Airmega 400S User manual
The following features are available for our Airmega Air Purifier.
Airmega’s pollution sensor tells you the indoor air quality in real-time.
The brightly colored LED ring lets you know if your indoor air is fresh or
unhealthy every minute of the day.
▶
AUTO
With Smart Mode, Airmega adapts to its surroundings. Fan speeds
automatically adjust based on the room’s air quality and room
conditions.
▶
With Airmega’s smartphone app, you can monitor the air quality inside
your home, see the status of the filters, schedule the timer, receive
real-time outdoor air quality updates, and even remotely activate the
Airmega. (400S and 300S only)
▶
The Max2 filter (an activated carbon filter plus Green True HEPA filter)
reduces more than 99% of volatile organic compounds (VOCs), odors
such as NH3, CH3CHO. It also captures and reduces up to 99.97 % of
airborne particles in the air such as pollen, pollution, and other allergens.
▶
With status alerts for the Max2 Filters and the Pre-filters, you’ll know
when it’s time to replace them. And because the Airmega gauges how
much air has traveled through it, you can be sure the notifications are
accurate.
▶
EN
Before operating the product, you must remove the plastic wrapping of the inserted Max2 filters on both sides.
For details, see page 14.
1 2
3
4
56
FRONT/전면/前
FRONT/전면/前
1
2
1
2
3
2
1
4
568
7
3
AIRMEGA
A
B
**
*
456
(400S/300S only)
Before connecting the air purifier and your smart phone, you must first download the Airmega App from Apple App
Store or Google Play Store. For more details, see page 16.
For Android, step 4, 5, and 6 will be proceeded automatically.
If the connection is completed
successfully,
the [Wi-Fi] indicator will be on.
* Advanced Settings to enter
the static IP address
EN
01 BEFOREUSINGTHEPRODUCT
02 PREPARATION
03 INSTALLATION
(400S/300S only)
04 OPERATION
05 MAINTENANCE
06 APPENDIX
The following symbols are used in this manual to explain procedures, restrictions, handling precautions, and
instructions that should be observed for safety.
WARNING
Warning indicates a potentially hazardous situation that may result in death or severe injury to the user or others.
CAUTION
Caution indicates a potentially hazardous situation that may result in injury to the user or others, or the loss of property.
NOTE
Note indicates useful tips or additional information for procedures and product use.
[ ]
This square bracket represents control buttons and indicators on the product.
e.g., [Power]
Illustrations used in this manual are of the 400S unless specified.
Read and follow all the safety tips and warnings before using the product.
01 BEFORE USING THE PRODUCT
WARNING
• Do not exceed the voltage and power rating of the power
outlet or connection device. This may generate excessive
heat and cause electric shock or fire.
• Only use the appropriate type of electric socket for the
product. Connecting the product to an incorrect socket
may result in damage.
• Do not immerse the product or any of its parts in water.
Operate the product only after a qualified technical
examines and replaces the parts that were under water.
• Do not touch the power plug with wet hands.
• If the electric outlet is wet, do not connect the power
plug of the product. Wait till the electric outlet dries
completely before use.
• Do not operate the product if the motor fan fails to
operate or is damaged.
• Disconnect the power plug from the electric outlet
if strange sounds, smells, or smoke come from
the product. Contact the customer service center
immediately for instructions.
• Disconnect the power plug from the electric outlet when
the product is not in use and before cleaning, inspecting,
or replacing parts.
• Use a dedicated electric outlet for the product. Do
not connect the product to a power strip that has
connections to several other products.
• Do not operate the product if the power plug or cords are
damaged.
• Do not forcibly bend, twist, pinch, or damage the power
cord.
• Do not force the power plug into an incorrect electric
outlet or into a loose electric outlet. Contact a qualified
technician to install a proper electric outlet.
• A damaged power plug or cord must be replaced by the
manufacturer or a qualified technician.
EN
• Remove the power plug from the electric outlet by
grasping the power plug and pulling it gently. Never
pull the cord to remove the power plug.
• Keep the electric cord away from heat sources.
• Do not repair the product unless this manual
recommends it. Doing so will void your warranty.
All repair work must be carried out by a qualified
technician.
• This product has a polarized plug (one blade is wider
than the other). To reduce the risk of electric shock, this
plug is intended to fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician.
Do not attempt to defeat this safety feature.
• Do not use this product in industrial areas or factories
where oil, grease, or dust particles may be present. This
product is for household use only.
• Do not change the filter while the product is operating.
Always turn off the product and unplug the power plug
before accessing the components inside the product.
• Do not place the product near a humidifier or in humid
areas, such as bathrooms or laundry rooms, where the
product may come into contact with water.
• Do not place the product near flammable gases,
cigarettes, incense, and other combustible materials.
• Do not place the product on a bed or against soft
objects, such as curtains.
• Do not clean the product using detergents, paint
thinner, or other household solvents.
