Aiwa Z-r990 User manual

S E R V I C E M A N U A L

SIMPLE MANUAL

•Replace this Service Manual with ”Revision Publishing” when it is issued.

Z-R990

• BASIC TAPE MECHANISM: 2ZM-3MK2 YPR5NM

• BASIC CD MECHANISM: 6ZG-1 YS2DSHNM • TYPE: K

S/M Code No. 09–986–262–0FE

COMPACT DISC STEREO

CASSETTE RECEIVER

ELECTRICAL MAIN PARTS LIST - 1/7

NOTE: The characters in the suffix column indicate the part usage.

KBNE ...................XX...................................B..................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

85-NF5-210-110 GUIDE,LED L ....................

85-NF5-211-110 GUIDE,LED R ....................

88-MA1-205-010 GUIDE,FL ....................

C 109 87-010-071-040 CAP,E 1-50 5L ....................

C 103 87-010-197-080 CAP, CHIP 0.01 DM ....................

C 104 87-010-312-080 C-CAP,S 15P-50 CH ....................

C 105 87-010-316-080 C-CAP,S 33P-50 CH ....................

C 106 87-010-320-080 CHIP CAP 68P ....................

C 102 87-010-320-080 CHIP CAP 68P ....................

C 101 87-010-320-080 CHIP CAP 68P ....................

C 108 87-010-405-040 CAP,E 10-50 ....................

C 107 87-012-157-080 C-CAP,S 330P-50 CH ....................

C 116 87-010-071-040 CAP,E 1-50 5L ....................

C 117 87-010-079-040 CAP,E 100-6.3 5L ....................

C 115 87-010-178-080 CHIP CAP 1000P ....................

C 119 87-010-408-040 CAP,E 47-50 SME ....................

C 118 87-012-369-080 C-CAP,S 0.047-50F ....................

C 113 87-A10-189-040 CAP,E 220-10 ....................

C 122 87-010-194-080 CAP, CHIP 0.047 ....................

C 121 87-010-421-040 CAP,E 4.7-50 5L ....................

C 120 87-010-421-040 CAP,E 4.7-50 5L ....................

C 204 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

C 203 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

C 281 87-010-198-080 CAP, CHIP 0.022 ....................

C 282 87-010-198-080 CAP, CHIP 0.022 ....................

C 381 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

C 387 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

C 385 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

C 383 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

C 386 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

C 384 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

C 382 87-012-158-080 C-CAP,S 390P-50 CH ....................

C 952 87-012-145-080 CAP, CHIP S 270P CH ....................

C 951 87-012-145-080 CAP, CHIP S 270P CH ....................

C 950 87-012-145-080 CAP, CHIP S 270P CH ....................

CN 101 87-099-720-010 CONN,30P TYK-B(P) ....................

CN 102 87-A60-137-010 CONN,12P V FE ....................

CN 104 87-A60-140-010 CONN,15P V FE ....................

CN 301 87-099-197-010 CONN, 9P 6216 V ....................

D 107 87-A40-270-080 C-DIODE,MC2838 ....................

D 109 87-A40-344-080 ZENER,MTZJ6.2C ....................

D 116 87-001-167-080 DIODE,1SS302 (100MA) ....................

D 110 87-A40-269-080 C-DIODE,MC2836 ....................

D 115 87-A40-345-080 ZENER,MTZJ10C ....................

D 331 87-A40-470-080 DIODE,1SS254 ....................

FL 101 88-MA1-604-010 FL,BJ612GK ....................

IC 102 87-NF8-614-010 IC,SPS-442-1-W ....................

IC 101 88-MA1-603-010 C-IC,LC866560W-5H45 ....................

IC 203 87-017-915-080 IC,BU4094BCF ....................

IC 201 87-017-915-080 IC,BU4094BCF ....................

IC 202 87-017-915-080 IC,BU4094BCF ....................

IC 204 87-017-915-080 IC,BU4094BCF ....................

IC 380 87-A20-083-010 IC,BA3835S ....................

JW 102 87-A90-246-080 PROTECTOR,0.25A 60 4 ....................

LED 207 87-070-197-080 LED,SLP7118C-51-S-T1 ....................

LED 208 87-070-197-080 LED,SLP7118C-51-S-T1 ....................

LED 209 87-070-197-080 LED,SLP7118C-51-S-T1 ....................

LED 206 87-070-197-080 LED,SLP7118C-51-S-T1 ....................

LED 212 87-070-197-080 LED,SLP7118C-51-S-T1 ....................

LED 214 87-070-197-080 LED,SLP7118C-51-S-T1 ....................

LED 210 87-070-197-080 LED,SLP7118C-51-S-T1 ....................

LED 213 87-070-197-080 LED,SLP7118C-51-S-T1 ....................

LED 211 87-070-197-080 LED,SLP7118C-51-S-T1 ....................

LED 215 87-070-197-080 LED,SLP7118C-51-S-T1 ....................

LED 219 87-A40-446-040 LED,SLP-7131F-81H-S-T1 P-GRN ....................

LED 217 87-A40-446-040 LED,SLP-7131F-81H-S-T1 P-GRN ....................

LED 216 87-A40-446-040 LED,SLP-7131F-81H-S-T1 P-GRN ....................

LED 218 87-A40-446-040 LED,SLP-7131F-81H-S-T1 P-GRN ....................

LED 220 87-A40-446-040 LED,SLP-7131F-81H-S-T1 P-GRN ....................

LED 221 87-A40-446-040 LED,SLP-7131F-81H-S-T1 P-GRN ....................

LED 236 87-070-278-010 LED,SLZ-738A-24-S ....................

LED 233 87-070-278-010 LED,SLZ-738A-24-S ....................

LED 234 87-070-278-010 LED,SLZ-738A-24-S ....................

LED 235 87-070-278-010 LED,SLZ-738A-24-S ....................

LED 238 87-070-290-010 LED,SLZ 936-30-S ....................

LED 237 87-070-290-010 LED,SLZ 936-30-S ....................

LED 244 87-070-201-080 LED,SLP9118C-51-S-T1 ....................

LED 248 87-070-201-080 LED,SLP9118C-51-S-T1 ....................

LED 249 87-070-201-080 LED,SLP9118C-51-S-T1 ....................

LED 246 87-070-201-080 LED,SLP9118C-51-S-T1 ....................

