Airo Wireless A25 User manual

A25TM Quick
Start Guide
Icons may vary depending on your service provider’s plan.
Refer to the A25 Owner’s Manual CD for complete instructions.
Rugged Handset for
Global Communications.

Contents
1
Features 2 - 3
Getting Started 4 - 7
Phone Setup 8 - 10
Windows®Mobile® Professional 11 - 12
Phone Operation 13
A25TM Specications 14
Regulatory Compliance 15 - 16
Safety Information 17 - 18
Usage Precautions 19 - 20
Antenna & Battery Information 20 - 21
AC Adapter Precautions 21 - 22
Contact Airo:
Corporate Web Site: www.airowireless.com
E-mail: [email protected]
US Phone: [phone]
A25 Support: www.airowireless.com/a25
A25 FAQ:
10 Most FAQ’s: www.airowireless.com/a25/faq/most
Device Questions: www.airowireless.com/a25/faq/device
Windows Mobile® 6 help: www.microsoft.com/windowsmobile/help/default.mspx
Accessories:
For a complete list of Airo designed and approved accessories for your A25,
visit: www.airowireless.com/a25/stuff
Only Airo certied charging devices and screwdrivers are recommended for your
A25. Use of non-certied charging devices voids your A25 warranty.
Index

Features
2
1- LCD Touch Screen 10 - Keypad
2- External GPS Antenna Outlet 11 - LED Indicators
3- Volume Up/Down Button 12 - Battery Cover
4- Push-To-Talk Button 13 - Speaker
5- Rubber Connector Cover 14 - External GSM Antenna Outlet
6- Earphone Jack 15 - Mini SD Card Slot
7- Reset Button 16 - Stylus
8- USB Power Connector 17 - Power Button
9- Microphone 18 - Emergency Rescue Button
(Requires Service Agreement)

Features
3
4
3
1
2
8
7
6
5
1- Windows®Start Button 5- Numeric Keypad
2- Left Soft Button 6- End Button
3- Initiate Call / Send Button 7- Right Soft Button
4- Navigation Button 8- OK Button
Notification LED Flashing LED indicates a system
message, missed phone call, email, etc.
GSM LED Flashing LED indicates connection
your wireless network. Solid LED indicates data
communication.
GPS LED Flashing LED indicates GPS is active.
Charging LED Flashing LED indicates battery
is charging properly. Solid LED indicates a fully
charged battery.
A25™ LED’s

4
Getting Started
For initial use, you need to charge your device for approximately
four hours. Once the Charging LED stops blinking and holds as solid
orange, the battery is fully charged and you may continue with
normal operation.
1. Install the interchangeable clip plug to the AC adapter by
sliding the clip plug into the clip plug holder. The clip plug
locks to the clip plug holder with an audible click. Ensure
you install the correct clip plug for your AC outlet.
Caution! Before you use or charge the device, you must ensure that
you understand the safety and battery rating labels. Locate the labels
by removing the battery cover. Follow steps one to three of the “Install the SIM
Card” on page 5 to locate the security and battery rating labels.
WARNING! THERE IS A DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED
BY THE MANUFACTURER. DISPOSE OF USED BATTERIES ACCORDING TO THE
MANUFACTURER’S INSTRUCTIONS.
Charge the Device

Getting Started
5
The fourth LED indicator on the right of the touch
screen is the Charging LED and lights amber to
signify that AC connection is made.
During charging, the Charging LED ashes amber
indicating the device is charging.
When the battery is fully charged, the Charging
LED indicator lights solid amber.
2. Open the rubber connector cover.
3. Connect the Mini USB
adapter cable into the
connector on the bottom
of the device - 1
4. Connect the AC adapter
cable into an electrical
outlet - 2
Securely closing all rubber connector covers
is essential to maintaining your A25’s water
resistance. Only Airo certied charging devices are
recommended for your A25. Use of non-certied Airo
charging devices voids your A25 warranty.

