AJA OG-Hi5-12G Operating instructions

OG-Hi5-12G
SDI to HDMI 2.0 Converter
Version 1.0
Published September 7, 2023
Installation and Operation Guide

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 2 www.aja.com
Notices
Trademarks
AJA® and Because it matters.® are registered trademarks of AJA Video Systems, Inc.
for use with most AJA products. AJA™ is a trademark of AJA Video Systems, Inc. for
use with recorder, router, software and camera products. Because it matters.™ is a
trademark of AJA Video Systems, Inc. for use with camera products.
Corvid Ultra®, lo®, Ki Pro®, KONA®, KUMO®, ROI® and T-Tap® are registered trademarks of
AJA Video Systems, Inc.
AJA Control Room™, KiStor™, Science of the Beautiful™, TruScale™, V2Analog™ and
V2Digital™ are trademarks of AJA Video Systems, Inc.
All other trademarks are the property of their respective owners.
Copyright
Copyright © 2023 AJA Video Systems, Inc. All rights reserved. All information in
this manual is subject to change without notice. No part of the document may be
reproduced or transmitted in any form, or by any means, electronic or mechanical,
including photocopying or recording, without the express written permission of AJA
Video Systems, Inc.
Contacting AJA Technical Support or Sales
Please have all pertinent information at hand prior to contacting AJA support or sales.
Support Telephone: [phone]
Support Website: https://www.aja.com/support/contact
Support Email: suppor[email protected]
Sales Email: [email protected]
Shipping Address: AJA Video Systems
180 Litton Drive
Grass Valley, CA 95945, USA

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 3 www.aja.com
Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Contacting AJA Technical Support or Sales . . . . . . . . . . . . . . . . . . . . . . . 2
Chapter 1 – Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Default Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
I/O Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Signal Indicators on the OG-Hi5-12G Card . . . . . . . . . . . . . . . . . . . . . . 5
Signal Indicators in the DashBoard Control System . . . . . . . . . . . . . . . . 6
User Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
DashBoard Control System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
openGear and AJA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
OG-Hi5-12G Rear Plate Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
OG-Hi5-12G Card Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Chapter 2 – Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Using the DashBoard Control System. . . . . . . . . . . . . . . . . . . . . . . . . . 13
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Conguration Settings Stored in OG Card . . . . . . . . . . . . . . . . . . . . . 13
Control Interface Basic Components . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Basic Tree View of Frames and Cards . . . . . . . . . . . . . . . . . . . . . . . . 14
Card Information and Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Parameter Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Input Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Output Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
HDR Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Audio Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Setup Tab Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Uploading New Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
To Upload New Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Rebooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
To Reboot the OG-Hi5-12G . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Appendix A – Specications . . . . . . . . . . . . . . . . . . . . . . . . 28
OG-Hi5-12G Family Tech Specs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Appendix B – Safety and Compliance . . . . . . . . . . . . . . . . . . 31
5 Year Warranty and Liability Information . . . . . . . . . . . . . . . 41
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Contents

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 4 www.aja.com
Chapter 1 – Introduction
Overview
The OG-Hi5-12G converts 12G-SDI to HDMI 2.0, with pristine image fidelity and
HFR support up to 60p for 4K/UltraHD, with single cable simplicity. OG-Hi5-12G
provides an easy to deploy monitoring connection from professional 4K 12G-SDI
devices to new displays with HDMI 2.0 inputs, for cost-effective monitoring in
professional workflows. The OG-Hi5-12G supports HDR signaling metadata pass-
through and optional override in accordance with HDMI v2.0 and CTA-861-G.
The OG-Hi5-12G features a 12G-SDI single link input with a reclocked SDI loop out
for simpler SDI confidence monitoring or pass on for SDI pipelines.
Fiber SFP equipped OG-Hi5-12G models are available including the OG-Hi5-12G-R
receiver, which can receive 4K signals over long distances from a Fiber connected
source, and the OG-Hi5-12G-TR transceiver, which delivers a 4K/UltraHD SDI or
Fiber source signal to an HDMI destination with pass on of the source through SDI
or Fiber to a secondary destination. The Video Source Auto Switch Over feature
(SDI and Optical Inputs) in OG-Hi5-12G-R and OG-Hi5-12G-TR provides automatic
input changeover with configurable Switch Over Priority selection (Last Valid
Input, Priority SDI, and Priority Optical).
Designed for use in high-density openGear’s 2RU frames and AJA’s OG-X-FR 2RU
frame, DashBoard Software support on Windows®, macOS® and Linux offers
remote control and monitoring of the openGear architecture and provides
convenient and industry-standard configuration, monitoring and control options
over a PC or local network.
Default Operation
The OG-Hi5-12G's default settings include many automatic settings. The
OG-Hi5-12G's Auto-Configure feature automatically identifies the incoming
SDI signal format and converts the signal based on the HDMI output default
configuration parameters.
Features
• Convert 12G-SDI to HDMI 2.0b at up to 4K 60p
• Support for 4:4:4/4:2:2/4:2:0 HDMI 2.0b output
• HDR signaling metadata pass-through and optional override