LED 245 87-070-201-080 LED,SLP9118C-51-S-T1 ....................

LED 247 87-070-201-080 LED,SLP9118C-51-S-T1 ....................

LED 250 87-070-201-080 LED,SLP9118C-51-S-T1 ....................

PR 201 87-A90-393-080 PROTECTOR,0.5A 491SERISE 60V ....................

Q 108 87-A30-071-080 C-TR,RT1N 144C ....................

Q 104 87-A30-073-080 C-TR,RT1N 141C ....................

ELECTRICAL MAIN PARTS LIST - 2/7

Q 101 87-A30-076-080 C-TR,2SC3052F ....................

Q 102 87-A30-076-080 C-TR,2SC3052F ....................

Q 105 87-A30-085-070 C-TR,CSA1362GR ....................

Q 106 87-A30-085-070 C-TR,CSA1362GR ....................

Q 107 89-112-965-080 TR,2SA1296 (0.75W) ....................

Q 115 87-A30-105-080 C-TR,RT1P 441C ....................

Q 202 87-026-580-080 C-TR,DTA123JK ....................

Q 205 87-026-580-080 C-TR,DTA123JK ....................

Q 201 87-026-580-080 C-TR,DTA123JK ....................

Q 203 87-026-580-080 C-TR,DTA123JK ....................

Q 204 87-026-580-080 C-TR,DTA123JK ....................

Q 206 87-A30-073-080 C-TR,RT1N 141C ....................

Q 207 87-A30-073-080 C-TR,RT1N 141C ....................

Q 251 87-A30-076-080 C-TR,2SC3052F ....................

Q 262 89-112-965-080 TR,2SA1296 (0.75W) ....................

Q 282 87-A30-105-080 C-TR,RT1P 441C ....................

Q 281 87-A30-105-080 C-TR,RT1P 441C ....................

Q 301 87-A30-075-080 C-TR,2SA1235F ....................

Q 302 87-A30-087-080 C-FET,2SK2158 ....................

R 301 87-022-355-080 C-RES,S10K-1/10W F ....................

R 321 87-022-355-080 C-RES,S10K-1/10W F ....................

R 341 87-022-355-080 C-RES,S10K-1/10W F ....................

S 101 87-A90-535-010 SW,RTRY EC16B24304 ....................

S 103 87-A90-792-010 SW,RTRY EC12E12244 ENCORDER ....................

S 337 87-A90-095-080 SW,TACT EVQ11G04M ....................

S 336 87-A90-095-080 SW,TACT EVQ11G04M ....................

X 101 87-A70-070-080 VIB,CER 5.76MHZ CRHF ....................

C 505 87-010-180-080 C-CER 1500P ....................

C 509 87-010-181-080 CAP,CHIP S 1800P ....................

C 508 87-010-197-080 CAP, CHIP 0.01 DM ....................

C 504 87-010-197-080 CAP, CHIP 0.01 DM ....................

C 506 87-010-213-080 C-CAP,S 0.015-50 B ....................

C 507 87-010-213-080 C-CAP,S 0.015-50 B ....................

C 502 87-010-319-080 C-CAP,S 56P-50 CH ....................

C 501 87-010-319-080 C-CAP,S 56P-50 CH ....................

C 503 87-012-393-080 C-CAP,S 0.22-16 R K ....................

C 511 87-010-067-040 CAP,E 0.1-50 5L ....................

C 513 87-010-071-040 CAP,E 1-50 5L ....................

C 514 87-010-071-040 CAP,E 1-50 5L ....................

C 516 87-010-183-080 C-CAP,S 2700P-50 B ....................

C 515 87-010-183-080 C-CAP,S 2700P-50 B ....................

C 510 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

C 518 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

C 519 87-010-263-040 CAP,E 100-10 ....................

C 512 87-010-503-040 CAP,E 220-4 GAS ....................

C 525 87-012-141-080 CHIP-CAPACITOR,0.22-16F ....................

C 609 87-010-068-040 CAP E 0.22-50 5L ....................

C 602 87-010-186-080 CAP,CHIP 4700P ....................

C 605 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

C 608 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

C 607 87-010-321-080 CHIP CAPACITOR,82P(J) ....................

C 606 87-010-322-080 C-CAP,S 100P-50 CH ....................

C 604 87-010-382-040 CAP,E 22-25 SME ....................

C 603 87-010-405-040 CAP,E 10-50 ....................

C 601 87-010-405-040 CAP,E 10-50 ....................

C 612 87-010-176-080 C-CAP,S 680P-50 SL ....................

C 611 87-010-176-080 C-CAP,S 680P-50 SL ....................

C 614 87-010-248-040 CAP,E 220-10 SME ....................

C 610 87-010-322-080 C-CAP,S 100P-50 CH ....................

D 501 87-017-931-080 ZENER,MTZJ5.6B ....................

D 601 87-A40-470-080 DIODE,1SS254 ....................

FB 601 87-A50-190-080 C-COIL,S BLM21A102S ....................

IC 501 87-A20-613-040 C-IC,BU9262AFS ....................

IC 601 87-017-888-080 IC,NJM4558MD ....................

J 602 87-099-659-010 JACK,6.3 JY-6314-01130 ....................

J 601 87-099-659-010 JACK,6.3 JY-6314-01130 ....................

L 501 87-005-448-080 COIL 220UH,K ....................

Q 601 87-A30-087-080 C-FET,2SK2158 ....................

C 801 87-010-263-040 CAP,E 100-10 ....................

C 805 87-010-315-080 C-CAP,S 27P-50 CH ....................

C 804 87-010-315-080 C-CAP,S 27P-50 CH ....................

C 803 87-010-400-040 CAP,E 0.47-50 ....................

C 853 87-010-404-040 CAP,E 4.7-50 SME ....................

C 852 87-012-156-080 C-CAP,S 220P-50 CH ....................

D 801 87-070-136-080 ZENER,MTZJ5.1B ....................

D 802 87-A40-470-080 DIODE,1SS254 ....................

IC 801 88-NF5-615-040 C-IC,MSM6654A-521GS-KR1 ....................

JR 802 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

Q 851 87-A30-076-080 C-TR,2SC3052F ....................

X 801 87-A70-075-080 VIB,CER 4.19MHZ CRHF ....................

