AirTrack S1-BT User manual

AirTrack S1-BT
General Purpose Handheld
Linear Imager Bar Code Reader
with Bluetooth® Wireless Technology
Quick Reference Guide

AirTrack
www.airtrack.com
Telephone: [phone]
©2014 - 2016 AirTrack, Inc.
An Unpublished Work - All rights reserved. No part of the con-
tents of this documentation or the procedures described
therein may be reproduced or transmitted in any form or by
any means without prior written permission of AirTrack or its
subsidiaries or affiliates.
Owners of AirTrack products are hereby granted a non-exclu-
sive, revocable license to reproduce and transmit this docu-
mentation for the purchaser's own internal business
purposes. Purchaser shall not remove or alter any proprietary
notices, including copyright notices, contained in this docu-
mentation and shall ensure that all notices appear on any
reproductions of the documentation.
Should future revisions of this manual be published, you can
acquire printed versions by contacting your AirTrack represen-
tative. Electronic versions may either be downloadable from
the AirTrack website (www.airtrack.com) or provided on
appropriate media. If you visit our website and would like to
make comments or suggestions about this or other AirTrack
publications, please let us know via the "Contact AirTrack"
page.
Disclaimer
AirTrack has taken reasonable measures to provide informa-
tion in this manual that is complete and accurate, however,
AirTrack reserves the right to change any specification at any
time without prior notice. AirTrack and the AirTrack logo are
registered trademarks of AirTrack. in many countries, includ-
ing the U.S. S1-BT is a trademark of AirTrack and/or its affili-
ates registered in many countries, including the U.S. The
Bluetooth word mark and logos are owned by Bluetooth SIG,
Inc. and any use of such marks by AirTrack Group companies
is under license. All other brand and product names may be
trademarks of their respective owners.
Patents
This product is covered by one or more of the following pat-
ents:
Design patents: EP002158717, USD723563,
ZL201330271434.1
Utility patents: EP1114390B1, EP1128315B1, EP1396811B1,
EP1413971B1, EP1825417B1, EP1828957B1, EP2275966B1,
EP2517148B1, EP2521068B1, EP2649555B1, EP2943909B1,
JP4435343B2, US6478224, US6512218, US6513714,
US6561427, US6808114, US6997385, US7053954, US7075663,
US7234641, US7387246, US7721966, US8245926, US8561906,
US8888003, US8915443, US9430689, US9613243, US9798948,
ZL200980163411.X, ZL201080071124.9
See the Regulatory Addendum included with
your product for additional regulatory, safety and
legal information.

Quick Reference Guide i
Table of Contents
Software Product Policy ............................................................. vi
Customers Under Software Support ................................ vi
Setting Up the Reader ................................................................. 2
Locking the Reader to the Base ........................................ 2
To Lock the Reader in the Base................................ 2
Connecting the Base Station ...................................................... 4
Base Station Connection and Routing .............................. 4
System and Network Layout ............................................. 6
Typical Setup with Cradle and Host ......................... 6
Using the BC-S1-S2 Radio Base ........................................ 7
Radio Base LEDs ........................................................ 7
Charging the Battery Pack ................................................. 8
Replacing the Battery Pack ................................................ 8
Using the Reader ........................................................................ 10
Bar Code Reading .............................................................. 10
Linking the Reader ..................................................................... 11
Link AirTrack RF Devices to Base........................... 11
Linking to a Bluetooth Adapter in
Serial Port Profile Mode .......................................... 11
Linking to a Bluetooth Adapter in HID mode........ 12
Variable PIN Code .................................................... 13
Programming ..............................................................................14
Using Programming Bar Codes .......................................14
Configure Other Settings ..................................................14
Resetting Standard Product Defaults ................... 14
HID Alt Mode ......................................................................15
Power Off ...........................................................................15
Country Mode .............................................................................16
Caps Lock State .......................................................................... 20
Selecting the Base Interface Type ............................................ 21
Interface Selection ............................................................21
Configuring the Interface ........................................ 21
Keyboard Interface .................................................. 23
Scancode Tables....................................................... 25
Numlock.................................................................... 26
Good Read Green Spot Duration .....................................27
Scan Modes ................................................................................ 28
Technical Specifications ............................................................30
LED and Beeper Indications ...................................................... 34
Error Codes .................................................................................36
Base Station Indications ........................................................... 36
AirTrack Limited Factory Warranty ................................. 37

