1. General
This Android-based mobile computer has a powerful quad-core processor, stable
wireless connectivity (4G LTE, Wi-Fi, Bluetooth), a high-resolution camera,
accurate GPS, NFC, optional 2D barcode scanner and Iris Recognition. This robust
device can be used in industries such as express delivery, logistics, warehousing,
manufacturing.
The free apps devin and aiBrowser for barcode and RFID management with
Android apps and Android web applications, as well as the app ScannerDemo
(including source code) are already pre-installed and enabled on this device. These
apps have been developed specifically for android-based LogiScan-15xx/17xx and
can only be run on these devices.
2. Batteries
Precautions for using Batteries
Do not damage the batteries, heat, compress, open (eg with a drill) or soak in
water: danger of explosion! Make sure to store batteries out of the reach of
children or animals.
Do not use the product in explosion hazardous areas.
If the product gets wet, do not heat or heat (eg heating, microwave, etc.).
Heated battery can cause an explosion, deform or become unusable. On
contact with water and other liquids, the sticker changes color inside the
terminal. In this case, the warranty claim expires.
Do not use in an airplane or hospital.
Do not expose batteries to direct sunlight (eg car dashboard), because they are
deformed by heat and become unusable.
Do not let the battery unused for long periods in the device or in storage. If the
battery has not been used for 6 months or longer, check the charge status and
charge or dispose of the battery if necessary.
The typical estimated life of a lithium-ion battery is approximately 2 to 3 years,
or 300 to 500 charge cycles, whichever occurs first. A charge cycle is the useful
life of fully charged to fully discharged and fully recharged. For batteries with
which no full charge cycles are run through, the life expectancy is about 2 to 3
years.
Rechargeable lithium ion batteries have a limited lifespan, and gradually lose
their ability to hold a charge. This loss in capacity (aging) is irreversible. Since
the battery capacity decreases, so does the time from about the device can be
operated with a fully charged battery.
Lithium-ion batteries gradually, if they are not in use or during storage (self-
discharge). The battery charge status should be checked regularly. The

LogiScan-17xx Operating Manual ___________________________________________
Edition 22.11.2018 _____________________________________________________ aitronic
3
instructions contain information such as the state of charge to check and how
the batteries must be recharged.
Observe and register the term, which can be reached with a new, fully charged
battery with your device. Use the term of a new battery as a basis to compare
the runtimes with older batteries. The duration of the batteries varies depending
on the configuration of the device and applications that are running.
Batteries that have almost reached the end of their estimated life is to carefully
monitor.
Replace the battery with a new one of the following conditions applies:
The battery life is less than about 80% of the initial term.
The battery charge time increases significantly.
If a battery is stored for long periods of time or otherwise not used, please see
the instructions for the storage of batteries in this document. If you have not
followed the instructions and the battery has no charge, you look at it as
damaged and replace it with a new one.
Observe the loading instructions in the user manual of the product and / or the
detailed online help to recharge your batteries.
Charging or discharging the battery to approximately 50% of capacity before
storage.
Charge the battery to approximately 50% of capacity at least once every 6
months.
Remove the battery and store these separately from your device.
Store the battery at a temperature between 5 °C and 20 °C (41 °F and 68 °F).
Charging the Battery
Direct Charging: Connect AC adapter with charging cable or AC adapter with
USB cable to USB jack of the Snap-On.
Please notice: If the device should be charged via the AC
adapter, the USB cable has to be disconnected, otherwise the
charging will be done via the USB cable.
Cradle Charging: Connect AC adapter to the cradle and plug LogiScan-1700
into the cradle.

LogiScan-17xx Operating Manual ___________________________________________
Edition 22.11.2018 _____________________________________________________ aitronic
4
Deeply discharged Batteries
Symptoms: A device with a deeply discharged battery can no longer be
switched on. After the AC adapter has been plugged in or the device has been
put into the cradle, the flash symbol can flash for a short time. Until then the
red charge LED at the top left of the device can go up to 10 minutes.
Leave the device connected in the cradle or the AC adapter!
Observe the notes in "Charging the Battery".
Thus, a deep discharge of the battery can be avoided:
Charge the batteries regularly. For intensive use should be loaded daily.
Charge the battery as soon as possible after you receive the prompt from the
device.
If a device is not used for more than 2 days, turn it off as follows: Press and
hold the power button on the side of the device, and then press "Turn off" in
the menu that appears.

