AJA HD10C2 Original operating instructions

Installation & Operation Guide
Version 1.0r2
Published: July 3, 2014
HD10C2 Mini-Converter
HD/SD Serial Digital to Analog

HD10C2 Mini-Converter v1.0r2 www.aja.com
2
Table of Contents
Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Contacting Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Simplified Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
I/O Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Video Output Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
User Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Chapter 2: Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
DIP Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
DIP Switch Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
HD VGA MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Internal Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Appendix A: Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Appendix B: Safety and Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Federal Communications Commission (FCC) Compliance Notices . . . . . . . . . . . . . . . . . . 10
Class A Interference Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
FCC Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Canadian ICES Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
European Union and European Free Trade Association (EFTA)
Regulatory Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Korean KCC Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Taiwan Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Japanese Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Recycling Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Translated Warning and Caution Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Before Operation Please Read These Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

HD10C2 Mini-Converter v1.0r2 www.aja.com
3
Notices
Trademarks
AJA®, lo®, Ki Pro®, KONA®, KUMO®,T-TAP®, Because it matters.® and ROI® are registered
trademarks of AJA Video Systems, Inc. in the United States. AJA and Ki Pro are trademarks
of AJA Video Systems, Inc. registered in other countries. AJA Control Room™, CION™,
Corvid Ultra™, FiDO™, Science of the Beautiful™, TruScale™, TruZoom™, V2Analog™ and
V2Digital™ are trademarks of AJA Video Systems, Inc.
AirPort, Apple, Apple logo, AppleShare, AppleTalk, FireWire, iPod, iPod touch, Mac and
Macintosh are registered trademarks of Apple Inc. Final Cut Pro, QuickTime and
QuickTime logo are trademarks of Apple Inc.
Avid, Avid DNxHD and Media Composer are registered trademarks of Avid Technology,
Inc.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing, LLC.
DVI is a registered trademark of DDWG.
TASCAM is a registered trademark of TEAC Corporation.
All other trademarks are the property of their respective holders.
Copyright
Copyright © 2014 AJA Video Systems, Inc. All rights reserved. All information in this
manual is subject to change without notice. No part of the document may be
reproduced or transmitted in any form, or by any means, electronic or mechanical,
including photocopying or recording, without the express written permission of AJA
Video Systems, Inc.
Contacting Support
When calling for support, have all information at hand prior to calling.
To contact AJA for sales or support, use any of the following methods:
Telephone: [phone]
FAX: [phone]
Web: http://www.aja.com
Support Email: [email protected]
Sales Email: [email protected]

HD10C2 Mini-Converter v1.0r2 www.aja.com
4
Chapter 1: Introduction
Overview
The HD10C2 is a high-quality 10-bit HD converter that’s “dual-rate”—and works with
both HD-SDI and SD SDI inputs. For HD-SDI inputs, the HD10C2 outputs full bandwidth
HD component or “VGA” style RGBHV video. For SD-SDI inputs, component or composite
SD outputs are supported. When connected to a multi-format monitor like the Sony
20L5, the HD10C2 will automatically provide an image from almost any HD or SD input
format. The HD10C2 also features 2 equalized HD/SD SDI outputs.
Features
• High-Quality 10-bit Dual Rate HD/SD D/A Conversion
• Full Bandwidth HD Analog RGB or YPbPr Output (HD input)
• Component/Composite SD Output (SD input)
• 2 Equalized Loop-Thru HD-SDI/SDI Outputs
• 5 wire RGBHV VGA style HD output
• HD Sync Selectable Between Bi-level and Tri-Level
• 4:3 Safe Area Graticule (HD)
• Uses universal input +5V power supply AJA model DWP-U-R1 (included)
• External Dip Switch Configuration

HD10C2 Mini-Converter v1.0r2 www.aja.com
5
Simplified Block Diagram
I/O Connections
HD RGB or YPbPr Outputs
(selected by DIP switch)
HD-SDI
Input
De-serializer
Cable EQ
Y G
Pb B
H Drive
V Drive
(Output is selected by DIP switch)
Pr R
DA Outputs
D/A
Conversion
HD-SDI Out 1
HD-SDI Out 2
HD-SDI Input
HD-SDI Loop
Output
Configuration
Determined by
DIP switch on
other side of
Converter
Output 1
BNC
Connects to Converter
Output Connector for
HD-RGB or YPbPr Video
Connects to Converter
Output Connector for
VGA Video
BNCs for HD-RGB
or YPbPr equipment
HD10C2 Component Video Cable and HD15 SVGA Adapter
HD-SDI Loop
Output 2
+ 5 VDC
Power
Input
D-Connector

HD10C2 Mini-Converter v1.0r2 www.aja.com
6
Video Output
Connector
The video output connector is a 13W3 D-sub with the following pinouts:
User Controls
The user interface for the HD10C2 is an 8-switch DIP accessible through a cut-out in the
bottom of the unit, and an internal jumper block accessed by removing the converter’s
cover (secured by 4 screws).
Use the jumper to configure HD Sync, if necessary. Then use the DIP switches to
configure the converter.
Factory default settings are internal jumper installed (HD uses Tri-level Sync), and all the
DIP switches in the leftmost position. The exact function of the jumper settings and each
DIP switch are described in “Operation” on page 7.
Installation
Typically, HD10C2 installation consists of the following:
1. Disconnect +5VDC from the converter.
2. If you wish to operate the HD10C2in HD with Bi-level Sync, open the case and set the
internal jumper as required.
3. Configure the DIP switches for the desired settings.
4. Connect external devices to the converter BNCs and breakout cable or VGA adapter.
5. Apply power to the converter.
Table 1. Video Output Connector Pinouts
Pin Description
1no connection
2V DRIVE
3no connection
4 GROUND
5H DRIVE
6 - 9 no connection
10 GROUND
A1 RED / Pr Video/ C
A2 GREEN / Y Video / Composite
A3 BLUE / Pb Video / Y