ii S1-BT
Warranty Coverage .................................................. 37
Warranty Claims Process........................................ 37
Warranty Exclusions................................................ 38
No Assignment ........................................................ 38
Risk of Loss .............................................................. 39
Technical Support ....................................................................... 40
Support Through the Website ......................................... 40
Reseller Technical Support ...............................................40
Ergonomic Recommendations ................................................. 40
Cleaning .......................................................................................41
Hex-Numeric Keypad .................................................................42
For HID Variable Pin Code only............................... 44

Quick Reference Guide iii
AIRTRACK
END USER SOFTWARE LICENSE AGREEMENT (EULA)
FOR THE S1-BT
Notice to End User: There are two types of software covered by this END USER
LICENSE AGREEMENT ("EULA"): (1) The AirTrack Product you have acquired contains
embedded software ("Embedded Software") which is integral to the Product's oper-
ation; and (2) Optional Application Software provided to you on an optional basis
("Application Software"). Embedded Software and Application Software are collec-
tively referred to as "Software" and are subject to the terms and conditions con-
tained in this EULA. Software is provided only for use with, and for authorized end
users of, the AirTrack S1-BT ("Product").
This EULA (End User Software License Agreement) ("EULA” or "Agreement") is a
legally binding agreement governing the licensing of the Software and Documenta-
tion by AirTrack and its subsidiaries and affiliates ("AirTrack") to the entity or person
who has purchased or otherwise acquired a AirTrack Product ("End User"). For pur-
poses of this Agreement, any software that is not Embedded Software or Applica-
tion Software is software associated with a separate end-user license agreement is
licensed to you under the terms of that license agreement.
AirTrack and End User hereby agree as follows:
1. Definitions.
1.1 "Affiliate" means a business entity currently existing or later acquired that
is controlled by, or is under common control with AirTrack.
1.2 "Documentation" means materials such as user's guides, program reference
guides, quick reference guides, manuals, or similar materials associated
with or related to the AirTrack Product, whether in printed, "online", or other
form.
1.3 "Proprietary Information" means: (a) source code, object code, software,
documentation, and any related internal design, system design, data base
design, algorithms, technology, technical data or information, implementa-
tion techniques, and trade secrets related to the Software, (b) any other
trade secrets marked appropriately or identified as proprietary or confiden-
tial, and (c) any information that End User, under the circumstances, should
recognize as confidential. Proprietary Information does not include any
information that the receiving party can establish was (1) in the public
domain, (2) already in the receiving party's possession or rightfully known
prior to receipt, (3) rightfully learned from a third party not in violation of
any other's proprietary rights, or (4) independently developed without
access to Proprietary Information.
1.4 "AirTrack Product" means the AirTrack S1-BT product series, including all
embedded Software in and all Documentation related to such product,
which has been purchased or otherwise acquired by End User, whether
obtained directly or indirectly from AirTrack.
1.5 "Software" means any software or computer programs of AirTrack or its
third party licensors in machine readable form which is embedded in the
AirTrack Product, whether obtained directly or indirectly from AirTrack,
including any replacement, update, upgrade, enhancement or modification.
2. Scope Of License Granted.
2.1 AirTrack grants to End User personal a non-exclusive, non-transferable,
perpetual license to use the Software, solely on the AirTrack Product in
which it is embedded ("designated AirTrack Product"), in machine-readable
form only, solely for End User's internal business purposes. This Agreement
does not convey ownership of the Software to End User. Title to the Soft-
ware shall be and remain with AirTrack or the third party from whom Air-
Track has obtained a licensed right. As used in this Agreement, the term
"purchase" or its equivalents when applied to the Software shall mean
"acquire under license." End User is not entitled to receipt or use of the
source code to any Software.
2.2 End User shall not copy, modify, decompile, disassemble, reverse engineer,
or otherwise reproduce or remanufacture the Software, whether modified
or unmodified, nor sell, assign, sublicense, distribute, lend, rent, give, or oth-
erwise transfer the Software to any other person or organization, for pur-
poses other than as expressly provided in this Agreement, without
AirTrack's prior written consent.

