Airtrack Sp1-c User manual

BT CCD Barcode Scanner

- SP1-C -

User's Manual

Version 1.0

Preface

About This Manual

Thank you for purchasing the product.

This manual explains how to install, operate and maintain our product.

No part of this publication may be reproduced or used in any form, or by any

electrical or mechanical means, such as photocopying, recording, or

information storage and retrieval systems, without permission in writing from

the manufacturer. The material in this manual is subject to change without

notice.

Regulatory Compliance Statements

FCC Warning Statements

This device has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference with radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference with radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

–Reorient or relocate the receiving antenna.

–Increase the separation between the equipment and receiver.

–Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

–Consult the dealer or an experienced radio/TV technician for help.

1. This transmitter must not be co-located or operating in conjunction with

any other antenna or transmitter.

2. This device complies with FCC RF radiation exposure limits set forth for

an uncontrolled environment. To maintain compliance with FCC RF

exposure requirements, avoid direct contact to the transmitting antenna

during transmitting.

3. Any changes or modifications (including the antennas) made to this device

that are not expressly approved by the manufacturer may void the user’s

authority to operate the equipment.

Operation on the 5.15 - 5.25GHz frequency band is restricted to indoor use

only. The FCC requires indoor use for the 5.15-5.25GHz band to reduce the

potential for harmful interference to co-channel Mobile Satellite Systems.

Therefore, it will only transmit on the 5.25-5.35 GHz, 5.47-5.725 GHz and

5.725–5.850 GHz band when associated with an access point (AP).

FCC Label Statement

This device complies with part 15 of the FCC rules. Operation is subject to the

following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference

that may cause undesired operation.

RF Radiation Exposure Statement

For body contact during operation, this device has been tested and meets FCC

RF exposure guidelines when used with an accessory that contains no metal

and that positions the handset a minimum of 1.5 cm from the body.

Use of other accessories may not ensure compliance with FCC RF exposure

guidelines.

Canadian Compliance Statement

This Class B Digital apparatus meets all requirements of the Canadian

Interference-Causing Equipment Regulations.

iii

Cet appareil numerique de la classe B respecte les exigences du Reglement

sur le material broilleur du Canada.

European Conformity Statement

Our company herewith declares that the product is in compliance with the

essential requirements and all other provisions of the RED 2014/53/EU

directive, the EMC 2014/30/EU directive and the Low Voltage 2014/35/EU

directive.

CE RF Exposure Compliance

This device meets EU requirements (2014/53/EU) on the limitation of exposure

of the general public to electromagnetic fields by way of health protection.

For body-worn operation, this device has been tested and meets the ICNIRP

guidelines and the European Standard EN 62209-2, for use with dedicated

accessories, SAR is measured with this device at a separation of 0.5 cm to the

body, while transmitting at the highest certified output power level in all

frequency bands of this device. Use of other accessories which contain metals

may not ensure compliance with ICNIRP exposure guidelines.

CE Mark Warning

This equipment complies with the requirements of Directive 2014/53/EU of the

European Parliament and Commission from 24 May, 2014 governing Radio

and Telecommunications Equipment and mutual recognition of conformity.

RoHS Statement

This device conforms to RoHS (Restriction of Hazardous Substances)

European Union regulations that set maximum concentration limits on

hazardous materials used in electrical and electronic equipment.

Waste electrical and electronic equipment (WEEE)

Our company has set up a policy and process to meet the

EU directive 2002/96/EC and update 2003/108/EC

concerning electronic waste disposal.

Taiwan NCC Warning Statement

低功率電波輻射性電機管理辦法

第十二條：經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者

均不得擅自變更頻率、加大功率或變更原設計之特性及功能。

第十四條：低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有

干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。

前項合法通信，指依電信法規定作業之無線電通信。

低功率射頻電機需忍受合法通信或工業、科學及醫療用電波輻射性電機設備

之干擾。

Laser Information

The product is certified in the U.S. to conform to the requirements of

DHHS/CDRH 21CFR Subchapter J and to the requirements of IEC 825-1.

Class II and Class 2 products are not considered to be hazardous. The product

contains internally a Visible Laser Diode (VLD) whose emissions do not

exceed the maximum limits as set forth in the above regulations. The scanner

is designed so that there is no human access to harmful laser light during

normal operation, user maintenance or prescribed service operations.

The laser safety warning label required by the DHHS/IEC for the product’s

optional laser scanner module is located on the memory compartment cover,

on the back of the unit.