C 199 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

FC 102 87-A90-505-080 FUSE CLAMP,TP00351-51 .B..................

FC 101 87-A90-505-080 FUSE CLAMP,TP00351-51 .B..................

PR 103 87-026-682-080 PROTECTOR,10A 60V491 .B..................

PR 104 87-026-682-080 PROTECTOR,10A 60V491 .B..................

PR 102 87-026-682-080 PROTECTOR,10A 60V491 .B..................

PR 101 87-026-682-080 PROTECTOR,10A 60V491 .B..................

T 101 87-A60-317-010 TERMINAL, 1P MSC .B..................

T 102 87-A60-317-010 TERMINAL, 1P MSC .B..................

W 104 85-NF5-628-010 F-CABLE 7P-2.5 .B..................

WH 101 87-A90-460-010 HLDR,WIRE 2.5-7P .B..................

87-067-579-010 TAPPING SCREW, BVT2+3-8 .B..................

ELECTRICAL MAIN PARTS LIST - 3/7

87-067-703-010 TAPPING SCREW, BVT2+3-10 .B..................

C 109 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 107 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 108 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 105 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 106 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 104 87-016-658-090 CAP,E 4700-35 SMG .B..................

C 103 87-016-658-090 CAP,E 4700-35 SMG .B..................

C 102 87-A10-231-090 CAP,E 3300-80 .B..................

C 101 87-A10-231-090 CAP,E 3300-80 .B..................

C 112 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 111 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 110 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 116 87-010-247-080 CAP, ELECT 100-50V .B..................

C 113 87-010-247-080 CAP, ELECT 100-50V .B..................

C 119 87-010-260-080 CAP, ELECT 47-25V .B..................

C 118 87-010-263-080 CAP, ELECT 100-10V .B..................

C 115 87-010-385-080 CAP, ELECT 220-25V ....................

C 114 87-010-385-080 CAP, ELECT 220-25V ....................

C 117 87-010-430-080 CAP, ELECT 100-63 .B..................

C 124 87-010-112-080 CAP, ELECT 100-16V .B..................

C 125 87-010-235-080 CAP,E 470-16 SME .B..................

C 123 87-010-247-080 CAP, ELECT 100-50V .B..................

C 120 87-010-403-080 CAP, ELECT 3.3-50V .B..................

C 121 87-012-140-080 CAP 470P .B..................

C 130 87-012-369-080 C-CAP,S 0.047-50F .B..................

C 131 87-012-369-080 C-CAP,S 0.047-50F .B..................

D 106 87-070-274-080 DIODE,1N4003 SEM .B..................

D 109 87-070-274-080 DIODE,1N4003 SEM .B..................

D 107 87-070-274-080 DIODE,1N4003 SEM .B..................

D 108 87-070-274-080 DIODE,1N4003 SEM .B..................

D 101 87-A40-224-010 DIODE,GBU8D .B..................

D 102 87-A40-224-010 DIODE,GBU8D .B..................

D 104 87-A40-269-080 C-DIODE,MC2836 .B..................

D 105 87-A40-270-080 C-DIODE,MC2838 .B..................

D 103 87-A40-470-080 DIODE,1SS254 .B..................

D 116 87-A40-269-080 C-DIODE,MC2836 .B..................

D 110 87-A40-341-080 ZENER,MTZJ 36 A .B..................

D 112 87-A40-345-080 ZENER,MTZJ10C .B..................

D 120 87-A40-004-080 ZENER,MTZJ16A .B..................

JW 138 87-008-372-080 FILTER, EMI BL OIRNI .B..................

Q 103 87-026-610-080 TR,KTC3198GR .B..................

Q 107 87-A30-075-080 C-TR,2SA1235F .B..................

Q 109 87-A30-075-080 C-TR,2SA1235F .B..................

Q 108 87-A30-076-080 C-TR,2SC3052F .B..................

Q 106 87-A30-076-080 C-TR,2SC3052F .B..................

Q 104 87-A30-076-080 C-TR,2SC3052F .B..................

Q 105 87-A30-196-080 TR,2SC4115SRS .B..................

Q 102 89-213-702-010 TR,2SB1370 (1.8W) .B..................

Q 101 89-213-702-010 TR,2SB1370 (1.8W) .B..................

Q 111 87-026-609-080 TR,KTA1266GR .B..................

Q 112 87-026-609-080 TR,KTA1266GR .B..................

Q 114 87-A30-075-080 C-TR,2SA1235F .B..................

Q 110 87-A30-076-080 C-TR,2SC3052F .B..................

RY 101 87-045-389-010 RELAY,OSA-SS-212DM5 .B..................

WH 102 87-A90-460-010 HLDR,WIRE 2.5-7P .B..................

C 0 87-018-134-080 CAPACITOR,TC-U 0.01-16 .B..................

C 209 87-010-400-080 CAP, ELECT 0.47-50V .B..................

C 204 87-016-299-080 CAP,E 10-100 SME .B..................

C 212 87-010-183-080 C-CAP,S 2700P-50 B .B..................

C 211 87-010-183-080 C-CAP,S 2700P-50 B .B..................

C 214 87-010-186-080 CAP,CHIP 4700P .B..................

C 213 87-010-186-080 CAP,CHIP 4700P .B..................

C 210 87-010-400-080 CAP, ELECT 0.47-50V .B..................

C 215 87-010-403-080 CAP, ELECT 3.3-50V .B..................

C 216 87-010-403-080 CAP, ELECT 3.3-50V .B..................

C 217 87-A10-899-080 CAP,E 47-25 M BP SME .B..................

C 218 87-A10-899-080 CAP,E 47-25 M BP SME .B..................

C 221 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 222 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 229 87-A10-812-080 C-CAP,S 220P-200 J CH .B..................

C 234 87-010-544-080 CAP, ELECT 0.1-50V .B..................

C 233 87-010-544-080 CAP, ELECT 0.1-50V .B..................

C 239 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 237 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 238 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 230 87-A10-812-080 C-CAP,S 220P-200 J CH .B..................

C 242 87-010-318-080 C-CAP,S 47P-50 CH .B..................

C 241 87-010-318-080 C-CAP,S 47P-50 CH .B..................

C 240 87-012-368-080 C-CAP,S 0.1-50 F .B..................

