Kramer VS-41HC User manual

Kramer Electronics, Ltd.
USER MANUAL
Model:
VS-41HC
4x1 HDMI Switcher

Contents
i
Contents
1Introduction 1
2Getting Started 1
2.1 Quick Start 1
3Overview 3
3.1 Defining EDID 3
3.2 About HDMI 3
3.3 Recommendations for Best Performance 4
4Your VS-41HC 4x1 HDMI Switcher 5
4.1 Using the IR Transmitter for the VS-41HC 4x1 HDMI Switcher 6
5Connecting a VS-41HC 4x1 HDMI Switcher 6
6Setting the EDID 8
6.1 Acquiring / Changing the EDID 8
6.2 Resetting the Default EDID 8
7Technical Specifications 8
Figures
Figure 1: VS-41HC 4x1 HDMI Switcher 5
Figure 2: Connecting a VS-41HC 4x1 HDMI Switcher 7
Tables
Table 1: VS-41HC 4x1 HDMI Switcher Front Panel Features 5
Table 2: Technical Specifications of the VS-41HC 4x1 HDMI Switcher 8

Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups1
Congratulations on purchasing your Kramer VS-41HC 4x1 HDMI Switcher.
that are clearly defined
by function.
The VS-41HCis ideal for home cinema, conference room presentations and
advertising applications.
Each package includes the following items:
•VS-41HC4x1 HDMI Switcher
•Power adapter (12V DC Input)
•Kramer RC-IR3Infrared Remote Control Transmitter (including the
required batteries and a separate user manual2)
•This user manual2
2 Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
•Review the contents of this user manual
•Use Kramer high performance high resolution cables3
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

Getting Started
KRAMER: SIMPLE CREATIVE TECHNOLOGY
2

Overview
3
3 Overview
The desktop-sized VS-41HCis a high performance switcher for HDMI
signals. It switches any one of the four inputs to a single HDMI output.
In particular, the VS-41HC features:
•Support for up to 2.25Gbps bandwidth per graphic channel1
•Support for HDCP (High Definition Digital Content Protection)
•HDTV compatibility
•A MUTE button to disconnect the output and a PANEL LOCK button to
prevent unwanted tampering with the buttons on the front panel
•EDID PassThru –Passes EDID/HDCP signals from source to display
•3D Pass-Through
•Control via the front panel buttons or remotely via the Kramer infrared
remote control transmitter
3.1 Defining EDID
The Extended Display Identification Data (EDID2
3.2 About HDMI
) is a data-structure,
provided by a display, to describe its capabilities to an HDMI source. The
EDID enables the VS-41HCto “know” what kind of monitor is connected to
the output. The EDID includes the manufacturer’s name, the product type, the
timing data supported by the display, the display size, luminance data and (for
digital displays only) the pixel mapping data.
High-Definition Multimedia Interface (HDMI) is an uncompressed all-digital3
In particular, HDMI
audio/video interface, widely supported in the entertainment and home cinema
industry. It delivers the highest high-definition image and sound quality.
4
•Provides a simple:
5interface between any audio/video source, such as a
set-top box, DVD player, or A/V receiver and video monitor, such as a
digital flat LCD / plasma television (DTV), over a single lengthy6
1 Suitable for resolutions higher than UXGA at 60Hz, and for all HD resolutions
cable
2 Defined by a standard published by the Video Electronics Standards Association (VESA)
3 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-
to-analog conversions
4 HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
licensing LLC
5 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables
currently used in A/V systems is reduced
6 HDMI technology has been designed to use standard copper cable construction at up to 15m

Overview
KRAMER: SIMPLE CREATIVE TECHNOLOGY
4
•Supports standard, enhanced, high-definition video, and multi-channel
digital audio1
•Transmits all ATSC HDTV standards and supports 8-channel digital audio,
with bandwidth to spare to accommodate future enhancements and
requirements
on a single cable
•Benefits consumers by providing superior, uncompressed digital video
quality via a single cable2
•Is backward-compatible with DVI (Digital Visual Interface)
, and user-friendly connector
•Supports two-way communication between the video source (such as a
DVD player) and the digital television, enabling new functionality such as
automatic configuration and one-button play
HDMI has the capacity to support:
•Existing high-definition video formats (720p, 1080i, and 1080p/60), as
well as standard definition formats such as NTSC or PAL
3.3 Recommendations for Best Performance
To achieve the best performance:
•Connect only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables)
•Avoid interference from neighboring electrical appliances and position
your VS-41HCaway from moisture, excessive sunlight and dust
1 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to
support Dolby 5.1 audio and high-resolution audio formats
2 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a
simple, cost-effective manner