Getting Started
6
Start the Device
After you have initially charged your device for approximately four
hours, your device is ready for use.
1. Press the Power button
located on the right side of
the touch screen.
2. Follow the on-screen
Welcome Screen Wizard
instructions.
Synchronizing your A25 with your PC’s settings and les is fast and
easy.
1. The A25 User Guide CD has the Microsoft ActiveSync software.
Or, download the ActiveSync setup software from the Microsoft
ActiveSync download page at www.microsoft.com/activesync.
2. Browse to the location of the downloaded le and double-click
the le.
3. Follow all on-screen instructions to complete installation.
Install Microsoft® ActiveSync®

Getting Started
7
1. Connect the USB sync cable into the connector on the bottom
of your A25 - 1
2. Plug the USB sync cable into a USB port on your computer - 2
After connecting your device, ActiveSync® should start
automatically and recognize your device. Follow the on-screen
instructions to establish a connection between the device and the
computer.
Connect the A25™ to Your Computer

8
Phone Setup
1. Turn the A25 over, then fully
loosen the four battery cover
screws. Even when fully loosened,
the screws are designed to
stay in the battery cover and
not fall out. Use the special Airo
screwdriver supplied with your
A25 retail kit.
2. Detach the battery cover from your A25.
Insert the SIM Card

Phone Setup
9
3. Slide the SIM card holder to the right - 1
4. Lift the holder halfway from the
recess area - 2
5. Insert the SIM card into the
SIM holder - 3, while noting the
correct position of the SIM card
connector. When inserting the
SIM card into the holder, the gold
area should be facing left with
the beveled corner of the SIM card facing up.
6. Press the SIM card holder
down - 4
7. Slide the card holder to the
left to lock it into place - 5

Phone Setup
10
8. Install the battery pack and reinstall the back cover.
Securely attaching the back
cover is critical in maintaining
the A25’s water resistance.
Additionally, over tightening
the screws or not using
the Airo screwdriver may
damage the screws and/or
back cover, resulting in poor
performance.
Enter Your PIN
Your SIM card may be preset with a PIN (Personal Identity Number)
provided by your service provider. If so, you need to enter the PIN
to establish your A25 service connection.
1. Press the Power button to turn on your A25.
2. Tap Start > Phone.
3. Enter the preset PIN from your service provider.
4. Tap Enter.
Notes: ____________________________________
________________________________________

11
Windows Mobile
Navigation Bar
The navigation bar is located on the top
of the screen. It shows the status icons for the battery, volume,
and data connectivity. Notications icons for system alarms and
reminders are also displayed here.
Today Screen
When you turn on your device for the
rst time each day (or after a preset
period of inactivity), you’ll see the Today
Screen. This screen shows you information
such as your appointments, active tasks,
unread messages, wireless carrier, active
programs, time, and connection status. This
screen is also where you’re taken when
you press the OK button on your A25.
Command Bar
Use the command bar at the bottom of
the screen to perform various program
tasks. The command bar includes menu names, action buttons
and the Input Selector button.
Windows® Mobile® 6.0 Professional
Icons may vary depending on your service
provider’s plan and installed programs.

12
Windows Mobile
Start Menu
Tapping the Start button on the Today
screen, or pressing the Windows soft
key on your A25 key
pad activates a drop-
down menu for selected
programs.
Tapping the Programs shows you the
rest of the programs installed on your
A25.
Note: Airo Services and Airo GroupLocate™ are
additional products offered by Airo Wireless, Inc.
Windows Mobile 6.0 also allows you to:
Surf the WEB
Play your favorite videos
Listen to your favorite songs
Customize your A25 with ringtones, games, news, etc.
For additional information on Windows®Mobile® 6.0 Professional,
visit: www.microsoft.com/windowsmobile/6

13
Phone Operation
Place and Receive phone calls
You have three methods by which to place a call:
1) Press the green CALL button
and dial the desired number
or scroll down to the previously
saved number. Press the green
CALL button again to initiate the
call.
2) From the Today screen, simply
dial the desired number. Then,
press the green CALL button to
initiate the call.
3) Tap PHONE on the command
bar. Then enter the desired
number and tap the TALK
button on your touch screen.
To receive a call, simply press the green CALL button.
To end a call, simply press the red END button.