* Laser information only applies to the products with laser components.

CAUTION! Use of controls or adjustments or performance of procedures

other than those specified herein may result in hazardous laser

light. Use of optical instruments with the scanner, including

binoculars, microscopes, and magnifying glasses, with will

increase eye damage.This does not include eyeglasses worn by

the user.

LED Information

The product contains LED indicator(s) or LED ring whose luminance is not

harmful to human eyes during normal operation, user maintenance or

prescribed service operations.

*LED information only applies to the products with LED components.

vii

Battery Notice

1. To guarantee optimal performance, it is recommended that rechargeable

batteries be replaced every year, or after 500 charging cycles are

completed. It is normal for the battery to balloon or expand after one year

or 500 cycles. Although it does not cause damage, it cannot be used

again and must be disposed of according to the location's safe battery

disposal procedures.

2. If a battery performance decreases more than 20%, the battery is at the

end of its life cycle. Stop use and ensure the battery is disposed of

properly.

3. The length of time that a battery lasts depends on the battery type and

how the device is used. Conserve the battery life by doing the following:

Avoid fully uncharging the battery because this places additional

strain on it. Several partial uncharges with frequent charges are better

than a fully uncharged battery. Charging a partially charged battery

does not cause harm to the unit.

Keep the battery cool. Avoid hot vehicles. For prolonged

storage, keep the battery at a 40% charge level.

Do not leave the battery uncharged and unused for an extended

period of time, the battery will wear out and the longevity of the

battery will be at least half of one with frequent charges.

4. Protect battery life by not over or under charging the battery.

5. Please do not leave battery unused for long time without charging it.

Despite our safety precautions, the battery pack may begin to change

shape. If so, stop using it immediately. Please check to see if you are

using a proper power adapter to charge the battery or contact your service

provider for service.

6. If you cannot charge the battery after it has been idle for an extended

period of time and it begins to heat up, please do not try to charge it. It

may not be functional anymore.

7. Please only use the original battery from our company. Using a third party

battery can damage our products. Please note that when such damage

occurs, it is not covered by our warranty policy

CAUTION! RISK OF EXPLOSION IF BATTERY IS

REPLACED INCORRECTLY.

viii

DISPOSE OF USED BATTERIES ACCORDING

TO THE INSTRUCTIONS..

如果更換不正確之電池行事會有爆炸的風險

請依製造商說明書處理用過之電池

如果更换不正确之电池行事会有爆炸的风险

请依制造商说明书处理用过之电池

Battery charge notice

It is important to consider temperature when the battery pack is charging.

Charging is most efficient at normal room temperature or in a slightly cooler

environment. It is essential that batteries are charged within the stated range of

0°C to 40°C. Charging batteries outside of the specified range could damage

the batteries and shorten their life cycle.

CAUTION! Do not charge batteries at a temperature lower than 0°C. This will

and make the batteries unstable and dangerous. Please use a

battery temperature detecting device for a charger to ensure a

safe charging temperature range.

CAUTION! To ensure the unit working properly, please keep all connectors

away from the contaminants staying inside of them such as dust,

grease, mud, and water. The negligence may cause the unit with

no communication, short circuited, overheated and so on.

CAUTION! If the connector is damaged, please ensure the connector is

being fully repaired before using the unit to avoid causing short

circuited.

Storage and safety notice

Although charged batteries may be left unused for several months, their

capacity may be depleted due to build up of internal resistance. If this happens,

they will require recharging prior to use. Batteries may be stored at

temperatures between -20°C to 60°C, however they may deplete more rapidly

at higher temperatures. It is recommended to store batteries at room

temperature.

* The message above only applies to the usage of the removable batteries.

For the products with non-removable batteries / without batteries, please refer to

the specification of each product.

Product Operation and Storage Notice

The product has applicable operation and storage temperature conditions.

Please follow the limitation of suggested temperature conditions to avoid

failure, damage or malfunction.

*For applicable temperature conditions, please refer to the specification of each

product.

Adapter Notice

1. Please do not leave the power adapter in the socket when it is not

connected to the product for charging.

2. Please remove the power adapter when the battery is fully recharged.

3. The bundled power adapter that comes with the product is not meant to be

used outdoors. An adapter exposed to water or rain, or a very humid

environment can cause damage to both the adapter and the product.

4. Please only use the bundled power adapter or same specification of

adapter to charge the product. Using the wrong power adapter can

damage the product.

* The message above only applies to the product connected to the adapter.