LogiScan-17xx Operating Manual ___________________________________________
Edition 22.11.2018 _____________________________________________________ aitronic
5
3. Controls
LogiScan-1700

LogiScan-17xx Operating Manual ___________________________________________
Edition 22.11.2018 _____________________________________________________ aitronic
6
LogiScan-1710

LogiScan-17xx Operating Manual ___________________________________________
Edition 22.11.2018 _____________________________________________________ aitronic
7
LogiScan-1720 UHF

LogiScan-17xx Operating Manual ___________________________________________
Edition 22.11.2018 _____________________________________________________ aitronic
8
4. Inserting SIM and Mini SD Cards
Open the rubber cap on the right side of the device.
Press with the tip of the included tool (or a straightened paper clip) into the
small lock of the SIM tray until it pops out a little bit and pull out the SIM tray.
Insert SIM and SD cards into the SIM tray as shown in the picture above.
Push the SIM tray completely into the receiving slot and close it with the rubber
cap.
SIM Card 1
Mini SD Card
SIM Card 2
Tool

LogiScan-17xx Operating Manual ___________________________________________
Edition 22.11.2018 _____________________________________________________ aitronic
9
5. AppCenter
The AppCenter contains a collection of apps for hardware-specific test functions,
such as
Barcode Scanner,
RFID Reader,
Fingerprint Sensor,
GPS,
Network,
Bluetooth,
NFC,
Telephone,
Camera,
Printer.
6. Barcode Scanning
7. Turning Device on/off
Press the power button at the side of the device short to switch on / off the device.
Press the power button at the side of the device and hold to start up / shut down
the device, to reboot or enable flight mode.
Right
Right
Wrong
Wrong
1D Barcode
2D Image

LogiScan-17xx Operating Manual ___________________________________________
Edition 22.11.2018 _____________________________________________________ aitronic
10
8. Pre-installed Android apps from aitronic
The following Android apps by aitronic are preinstalled on Android-based devices
from aitronic:
devin
allows the transfer of the scanned barcode scanner or RFID reader data of an
android-based LogiScan to the keyboard buffer or the clipboard. Alternatively,
a broadcast message is possible. Thus, the bar code scanner and RFID
reader can serve as a data source for each app.
aibrowser
interacts with the Android app devin and allows the transfer of the scanned
barcode scanner or RFID reader data of an android-based LogiScan into web
applications. The aiBrowser is HTML-5 compliant and is useful for modern
JavaScript-based web applications (such as Microsoft Dynamics NAV). The
optional kiosk mode prevents access to the system.
ScannerDemo
serves as a demonstration for the barcode and transponder tag pickup, on the
other hand it serves app developers as an example of the integration of
barcode scanners and RFID scanner features in a native app. We provide this
demo app to incl. source code for download.
aiInventur
The Android app aiInventur interacts with the Android app devin. aiInventur is
used for the demonstration of barcode scanners and/or RFID readers and can
be used for simple inventory with android based LogiScan.
These apps as well as the corresponding documentation can be downloaded at
https://www.aitronic.de/en/support/downloads.
9. Reset to Factory Default
Before resetting the device to factory default setttings, please save the folder
/aitronic from the device on your PC/Mac.
After the reset, copy this folder back to the device to continue using the aitronic
apps.

LogiScan-17xx Operating Manual ___________________________________________
Edition 22.11.2018 _____________________________________________________ aitronic
11
10.Disposal
Disposal of Batteries
Duty to inform in accordance with battery legislation (BattG)
Batteries and rechargeable batteries do not belong in household
waste. The consumer is obliged to dispose of no longer used batteries
properly. Let please dispose of them only through retailers or battery
collection points. Hereby you make an actual contribution to
environmental protection. Since 2009, the German battery legislation
obligates all citizens to dispose of used batteries exclusively via the trade or
specially equipped collection points (statutory obligation to return). Retailers and
manufacturers are obliged to take back these batteries free of charge and properly
and batteries to be recycled or disposed of as hazardous waste (legal obligation).
Batteries may only be disposed in the discharged state at the return points, and / or
(e.g. by isolating the poles with adhesive strips), precaution against short-circuits
has to be taken.
The built-in Li-Polymer battery of this device is marked with the adjacent Disposal
characters (consisting of a crossed out dustbin and the type of batteries used).
The symbols shown on the batteries have the following meaning:
= Battery must not be placed in household waste
Pb = Battery contains more than 0.004 percent lead
Cd = Battery contains more than 0.002 percent cadmium
Hg = Battery contains more than 0.0005 per cent of mercury
Legal notice for waste disposal
In accordance with the European legislation, it is forbidden to dispose of
electrical and electronic equipment in the domestic waste. The aitronic
GmbH takes back all of it placed on the market or sold electronic devices
and accessories. So environmentally sound disposal is ensured.