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 5 www.aja.com
• HDR support for HDR10 and HLG
• Embedded audio pass-through of E-AC-3 (Dolby Digital Plus) compressed
audio, including DD+ Atmos
• 12G-SDI loop out
• Remote configuration through DashBoard Control System for an openGear
Frame
• Rear I/O plate included
• Compatible with OG-X-FR, OG3 and DFR-8321 openGear frames
• Fiber SFP models available
• Five year warranty
Block Diagram
Figure 1. OG-Hi5-12G Converter, Simplified Block Diagram
Video
Video
Audio
Audio
Embed
Audio
Analog
Audio Out 1
Analog
Audio Out 2
D/A
Converter
Optional SFP
Input with
Embedded Audio
HDMI v2.0
Output with
Embedded
Audio
Adjustable
Delay
Video
Processing
SDI Input with
Embedded Audio
SDI Loop
Output
SDI
RCVR
SDI
RCVR
HDMI
XMIT
Optional SFP
Loop Output
Disembed
Audio
Control
DashBoard
I/O Connections
Figure 2. OG-Hi5-12G Converter Connections
Analog Audio
Output L
Analog Audio
Output R
HDMI Output
SFP Opening
SDI Input
BNC (J1)
SDI Loop Out
BNC (J2)
Front Card
Retention Screw
Signal Indicators on the OG-Hi5-12G Card
Located at the upper front area of the OG-Hi5-12G card, the Lock LED indicates by
color the type of signal detected by the SDI input (Table 1).

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 6 www.aja.com
Table 1. SDI In Lock LED Signal Detected
Signal Detected Color
No Signal Off
270M Green
1.5G Red
3G Amber
6G Purple
12G Blue
Signal Indicators in the DashBoard Control System
Card Alarm State – Red
These potential card states will result in a red alarm indicator:
• HW Status Unsupported Rear Module
• HW Status FPGA Load Failure
Card Alarm State – Yellow
When the signal is either not present or is not locked, the DashBoard Control
System shows a yellow Card state alarm: "Video Source No Input". Additionally, a
yellow Video Source alarm: "No Input" is shown under the Status tab.
Figure 3. Signal is Not Present or Not Locked

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 7 www.aja.com
When there is a valid input signal detected, but the HDMI output cable is not
connected, either at the rear panel of the card or at the HDMI signal destination,
the DashBoard Control System shows a yellow Card state alarm: "HDMI Output
Disconnected." Additionally, the HDMI Output status shows a yellow alarm state
of "Disconnected" under the Status tab.
Figure 4. HDMI Not Connected
Card Alarm State – Green
When there is a valid input signal detected and a valid HDMI sink is connected to
the output, the DashBoard Control System shows a green Card state. Additionally,
the Signal State is shown as "OK" under the Status tab. The type of SDI Signal
detected is also indicated.

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 8 www.aja.com
Figure 5. Signal Present and Locked
User Controls
The OG-Hi5-12G can be immediately used for many applications, since it is
designed to recognize inputs and perform standard actions automatically.
However, you can also manually configure the OG-Hi5-12G using remote
conguration through the DashBoard Control System for an openGear Frame.
DashBoard Control System
The DashBoard Control System, created by Ross Video, provides a control
interface between Windows, macOS and Linux computers and the cards installed
in an openGear frame. DashBoard operates through TCP/IP communication
and requires an Ethernet connection between the controlling computer and an
openGear frame.
For details about acquiring and using the DashBoard Control System, refer to
"Using the DashBoard Control System" on page 13.