iv S1-BT
3. Transfers, Support.
3.1 Any copying, installing, reproduction, remanufacture, reverse engineering,
electronic transfer, or other use of the Software on other than the desig-
nated AirTrack Product will be a material breach of this Agreement. How-
ever, AirTrack may elect not to terminate this Agreement or the granted
licenses, but instead may elect to notify End User that End User is deemed
to have ordered and accepted a license for each breaching use. End User
shall pay AirTrack the applicable list price for such licenses as of the date of
such breach.
3.2 End User shall not sell, assign, sublicense, distribute, lend, rent, give, or oth-
erwise transfer the AirTrack Product to any third party unless such third
party agrees with AirTrack in writing to be bound by the terms and condi-
tions of this Agreement. Any such transfer of the AirTrack Product absent
such agreement shall be null and void.
3.3 End User may obtain support for Software from AirTrack at AirTrack's stan-
dard support fees and under AirTrack's standard support terms and condi-
tions in effect at the time the support is requested.
4. Intellectual Property.
End User acknowledges that the Software comprises valuable trade secrets of
AirTrack or AirTrack's third party licensors and that the Software is protected by
United States copyright law and trade secret law, and by all applicable international
intellectual property laws and treaty provisions. The license set forth in this Agree-
ment does not transfer to End User any ownership of AirTrack's or its third party
licensors' copyrights, patents, trademarks, service marks, trade secrets, or other
intellectual property rights and End User shall have no right to commence any legal
actions to obtain such rights. End User shall not remove, modify, or take any other
action that would obscure any copyright, trademark, patent marking, or other intel-
lectual property notices contained in or on the AirTrack Product.
5. Proprietary Information.
5.1 End User acknowledges that Proprietary Information is the confidential,
proprietary, and trade secret property of AirTrack and AirTrack's third party
licensors and End User acquires no right or interest in any Proprietary Infor-
mation.
5.2 End User shall not disclose, provide, or otherwise make available the Propri-
etary Information of AirTrack or its third party licensors to any person other
than End User's authorized employees or agents who are under confidenti-
ality agreement, and End User shall not use the Proprietary Information
other than in conjunction with use of the AirTrack Product exclusively for
End User's internal business purposes. End User shall take steps to protect
the Proprietary Information no less securely than if it were End User's own
intellectual property.
5.3 The provisions of this Proprietary Information Section shall survive and
continue for five (5) years after the termination of this Agreement.
6. Limited Warranty.
6.1 AirTrack warrants that, under normal use and operation, the AirTrack Prod-
uct will conform substantially to the applicable Documentation for the
period specified in the Documentation. During this period, for all reproduc-
ible nonconformities for which AirTrack has been given written notice, Air-
Track will use commercially reasonable efforts to remedy nonconformities
verified by AirTrack. End User agrees to supply AirTrack with all reasonably
requested information and assistance necessary to help AirTrack in reme-
dying such nonconformities. For all defects reported to AirTrack within the
warranty period, AirTrack's liability is limited to providing End User with one
copy of corrections or responding to End User's problem reports according
to AirTrack's standard assistance practices. AirTrack does not warrant that
the product will meet End User's requirements or that use of the product
will be uninterrupted or error free, or that AirTrack's remedial efforts will
correct any nonconformance. This limited warranty does not cover any
product that have been subjected to damage or abuse, whether intention-
ally, accidentally, or by neglect, or to unauthorized repair or unauthorized
installation, and shall be void if End User modifies the product, uses the
product in any manner other than as established in the Documentation, or
if End User breaches any of the provisions of this Agreement.
6.2 EXCEPT AS PROVIDED IN THIS AGREEMENT, THE AIRTRACK PRODUCT IS
PROVIDED "AS IS" AND AIRTRACK MAKES NO WARRANTIES OF ANY KIND,
EXPRESS OR IMPLIED, WRITTEN OR ORAL, WITH RESPECT TO THE PROD-
UCT, AND SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF MER-
CHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Quick Reference Guide v
7. Infringement.
To the maximum extent permitted by law, End User agrees to defend, indemnify
and hold harmless AirTrack, its affiliates and their respective directors, officers,
employees and agents from and against any and all claims, actions, suits or pro-
ceedings, as well as any and all losses, liabilities, damages, costs and expenses
(including reasonable attorney’s fees) arising out of or accruing from (a) the End
User’s use of Software, (b) any application the End User develops on the Software
that infringes any Intellectual Property Rights of any person or defames any per-
son or violates their rights of publicity or privacy, and (c) any non-compliance by
the End User of this Agreement.
8. Limitation Of Liability.
AIRTRACK SHALL NOT BE LIABLE FOR ANY CLAIMS AGAINST END USER BY ANY
OTHER PARTY. IN NO EVENT SHALL AIRTRACK'S LIABILITY FOR DAMAGES, IF ANY,
WHETHER BASED UPON CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIA-
BILITY, STRICT LIABILITY, WARRANTY, OR ANY OTHER BASIS, EXCEED THE PRICE OR
FEE PAID BY END USER FOR THE AIRTRACK PRODUCT. UNDER NO CIRCUMSTANCES
SHALL AIRTRACK BE LIABLE TO END USER OR ANY THIRD PARTY FOR LOST PROF-
ITS, LOST DATA, INTERRUPTION OF BUSINESS OR SERVICE, OR FOR ANY OTHER SPE-
CIAL, CONSEQUENTIAL, CONTINGENT, INDIRECT, INCIDENTAL, PUNITIVE,
EXEMPLARY, OR OTHER SIMILAR DAMAGES, EVEN IF AIRTRACK HAS BEEN ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES.
9. Government Restricted Rights; International Use.
9.1 Use, duplication, or disclosure of the Software by the U.S. Government is
subject to the restrictions for computer software developed at private
expense as set forth in the U.S. Federal Acquisition Regulations at FAR
52.227-14(g), or 52.227-19 or in the Rights in Technical Data and Computer
Software clause at DFARS 252.227-7013(c)(1)(ii), whichever is applicable.
9.2 If End User is using the AirTrack Product outside of the United States, End
User must comply with the applicable local laws of the country in which the
AirTrack Product is used, with U.S. export control laws, and with the English
language version of this Agreement. The provisions of the "United Nations
Convention on International Sale of Goods" shall not apply to this Agree-
ment.
10. Termination.
10.1 Either party may terminate this Agreement or any license granted under
this Agreement at any time upon written notice if the other party breaches
any provision of this Agreement.
10.2 Upon termination of this Agreement, End User immediately shall cease
using any nonembedded software and shall return to AirTrack or destroy all
non-embedded software covered by this Agreement, and shall furnish Air-
Track with a certificate of compliance with this provision signed by an offi-
cer or authorized representative of End User. For embedded software, End
User agrees to sign a waiver prepared by AirTrack concerning further use of
the embedded Software. End User's resumed or continued use of the
embedded Software after termination shall constitute End User's agree-
ment to be bound by the terms and conditions of this Agreement for such
use.
11. General Provisions.
11.1 Entire Agreement; Amendment. This document contains the entire agree-
ment between the parties relating to the licensing of the Software and
supersedes all prior or contemporaneous agreements, written or oral,
between the parties concerning the licensing of the Software. This Agree-
ment may not be changed, amended, or modified except by written docu-
ment signed by AirTrack.
11.2 Notice. All notices required or authorized under this Agreement shall be
given in writing, and shall be effective when received, with evidence of
receipt. Notices to AirTrack shall be sent to the attention of AirTrack & IP
Department, Via San Vitalino 13, 40012 Calderara di Reno (Bologna), Italy or
such other address as may be specified by AirTrack in writing.
11.3 Waiver. A party's failure to enforce any of the terms and conditions of this
Agreement shall not prevent the party's later enforcement of such terms
and conditions.
11.4 Governing Law; Venue: Both parties agree to the application of the laws of
the country in which End User obtained the license to govern, interpret, and
enforce all of End User’s and AirTrack’s respective rights, duties, and obliga-
tions arising from, or relating in any manner to, the subject matter of this
Agreement, without regard to conflict of law principles. The United Nations
Convention on Contracts for the International Sale of Goods does not apply.