14
A25 Specications
A25™ Specications
CPU Intel® PXA270 416 MHz
Memory SDRAM - 64MB
Flash ROM - 128MB
Display 2.8” Thin Film Transistor Liquid Crystal Display (TFT LCD)
320 x 240 Quarter Video Graphics Array (QVGA)
65536 Color Support
Audio AC 97 Interface with WolfSon WM9713
0.4W 15mm mono speaker
Embedded mono microphone
Mobile Connectivity Quad-band GSM broadband function(850/900/1800/1900 MHz)
GPRS class 12, EDGE Multi-slot class 10, Bluetooth®2.0
GPS Global Locate GPS/A-GPS Receiver (-150dBm)
Hardware Connectivity Mini USB connector/charger, External GPS antenna port,
External GSM antenna port, mini SD card slot,
2.5mm Earphone jack
LED Indicators Notication, GPS, GSM & Charging
Power 5V 2A AC Adapter, Detachable 2-wire AC power cord
Dimensions Length: 143.5mm Width: 68.3mm
Depth : 24.2mm Weight: 235g
Battery Rechargeable lithium polymer
Sony US45261A8T
Temperature range - 0-45oC
Rating - 3.7V, 1592 mAh
Included Accessories 5V - 2A AC Adapter, holster with belt clip, additional stylus

15
Regulatory Compliance
Phone Operation
When speaking into the device microphone or the headset microphone, a minimum
separation distance of 1 inch (2.5 cm) must be maintained between the user’s face and the
device, including its antenna, to comply with the FCC exposure limits.
NOTE: Do not touch the antenna unnecessarily when using the phone function. Contact with
the antenna affects call quality and may cause the device to operate at a higher power level
than otherwise needed.
Phone Usage Regulations
Never violate any of the following FCC Rules and Regulations when using your device. The
following offenses are punishable by ne, imprisonment, or both:
• Using obscene, indecent, or profane language.
• Using the unit to give off false distress calls.
• Wiretapping or otherwise intercepting a telephone call, unless that person has rst
obtained the consent of the parties participating in the call.
• Making anonymous calls to annoy, harass, or molest other people.
• Charging to an account without authorization to avoid payment for service.
• Refusing to yield a party line when informed that it is needed for an emergency call (It is
also unlawful to take over a party line by stating falsely that it is needed for an
emergency).
Regulatory Compliance Statements
FCC (Federal Communication Commission) Notice
This device has been tested and found to comply with the limits for a Class B digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This device generates, uses, and
can radiate radio frequency energy, and if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this device does cause
harmful interference to radio or television reception, which can be determined by turning

16
Regulatory Compliance
the device off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the device and receiver
• Connect the device into an outlet on a circuit different from that to which the receiver is
connected
• Consult the dealer or an experienced radio/television technician for help
Notice: Shielded cables
All connections to other computing devices must be made using shielded cables to maintain
compliance with FCC regulations.
Notice: Peripheral Devices
Only peripherals (input/output devices, terminals, printers, etc.) certied to comply with the
Class A or Class B limits may be attached to this equipment. Operation with noncertied
peripherals is likely to result in interference to radio and TV reception.
CAUTION: Changes or modications not expressly approved by the manufacturer could void
the user’s authority, which is granted by the Federal Communications Commission, to operate
this device.
Use conditions
This part complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
SAR statement
The FCC has granted an Equipment Authorization for this device with all reported SAR levels
evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this
device is on le with the FCC and can be found under the Display Grant section of http://www.
fcc.gov/oet/fccid after searching for FCC ID PU5SP300. Additional SAR information can be
found on the Cellular Telecommunications & Internet Association (CTIA) web site at http://
www.phonefacts.net.

17
Safety Information
Safety Information
Radio frequency (RF) Energy Emission
Your device is a low power radio transmitter and receiver. When it is ON, it receives and sends
out RF signals. In August 1996, the Federal Communications Commissions (FCC) adopted
RF exposure guidelines with safety levels for handheld wireless phones. Those guidelines are
consistent with the safety standards previously set by both U.S. and international standards
bodies:
• ANSI C95.1 (1992) • NCRP Report 86 (1986) • ICNIRP (1996)
Those standards were based on comprehensive and periodic evaluations of the relevant
scientic literature. For example, over 120 scientists, engineers, and physicians from universities,
government health agencies, and industry reviewed the available body of research to develop
the ANSI Standard (C951). Your device has been equipped with internal shielding to minimize
stray emissions of RF energy. However, using your device can still be limited in the some
instances. Turn your device OFF in any facility where posted notices require so.
When boarding aircraft
• Most airline regulations prohibit the on-board use of portable PCs (and all other portable
electronic devices that could potentially emit stray RF energy), particularly during take-
offs and landings, to prevent any possible interference with the reception
of signals by airborne electronic navigational devices.
• FCC regulations prohibit using your device while in the air. Turn your device OFF before
boarding an aircraft.
• Always request and obtain prior consent and approval of an authorized airline
representative before using your device aboard an aircraft.
• Always follow the instructions of the airline representative whenever using your device
aboard an aircraft, to prevent any possible interference with airborne
electronic equipment.
When inside hospitals and other health care facilities
• Turn your device OFF in health care facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities may be using equipment that could
be sensitive to external RF energy. “Device OFF” means to turn the radio stand by switch
“OFF”, then turn the power off by pressing the Power button.
• Always comply with posted prohibitions of the use of RF-emitting devices in hospitals and
other medical facilities. Failure to follow such directives could result in the interference with
medical equipment and/or devices.