C 280 87-010-191-080 C-CAP,S 0.015-50 F .B..................

C 299 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

D 213 87-070-136-080 ZENER,MTZJ5.1B .B..................

D 214 87-070-136-080 ZENER,MTZJ5.1B .B..................

D 212 87-A40-274-010 DIODE,FMB-G16L .B..................

D 211 87-A40-274-010 DIODE,FMB-G16L .B..................

D 218 87-A40-470-080 DIODE,1SS254 .B..................

D 217 87-A40-470-080 DIODE,1SS254 .B..................

D 221 87-A40-270-080 C-DIODE,MC2838 .B..................

D 220 87-A40-345-080 ZENER,MTZJ10C .B..................

D 227 87-A40-470-080 DIODE,1SS254 .B..................

D 225 87-A40-488-080 DIODE,1SS244 .B..................

ELECTRICAL MAIN PARTS LIST - 4/7

D 226 87-A40-488-080 DIODE,1SS244 .B..................

D 233 87-A40-470-080 DIODE,1SS254 .B..................

D 234 87-A40-470-080 DIODE,1SS254 .B..................

D 280 87-A40-470-080 DIODE,1SS254 .B..................

D 297 87-A40-470-080 DIODE,1SS254 .B..................

D 299 87-A40-470-080 DIODE,1SS254 .B..................

D 295 87-A40-470-080 DIODE,1SS254 .B..................

D 296 87-A40-470-080 DIODE,1SS254 .B..................

J 203 87-033-240-010 TERMINAL,SP 4P32SV1-05 .B..................

J 201 87-A60-488-010 JACK,DIA6.3 BLK ST W/SW KM16AT .B..................

J 202 87-A60-547-010 JACK,PIN 4P R/W/B .B..................

L 202 87-003-383-010 COIL,1UH-S .B..................

L 201 87-003-383-010 COIL,1UH-S .B..................

Q 212 87-A30-076-080 C-TR,2SC3052F .B..................

Q 213 87-A30-076-080 C-TR,2SC3052F .B..................

Q 211 87-A30-076-080 C-TR,2SC3052F .B..................

Q 214 87-A30-076-080 C-TR,2SC3052F .B..................

Q 217 87-A30-097-010 TR,FN 1016 .B..................

Q 218 87-A30-097-010 TR,FN 1016 .B..................

Q 219 87-A30-098-010 TR,FP 1016 .B..................

Q 215 87-A30-190-080 TR,CC5551 .B..................

Q 216 87-A30-190-080 TR,CC5551 .B..................

Q 227 87-A30-072-080 C-TR,RT1P 144C .B..................

Q 226 87-A30-075-080 C-TR,2SA1235F .B..................

Q 225 87-A30-076-080 C-TR,2SC3052F .B..................

Q 220 87-A30-098-010 TR,FP 1016 .B..................

Q 222 87-A30-106-070 C-TR,CMBT5551 .B..................

Q 221 87-A30-106-070 C-TR,CMBT5551 .B..................

Q 223 87-A30-162-010 FET,2SK2937 .B..................

Q 224 87-A30-162-010 FET,2SK2937 .B..................

Q 299 87-A30-073-080 C-TR,RT1N 141C .B..................

Q 291 87-A30-074-080 C-TR,RT1P 141C .B..................

Q 290 87-A30-107-070 C-TR,CMBT5401 .B..................

Q 295 87-A30-142-040 C-TR,DTA123EKA .B..................

R 237 87-A00-262-080 RES,M/F 0.15-2W J .B..................

R 239 87-A00-262-080 RES,M/F 0.15-2W J .B..................

R 238 87-A00-262-080 RES,M/F 0.15-2W J .B..................

R 240 87-A00-262-080 RES,M/F 0.15-2W J .B..................

R 284 88-121-223-080 RESISTOR, 1/8W-22K .B..................

RY 201 87-045-382-010 RELAY,OUAZ-SH-112L .B..................

TH 202 87-A90-221-080 C-THMS,100K .B..................

TH 201 87-A90-221-080 C-THMS,100K .B..................

C 307 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 302 87-010-318-080 C-CAP,S 47P-50 CH .B..................

C 301 87-010-318-080 C-CAP,S 47P-50 CH .B..................

C 305 87-012-145-080 CAP, CHIP S 270P CH .B..................

C 306 87-012-145-080 CAP, CHIP S 270P CH .B..................

C 303 87-012-157-080 C-CAP,S 330P-50 CH .B..................

C 304 87-012-157-080 C-CAP,S 330P-50 CH .B..................

C 315 87-010-181-080 CAP,CHIP S 1800P .B..................

C 316 87-010-181-080 CAP,CHIP S 1800P .B..................

C 314 87-010-182-080 C-CAP,S 2200P-50 B .B..................

C 313 87-010-182-080 C-CAP,S 2200P-50 B .B..................

C 312 87-010-198-080 CAP, CHIP 0.022 .B..................

C 311 87-010-198-080 CAP, CHIP 0.022 .B..................

C 319 87-012-141-080 CHIP-CAPACITOR,0.22-16F .B..................

C 318 87-012-142-080 CAP, S 0.33-16 .B..................

C 317 87-012-142-080 CAP, S 0.33-16 .B..................

C 324 87-010-260-080 CAP, ELECT 47-25V .B..................

C 325 87-010-370-080 CAP,E 330-6.3 SME .B..................

C 328 87-010-404-080 CAP, ELECT 4.7-50V .B..................

C 327 87-010-404-080 CAP, ELECT 4.7-50V .B..................

C 320 87-012-141-080 CHIP-CAPACITOR,0.22-16F .B..................

C 322 87-012-141-080 CHIP-CAPACITOR,0.22-16F .B..................

C 321 87-012-141-080 CHIP-CAPACITOR,0.22-16F .B..................

C 339 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 332 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 337 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 336 87-010-401-080 CAP, ELECT 1-50V .B..................

C 335 87-010-401-080 CAP, ELECT 1-50V .B..................

C 340 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 354 87-010-175-080 CAP 560P .B..................

C 355 87-010-178-080 CHIP CAP 1000P .B..................

C 359 87-010-183-080 C-CAP,S 2700P-50 B .B..................

C 358 87-010-183-080 C-CAP,S 2700P-50 B .B..................

C 357 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 356 87-010-260-080 CAP, ELECT 47-25V .B..................