For the products without using the adapters, please refer to the specification of

each product.

Hearing Damage Warning

Zx.3 Warning

The warning shall be placed on the equipment, or on the packaging, or in the instruction manual and shall consist of

the following:

- the symbol of Figure 1 with a minimum height of 5 mm; and

- the following wording, or similar :

To prevent possible hearing damage, do not listen at high volume levels for long periods.

Alternatively, the entire warning may be given through the equipment display during use, when the user is asked to

acknowledge activation of the higher level.

Table of Contents

Preface...........................................................................................................i

About This Manual ........................................................................................i

Regulatory Compliance Statements..............................................................i

Laser Information ........................................................................................vi

LED Information ..........................................................................................vi

Battery Notice............................................................................................. vii

Adapter Notice.............................................................................................ix

Hearing Damage Warning............................................................................x

Chapter 1 - Overview................................................................................1

1.1 Package .................................................................................................1

1.2 Scanner Detail........................................................................................2

1.3 Specifications .........................................................................................3

1.4 Getting Started .......................................................................................5

1.5 Battery Charging ....................................................................................5

1.6 LED Indicator / Beeper Sequence..........................................................6

Chapter 2 – Configuration-General ......................................................7

2.1 BT HID....................................................................................................7

2.2 BT SPP.................................................................................................12

Chapter 3 –Bar Codes & Others..........................................................13

3.1 All SymboIogies....................................................................................13

3.2 MSI / UK Plessey code.........................................................................16

3.3 Code93 / Telepen / IATA.......................................................................17

3.4 Interleaved 2 of 5 / Code 11 .................................................................18

3.5 Industrial 2 of 5 / Matrix 2 of 5..............................................................19

3.6 Codabar ...............................................................................................20

3.7 ABC Codabar, CX Codabar..................................................................21

3.8 Code 39 (Full ASCII/Standard) / Code 32.............................................23

3.9 UPC-E..................................................................................................24

3.10 UPC-E(0)&(1) / UPC-E EXPAND .......................................................25

3.11 UPC-A ................................................................................................26

3.12 EAN-8.................................................................................................27

3.13 EAN-13 / ISSN / ISBN / ISMN............................................................28

3.14 EAN & UCC128/Code 128 .................................................................30

xii

3.15 DataBar (RSS) ...................................................................................31

Chapter 4 – Command Setting.............................................................33

4.1 System Setting.....................................................................................33

4.2 BT Pairing.............................................................................................34

4.3 Output data transmit.............................................................................41

4.4 BT Config .............................................................................................50

4.5 Beep tone, Terminator..........................................................................54

4.6 Scan mode...........................................................................................55

4.7 Send Data Length, Preamble, Postamble ............................................56

4.8 Accuracy Adjustment............................................................................57

4.9 Code ID, Inverse Barcode....................................................................58

4.10 Power off Timeout ..............................................................................62

Appendix A – Numeric Bar Codes.......................................................63

Appendix B – Full ASCII Table(Code39)............................................64

Appendix C – Default Table..................................................................75

SP1-C User’s Manual

Chapter 1 - Overview

1.1 Package

Please make sure the following contents are in the SP1-C gift box.

If something is missing or damaged, please contact our representative.

The standard package contents:

SP1-C Scanner

Quick Start Guide

Regulatory Compliance Statements

USB Charging Cable

Hand Strap

Note: To scan a barcode, make sure the aiming beam crosses every bar and

space of the barcode.

SP1-C User’s Manual

1.2 Scanner Detail

Mini USB port

Hard Reset Button in the back

of SP1-C (insert pin into the hole )

Scan Window

LED lndicators

Trigger

SP1-C User’s Manual

1.3 Specifications

Performance/Optical

Image Sensor Linear CMOS sensor

Light Source 625nm Visible Red LED

Max. Resolution 4 mil (0.1mm)

Scan Rate 650 scans/ second

Printing Contrast Scale 30% Minimum

Depth of Field

Reading Distance

(DOF PCS=90%)

Code 39, 4mil: 40mm (near) / 65mm (far)

Code 39, 5mil: 35mm (near) / 90mm (far)

Code 39, 10mil: 35mm (near) / 195mm (far)

Code 39, 15mil: 50mm (near) / 280mm (far)

UPC/EAN, 13mil: 35mm (near) / 230mm (far)

Functionality

Symbologies UPC-A/UPC-E, EAN-8/EAN-13, Industrial 2of 5,

Codabar, Matrix 2 of 5, Code 11, Code93, Code

32, Code 128, Standard Code 39,Full ASCII

Code 39, Interleaved 2 of 5, ChinaPostal Code,

MSI Plessy Code, UK PlessyCode, EAN/UCC

128, Telepen Code, IATACode, GS1 Databar.