• Do not spray insecticides or other flammable materials
near the product.
• This product contains a chemical known to the State
of Califonia to cause cancer and birth defects or other
reproductive harm.
(California law requires this warning to be given to
customers in the State of California)
CAUTION
• This product should not be used by children under 8
without supervision.
• This product should not be used by persons with
reduced physical, sensory, or mental capabilities or
lack of experience without supervision or instruction
concerning to the use of the product in a safe way and
understand the hazards involved.
• Do not allow children to play with the plastic wrapping
and product.
• Do not use this product with any solid-state speed
control device, as it may result in electric shock or fire.
• Do not use an adapter or extension cord, as it may
cause fire, shock, or personal injury.
• Do not use attachments or filters not recommended by
the manufacturer.
• Exercise caution while removing the components from
the product. Ensure that your body parts do not get
stuck or scratched while servicing the product.
• Do not insert any objects or finger into the openings
of the product. If any objects fall into the openings,
immediately turn off the product and unplug the
power plug. Contact a qualified technician or the
manufacturer to remove the object.
• Do not wash or reuse the Max2 filters.
• Do not block the air outlet of the product. Doing so may
decrease the efficiency of the product and increase the
risk of injury.
• This product is for household use as described in this
manual. Using it in an industrial environment or any
other place not recommended by the manufacturer
and may result in electric shock, fire, and injury to
person.
• Do not place anything on top of the product.
• Do not run the power cord under carpets or cover it
with rugs.
• Change the filters at the recommended intervals so that
excess dust does not accumulate.
• Do not place the product where the both sides of
product are blocked.
• Do not place the product in direct sunlight.
• Do not place the product next to or on windows.
• Place the product on a firm, flat, and dry surface that
provides sufficient air circulation.
• Keep the product and its cord out of way, where it
cannot be stepped on or tripped over.
• The end user has to be informed to keep at least 20 cm
separation with the antenna while this end product is
installed and operated.
• Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Before installing the air purifier, make sure all of the components are present. If any items are missing or damaged,
contact the customer service center.
02 PREPARATION
* These are installed in the main unit.
Captures large particles like
hair, fur, and dust by micro
mesh.
Captures and reduces more
than 99 % of VOCs and
odors such as NH3, CH3CHO.
It also captures and reduces
up to 99.97 % of airborne
particles, allergens, and
contaminants down to 0.3
microns in size.
EN
Check the parts of the product (exterior in the front and top view and control panel) and how they function.
Check the parts and functions of the exterior of the product.
This shows the air pollution level around the product in
real time.
The color changes depending on the pollution level.
Hold these handles to lift or transport the air purifier.
Open this cover when cleaning the pollution sensor.
Open these covers when cleaning or replacing the filters.
Plug the end of the power cord into a power outlet
(120 V~ 60 Hz).
Open this cover when removing any foreign objects fallen
and cleaning the air outlet.
These controls allow you to operate the product and
monitor the current operation status.
400S
Touch this button to connect to a Wi-Fi
network. When the Wi-Fi connection is
completed, the indicator is turned on.
* The status of Wi-Fi LED :
- Blinking : Not connected yet or in the
pairing process
- Constant LED: Wi-Fi connected
- LED off: Wi-Fi off
400
Touch this button to automatically turn
off after an hour, 4 hours, or 8 hours.
NOTE
For 400S users, you can set the timer
and scheduler using Airmega mobile
application.
Touch this button to turn the air
quality indicator and light on or off.
This sensor detects the intensity
of light. When the product is set to
Smart mode and it is dark,
for 3 minutes, the product enters
Sleep mode automatically.
However, if the air speed is set
manually or pollution level is
above normal (in Smart mode),
Sleep mode will not be activated
automatically.
Shows the pre-filter cleaning cycle at 5 levels
(100 %, 80 %, 60 %, 40 %, 20 %, 0 %). When the
letters on button is lit, it indicates that
the pre-filters need to be cleaned.
*Aftercleaningthepre-filters,touchandhold
thisbuttonfor2~3secondstoresettheindicator.
Shows the Max2 filter lifetime at 5 levels
(100 %, 80 %, 60 %, 40 %, 20 %, 0 %). When the
letters on button is lit, it indicates that the Max2
filters need to be replaced.
*AfterreplacingtheMax2filters,touchandhold
thisbuttonfor2~3secondstoresettheindicator.
EN
Air speed
Sleep mode
Smart mode
Touch this button to turn the product on.
Touch and hold this button for 2~3 seconds
to turn the product off.
Touch the sensor to select the air speed or set
the product to Smart mode or Sleep mode.
Touch this button to turn the air
quality indicator and light on or off.
300S
Touch this button to connect to a Wi-Fi
network. When the Wi-Fi connection is
completed, the indicator is turned on.