C 351 87-012-140-080 CAP 470P .B..................

C 352 87-012-140-080 CAP 470P .B..................

C 360 87-010-183-080 C-CAP,S 2700P-50 B .B..................

C 374 87-010-179-080 CAP,CHIP S B1200P .B..................

C 373 87-010-179-080 CAP,CHIP S B1200P .B..................

C 372 87-010-179-080 CAP,CHIP S B1200P .B..................

C 371 87-010-179-080 CAP,CHIP S B1200P .B..................

C 370 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 378 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 376 87-010-545-080 CAP, ELECT 0.22-50V .B..................

C 375 87-010-545-080 CAP, ELECT 0.22-50V .B..................

C 385 87-010-184-080 CHIP CAPACITOR 3300P(K) .B..................

C 386 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 381 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 383 87-010-197-080 CAP, CHIP 0.01 DM .B..................

ELECTRICAL MAIN PARTS LIST - 5/7

C 382 87-010-318-080 C-CAP,S 47P-50 CH .B..................

C 384 87-010-402-080 CAP, ELECT 2.2-50V .B..................

CN 301 87-099-827-010 CONN,3P S2M-3W .B..................

CN 351 87-099-832-010 CONN,8P S2M-8W .B..................

D 352 87-A40-269-080 C-DIODE,MC2836 .B..................

D 351 87-A40-470-080 DIODE,1SS254 .B..................

FB 301 87-008-372-080 FILTER, EMI BL OIRNI .B..................

IC 302 87-A20-355-010 IC,CXA1553P .B..................

IC 301 87-A20-455-010 IC,HA12211 .B..................

L 302 87-A50-049-010 COIL,TRAP 85K(COI) .B..................

L 301 87-A50-049-010 COIL,TRAP 85K(COI) .B..................

L 351 87-007-342-010 COIL,OSC 85K BIAS .B..................

Q 355 87-026-211-080 TR,DTA144EK .B..................

Q 359 87-026-610-080 TR,KTC3198GR .B..................

Q 357 87-026-610-080 TR,KTC3198GR .B..................

Q 358 87-026-610-080 TR,KTC3198GR .B..................

Q 351 87-A30-087-080 C-FET,2SK2158 .B..................

Q 354 87-A30-087-080 C-FET,2SK2158 .B..................

Q 353 87-A30-087-080 C-FET,2SK2158 .B..................

Q 360 87-A30-087-080 C-FET,2SK2158 .B..................

Q 382 87-A30-076-080 C-TR,2SC3052F .B..................

Q 381 87-A30-076-080 C-TR,2SC3052F .B..................

SFR 306 87-A90-433-080 SFR,50K H NVZ6TLTA .B..................

SFR 305 87-A90-433-080 SFR,50K H NVZ6TLTA .B..................

SFR 304 87-A90-557-080 SFR,33K H HOKU .B..................

SFR 302 87-A90-557-080 SFR,33K H HOKU .B..................

SFR 301 87-A90-557-080 SFR,33K H HOKU .B..................

SFR 303 87-A90-557-080 SFR,33K H HOKU .B..................

SFR 352 87-A90-433-080 SFR,50K H NVZ6TLTA .B..................

SFR 351 87-A90-433-080 SFR,50K H NVZ6TLTA .B..................

C 404 87-010-183-080 C-CAP,S 2700P-50 B .B..................

C 403 87-010-183-080 C-CAP,S 2700P-50 B .B..................

C 406 87-010-193-080 CHIP CAPACITOR,0.033 .B..................

C 405 87-010-193-080 CHIP CAPACITOR,0.033 .B..................

C 409 87-010-380-080 CAP, ELECT 47-16V .B..................

C 407 87-010-405-080 CAP, ELECT 10-50V .B..................

C 402 87-010-405-080 CAP, ELECT 10-50V .B..................

C 401 87-010-405-080 CAP, ELECT 10-50V .B..................

C 408 87-010-405-080 CAP, ELECT 10-50V .B..................

C 412 87-010-112-080 CAP, ELECT 100-16V .B..................

C 416 87-010-184-080 CHIP CAPACITOR 3300P(K) .B..................

C 415 87-010-184-080 CHIP CAPACITOR 3300P(K) .B..................

C 410 87-010-380-080 CAP, ELECT 47-16V .B..................

C 411 87-010-405-080 CAP, ELECT 10-50V .B..................

IC 401 87-A20-804-040 C-IC,NJM2152M .B..................

C 507 87-010-183-080 C-CAP,S 2700P-50 B ....................

C 509 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 505 87-012-145-080 CAP, CHIP S 270P CH ....................

C 506 87-012-145-080 CAP, CHIP S 270P CH ....................

C 504 87-012-154-080 C-CAP,S 150P-50 CH ....................

C 503 87-012-154-080 C-CAP,S 150P-50 CH ....................

C 502 87-A10-060-080 C-CAP,S 0.18-16 K B ....................

C 501 87-A10-060-080 C-CAP,S 0.18-16 K B ....................

C 511 87-010-177-080 C-CAP,S 820P-50 SL ....................

C 510 87-010-177-080 C-CAP,S 820P-50 SL ....................

C 517 87-010-183-080 C-CAP,S 2700P-50 B ....................

C 514 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 512 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 515 87-010-263-080 CAP, ELECT 100-10V ....................

C 513 87-010-374-080 CAP, ELECT 47-10V ....................

C 527 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 521 87-016-460-080 C-CAP,S 0.22-16 B ....................

C 523 87-016-460-080 C-CAP,S 0.22-16 B ....................

C 522 87-016-460-080 C-CAP,S 0.22-16 B ....................

D 501 87-070-136-080 ZENER,MTZJ5.1B ....................

IC 501 87-A20-561-040 C-IC,M65847AFP ....................

C 602 87-010-180-080 C-CER 1500P .B..................

C 601 87-010-180-080 C-CER 1500P .B..................

C 607 87-010-318-080 C-CAP,S 47P-50 CH .B..................

C 606 87-010-318-080 C-CAP,S 47P-50 CH .B..................

C 608 87-010-318-080 C-CAP,S 47P-50 CH .B..................

C 605 87-010-318-080 C-CAP,S 47P-50 CH .B..................

C 619 87-010-185-080 C-CAP,S 3900P-50 B .B..................