Software Product Policy
vi S1-BT
All rights, duties, and obligations are subject to the courts of the country in
which End User obtained the license. For licenses granted by Licensee who
operates in the countries specified below, the following terms applies.
For Americas.
This Agreement is governed by the laws of the State of Oregon. This Agree-
ment and the rights of the parties hereunder shall be governed by and con-
strued in accordance with the laws of the State of Oregon U.S.A, without
regard to the rules governing conflicts of law. The state or federal courts of
the State of Oregon located in either Multnomah or Lane counties shall
have exclusive jurisdiction over all matters regarding this Agreement,
except that AirTrack shall have the right, at its absolute discretion, to initi-
ate proceedings in the courts of any other state, country, or territory in
which End User resides, or in which any of End User's assets are located. In
the event an action is brought to enforce the terms and conditions of this
Agreement, the prevailing party shall be entitled to reasonable attorneys’
fees, both at trial and on appeal.
For Europe, Middle East and Africa
This Agreement is governed by the laws of Italy. This Agreement and the
rights of the parties hereunder shall be governed by and construed in
accordance with the laws of Italy, without regard to the rules governing
conflicts of law. Italian Court of Bologna shall have exclusive jurisdiction
over all matters regarding this Agreement, except that AirTrack shall have
the right, at its absolute discretion, to initiate proceedings in the courts of
any other state, country, or territory in which End User resides, or in which
any of End User's assets are located. In the event an action is brought to
enforce the terms and conditions of this Agreement, the prevailing party
shall be entitled to reasonable attorneys’ fees, both at trial and on appeal.
For Asia- Pacific Countries
This Agreement is governed by the laws of the State of Hong Kong. This
Agreement and the rights of the parties hereunder shall be governed by
and construed in accordance with the laws of the State of Hong Kong with-
out regard to the rules governing conflicts of law. The Court of Hong Kong
shall have exclusive jurisdiction over all matters regarding this Agreement,
except that AirTrack shall have the right, at its absolute discretion, to initi-
ate proceedings in the courts of any other state, country, or territory in
which End User resides, or in which any of End User's assets are located. In
the event an action is brought to enforce the terms and conditions of this
Agreement, the prevailing party shall be entitled to reasonable attorneys’
fees, both at trial and on appeal.
11.5 Attorneys' Fees. In the event an action is brought to enforce the terms and
conditions of this Agreement, the prevailing party shall be entitled to rea-
sonable attorneys' fees, both at trial and on appeal.
- END -
Software Product Policy
AirTrack reserves the right to ship its products with the latest version
of software/firmware available. This provides our customers with the
very latest in AirTrack software technology.
The only exception to this policy is when the buyer has a signed contract
with AirTrack that clearly defines the terms and conditions for making
software/firmware changes in products shipped to the buyer.
Customers Under Software Support
To arrange for a Software Maintenance and Support Agreement please
contact your AirTrack sales person.