LogiScan-17xx Operating Manual ___________________________________________
Edition 22.11.2018 _____________________________________________________ aitronic
12
11.Technical Specifications
LogiScan-1700
Physical Characteristics
Dimension, Weight
163,8 x 79,2 x 13,8 mm (L x W x H), 242 g
Display
5.2 inch, high resolution (1920 x 1080)
Touch Panel
Corning Gorilla Glass, multi-touch panel, gloves and wet hands
supported
Tastatur
4 front buttons, 1 side button, 2 scan keys, 1 multifunctional key
Battery
Li-ion, rechargeable, 4000 mAh
Expansion Slot
1 slot for SIM card, 1 slot for SIM or TF card
Audio
speaker, 2 microphones
Performance
CPU
Cortex-A53 1,3 GHz Quad-Core
Memory
2 GB RAM, 16 GB ROM, Supports up to 32 GB Micro SD card
Interfaces
USB2.0 Type-C, OTG
Developing Environment
Operating System
Android 6.0
SDK
Chainway SDK
Programming Language
Java
Development Tool
Android Studio
Wireless Communication
WWAN & Voice
2G: 850/900/1800/1900 Mhz, 3G: 850/900/1900/2100 Mhz, 4G: B1,
B3, B5, B7, B8, B20, B40
WLAN
IEEE802.11 a/b/g/n, 2,4 GHz/5 GHz Dual Band, internal antenna
WPAN
Bluetooth 4.0, BLE
GPS
GPS/AGPS, GLONASS, BeiDou, internal antenna
Data Capturing
1D/2D Imager (optional)
ZEBRA SE4710, all common 1D barcode types and the following
2D codes: PDF417, MicroPDF417, Composite, RSS, TLC-39,
Datamatrix, QR Code, Micro QR Code, Aztec, MaxiCode; Postal
Codes: US PostNet, US Planet, UK Postal, Australian Postal,
Japan Postal, Dutch Postal (KIX), etc.
Camera (optional)
Rear: 13 Megapixel, autofocus with flash, front camera 5
Megapixel (optional)
NFC
13.56 MHz, Protocol: ISO/IEC 18092 (ECMA 340) and ISO/IEC
21481 (ECMA 352), range 2 - 4 cm
Iris Recognition
(optional)
Rate < 150 ms, scan range 20 - 40 cm, FAR (False Acceptance
Rate) 1/10.000.000

LogiScan-17xx Operating Manual ___________________________________________
Edition 22.11.2018 _____________________________________________________ aitronic
13
User Environment
Operating Temperature
-20 to 50° C
Storage Temperature
-40 to 70° C
Humidity
5% - 95% (not condensing)
Drop Specification
At least 1.8 m drops to the concrete across the operating
temperature range and 1000 0.5 m falls at room temperature
ESD
± 8 kV air discharge, ±4 kV conductive discharge
Sealing
IP67
LogiScan-1710
Physical Characteristics
Dimension, Weight
164.2 x 78.8 x 17.0 mm (L x B x W), 288 g
Display
5.2 inch, high resolution (1920 x 1080)
Touch Panel
Corning Gorilla Glass, multi-touch panel, gloves and wet hands
supported
Tastatur
4 front buttons, 1 side button, 2 scan keys, 1 multifunctional key
Battery
Li-ion, rechargeable, 5000 mAh
Expansion Slot
1 slot for SIM card, 1 slot for SIM or TF card
Audio
speaker, 2 microphones
Sensors
Gravity, light and proximity sensor, vibration motor
Performance
CPU
Cortex-A53 1,3 GHz Quad-Core
Memory
2 GB RAM, 16 GB ROM, Supports up to 32 GB Micro SD card
Interfaces
USB2.0 Type-C, OTG
Developing Environment
Operating System
Android 6.0
SDK
Chainway SDK
Programming Language
Java
Development Tool
Android Studio
Wireless Communication
WWAN & Voice
2G: 850/900/1800/1900 MHz, 3G: 850/900/1900/2100 Mhz, 4G: B1,
B3, B5, B7, B8, B20, B40
WLAN
IEEE802.11 a/b/g/n, 2.4/5 GHz Dual Band, internal antenna
WPAN
Bluetooth 4.0, BLE
GPS
PS/AGPS, GLONASS, BeiDou, internal antenna

