Airworkx 600N Administrator Guide

CAUTION
Do not use in hazardous atmosphere.
Do not use to exhaust combustible or
explosive gases.
Do not expose to water or rain.
Connect only to grounded outlet
with GFCI device.
Disconnect power for cleaning and servicing.
AirWorkx 600N
Negative Air Machine
OPERATION & INSTRUCTION
MANUAL
IMPORTANT INSTRUCTIONS
DO NOT DISCARD;
HEPAAir Filtration Equipment
Air Scrubbers for Mold, Asbestos and Lead Abatement Industry
compact, light weight machine, 2-speeds: 350 and
425 cfm. Weight: 40 lbs. Size: 14”Hx14”Wx26.5”L
Accessories: Activated carbon filter for toxic fumes and odors.
compact, variable speed control, 150 - 600 cfm.
Weight: 55 lbs. Size: 16”Hx14”Wx30.5”L Accessories: Activated
carbon filter for toxic fumes and odors; UV-C Germicidal Light for
viruses, bacteria, mold and odors.
compact, versatile, variable speed control,
300 - 950 cfm. Weight: 75 lbs. Size: 21”Hx18”Wx32”L
Accessories: Activated carbon filter for toxic fumes and odors.
AWX1300V - narrow profile housing, variable speed
control, 300 - 1250 cfm. Weight: 90 lbs. Size: 29”Hx14”Wx33”L
Accessories: Activated carbon filter for toxic fumes and odors.
AWX2000C and 2000V - 2-speed, 1000 and 1900 cfm or variable
speed control, 300 - 1900 cfm. Weight: 110 lbs. Size:
30”Hx20”Wx33”L Accessories: Activated carbon filter for toxic
fumes and odors; UV-C Germicidal Light for viruses, bacteria, mold
and odors.
AWX2200C - 2-speed, 1000 and 2000 cfm. Weight: 125 lbs.
Size: 31”Hx26”Wx32”L. Accessories: Activated carbon filter.
AWX100V - compact and modular, variable speed control,
300 - 1900 cfm. Weight: 95 lbs. Size: 27”Hx18”Wx32”L with filter
attached. Accessories: Activated carbon filter for toxic fumes and
odors.
AWX400C -
AWX600V -
AWX1000V -
1-855-668-8400
www.airworkx.com
AirWorkx
www.airworkx.com
1-855-668-8400

2” Pleated Pre-filter,
MERV 11. Can be used in
conjunction with the stan-
dard Primary/Secondary or
as a stand alone. Slides
down into the door pocket.
2” OdorGuard 600 Carbon
Filter. Use with the stan-
dard Primary/Secondary
filter. Slides down into the
door pocket.
Geo95 MERV 14 filter can
be used in place of the
HEPA filter. Provides
economical filtration for
non-hazardous dust and
contaminants.
Shown with HEPA Filter
99.97% @ 0.3 micron
installed
Dustlok Primary/Secondary
filter inside door pocket
Pre-filters Optional Particulates Filter
Optional Odor/Fumes Filter
or
Final Filter
Optional Final Filter

