click “Next” to process the installation if you accept the license agreement.
D. The system starts to install the software of the card.

AirLive WL-1000CAM User’s Manual
9
E. The system will automatically detect the card and display “Hardware Installation” screen.
Click “Install” to continue.
F. Please click “Finish” to complete the installation.

AirLive WT-2000USB User’s Manual
10
Chapter III: Configuration Utility
The Configuration Utility is a powerful application that helps you configure the PCI card and monitor the
link status and the statistics during the communication process.
When the card is installed, the configuration utility will be displayed automatically. This card will auto
connect to wireless device which has better signal strength and no wireless security setting.
The Configuration Utility appears as an icon on the system tray of Windows while the card is running.
You can open the utility by double-click on the icon.
Right click the icon, there are some items for you to operate the configuration utility.
zLauch Config Utilities
Select “Lauch Config Utilities” to open the Configuration Utility tool.
zUse Zero Configuration as Configuration Utility
zSelect “Use Zero Configuration as Configuration Utility” to use Windows XP built-in wireless
configuration utility (Windows Zero Configuration) to configure the card.
zExit
Select “Exit” to close the Configuration Utility tool.
In Windows XP, there is a “Windows Zero Configuration Tool” for you to setup wireless clients. By

AirLive WL-1000CAM User’s Manual
11
default, this “Windows Zero Configuration Tool” is enabled. If you want to use the Utility for the card,
please follow one of the ways as below.
First Way
Right click the icon in the system tray and select “Use RaConfig as Configuration Utility”.
Second Way
A. Right-click the icon and select “View Available Wireless Networks”.
B. Click “Advanced”.

AirLive WT-2000USB User’s Manual
12
C. Uncheck “Use Windows to configure my wireless network settings” to enable the utility for the
card.
Note: If “Wireless Zero Configuration” is enabled, you can only configure the advance setting or check
the link status and statistics from the configuration utility of the card.

AirLive WL-1000CAM User’s Manual
13
3.1 Site Survey
When you open the Configuration Utility, the system will scan all the channels to find all the access
points/stations within the accessible range of your card and automatically connect to the wireless
device with the highest signal strength. From the “Site Survey”, all the networks nearby will be listed.
You can change the connection to another networks or add one of the networks to your own profile list.
Parameter Description
Available Networks This list shows all available wireless networks within range of your
card. It also displays the information of the networks including the
SSID, BSSID, Signal Strength, Channel, Encryption,
Authentication and Network Type. If you want to connect to any
networks on the list, double-click the item on the list, and the card
will automatically connect to the selected network.
Rescan Button Click “Rescan” button to collect the new information of all the
wireless networks nearby.
Connect Button Click “Connect” to connect to the selected network.
Add to Profile Button Add the selected network to Profiles list.

AirLive WT-2000USB User’s Manual
14
3.2 Profile
The “Profiles List” is for you to manage the networks you connect to frequently. You are able to
Add/Delete/Edit/Activate a profile.
Parameter Description
Profiles List The profiles list display all the profiles and the relative settings of
the profiles including Profile Name, SSID, Channel, etc.
This sign indicates the activated profile is been connecting.
This sign indicates the activated profile is not been
connecting.
Add/Delete/Edit Button Click these buttons to add/delete/edit the selected profiles.
Activate Button Click “Activate” to connect to the selected profile. When a profile is
activated, the card will be initially connected to the profile.

AirLive WL-1000CAM User’s Manual
15
3.2.1 Configure the Profile

AirLive WT-2000USB User’s Manual
16
3.2.1.1 Configuration
Parameter Description
Profile Name Define a recognizable profile name for you to identify the different
networks.
SSID The SSID (up to 32 printable ASCII characters) is the unique name
identified in a WLAN. The ID prevents the unintentional merging of two
co-located WLANs.
You may specify a SSID for the card and then only the device with the
same SSID can interconnect to the card. If you want to add the network
nearby to the profile list, pull down the menu, all the networks will be
listed for you to add one of them to the profile list.
Parameter Description
PSM (Power Saving Mode) The power saving function is only available when the network type is in
Infrastructure.
CAM (Constantly Awake Mode) – The card will always set in active
mode.
PSM (Power Saving Mode) – Enable the card in the power saving
mode when it is idle.
Network Type Infrastructure – This operation mode requires the presence of an
802.11 Access Point. All communication is done via the Access Point or
Router.
Ad-Hoc – Select this mode if you want to connect to another wireless
stations in the Wireless LAN network without through an Access Point
or Router.
TX Power If you want to lower the transmit power of the card for saving the power
of the system, you can select the lower percentages from the list. The
lower power will cause the lower signal strength and the coverage
range.
Ad Hoc Wireless Mode When the card is set in Ad Hoc (Peer to Peer Mode), you can designate
the wireless connection mode for the Ad Hoc network.
802.11 B only – This card can be compatible with both 802.11g and
802.11b wireless stations. If there are only 802.11b wireless stations in
the network, you can set the card to this mode.
802.11 B/G mix – If you have a mix of 802.11b and 802.11g wireless
stations in your network, it is recommended to setting the card to this
mode. This mode is also the default setting.
802.11 G only – This card can be compatible with both 802.11g and
802.11b wireless stations. If there are only 802.11g wireless stations in
the network, you can set the card to this mode.
Preamble The preamble defines the length of the CRC block for communication

AirLive WL-1000CAM User’s Manual
17
among wireless devices. This option is only active in the Ad Hoc
network.
There are two modes including Auto and Long Preamble. If
“Auto“ mode is selected, the card will auto switch the preamble mode
depending on the wireless devices the card is connecting to.
Parameter Description
RTS Threshold Minimum packet size required for an RTS (Request To Send). For
packets smaller than this threshold, an RTS is not sent and the packet
is transmitted directly to the wireless network. Select a setting within a
range of 0 to 2347 bytes. Minor change is recommended.
Fragment Threshold The value defines the maximum size of packets; any packet size larger
than the value will be fragmented. If you have decreased this value and
experience high packet error rates, you can increase it again, but it will
likely decrease overall network performance. Select a setting within a
range of 256 to 2346 bytes. Minor change is recommended.
Channel This setting is only available for Ad Hoc mode. Select the number of the
radio channel used for the networking. The channel setting should be
the same with the network you are connecting to.