Quick Reference Guide 1
AirTrack S1-BT
With rich feature sets and extensive options, the S1-BT prod-
uct series from AirTrack represents the premium level of data
collection equipment for general purpose applications. The
S1-BT readers have enhanced optics with improved motion
tolerance, allowing codes placed on fast moving objects to be
easily and quickly captured. These features help to create the
ideal reader for tasks requiring high throughput like those
found in retail and light industrial environments.
Omni-
Directional
Operation
To read a symbol simply aim the reader and pull the
trigger. The
S1-BT reader is a versatile linear imager,
featuring a wide scanning angle with an extended
scanning line which is perfect for reading long and
truncated bar codes.
AirTrack's exclusive patented `Green Spot' for good-
read feedback helps to improve productivity in noisy
environments or in situations where silence is
required.
Decoding
Reliably decodes all standard 1D (linear) bar codes,
including GS1 DataBar™ linear codes.
The data stream — acquired from decoding a symbol
— is rapidly sent to the host. The reader is immedi-
ately available to read another symbol.

Setting Up the Reader
2S1-BT
Setting Up the Reader
Follow the steps below to connect and get your reader up, and
communicating with its host.
1. Configure the Base Station starting on this page.
2. Charge the Batteries (see page 8).
3. Link to the Base Station (see page 11).
4. Select the Interface Type (see page 21).
5. Configure the Reader starting on page 14 (optional,
depends on settings needed).
Locking the Reader to the Base
The Base Station provides a locking mechanism to ensure
electrical contact between Reader and Base, in case of inad-
vertent movements.
To Lock the Reader in the Base
1. Insert the Reader into the Base. The lock lever rests
in its natural disengaged position toward the bot-
tom of the Base.
Lock
Lever

Setting Up the Reader
Quick Reference Guide 3
Figure 1. Lock lever disengaged
2. Engage the locking mechanism by pushing up the lever
as far as it will go.
Figure 2. Lever in locked position
NOTE
It is good practice to put the reader in the locked
condition at the end of the working shift, or
when not in use for an extended period of time.
This will ensure that the scanner is fully seated
for complete battery recharge.

Connecting the Base Station
4S1-BT
Connecting the Base Station
Figure 3 on page 5 shows how to connect the Base Station to
a terminal, PC or other host device. Turn off the host before
connection and consult the manual for that equipment (if
necessary) before proceeding. Connect the interface cable
before applying power to the Base Station.
Base Station Connection and Routing
1. Remove the rubber Cable Stopper from the bottom of
the Base Station.
2. Securely plug the Power Cable (if used) and Interface
(I/F) Cable connectors into their respective ports in the
underside of the Base Station.
NOTE
The S1-BT can also be Powered by the Terminal.
When powered by the Terminal, the battery char-
ger is automatically set as Slow charge.
For some specific interfaces, hosts, or lengths of
cable, the use of an external power supply may be
recommended for full recharging capability (see
"Technical Specifications" on page 30 for more
details).
Cable Stopper
Power Cable
I/F Cable

Connecting the Base Station
Quick Reference Guide 5
3. After the cables are plugged in, reinsert the Cable Stop-
per.
4. Connect the Base Station power adapter to an AC wall
outlet.
Figure 3. Connecting the Base Station
Host Connection —
Verify before connection that the reader’s
cable type is compatible with your host equipment.
NOTE
The S1-BT can be set up to require a PIN code
when connecting to the host. If you are adding
new equipment to a system that uses a custom
security PIN, please see the PRG (Product Ref-
erence Guide, available on the AirTrack website)
for more information.
Cable Stopper
reinserted

Connecting the Base Station
6S1-BT
Most connections plug directly into the host device as shown
in Figure 4. Keyboard Wedge interface cables have a ‘Y’ con-
nection where its female end mates with the male end of the
cable from the keyboard and the remaining end at the key-
board port on the terminal/PC.
Figure 4. Connecting to the Host
Power Connection —
Plug the AC Adapter into an approved AC
socket. If plugged into the wall, ensure cable is facing down-
wards (as shown in Figure 3) to prevent undue strain on the
socket.
System and Network Layout
Typical Setup with Cradle and Host
Figure 5. Reader Layout
U
S
B
K
e
y
b
o
a
r
d
W
e
d
g
e
or...
Reader
Base Station
Host
Power Supply