Specifications
Air flow: 200 to 600 cfm with variable speed controller, 1,000
cfm free flow.
Power requirements: 115 VAC/50-60 Hz, 2.2 Amp.
Controls: Speed Controller, Circuit Breaker 12 Amp, Power and
Change Filter indicator lights.
GFCI Protected Outlets: Use for additional small machines and
equipment. Maximum load is 8 amps at 115 VAC.
HEPA Filter: 99.97% @ 0.3 micron efficiency, individually
tested and certified, 16”x16”x6”, highflow.
Primary/Secondary filter: Polyester, MERV 8, dual density with
antimicrobial inhibitor and tactifier.
Blower: Motorizedimpeller with thermal overload.
Housing: Polyethylene flame retardant resin with UL94-V
rating, UV resistant Class 8, Rotomold seamless construction.
Dimensions: 25” L x 18½” H x 18” W with 10” diameter
connections for flex hoses on suction and discharge side.
Weight with filters installed: 36 lbs.
Warning: To prevent injury, always disconnect
the machine from power outlet when servicing.
Motor/blower will automatically restart after
thermal overload or momentary loss of power.
ORDERING INFO PART NUMBER
AirWorkx 600N AWX600N
HEPA Filter AWXOAH15156
Geo95 Filter AWXOAG15154
Primary/Secondary Filter (qty 20) AWXOAP1616
OdorGuard 600 AWXOG1616
Primary Pleated Filter MERV 11 AWXOPF1616
Quick Clamp AWXQCW12
Flexible Duct, 10" x 25' AWXOAD10
AirWorkx 600N - NITRO 600
The NITRO 600 is a portable multi-use air filtration machine for
commercial and industrial use. Machine comes with Dustlok
Primary/Secondary MERV 8 filter and a choice of final filter,
HEPA 99.97% or Geo95 MERV 14 filter. Optional pleated
MERV 11 dust filter and OdorGuard carbon filter for odors and
fumes can be added at any time. The NITRO 600 provides a
cleaner and healthier environment at construction and renovation
projectsand in industrial environments.
Requirements for safe operation
1. Only properly trained personnel should operate this equipment
- read manual.
2. Check power cord for damage or breaks.
3. Do not lay power cords in water or expose to heat or sharp
edges. Replace cord when damaged.
4. Never clean or repair the unit while connected to power outlet.
5. CAUTION:
• Do not use in hazardous atmosphere.
• Do not use to exhaust combustible or explosive gases.
• Do not expose to water or rain.
• Connect only to grounded outlets with GFCI device.
• Disconnect power when cleaning and servicing.
Electrical Requirements:
1. Power requirements, 115 VAC, 50/60 Hz
2. Extension cords should be UL/CSA listed, 3 wire, 15 Amp
rating. Cordsshould not exceed 50 feet in length.
3. The power outlet should be 3-prong, grounded electrical
outlet.
Typical Applications Filters To Use
Mold and Fungi Spores HEPA 99.97 @ 0.3 micron, Primary/Secondary
Lung-damaging Particulates HEPA 99.97 @ 0.3 micron, Primary/Secondary
Volatile Organic Compounds HEPA 99.97 @ 0.3 micron, OdorGuard, Pri/Sec
Irritating Odors HEPA 99.97 @ 0.3 micron, OdorGuard, Pri/Sec
Organic Vapor Gases HEPA 99.97 @ 0.3 micron, OdorGuard, Pri/Sec
Smoke HEPA 99.97 @ 0.3 micron, OdorGuard, Pri/Sec
Construction Dust Geo95, Primary/Secondary
Drywall Dust Geo95, Primary/Secondary
Sawdust Geo95, Primary/Secondary

Filtration Stages
The NITRO 600 has a multistage pre-filter located in the door
compartment and HEPA or Geo95 filter mounted inside the main
body.
• Primary/secondary filters are combined in dual density poly
pad filter with MERV 8 efficiency. Filter is treated with anti-
microbial additive and tactifier to increase dust holding capac-
ity. Very efficient and economical filter for all types of appli-
cations.
• HEPA filter - Individually tested and certified for efficiency
99.97% of 0.3 micron size particulates.
• Optional filter:OdorGuard 600 activated carbon filter for
removal of odors, gases and VOC vapor. This 2” deep carbon
filter contains 600 grams of granular carbon per square foot
which is 12 times the amount of carbon in a typical carbon
pleated filter.
• Optional filter: MERV 11 pleated filter 2” deep - High ef-
ficiency filtration for 1 to 20 micron size particulates.
• Optional filter: Geo95 MERV 14 filter - Can be used in
place of HEPA filter on non-hazardous applications.
Operation
1. With the speed controller in the OFF position, plug the power
cord into a 115 VAC power source.
2. Turn the speed control knob from the OFF to the MAX posi-
tion and allow the motor to come up to full speed. The
POWER indicator light will come on at this time.
3. Adjust the speed control to produce the desired air flow.
4. When the CHANGE FILTER light comes on during operation,
it indicates that the air flow is restricted. See the Trouble-
shooting section of this manual to correct the problem.
Troubleshooting
The AirWorkx 600N Nitro has been engineered to provide long
lasting service. High quality materials and components are used in
the manufacturing process, but there may be an instance where
you need to refer to these common sense guides.
1. Unit does not start when turned ‘ON’.
Make sure the power cord isnot damaged and that it is
plugged into a power source.
If the circuit breaker on the machine has tripped, re-set it.
If the GFCI on the machine has tripped, re-set it.
If the motor smells hot it is possible that the thermal overload
on the motor has tripped. Wait 30 minutes to allow the motor
to cool and restart.
2. Building circuit breakerhastripped.
The circuit may be overloaded. Unplug other equipment using
the same circuit or reposition the machine to a different circuit.
3. “CHANGE FILTER” indicator light is on.
If the Primary/Secondary filter looks dirty, replace it.
The HEPA filter may be “full” and needs to be replaced.
Visually inspect the HEPA filter and if it looks clogged then
replace the filter. If the filter does not look clogged then
inspect the flex hose on the intake side of the machine if you
are using one. If the flex hose is kinked or curved too abruptly
then straighten it out and see if that corrects the problem. If
you are using another optional filter then inspect that filter to
make sure you have removed whatever packing material it
mayhave been shipped in.
If the light remains illuminated and you have checked the
hoses and replaced the primary/secondary filter then the final
stage filter, whether it is the HEPA or Geo95 must be replaced
at this time.
Proper handling of equipment will keep it in operating condition
for a long time. Please protect your investment wisely.