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 9 www.aja.com
openGear and AJA
openGear is an open-architecture, modular frame system designed by Ross
Video and supported by a diverse range of terminal equipment manufacturers,
including AJA. Ross Video manufactures the frames, power supplies and network
cards for openGear. AJA is a reseller of the openGear frames.
AJA Video is a leading manufacturer of video interface technologies, converters,
digital video recording solutions and professional cameras, bringing high-
quality, cost-effective products to the professional, broadcast and post-
production markets. AJA products, including openGear cards, are designed and
manufactured at our facilities in Grass Valley, California.
Installation
Summary
Installing an OG-Hi5-12G card into an OGX or OG3 openGear frame consists of the
following steps:
• Install the rear plate onto the back of the frame corresponding to the slot pair
you will be using for the OG-Hi5-12G card.
• Insert the OG-Hi5-12G card into the frame in the left (odd numbered) slot of
the pair.
• Connect the BNC, HDMI and audio cabling to the rear plate.
ESD Susceptibility - Static discharge can cause serious damage to sensitive
semiconductor devices. Avoid handling circuit boards in high static
environments such as carpeted areas, and when wearing synthetic fiber
clothing. Always exercise proper grounding precautions when working on circuit
boards and related equipment.
Unpacking
Unpack each openGear product you received from the shipping container and
ensure that all items are included. If any items are missing or damaged, contact
your sales representative or AJA directly.
Parts List
Quantity Description
1 OG-Hi5-12G Front Card in ESD bag
1 Compatible Rear Plate
2 WECO 3-Pin Terminal Connector Plug 3.5mm
OG-Hi5-12G Rear Plate Installation
1. Ensure that the chassis is properly installed in a secure rackframe.
2. Locate the card frame slot on the rear of the openGear frame into which you
wish to install the openGear card.
NOTE: An OG-Hi5-12G card occupies two slots in the frame.
3. Using a Phillips screwdriver, unscrew the top screw from the desired blank
rear plate and remove it.

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 10 www.aja.com
4. Seat the bottom of the rear plate in the seating slot at the base of the frame
back plane (Figure 6).
Figure 6. Inserting Rear Plate Into Frame Seating Slot
5. Align the top screw of the rear plate with the screw hole on the top edge of
the frame back plane.
6. Ensure the rear plate aligns with the desired card slot before tightening the
screw.
7. Using a Phillips screwdriver, fasten the rear plate to the frame back plane
(Figure 7). Do not over tighten.
Figure 7. Rear Plate Inserted Into Frame Seating Slot
8. Ensure proper frame cooling and ventilation by having all rear frame slots
covered with either OG card rear plates or blank metal plates.
OG-Hi5-12G Card Installation
Caution! The SFP module must be removed from an OG-Hi5-12G card before
inserting the card into or removing the card from an openGear frame.
1. If necessary, remove the SFP module from the Front Card by lifting the lever
(also referred to as a "bale") and pulling out the module.
2. Open the openGear frame door as follows:
A. Gently pull the side door tabs towards the center of the door, releasing the
door from the frame.
B. Using both hands, pull the door towards you. The door extender arms
prevent the door from falling.

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 11 www.aja.com
3. Locate the rear plate you installed as described above. The interior slot
number is dependent on the slot combinations into which you installed the
rear plate. This allows adequate spacing to avoid damaging the card, the
cards installed in the neighboring slots, or both.
4. Hold the card by the edges and carefully align the card edges with the rails
inside the frame. The slots are numbered starting from the left-most slot
when facing the frame front.
IMPORTANT: OG-Hi5-12G cards are installed into the left (odd numbered) slot of the pair
in order to connect with the rear plate.
5. Insert the card into the frame until the card is properly seated in the Rear
Plate. After you feel the card's first click, its position in the frame will
resemble Figure 8.
Figure 8. Card on Right Not Fully Inserted
6. Next, press against the white plastic tab again until you feel the second
click. Make sure that the plastic tab at the bottom of the front edge of the
card is completely upright. If it is tilting forward, the card is not yet fully
inserted. A properly seated card position should resemble Figure 9.
Figure 9. Card Fully Inserted, White Plastic Tab Upright
7. Some OG cards require more pressure than others to be fully inserted.
Because this OG card has a rear SFP port that passes through the rear plate,
alignment is especially important. Do not apply excessive force if you
cannot completely insert the card into its slot.
NOTE: If the SFP port at the rear of the card fails to line up with the square opening in the
rear plate, the card will fail to insert fully into the rack. Please contact AJA Support
if you are experiencing this issue.