LogiScan-17xx Operating Manual ___________________________________________
Edition 22.11.2018 _____________________________________________________ aitronic
14
Data Capturing
1D/2D Imager (optional)
ZEBRA SE4750, alle gängigen 1D- und folgende 2D-Codes:
PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR
code, Micro QR code, Aztec, MaxiCode; Postal Codes: US
PostNet, US Planet, UK Postal, Australian Postal, Japan Postal,
Dutch Postal (KIX), etc.
Camera (optional)
5 MP, autofocus with flash
NFC
13.56 MHz, Protocol: ISO/IEC 18092 (ECMA 340) and ISO/IEC
21481 (ECMA 352), range 2 - 4 cm
RFID LF/HF Reader
Modul Standard or
LEGIC (optional)
125 and 134 kHz, 13,56 MHz
Supported transponder tag types see pages 17 and 18
Iris Recognition
(optional)
Rate < 150 ms, scan range 20 - 40 cm, FAR (False Acceptance
Rate) 1/10.000.000
User Environment
Operating Temperature
-20 to 50° C
Storage Temperature
-40 to 70° C
Humidity
5% - 95% (not condensing)
Drop Specification
At least 1.8 m drops to the concrete across the operating
temperature range and 1000 0.5 m falls at room temperature
ESD
± 8 kV air discharge, ±4 kV conductive discharge
Sealing
IP67
LogiScan-1710 UHF
Physical Characteristics
Dimension, Weight
164.2 x 78.8 x 17.0 mm (L x B x W), 321 g
Display
5.2 inch, high resolution (1920 x 1080)
Touch Panel
Corning Gorilla Glass, multi-touch panel, gloves and wet hands
supported
Tastatur
4 front buttons, 1 side button, 2 scan keys, 1 multifunctional key
Battery
Li-ion, rechargeable, 5000 mAh
Expansion Slot
1 slot for SIM card, 1 slot for SIM or TF card
Audio
speaker, 2 microphones
Sensors
Gravity, light and proximity sensor, vibration motor
Performance
CPU
Cortex-A53 1,3 GHz Quad-Core
Memory
2 GB RAM, 16 GB ROM, Supports up to 32 GB Micro SD card
Interfaces
USB2.0 Type-C, OTG

LogiScan-17xx Operating Manual ___________________________________________
Edition 22.11.2018 _____________________________________________________ aitronic
15
Developing Environment
Operating System
Android 6.0
SDK
Chainway SDK
Programming Language
Java
Development Tool
Android Studio
Wireless Communication
WWAN & Voice
2G: 850/900/1800/1900 MHz, 3G: 850/900/1900/2100 Mhz, 4G: B1,
B3, B5, B7, B8, B20, B40
WLAN
IEEE802.11 a/b/g/n, 2.4/5 GHz Dual Band, internal antenna
WPAN
Bluetooth 4.0, BLE
GPS
PS/AGPS, GLONASS, BeiDou, internal antenna
Data Capturing
1D/2D Imager (optional)
ZEBRA SE4750, alle gängigen 1D- und folgende 2D-Codes:
PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR
code, Micro QR code, Aztec, MaxiCode; Postal Codes: US
PostNet, US Planet, UK Postal, Australian Postal, Japan Postal,
Dutch Postal (KIX), etc.
Camera (optional)
5 MP, autofocus with flash
NFC
13.56 MHz, Protocol: ISO/IEC 18092 (ECMA 340) and ISO/IEC
21481 (ECMA 352), range 2 - 4 cm
UHF
865 MHz - 868 MHz / 920 - 925 MHz / 902 - 928 MHz, circular
polarization, range 5 –100 cm
Iris Recognition
(optional)
Rate < 150 ms, scan range 20 - 40 cm, FAR (False Acceptance
Rate) 1/10.000.000
User Environment
Operating Temperature
-20 to 50° C
Storage Temperature
-40 to 70° C
Humidity
5% - 95% (not condensing)
Drop Specification
At least 1.8 m drops to the concrete across the operating
temperature range and 1000 0.5 m falls at room temperature
ESD
± 8 kV air discharge, ±4 kV conductive discharge
Sealing
IP67
LogiScan-1720 UHF
Physical Characteristics
Dimension, Weight
164.2 x 80.0 x 24.3 mm (L x B x W), 654 g
Display
5.2 inch, high resolution (1920 x 1080)
Touch Panel
Corning Gorilla Glass, multi-touch panel, gloves and wet hands
supported
Tastatur
4 front buttons, 1 side button, 2 scan keys, 1 multifunctional key
Battery
Li-ion, rechargeable, 8000 mAh
Expansion Slot
1 slot for SIM card, 1 slot for SIM or TF card
Audio
speaker, 2 microphones