Your VS-41HC 4x1 HDMI Switcher
5
4 Your VS-41HC 4x1 HDMI Switcher
Figure 1 and Table 1 define the front and rear panels of the VS-41HC.
Figure 1: VS-41HC 4x1 HDMI Switcher
Table 1: VS-41HC 4x1 HDMI Switcher Front Panel Features
#
Feature
Function
1 IR Receiver The red LED lights when receiving signals from the
Infrared remote control transmitter
2 MUTE Button Press to toggle disconnecting the output
3 INPUT SELECTOR Buttons Press an INPUT button to select an input (from 1 to 4)
4 EDID Button1Press to acquire the EDID
5 PANEL LOCK Button Press to toggle disengaging the front panel buttons
6 INPUT HDMI Connectors Connect to the HDMI sources (from 1 to 4)
7 OUTPUT HDMI Connector Connect to the HDMI acceptor
8 12V DC +12V DC connector for powering the unit
9 REMOTE IR Opening
2
Connects to an external IR receiver unit for controlling the machine via an
IR remote controller instead of using the front panel IR receiver
3
1 Illuminates when configuring the EDID
2 Covered by a cap. The 3.5mm connector at the end of the internal IR connection cable fits through this opening
3 Optional. Can be used instead of the front panel (built-in) IR receiver to remotely control the machine (only if the internal
IR connection cable has been installed)

Connecting a VS-41HC 4x1 HDMI Switcher
KRAMER: SIMPLE CREATIVE TECHNOLOGY
6
4.1 Using the IR Transmitter for the VS-41HC 4x1 HDMI Switcher
You can use the RC-IR3IR transmitter to control the machine via the built-in
IR receiver on the front panel or, instead, via an optional external IR
receiver1. The external IR receiver can be located 15 meters away from the
machine. This distance can be extended to up to 60 meters when used with
three extension cables2
Before using the external IR receiver, be sure to arrange for your Kramer
dealer to insert the internal IR connection cable16F
3with the 3.5mm connector
that fits into the REMOTE IR opening on the rear panel. Connect the external
IR receiver to the REMOTE IR 3.5mm connector.
5 Connecting a VS-41HC 4x1 HDMI Switcher
To connect the VS-41HC 4x1 HDMI Switcher (as illustrated in Figure 2), do
the following17F
4:
1. If required, acquire the EDID (see section 6).
2. Connect the OUTPUT HDMI connector to an HDMI acceptor (for example,
an LCD display).
3. Connect18F
5the HDMI sources as follows:
A multimedia player to INPUT 1
A set top box to INPUT 2
A DVD player to INPUT 3
A DVD player to INPUT 4
4. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity (not shown in Figure 2).
Press an INPUT SELECTOR button (from 1 to 4) to choose which HDMI
input to route to the output.
1 Model: C-A35M/IRR-50
2 Model: C-A35M/A35F-50
3 P/N: 505-70434010-S
4 Switch OFF the power on each device before connecting it to your VS-41HC. After connecting your VS-41HC, switch on
its power and then switch on the power on each device
5 You do not have to connect all the HDMI sources

Connecting a VS-41HC 4x1 HDMI Switcher
7
.
Figure 2: Connecting a VS-41HC 4x1 HDMI Switcher

Setting the EDID
KRAMER: SIMPLE CREATIVE TECHNOLOGY
8
6 Setting the EDID
You can acquire or change the EDID (see section 6.1) or reset the machine to
the default EDID (see section 6.2).
6.1 Acquiring / Changing the EDID
You can work with the default EDID or acquire or change an EDID via the
connected output. Use the EDID button to acquire the output EDID
information.
To acquire or change the EDID of a new output display:
1. Connect the power supply.
2. Connect the new output display device.
3. Press the EDID button.
The INPUT buttons blink in sequence until the EDID is acquired.
6.2 Resetting the Default EDID
To reset the default EDID, disconnect the output and repeat the steps in
section 6.1.
7 Technical Specifications
Table 2 includes the technical specifications:
Table 2: Technical Specifications1
INPUTS:
of the VS-41HC 4x1 HDMI Switcher
4 HDMI Connectors
OUTPUT: 1 HDMI Connector
BANDWIDTH: Supports up to 2.25Gbps bandwidth per graphic channel
COMPLIANCE WITH
HDMI STANDARD: Supports HDMI and HDCP
RESOLUTION: 1080p @30bpp
POWER SOURCE: 12V DC, 320mA; 12V/1.25A Adapter
CONTROLS: Front panel buttons, Infrared remote control transmitter
DIMENSIONS: 22cm x 18cm x 4.5cm (8.6” x 7” x 1.8”)W, D, H. Half 19 inch 1U
WEIGHT: 1.3kg (2.9lbs) approx.
ACCESSORIES: Power cord, IR remote control
OPTIONS: Kramer HDMI cables20 F
2
, external remote IR receiver cable, RK-1 rack adapter
1 Specifications are subject to change without notice
2 For best results, use Kramer cables such as the C-H/H series, the C-H-DVI series and/or our HDMI over fiber optics
C-FOHM/FOHM series