* The status of Wi-Fi LED :
- Blinking : Not connected yet or in the
pairing process
- Constant LED: Wi-Fi connected
- LED off: Wi-Fi off
300
Touch this button to automatically turn
off after an hour, 4 hours, or 8 hours.
NOTE
For 300S users, you can set the timer
and scheduler using Airmega mobile
application.
Shows the time of pre-filter cleaning cycle. When
the letters on the button is lit, clean the pre-filter.
*Aftercleaningthepre-filters,touchandholdthis
buttonfor2~3secondstoresettheindicator.
Shows the time of Max2 filter life. When the letters
on the button is lit, replace the Max2 filters.
*AfterreplacingtheMax2filters,touchandhold
thisbuttonfor2~3secondstoresettheindicator.
EN
Air speed
Sleep mode
Smart mode
Touch this button to turn the product on.
Touch and hold this button for 2~3 seconds
to turn the product off.
Touch this button to select the air speed
or set the product to Smart mode or Sleep
mode.
Before using the product, you must remove the plastic wrapping of the inserted Max2 filters on both sides.
03 INSTALLATION
CAUTION
Make sure that the power cord is unplugged before opening the covers.
1
Covers ▶ Pre-filters ▶ Max2 filters
FRONT/전면/前
FRONT/전면/前
2
Discard the plastic wrapping for Max2 filters.
CAUTION
• When removing the plastic wrapping from
the filters, be careful not to damage the
surface of filters.
• Do not allow children to play with the
plastic wrapping.
3
Max2 filters ▶ Pre-filters ▶ Covers
NOTE
• Place the Max2 filters into the filter case
with the green side facing the product.
Reversed placement may affect the filter
lifetime.
• The product will not turn on if the right and
left covers are installed incorrectly.
1
2
Max2 filter Pre-filter Cover
1
2
Max2 filter Pre-filter Cover
EN
When your filters are prepared, connect the power and turn on the air purifier.
CAUTION
This product is for 120 V~ 60 Hz use only. Make sure your power supply meets these requirements.
1
The indicators on the air purifier will blink.
2
You will hear a chime sound when the air
purifier starts to operate.
(400S/300S only)
If your product is a Wi-Fi enabled models you can connect the product to your Wi-Fi network for monitoring air
quality and remotely operating the product using your smart phone application.
To use the Wi‐Fi function, you must first download and install the Airmega application to your smart phone. You can
download the Airmega application from Apple App Store or Google Play Store.
1 Launch the AppleAppStore or GooglePlayStore on your smart phone.
2 Enter AIRMEGA to search the Airmega application.
3 Tap Install to download the application on your smart phone.
The app-enabled Airmega air purifier can be controlled via smart phone, by pairing it with your smart phone.
NOTE
• The screens used in this manual are of the screens captured on iOS version unless specified.
• Your smart phone must be connected to a Wi-Fi network until pairing is complete.
• The application may not be operated properly, depending on your network connection (Wi-Fi, 3G, 4G). Some feature
responses and information transmissions may be delayed. In such cases, try again or refresh the screen after some
time.
• The Airmega app is optimized for the devices and specifications shown below:
iOS 8 or later Android 4 or later
iPhone 5, 5s, 6, 6+
• Samsung: Galaxy S4, S5, S6, Galaxy Note 4
• Google: Nexus 5
AIRMEGA
1
EN
2
1
2
Next
If there is no password, tap Next without
entering the password.
NOTE
Tap AdvancedSettings to enter the static
IP address.
2
1
3
Next
NOTE
Tap ScanBarcode to read the barcode
automatically.
4 Next
5
ForAndroidusers
6
7
A
B
EN
8
Finish
When the connection of the air purifier and
your smart phone is completed successfully,
[Wi-Fi] indicator is on.
NOTE
If you encounter trouble and cannot
proceed to the next, repeat the steps
from the first one or verify your network
environment.
9
2
1
For Android, step 4, 5, and 6 will be
proceeded automatically.
4
5
6
04 OPERATION
ScreenLayoutofAirmegaApp
Moves to the main page.
Shows the outdoor air quality
of the location you set.
Shows the filter lifetime.
It turns red when the
lifetime is left below 20 %
and blinking below 0 %.
Turns the air quality
indicator on or off.
Shows the real time indoor
air quality at 4 stages.
Moves to the indoor Air
Quality Indicator report
(24 hours, 7 days, 30 days,
12 months).
The name of product (This
can be changed in Setting.)
Moves to the more sections.
Purchase/About Airmega/
Help/Notification Settings/
Change Password options
are available.
Moves to the setting section.
Pre-filter Wash Frequency/
Smart Mode Sensitivity/
Name/Time Zone/Warranty
options are available.
Shows the current air speed
and selects the air speed.
Shows the activation of timer
and scheduler.
Turns the product on or off.
This manual suits for next models
3
Table of contents
Other Airmega Air Cleaner manuals