LogiScan-17xx Operating Manual ___________________________________________
Edition 22.11.2018 _____________________________________________________ aitronic
16
Performance
CPU
Cortex-A53 1,3 GHz Quad-Core
Memory
2 GB RAM, 16 GB ROM, Supports up to 32 GB Micro SD card
Interfaces
USB2.0 Type-C, OTG
Developing Environment
Operating System
Android 6.0
SDK
Chainway SDK
Programming Language
Java
Development Tool
Android Studio
Wireless Communication
WWAN & Voice
2G: 850/900/1800/1900 MHz, 3G: 850/900/1900/2100 Mhz, 4G: B1,
B3, B5, B7, B8, B20, B40
WLAN
IEEE802.11 a/b/g/n, 2,4/5 GHz Dual-Band, internal antenna
WPAN
Bluetooth 4.0, BLE
GPS
PS/AGPS, GLONASS, BeiDou, internal antenna
Data Capturing
Camera (optional)
5 MP, autofocus with flash
UHF
13.56 MHz, Protokoll: ISO/IEC 18092 (ECMA 340) und ISO/IEC
21481 (ECMA 352), range 2 - 4 cm
HF, NFC (optional)
13.56 MHz, Protocol: ISO/IEC 18092 (ECMA 340) and ISO/IEC
21481 (ECMA 352), range 2 - 4 cm
1D/2D Imager (optional)
ZEBRA SE4750, alle gängigen 1D- und folgende 2D-Codes:
PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR
code, Micro QR code, Aztec, MaxiCode; Postal Codes: US
PostNet, US Planet, UK Postal, Australian Postal, Japan Postal,
Dutch Postal (KIX), etc.
Iris Recognition
(optional)
Rate < 150 ms, scan range 20 - 40 cm, FAR (False Acceptance
Rate) 1/10.000.000
User Environment
Operating Temperature
-20 to 50° C
Storage Temperature
-40 to 70° C
Humidity
5% - 95% (not condensing)
Drop Specification
At least 1.8 m drops to the concrete across the operating
temperature range and 1000 0.5 m falls at room temperature
ESD
± 8 kV air discharge, ±4 kV conductive discharge
Sealing
IP65

LogiScan-17xx Operating Manual ___________________________________________
Edition 22.11.2018 _____________________________________________________ aitronic
17
RFID LF/HF Reader Modul
Supported Transponder Tag Types
Tag Type
Reader Type
Standard
LEGIC
13,5 MHz
ISO14443A
LEGIC Advant
✔1)
✔
MIFARE: Classic/DESFire EV1/Mini/Plus S &
X/Ultralight/Ultralight C & EV1
✔
✔
MIFARE Classic EV1
✔5)
✔5)
MIFARE DESFire EV2
✔5)
✔5)
MIFARE Pro X, Smart MX
✔6)
✔6)
LEGIC Prime
✔
NTAG2xx, SLE44R35
✔
✔
PayPass
✔6)
✔6)
SLE66Rxx (my-d move)
✔6)
✔6)
Topaz
✔
ISO14443B
Calypso, CEPAS, Moneo
✔6)
✔6)
Calypso Innovatron protocol
✔5)
Pico Pass
✔2)
✔1)
SRI4K, SRIX4K, SRI512, SRT512
✔
HID iCLASS
✔1)
✔1)
ISO18092 / ECMA-340
NFC Forum Tag 1-5
✔
NFC Peer-to-Peer, NFC active and passive
communication mode
✔
✔
Sony FeliCa
✔7)
✔7)
Passive peer-to-peer mode - initiator, NFC Tag
2/3/4
✔
ISO15693
EM4x33, EM4x35
✔6)
✔6)
HID iCLASS, HID iCLASS SE/SR
✔1)
✔1)
ICODE SLI, Tag-it
✔
✔
LEGIC Advant
✔1)
✔
M24LR16/64
✔
✔
MB89R118/119
✔12)
SRF55Vxx (my-d vicinity)
✔6)
✔6)
Pico Pass
✔2)
✔1)
LEGIC Prime
✔
✔
1) UID only, 2) UID Only, read/write on request, 3) on request, 4) r/w, enhanced security features
on request, 5) r/w in direct chip command mode, 6) UID + r/w public area, 7) without crypto, 8)
hash value only, 9) UID + PAC (CSN & Facility Code), r/w on request, 10) only emulation of
4100, 4102, 11) supported by TWN4 MultiTech 2/3 BLE and TWN4 MultiTech Nano only, 12) not
supported by TWN4 MultiTech HF Mini, 13)AES only