C 614 87-016-081-080 C-CAP,S 0.1-16 RK .B..................

C 613 87-016-081-080 C-CAP,S 0.1-16 RK .B..................

C 620 87-010-185-080 C-CAP,S 3900P-50 B .B..................

C 622 87-010-401-080 CAP, ELECT 1-50V .B..................

C 621 87-010-401-080 CAP, ELECT 1-50V .B..................

C 629 87-010-405-080 CAP, ELECT 10-50V .B..................

C 626 87-010-405-080 CAP, ELECT 10-50V .B..................

C 625 87-010-405-080 CAP, ELECT 10-50V .B..................

C 637 87-010-183-080 C-CAP,S 2700P-50 B .B..................

C 635 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 634 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 636 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 630 87-010-213-080 C-CAP,S 0.015-50 B .B..................

C 632 87-010-263-080 CAP, ELECT 100-10V .B..................

C 633 87-010-263-080 CAP, ELECT 100-10V .B..................

C 631 87-010-992-080 C-CAP,S 0.047-25 B .B..................

C 641 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 667 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 661 87-010-322-080 C-CAP,S 100P-50 CH .B..................

ELECTRICAL MAIN PARTS LIST - 6/7

C 664 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 663 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 662 87-010-322-080 C-CAP,S 100P-50 CH .B..................

CN 601 87-099-719-010 CONN,30P TYK-B(X) .B..................

CN 602 87-A60-131-010 CONN,6P V FE .B..................

D 601 87-A40-002-080 ZENER,MTZJ5.1C .B..................

D 602 87-A40-438-080 ZENER,MTZJ4.7A .B..................

FB 601 87-A50-190-080 C-COIL,S BLM21A102S .B..................

IC 601 87-A20-954-040 C-IC,M62445FP-601 .B..................

J 602 87-099-625-010 JACK PIN 4P,RVS (KM) .B..................

JW 637 87-008-372-080 FILTER, EMI BL OIRNI .B..................

Q 601 87-026-609-080 TR,KTA1266GR .B..................

C 701 87-010-381-080 CAP, ELECT 330-16V .B..................

C 702 87-010-404-080 CAP, ELECT 4.7-50V .B..................

C 712 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 714 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 711 87-010-263-080 CAP, ELECT 100-10V .B..................

C 715 87-010-322-080 C-CAP,S 100P-50 CH .B..................

C 725 87-010-178-080 CHIP CAP 1000P .B..................

C 723 87-010-178-080 CHIP CAP 1000P .B..................

C 727 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 728 87-010-248-080 CAP, ELECT 220-10V .B..................

C 722 87-010-312-080 C-CAP,S 15P-50 CH .B..................

C 721 87-010-312-080 C-CAP,S 15P-50 CH .B..................

D 721 87-A40-234-080 ZENER,MTZJ5.6A .B..................

D 722 87-A40-470-080 DIODE,1SS254 .B..................

IC 721 86-NFZ-655-010 IC,LC72131D(Z) .B..................

Q 711 87-A30-196-080 TR,2SC4115SRS .B..................

X 721 87-A70-061-010 VIB,XTAL 4.500MHZ CSA-309 .B..................

C 758 87-010-149-080 C-CAP,S 5P-50 CH .B..................

C 755 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 756 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 757 87-010-318-080 C-CAP,S 47P-50 CH .B..................

C 763 87-010-194-080 CAP, CHIP 0.047 .B..................

C 761 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 765 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 768 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 762 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 766 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 764 87-010-319-080 C-CAP,S 56P-50 CH ....................

C 767 87-010-405-080 CAP, ELECT 10-50V .B..................

C 769 87-010-408-080 CAP, ELECT 47-50V .B..................

C 772 87-010-194-080 CAP, CHIP 0.047 .B..................

C 773 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 774 87-010-263-080 CAP, ELECT 100-10V .B..................

C 777 87-010-400-080 CAP, ELECT 0.47-50V .B..................

C 779 87-010-401-080 CAP, ELECT 1-50V .B..................

C 778 87-010-401-080 CAP, ELECT 1-50V .B..................

C 775 87-010-404-080 CAP, ELECT 4.7-50V .B..................

C 771 87-010-407-080 CAP, ELECT 33-50V .B..................

C 770 87-015-821-080 C-CAP 0.047 .B..................

C 789 87-010-179-080 CAP,CHIP S B1200P .B..................

C 788 87-010-184-080 CHIP CAPACITOR 3300P(K) ....................

C 787 87-010-184-080 CHIP CAPACITOR 3300P(K) ....................

C 787 87-010-186-080 CAP,CHIP 4700P .B..................

C 788 87-010-186-080 CAP,CHIP 4700P .B..................

C 780 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 784 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 782 87-010-405-080 CAP, ELECT 10-50V .B..................

C 781 87-010-405-080 CAP, ELECT 10-50V .B..................

C 783 87-015-819-080 CAPACITOR,0.01 .B..................

C 793 87-010-177-080 C-CAP,S 820P-50 SL ....................

C 790 87-010-179-080 CAP,CHIP S B1200P .B..................

C 798 87-010-180-080 C-CER 1500P .B..................

C 797 87-010-180-080 C-CER 1500P .B..................

C 793 87-010-181-080 CAP,CHIP S 1800P .B..................

C 797 87-010-182-080 C-CAP,S 2200P-50 B ....................

C 798 87-010-182-080 C-CAP,S 2200P-50 B ....................

C 799 87-010-194-080 CAP, CHIP 0.047 .B..................

C 796 87-010-403-080 CAP, ELECT 3.3-50V .B..................

C 791 87-010-405-080 CAP, ELECT 10-50V .B..................

C 794 87-010-406-080 CAP, ELECT 22-50 .B..................

C 795 87-010-596-080 CAP, S 0.047-16 .B..................

D 771 87-A40-470-080 DIODE,1SS254 .B..................

IC 771 87-A20-438-010 IC,LA1837 ....................

IC 771 87-A20-913-010 IC,LA1837NL .B..................

L 771 87-A50-266-010 COIL,FM DET-2N(TOK) .B..................

L 772 87-A90-733-010 FLTR,PCFAZH-450 (TOK) .B..................

L 781 87-005-847-080 COIL,2.2UH(CECS) .B..................