HD10C2 Mini-Converter v1.0r2 www.aja.com
7
Chapter 2: Operation
DIP Switches
DIP switches on the back of the unit are used to configure output formats, and enable/
disable video sync and graticule.
Figure 1. HD10C2 DIP Switches and Label.
DIP Switch Settings The combination of switch settings determines the overall operation of the HD10C2.
DIP Switches
LEFT RIGHT
Table 1. HD10C2 DIP Switch Setting Descriptions
SWITCH FUNCTION DIP Set LEFT (default) DIP Set RIGHT
1Component Video
Output Format
YPbPr:
Selects YPbPr Component output
(YPbPr)
RGB:
Selects RGB Component output
2SD Output Format: COMPONENT:
Selects Component output (SD Input)
COMPOSITE:
Selects Composite output (SD Input)
3SD Pedestal OFF:
Disable pedestal (SD Input)
ON:
Enable pedestal (SD Input)
4SD Blanking NARROW:
Select narrow blanking
WIDE:
Selects wide blanking
5Graticule:
(HD Mode 4:3 Safe Area)
OFF:
Disable graticule
ON:
Enable graticule
6SD Format NTSC:
(SD Input)
NTSCJ:
Selects Japan’s NTSCJ format (SD Input)
7HD Sync ON:
Enable HD Sync
OFF:
Disable HD Sync (remove sync on RGB)
8Aux Not currently used

HD10C2 Mini-Converter v1.0r2 www.aja.com
8
HD VGA MODE For HD VGA mode use the supplied 15 pin D adapter and make the following DIP switch
settings:
•S1=RGB(right)
• S7 = HD SYNC OFF (right)—Note: only certain monitors require no sync on video.
Internal Jumper
An internal jumper inside the HD10C2 case allows you to select between bi and tri level
sync. To set the jumper, remove the four phillips screws securing the case cover
(dipswitch side) and locate the jumper in the middle of the circuit board (see illustration
below). Placing the internal jumper "S2" in the "0" position provides tri-level sync on the
HD output; alternatively, placing it in the "1" position allows for bi-level sync on HD
output. SD output is always bi-level. Note: jumper S1 is not used.
0
1
S1 S2
0
1
S1 S2
S2 Set
For
Tri-level
Sync
S2 Set
For
Bi-level
Sync

HD10C2 Mini-Converter v1.0r2 www.aja.com
9
Appendix A: Specifications
Formats • 1080i @ 50/59.94/60 Hz
• 1080p sf @ 23.98/24/25/29.97/30 Hz (displayed as interlaced)
• 1035i @ 59.94/60 Hz
• 720p @ 59.94/60 Hz
• 525i @ 59.94 Hz
•625i@50Hz
Input Selection Automatic
Video Input HD-SDI/SDI, SMPTE-259/292/296
Input Equalization 100/300 meter 1694 cable (SD/HD)
SDI Outputs HD-SDI/SDI, active input loop, equalizing
Video Output: HD:YPbPr, RGB
SD: YPbPr, RGB (component mode)
Composite/YC (composite mode)
D/A converters: 12 bits
Sync Bi-level, Tri-level, H/V drive
2T K factor < 1% (Y)
Frequency Response • Y +/ -.5db to 30 MHz
• C +/- .25db to 15 MHz
Y/C delay < 2 ns
Power Uses AJA Power Supply model DWP-U-R1 (included)
• 100-240V, 50/60Hz Universal Input
• +5V DC regulated, 7.5 watt capacity
Size 147 x 79 x 25 mm
NOTE: Most VGA monitors are not compatible with a Horizontal scan rate below 30 Khz (including
the SONY GDM-W900, a popular HD monitor). The Sony 20L5 and 14L5 are compatible with
all formats supported on the HD10C2.
Table 2. Horizontal Scan Rates
Format H ScanRate
1080i 59.94 / 60 Hz 33.75 Khz
1080i 50 28.125 Khz (see note below)
1080p sf 23.98 / 24 Hz 27.000 Khz (see note below)
720p 59.94 / 60 Hz 45.000 Khz

HD10C2 Mini-Converter v1.0r2 www.aja.com
10
Appendix B: Safety and Compliance
Federal Communications Commission (FCC) Compliance Notices
Class A Interference
Statement
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15, Subpart B of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Canadian ICES Statement
Canadian Department of Communications Radio Interference Regulations
This digital apparatus does not exceed the Class A limits for radio-noise emissions from a
digital apparatus as set out in the Radio Interference Regulations of the Canadian
Department of Communications. This Class A digital apparatus complies with Canadian
ICES-003.
Règlement sur le brouillage radioélectrique du ministère des Communications
Cet appareil numérique respecte les limites de bruits radioélectriques visant les appareils
numériques de classe A prescrites dans le Règlement sur le brouillage radioélectrique du
ministère des Communications du Canada. Cet appareil numérique de la Classe A est
conforme à la norme NMB-003 du Canada.