9
LIMITED WARRANTY
WHO IS PROTECTED?
WHAT IS COVEREDAND WHAT IS NOT COVERED
WHAT WE WILL PAY FOR AND WHAT WE WILL NOT PAYF OR
HOW YOU CAN GET WARRANTY SERVICE
LIMI TATION OF IMPLIED WA RRA NTIES
EXCLUSIO N OF DAMAGES
CAUTION!
Kramer Electronics (hereafter ) warrants this product free from defects in material and workmanship under the
following terms.
Kramer
HOW LON G IS THE WA RRANTY
Labor and parts are warranted for three years from the date of the first customer purchase.
Only the first purchase customer may enforce this warranty.
We will pay labor and material expenses for covered items. We will not payfor the following:
The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall
not be liable for:
This warranty gives you specific legal rights, and you may also have other rights, which vary from place to place.
All products returned to Kramer for service must have prior approval.Thismay be obtained from your dealer.
This equipment has been testedto determine compliance with the requirements of:
EN-50081: "Electromagnetic compatibility (EMC);
generic emission standard.
Residential, commercial and light industry"
EN-50082: "Electromagnetic compatibility (EMC) generic immunity standard.
Part 1: Residential, commercial and light industry environment".
CFR-47: FCC* Rules and Regulations:
Part 15: “Radio frequency devices
Subpart B Unintentional radiators”
Except as below, this warranty covers all defects in material or workmanship in this product. The following are not covered
by the warranty:
1. Any product which is not distributed by Kramer, or which is not purchased from an authorized Kramer dealer. If you are
uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site
www.kramerelectronics.com.
2. Any product, on which the serial number has been defaced, modified or removed, or on which the WARRANTY VOID
TAMPERED sticker has been torn,
3. Damage, deterioration or malfunctionresulting from:
i) Accident, misuse, abuse, neglect, fire, water, lightning or other acts of nature
ii) Product modification, or failure to followinstructions supplied with the product
iii) Repair or attemptedrepair by anyone not authorized by Kramer
iv) Any shipment of the product (claims must be presented to the carrier)
v) Removal or installationof the product
vi) Any other cause, which does not relate to a product defect
vii) Cartons, equipment enclosures, cables or accessories used in conjunction with the product
1. Removal or installations charges.
2. Costs of
initial technical adjustments (set-up), including adjustment of user controls or programming. These costs are the
responsibility of the Kramer dealer from whom the product was purchased.
3. Shipping charges.
1. To obtain service on you product, you must take or ship it prepaid to any authorized Kramer service center.
2. Whenever warranty service is required, the original dated invoice (or a copy) must be presented as proof of warranty
coverage, and should be included in any shipment of the product. Please also include in any mailing a contact name,
company, address, and a description of the problem(s).
3. For the name of the nearest Kramer authorized service center, consult your authorized dealer.
All implied warranties, including warranties of merchantability and fitness for a particular purpose, are limited in duration to
the length of this warranty.
1. Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss
of time, commercial loss; or:
2. Any other damages, whether incidental, consequential or otherwise. Some countries may not allow limitations on how long an
implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitations and exclusions maynot apply to you.
Servicing the machines can only be done by an authorized Kramer technician. Any user who makes changes or
modifications to the unit without the expressed approval of the manufacturer will void user authority to operate the
equipment.
Use the suppliedDC power supply to feed power to themachine.
Please use recommended interconnection cables to connect the machine to other components.
IF reattached, removed or otherwise interfered with.
* FCC and CE approved using STPcable (for twisted pair products)
NOTE:
Part 1:

Kramer Electronics, Ltd.
Web site: www.kramerelectronics.com
E-mail: [e-mail]
P/N: 2900-000423 REV 3
For the latest information on our products and a list of Kramer
distributors, visit our Web site: www.kramerelectronics.com,
where updates to this user manual may be found.
We welcome your questions, comments and feedback.
Caution
Safety Warning:
Disconnect the unit from the power supply before
opening/servicing.