18
Safety Information
Blasting areas
To avoid interfering with blasting operations, turn your device OFF when in a
“blasting area” or in areas posted “Turn off two-way radio”. Obey all signs and instructions.
Within certain radius from some electronic equipment Most modern electronic equipment is
shielded from RF signals. However, certain electronic equipment may not be shielded against
the RF signals from your device including:
• Pacemakers
The Health Industry Manufacturers Association recommends that a minimum separation
of six (6”) inches must be maintained between your device and a pacemaker to avoid
potential interference with the pacemaker. These recommendations are consistent
with the independent research and recommendations of Wireless Technology Research.
Never come closer than six (6) inches to a person with a heart pacemaker implant
when using this device. Failure to do so could result in interference with the function of the
pacemaker.
Persons with pacemakers
o You should ALWAYS keep the device more than six inches from their
pacemaker when the device is turned ON.
o You should not carry the device in a breast pocket.
o If you have any reason to suspect that interference is taking place, turn your
device OFF immediately.
•Hearing aids
Some digital wireless phones may interfere with some hearing aids. In the event of such
interference, you may want to consult your service provider (or call the customer service
line to discuss alternatives).
• Other medical devices
If you use any other personal medical device, consult the manufacturer of your device to
determine if they are adequately shielded from external RF energy. Your physician may
be able to assist you in obtaining this information.
• Motor vehicles
RF signals may affect improperly installed or inadequately shielded electronic systems in
motor vehicles. Check with the manufacturer or its representative regarding your
vehicle. You should also consult the manufacturer of any equipment that has been
added to your vehicle.

19
Usage Precautions
Usage Precautions
Failure to follow the directions below could result in death or catastrophic bodily injury.
• Never use your device while driving an automobile or any other moving vehicle. Always
pull out of trafc and come to a stop in a legally permissible and safe location before
using your device. Failure to do so could result in serious bodily injury in a trafc accident.
Driving safely
When driving:
• Never place your device on the passenger seat or any place else in the car where it can
become a projectile during a collision or stop.
• An air bag inates with great force. DO NOT place objects, including both installed or
portable wireless equipment, in the area over the air bag or in the air bag deployment
area. If in-vehicle wireless equipment is improperly installed and the air bag inates, serious
injury could result. Talking on your A25 phone while driving is extremely dangerous and is
illegal in some states. Remember, safety comes rst. Check the laws and regulations on
the use of phones in the areas where you drive. Always obey them. If you must use the
phone function while driving, please:
• Give full attention to driving. Driving safely is your rst responsibility.
• Use hands-free features by attaching the single earbud headset and
enabling the speed dial and auto-pick up functions.
• Pull off the road and park before making answering a call, if driving conditions so require.
• Never use your device while walking. Usage while walking could result in bodily injury
caused by inattention to automobile trafc or other pedestrian hazards.
• Never use your device in any area with a potentially explosive atmosphere and obey all
signs and instructions. Sparks in such areas could cause an explosion or re resulting in
bodily injury or even death.
Usage Instructions
• Always use AIRO authorized accessories and optional devices when operating this device,
as the use of incompatible auxiliary equipment could result in re, electric shock or other
bodily injury. The use of unauthorized accessories will also void your warranty.
• Never attempt to disassemble, repair or make any modication to your device.
Disassembly, modication or any attempt at repair could cause bodily injury or property
damage, as well as damage to the device itself.