L 792 87-A50-027-010 COIL,1 POLE MPX(TOK) .B..................

L 791 87-A50-027-010 COIL,1 POLE MPX(TOK) .B..................

L 792 87-A50-209-010 COIL,1POLE MPX(MIT) ....................

L 791 87-A50-209-010 COIL,1POLE MPX(MIT) ....................

C 812 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 814 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 828 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 829 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 821 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 822 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 823 87-010-197-080 CAP, CHIP 0.01 DM .B..................

C 820 87-010-408-080 CAP, ELECT 47-50V .B..................

C 942 87-010-151-080 C-CAP,S 7P-50 CH .B..................

ELECTRICAL MAIN PARTS LIST - 7/7

C 949 87-014-049-080 CAP,PP 470P-100 J .B..................

C 959 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 957 87-010-311-080 CAP 12P .B..................

C 961 87-010-152-080 C-CAP,S 8P-50 CH ....................

C 960 87-010-196-080 CHIP CAPACITOR,0.1-25 .B..................

C 962 87-010-401-080 CAP, ELECT 1-50V .B..................

CF 802 82-785-747-010 CF MS2 GHY R .B..................

CF 801 87-008-261-010 FILTER, SFE10.7MA5-A ....................

CF 802 87-008-261-010 FILTER, SFE10.7MA5-A ....................

CF 801 87-008-423-010 CERAMIC FILTER, SFE10.7 .B..................

D 942 87-A40-270-080 C-DIODE,MC2838 .B..................

D 944 87-A40-470-080 DIODE,1SS254 .B..................

FFE 801 A8-6ZA-191-130 6ZA-1 FEENM ....................

FFE 801 A8-6ZA-19C-170 6ZA-1 YFEENC .B..................

FFE 801 A8-8ZA-190-030 8ZA-1 FEUNM ....................

J 802 87-033-230-010 TERMINAL,ANT AJ-2016 .B..................

J 801 87-033-239-010 TERMINAL,HSP-154V-2 ....................

L 832 87-005-847-080 COIL,2.2UH(CECS) .B..................

L 942 87-A50-019-010 COIL,OSC LW(COI) .B..................

L 941 87-A50-020-010 COIL,ANT LW(COI) .B..................

L 981 87-NF4-650-010 COIL,AM PACK 4N(TOK) ....................

L 981 87-NF4-651-010 COIL,AM PACK2N(TOM) .B..................

Q 806 87-A30-072-080 C-TR,RT1P 144C .B..................

Q 805 89-327-143-080 TR,2SC2714 (0.1W) .B..................

Q 948 87-A30-086-070 C-TR,CSD1306E .B..................

Q 947 89-505-434-540 C-FET,2SK543(4/5) .B..................

Q 951 87-A30-074-080 C-TR,RT1P 141C .B..................

Q 952 87-A30-086-070 C-TR,CSD1306E .B..................

TC 942 87-011-221-080 CAP, TRIMMER 30P .B..................

FC 101 87-033-147-010 FUSE CLAMP A...................

FC 102 87-033-147-010 FUSE CLAMP A...................

S 101 87-A90-165-010 SW,SL 1-2-3 SWS2301 A...................

T 102 87-A60-317-010 TERMINAL, 1P MSC A...................

T 101 87-A60-317-010 TERMINAL, 1P MSC A...................

C 287 87-010-196-080 CHIP CAPACITOR,0.1-25 ....................

CN 302 87-099-202-010 CONN,9P 6216 H ....................

IC 281 87-070-289-040 IC,BU 2092F ....................

LED 258 88-MA1-630-080 LED,SML76755WN ....................

LED 259 88-MA1-630-080 LED,SML76755WN ....................

LED 262 88-MA1-630-080 LED,SML76755WN ....................

LED 260 88-MA1-630-080 LED,SML76755WN ....................

LED 261 88-MA1-630-080 LED,SML76755WN ....................

S 318 87-A90-095-080 SW,TACT EVQ11G04M ....................

S 312 87-A90-095-080 SW,TACT EVQ11G04M ....................

S 313 87-A90-095-080 SW,TACT EVQ11G04M ....................

S 316 87-A90-095-080 SW,TACT EVQ11G04M ....................

S 315 87-A90-095-080 SW,TACT EVQ11G04M ....................

S 317 87-A90-095-080 SW,TACT EVQ11G04M ....................

S 314 87-A90-095-080 SW,TACT EVQ11G04M ....................

C 101 87-010-805-080 CAP, S 1-16 ....................

C 102 87-012-368-080 C-CAP,S 0.1-50 F ....................

D 101 87-A40-269-080 C-DIODE,MC2836 ....................

D 103 87-A40-269-080 C-DIODE,MC2836 ....................

D 102 87-A40-269-080 C-DIODE,MC2836 ....................

Q 101 87-026-210-080 CHIP-TR,DTC144EK ....................

Q 102 87-026-210-080 CHIP-TR,DTC144EK ....................

Q 104 87-026-211-080 TR,DTA144EK ....................

Q 103 87-026-213-080 CHIP-TR,DTC114YK ....................

Q 105 87-A30-076-080 C-TR,2SC3052F ....................

C 457 87-010-404-080 CAP, ELECT 4.7-50V .B..................

C 458 87-010-404-080 CAP, ELECT 4.7-50V .B..................

MECHANICAL PARTS LIST - 1/2

NOTE: The characters in the suffix column indicate the part usage.

KBNE ...................XX...................................B..................

KANRI

REF.NO PARTS NO. NO. DESCRIPTION SUFFIX

82-NE8-032-010 BADGE,AIWA 27.5 A...................

88-MA1-001-010 CABI,FR H ....................

88-MA1-002-010 CABI,FR E ....................

88-MA1-004-010 BOX,CASS L A...................

88-MA1-005-010 BOX,CASS R A...................

88-MA1-006-010 PANEL,TOP AB..................

88-MA1-007-010 PANEL,SIDE L AB..................

88-MA1-008-010 PANEL,SIDE R AB..................

88-MA1-032-010 PANEL,FR A...................

88-MA1-042-010 CABI,REAR EZ .B..................

88-MA1-044-010 CABI,REAR LH A...................

88-MA1-056-010 PANEL,FR H ....................

88-MA1-062-010 CABI,FR LH(997) A...................

