AIS WatchMate Quick start guide

10-16 VDC Neg (-)
10-16 VDC Pos (+)
Circuit breaker
or Fuse (2A max)
AISWatchMate®
Blue
Brown
AISWatchMate Power Supply Wiring Diagram
Rev A - 0905

AISWatchMate®
Green
Yellow
AISWatchMate Wiring Diagram for GPS and AIS Receiver
Rev A - 0905
GNDData
Out
3
2
5
GPS
AIS
Receiver GND
OUT
IN
Use the supplied 9 pin
connector/cable if your
AIS receiver requires it.
Set GPS for NMEA 0183
output and 4800 baud
Pin

AISWatchMate®
Green
Yellow
AISWatchMate Wiring Diagram for GPS and AIS Receiver
Alternative for Separate Connections
Rev A - 0905
GND
Data
Out
3
2
5
GPS
AIS
Receiver GND
OUT
Use the supplied 9 pin
connector/cable if your
AIS receiver requires it.
Set GPS for NMEA 0183
output and 4800 baud
Use SETUP mode to change
I/O port 1 input device to GPS
RedPink
Not used
Pin

AISWatchMate®
Green
Yellow
AISWatchMate Wiring Diagram for AIS Transponder
Rev A - 0905
3
2
5
AIS
Transponder GND
OUT
IN
Use the supplied 9 pin
connector/cable if your
AIS receiver requires it.
White
Pin

AISWatchMate Wiring Diagram for AIS Transponder
Using NMEA Connections
Rev A - 0905
AIS
Transponder NMEA +
NMEA -
Use this setup if you want to make the 9-pin connector on your transponder available for connecting to a computer
Green
Yellow
AISWatchMate®
Black
Orange
Orange and black are the colors
used by most transponders.
Please check your transponder
manual to ensure this is correct.

AISWatchMate®
Grey
Red
AISWatchMate Wiring Diagram for Computer
Rev A - 0905
3
2
5
Computer
Use a female 9 pin connector/cable (not supplied).
You may also require a USB-to-serial adpater if your
computer does not have a 9 pin serial connection.
Pink
Pin

12 VDC
Neg (-)
12 VDC
Pos (+)
Fuse (2A max)
External
12V buzzer
or indicator
Neg (-)
Pos (+)
AISWatchMate®
Orange
Black
AISWatchMate Wiring Diagram for External Alarm or Indicator
Rev A - 0905