Connecting the Base Station
Quick Reference Guide 7
Using the BC-S1-S2 Radio Base
Radio Base LEDs
LEDs on the S1-BT Base provide information about the Base
as well as battery charging status, as shown in Figure 6.
Figure 6. S1-BT Base LEDs
Table 1. Radio Base LEDs
LED STATUS
Power on /
Data
Yellow On = Base is powered
Yellow Blinking = Base receives data
and commands from the Host or the
Reader.
Charging Red On = the Battery is charging.
Charge com-
pleted
Green On = the Battery is completely
charged.
Charging +
Charge com-
pleted
Red and Green Blinking together =
the Reader is not correctly placed
onto the Base.
YELLOW LED
RED LED /
GREEN LED

Connecting the Base Station
8S1-BT
Charging the Battery Pack
To charge the battery, simply insert the S1-BT reader into the
base. When the scanner is fully seated in the cradle, it will
sound a “chirp” to indicate that the cradle has detected the
scanner connection.
The LEDs on the base (shown in Table 1 on page 7) will indi-
cate the status of the battery.
Alternatively, the battery can be charged by connecting the
reader directly to a host through the micro-USB connector
available in the bottom of the handle, as shown.
Replacing the Battery Pack
1. Using a coin or screwdriver, unscrew the captive screw
located on the bottom of the scanner handle until the
battery pack is disengaged.
The battery pack will rise slightly in the rear, pushed by
the contact springs.
NOTE
Before using the battery, read “Battery Safety” in
the Regulatory Addendum included with your
product. AirTrack recommends annual replace-
ment of rechargeable battery packs to ensure
maximum performance.
Micro-USB
Connector

Connecting the Base Station
Quick Reference Guide 9
2. Extract the battery pack by slightly rotating the pack
and pulling away from the reader.
To mount the new battery pack reverse the process:
1. Insert the top of the new pack inside the reader’s han-
dle.
2. Rotate the battery pack downward while pressing the
bottom side of the battery pack (to seat securely into
the contact springs) so that the edges of the pack and
the handle board are aligned, while securing the cap-
tive screw in the bottom of the handle.

Using the Reader
10 S1-BT
Using the Reader
Bar Code Reading
Point the reader at the target and pull the trigger to enable
the illuminator (red beam) to decode the bar code label. The
illuminator will remain on until the symbol is decoded.
When scanning a bar code label, you can adjust the distance
or angle to the label to help facilitate reading.
Aim and Scan
012345 012345
65°65°

Linking the Reader
Quick Reference Guide 11
Linking the Reader
Link AirTrack RF Devices to Base
For RF devices, before configuring the interface it is nec-
essary to link the handheld with the base.
To link the handheld and the base, press the trigger to
wake up the handheld and mount it into the base. If the
reader was previously linked to another base, you must
first press and hold the button on the base (>5 seconds),
then scan the
Unlink bar code before re-linking to the new
base.
Linking to a Bluetooth Adapter in
Serial Port Profile Mode
1. Install any drivers provided with the Bluetooth
adapter.
2. Scan the
Enable RF Link to Server label below to
make the scanner visible to the host computer.
3. Use the host computer’s Bluetooth manager to
“Discover new devices” and select "AirTrack
Scanner." If you receive an error message, it may
be necessary to disable security on the device.
4. Use an RS-232 terminal program to see incom-
ing data on the port designated by the com-
puter's Bluetooth manager.
Unlink
Enable RF Link to Server

Linking the Reader
12 S1-BT
Linking to a Bluetooth Adapter in HID mode
1. Install any drivers provided with the Bluetooth
adapter.
2. Scan the
Link to PC in HID label below..
3. Use the host computer’s Bluetooth manager to
“Discover new devices” and select "AirTrack
Scanner." If you receive an error message, it may
be necessary to disable security on the device.
4. Use a text editor to see incoming data on the
port designated by the computer's Bluetooth
manager.
NOTE
The S1-BT can be set up to require a PIN code
when connecting. If you want to set up a PIN, or
when adding new equipment to a system that
uses a custom security PIN, please see the PRG
(Product Reference Guide) for information.
Link to PC in HID