88-MA1-009-010 KEY,DIRECT A...................

88-MA1-010-010 KEY,OPEN A...................

88-MA1-011-010 KEY,CHANGE A...................

88-MA1-014-010 KEY,GEQ A...................

88-MA1-015-010 KEY,POWER A...................

88-MA1-016-010 KEY,BBE A...................

88-MA1-017-010 KEY,PRGM A...................

88-MA1-018-010 KEY,FUN A...................

88-MA1-019-010 KEY,JOG A...................

88-MA1-022-010 KEY,MIC A...................

88-MA1-024-010 KEY,VF A...................

88-MA1-029-010 RING,VOL A...................

88-MA1-030-010 KNOB,RTRY MAIN A...................

88-MA1-039-010 KEY,ASSY PLAY A...................

88-MA1-040-010 KEY,ASSY FF A...................

88-MA1-057-010 KEY,KARAOKE ....................

88-MA1-058-010 KEY,REV A...................

88-MA1-059-010 KEY,DEMO A...................

88-MA1-060-010 KNOB,RTRY RHYTHM A...................

81-532-080-010 LABEL, CASS. COMPT A...................

86-MA3-042-010 WINDOW,TOP AB..................

86-NF6-061-010 REFLECTOR,CASS A...................

88-MA1-012-010 PANEL,CD A...................

88-MA1-013-010 PANEL,TRAY AB..................

88-MA1-025-010 WINDOW,CD A...................

88-MA1-026-010 WINDOW,AMP A...................

88-MA1-027-010 WINDOW,CASS L A...................

88-MA1-028-010 WINDOW,CASS R A...................

88-MA1-033-010 PLATE,GEQ A...................

88-MA1-045-010 REFLECTOR,FUN A...................

84-ZG1-245-210 CAP,OPTICAL AB..................

82-NF5-218-010 SPR-T,EJECT 1 (SIN) A...................

82-NF5-219-010 SPR-T,EJECT 2 (SIN) A...................

82-NF5-229-010 PLATE,LOCK A...................

86-NF9-224-010 SPR-C,LOCK A...................

87-064-185-010 HLDR,WIRE AB..................

87-MA3-062-010 FOOT, H17 AB..................

87-NF4-216-010 HLDR,LOCK 1 A...................

87-NF4-217-010 HLDR,LOCK 2 A...................

87-NF4-221-010 HLDR,CABLE AB..................

87-NF8-220-010 DMPR,150 A...................

88-MA1-201-010 GUIDE,PLAY A...................

88-MA1-203-010 HLDR,HT-SINK AB..................

88-MA1-207-010 HLDR,PWB AB..................

88-MA1-208-010 JOINT,CABI AB..................

81-MK1-210-010 S-SCREW,VFT2+3-16 A...................

87-067-579-010 TAPPING SCREW, BVT2+3-8 AB..................

87-067-581-010 TAPPING SCREW, BVT2+3-15 AB..................

87-067-641-010 UTT2+3-8(W/O SLOT)BL AB..................

87-067-688-010 BVTT+3-6 AB..................

87-067-703-010 TAPPING SCREW, BVT2+3-10 AB..................

87-067-758-010 BVT2+3-12 W/O SLOT AB..................

87-067-975-010 S-SCREW,IT+4-8 AB..................

87-078-060-010 BVIT3PB+3-10 AB..................

87-591-095-410 TAPPING SCREW, QIT+3-8 (GLD) AB..................

87-B10-090-010 BVIT3B+3-12 GOLD AB..................

87-NF4-224-010 S-SCREW,IT3B+3-8 CU AB..................

83-NEG-608-010 CONN ASSY 8P-RPB AB..................

85-MA2-602-010 CABLE,FFC 15P-1.25 A...................

87-085-185-010 BUSHING, AC CORD (E) AB..................

87-A80-059-010 AC CORD ASSY,K 3P (5A) ....................

87-A80-103-010 AC CORD ASSY,K 3P (5A) .B..................

88-906-251-110 FF-CABLE,6P 1.25 AB..................

88-909-231-110 FF-CABLE, 9P 1.25 A...................

88-912-281-110 FF-CABLE,12P 1.25 A...................

F 101 87-035-459-010 FUSE,5A 250V AB..................

PT 101 88-MA1-606-010 PT,8MA-1 HE ....................

PT 101 88-MA1-608-010 PT,8MA-1 EZ .B..................

PT 101 88-MA1-609-010 PT,8MA-1 LH A...................

W 101 87-050-079-010 AC-CORD ASSY,E A...................

85-NF5-210-110 GUIDE,LED L ....................

85-NF5-211-110 GUIDE,LED R ....................

88-MA1-205-010 GUIDE,FL ....................

W 104 85-NF5-628-010 F-CABLE 7P-2.5 .B..................

WH 101 87-A90-460-010 HLDR,WIRE 2.5-7P .B..................

87-067-579-010 TAPPING SCREW, BVT2+3-8 .B..................

87-067-703-010 TAPPING SCREW, BVT2+3-10 .B..................

WH 102 87-A90-460-010 HLDR,WIRE 2.5-7P .B..................

MECHANICAL PARTS LIST - 2/2

Table of contents

Popular Car Receiver manuals by other brands

Linear Series

Linear Series LS5050 Operation and installation manual

Kenwood

Kenwood KRC-160 instruction manual

Sony

Sony XR-CA430X Service manual

T+A Elektroakustik

T+A Elektroakustik K1 CD-RECEIVER operating instructions

SoundMax

SoundMax SM-CDM1052 instruction manual

Xtrons

Xtrons HD107HD user manual

Mopar

Mopar RB3 manual

Clarion

Clarion ADDZEST DMZ615 owner's manual

Sony

Sony XAV-601BT Specifications

PIE

PIE GM12-POD/S Operation manual

Hyundai

Hyundai H-910H instruction manual

Sony

Sony XR-C6100 Service manual

Sony

Sony CDX-L600X - Fm/am Compact Disc Player Installation/connections

Motorola

Motorola VWA63 Service manual

Sound Storm

Sound Storm STM93R user manual

Nextar

Nextar D3201 instruction manual

Alpine

Alpine CDE-163BT owner's manual

Kenwood

Kenwood KDC-X303 quick start guide

Aiwa Z-R990 User manual

Popular Car Receiver manuals by other brands