Configuration Method Configuration barcodes

Electrical

Operation Voltage 3.7VDC ± 5%

Battery Type Lithium-Ion

Current Consumption Operation mode: < 145mA

Standby mode: < 55mA

Battery Duration 6000 scans/ charge

SP1-C User’s Manual

Environmental

ESD Protection Functional after 4KV Contact and 8KV Air

Operating Temperature 0°C to 50°C

Storage Temperature -20°C to 60°C

Relative Humidity 0% to 95% non-condensing

Drop Test 1.5M

Communication

Range 10M (line of sight)

Host Interface supported Mini USB

Interface/Profile SPP,HID

Wireless Class Wireless Class 2

Mechanical

Housing Material ABS + PC

Dimensions L65 x ABS + PC

18mm / 2.6 x 0.9 x 0.7in

Weight 30.2g / 1.06oz

Regulation Approvals

FCC Part15B, FCC Part15C, EN301489-1-17, EN62133, EN60950-1,

EN300328, IEC 62471, NCC, TELEC, VCCI, BSMI

Accessories

Mini USB cable, Hand Strap

Radio type / Description Transmitter Frequency Maximum Output Power

Bluetooth Bluetooth 2400-2483.5MHz 4.6dBm

SP1-C User’s Manual

1.4 Getting Started

Please make sure your PC or Smartphone has a built-in wireless adaptor; the

SP1-C supports both HID and SPP wireless proﬁles. If you are connecting it to

an iOS (Apple) smartphone, please follow the instruction of “Connecting via

Human Interface Device (HID) Mode”; if you are connecting it to an Android

smartphone, please follow the instruction of “Connecting via Serial Port Proﬁle

(SPP) Mode” or the instruction of “Human Interface Device (HID) Mode”.

Note: Android 2.x devices can work with SP1-C in the SPP mode ONLY.

The SPP mode or/and the HID mode are not deﬁnitely compatible with each version of

Android OS, and thus depends on the Android-based hardware speciﬁcations deﬁned

by the Android device manufacturers.

1.5 Battery Charging

1. Flip open the mini USB port on the scanner.

2. Insert the mini USB connector into the port on the scanner and USB

connector into a USB port on the host PC.

3. Please charge the scanner for at least 2 hours (until the LED indicator

turns off).

SP1-C User’s Manual

1.6 LED Indicator / Beeper Sequence

Scanner LED & Beeper Indication

Green LED Red LED Beeper Remark

Power Off or

Standby - - -

See Power Off

Timeout

Charging - Solid - -

Disconnected or

Discoverable Flash - - -

Initializing Flash Flash 1 long beep -

Power Up - - 1 long beep -

Barcode

scanning w/o

proper

connection

Flash - 1 beep -

Successful

barcode scan 1 Flash - 1 beep -

Successful

Connection - - 2 beeps -

Unsuccessful

Pincode Setup - Flash

3 short

beeps Scan [Pincode

Stop] and retry

Low Power - Flash 5 beeps -

Scanner

Out of range 1 Flash - 4 beeps

(high-low-

high-low)

Move closer to

the host.

SP1-C User’s Manual

Chapter 2 – Configuration-General

2.1 BT HID

1. Turn on the wireless device on your host (PC, Smartphone, or Tablet).

2. Hold the trigger for one second to activate the scanner.

3. Scan the [Disconnect] barcode.

Disconnect

4. Hold the trigger for one second to activate the scanner.

5. Scan the [HID] barcode below. HID

6. The scanner will emit several short beeps and then stop beeping. The

green LED light will flash continually during the pairing process.

7. On your host device, in the settings section where you can see Bluetooth

settings and manage your connections.

a. You will see the SP1-C listed as [Wireless Scanner] under Bluetooth

devices.

b. You will see a message under that [Pair with this device].

c. Select this device on your host and begin to pair.

8. Your Host device will ask you to type in a pin code.

a. Use your host device keypad to enter this pin code.

b. The pin code can be any set of numbers.

c. We suggest using 4 numbers.

9. Once you have entered the pin code on the Host device, you need to set up

the pin code on the SP1-C to match.

a. With the SP1-C, scan the Pincode Start barcode below.

Pincode Start
