Airthings 281 User manual

Airthings Hub
Remote access to your ecosystem Operating manual
Version 1, October 19, 2018


The Airthings Hub was created to be used with Airthings indoor air quality monitoring devices.

Set up your device
1. Register the Hub on https://dashboard.airthings.com/add-device
2. Register all the Airthings indoor air quality monitoring devices that you want to connect to the Hub
on https://dashboard.airthings.com/add-device
3. Plug in the power cord of the Hub
4. Plug in the ethernet cable of the Hub. Skip this step if you have Hub Cellular
5. Let the network of Hub and Airthings indoor air quality monitoring devices form over up to 24
hours
6. Log in to the dashboard and observe sensor data of your Airthings indoor air quality monitoring
devices
7. Airthings indoor air quality monitoring devices that do not show up in the dashboard can be out or
range of the Hub and should be moved closer to the Hub.
Many easy ways to contact Airthings


Have any questions or comments that we didn’t get to here? Let us know! support.airthings.com


Congratulations on taking this important step toward living a healthier life.

By keeping track of your Indoor Air Quality and radon levels, you can make healthier decisions in
the spaces where you spend most of your time. Increased productivity and energy levels, better
quality sleep, and resistance to illness are just a few of the benefits. Lessening your exposure to
radon will reduce your risk of lung cancer.

The Airthings HUB provides you 24/7 access to your Airthings indoor air quality monitoring
devices with detailed information about Radon, VOCs, CO2, Temperature, Humidity and Air
Pressure levels on your Airthings Dashboard

Breathe better, live better.
The Airthings team


Features and content


Hub, wall mount bracket, supply adaptor, power outlet blade for the US and Europe, ethernet
cable (not needed for Hub cellular).

To replace the power outlet blade simply press the ejector button and slide the blade

Status Indicators: 


Power Supply Cloud  Smartlink



Easy to mount


Fix the mounting bracket to the ceiling or wall using the build in leveler. Make sure you use
appropriate screws for your wall type.


Connectivity


The Airthings Hub communicates with multiple Airthings devices bringing them online. The Hub
supports Airthings devices including:

Wave Plus with Airthings Smartlink
Wave 2nd Gen with Airthings Smartlink
Wave Mini and Wave Mist with Airthings Smartlink
Wave over Bluetooth (target availability 2Q19)

Airthings Ecosystem


Once registration is complete, the network will form by itself.

The placement of your Airthings Ecosystem devices depends on a number of factors, like walls or
barriers that break up the space. It is also important to consider what the building is made of to
determine the range for the Airthings SmartLink or Bluetooth connection.


Apps and software
Web Dashboard



Power Supply
100-240V AC / 50-60 Hz Adapter to 5V DC 2A










Connectivity
Bluetooth 5.0
Ethernet


Protocols
Airthings Smartlink, 868/915MHz
long-range (300ft/100m) wireless connection



Cellular option
LTE Cat.M1 & Cat.NB1 & EGPRS(2G)
Integrated eSIM with global coverage


Remote access
Up to 50 Airthings devices









Cloud storage
Live data streaming to the cloud


Installation
Use appropriate screws for ceiling or wall mount
Troubleshooting

If you need further assistance, read our
Frequently Asked Questions, or simply contact
support at support.airthings.com.

Technical specifications

Operational Environment: 4ºC to 40°C
Weight: < 260g
Dimensions: < 125 x 125 x 25 mm
Power supply: 100–240 V AC / 50–60Hz
Protocols: Bluetooth 5, Airthings Smartlink
Frequency band: 868/915 MHz & 2.4GH

Safety and maintenance

The Airthings Wave Plus is intended for indoor use
only. Avoid direct exposure to sunlight for long
periods. Avoid exposure to direct heat sources. For
correct usage, make sure the detector is operating in
the specified temperature range (see technical
specifications).

Exposure to high humidity might permanently alter
the detector sensitivity or damage it.

Do not disassemble. If the Airthings HUB does not
work as specified or you are in doubt, contact your
local dealer or visit us at Airthings.com.

Use a dry cloth to clean the detector.

Use only the adaptor supply shipped with the product. 

Always snap the mounting bracket to the detector’s
rear side to protect the product, even if the product is
not permanently mounted.

Disposal: electronic equipment.

Limited liability
The instrument is tested and quality-assured by
production. It meets the accuracy values set out in the
specifications.
It is recommended to keep the instrument constantly
activated and the batteries in place until drained.

Airthings AS shall not be liable for damages related to
failure or loss of data arising from incorrect operations
and handling of the instrument.

Terms & conditions
airthings.com/terms-use-privacy/

For other languages or additional questions go to
support.airthings.com

The Bluetooth word mark and logos are registered
trademarks owned by the Bluetooth SIG, Inc. and any
use of such marks by Airthings is under license.

Copyright Airthings AS, 2018


Regulatory
information
Regulatory information Canada
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
Les changements ou modifications non expressément
approuvés par la partie responsable de la conformité
pourraient annuler l'autorisation de l'utilisateur
d'utiliser l'équipement.
This device complies with Innovation, Science and
Economic Development Canada’s license-exempt
RSS(s). Operation is subject to the following two
conditions: (1) This device may not cause interference;
and (2) This device must accept any interference,
including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR de l’ISDE
applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si
le brouillage est susceptible d'en compromettre le
fonctionnement.
RF exposure safety
This product is a radio transmitter and receiver.
It is designed not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the
ISED.
The antenna must be installed and operated with
minimum distance of 20 cm between the radiator and
your body.
This transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter.
Ce produit est un émetteur et un récepteur radio.
Il est conçu pour ne pas dépasser les limites
d'émission pour l'exposition à l'énergie
radiofréquence (RF) établie par l'ISDE.
L’antenne doit être installé de façon à garder une
distance minimale de 20 cm entre la source de
rayonnements et votre corps.
L’émetteur ne doit pas être colocalisé ni fonctionner
conjointement avec à autre antenneou autre émetteur.

CAN ICES-3 (B)/NMB-3(B)
This Class B digital apparatus complies with Canadian
ICES-003
Cet appareil numérique de clase B est conforme à la
norme Canadienne ICES-003
Regulatory information USA
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Class B device notice
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and
receiver.
—Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV
technician for help.
RF exposure safety
This product is a radio transmitter and receiver.
It is designed not to exceed the emission limits for
exposure to radio frequency (RF) energy set by the
Federal Communications Commission.
The antenna must be installed and operated with
minimum distance of 20 cm between the radiator and
your body.

This transmitter must not be co-located or operating
in conjunction with any other antenna or transmitter.