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 12 www.aja.com
8. Close the frame door as follows:
A. Slide the door into the frame.
B. Pull and release the door tabs to ensure the frame door is securely locked
to the frame.
9. After the front card is fully seated, locate the card retention screw on the
rear plate. Torque the card-retention screw into the front card's L bracket
using a Phillips screwdriver. Do not overtighten.
10. Insert the SFP ber module into the socket until it clicks and locks. The lever
handle is on the left.
NOTE: The SFP module must match the card’s capabilities for proper operation. Input
and output triangles next to the fiber ports identify which are inputs and which
are outputs.
IMPORTANT: Reverse these steps for removal of the front card to avoid damage to the
SFP. Remove the SFP, unscrew the card retention screw, and then withdraw the
front card from the frame.
Cabling
Refer to "I/O Connections" on page 5 to identify the input and output signal
connectors.
NOTE: Keep the protective dust cap in the SFP module until the fiber cabling is actually
connected to the module.

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 13 www.aja.com
Chapter 2 – Operation
Using the DashBoard Control System
The DashBoard Control System is available as a free download from the openGear
DashBoard Software Download webpage:
https://www.opengear.tv/frame-and-control/control-system/download/
Ross Video offers comprehensive documentation that covers the extensive
capabilities of the DashBoard Control System:
https://www.rossvideo.com/support/product-documentation/dashboard/
This AJA OG-Hi5-12G manual addresses only those essential aspects of the
DashBoard Control System needed to control the OG-Hi5-12G card.
Requirements
The DashBoard Control System requires the following components:
• openGear frame with a Frame Controller card
• Ethernet connection between the controlling computer and the openGear
frame
NOTE: The openGear frame ships from AJA with the MFC-8322-S Frame Controller card
for controlling the new AJA DashBoard cards. The openGear frame also supports
the MFC-0G3-N Advanced Networking Frame Controller card, which can be used
to control compatible OG cards.
DashBoard automatically discovers openGear and DashBoard Connect devices,
such as openGear frames and cards that are present and accessible on your
network.
Configuration Settings Stored in OG Card
Configuration settings made through DashBoard are stored in the OG-Hi5-12G
unit through subsequent power cycles.
Control Interface Basic Components
The basic components of the DashBoard Control System user interface consist of
the basic tree view of frames and cards, the card information and status panel,
and the parameter controls panel. These elements are shown below in Figure 10.
The basic tree view of frames and cards shows the frames and cards that are
discoverable by DashBoard on your network.
The card information and status panel, shown in the middle panel, display the
basic status of the card currently selected in DashBoard.
The parameter controls panel shows the tabs and parameters that the selected
card has available for configuration and control.

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 14 www.aja.com
Figure 10. Main Sections of the DashBoard User Interface
Parameter
Controls
Card Information
and Status
Basic Tree View of
Frames and Cards
Basic Tree View of Frames and Cards
The basic tree view in the left column shows the frames and cards that are
discoverable by DashBoard on your network.
Card Information and Status
The card information and status panel, shown in the middle panel, display the
basic status of the card currently selected in DashBoard. The yellow fields in this
panel indicate that they are read-only.

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 15 www.aja.com
Card Information Screen
Figure 11. OG-Hi5-12G Card Information Screen in DashBoard
The Card information screen indicates the basic information about the card itself
such as the card name, hardware status, serial number, software version and
other items.
Card Name - This field reports that OG card's name, which you can define with
the Setup Tab Screen.
Assembly - This is the factory assembly number.
Serial Number - This is the factory set unique serial number of your OG card. If
you ever call AJA Support for service, you may be asked for this number.
Software Ver - This shows the currently installed firmware for that OG card.

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 16 www.aja.com
Status Information Screen
Figure 12. OG-Hi5-12G Status Information Screen in DashBoard
The Video Source status field reports whether the signal is connected. The SDI
Format status field reports the signal detected by the card's SDI input.
The HDMI Out status field reports the type of HDMI signal generated by the HDMI
Output.

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 17 www.aja.com
HDR Information Screen
Figure 13. OG-Hi5-12G HDR Information Screen in DashBoard
Click on the HDR information tab to view the received High Dynamic Range static
metadata extensions settings. This HDR tab indicates whether HDR metadata is
being received on the SDI or Optical inputs and identifies the type of HDR and its
Colorimetry. It also reports the same information for the OG card's HDMI output.
Parameter Controls
The parameter controls panel on the right side of DashBoard shows the tabs and
parameters that are configurable for the selected card.
Input Tab Screen
Click on the Input tab to view and make changes to the converter’s input settings.

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 18 www.aja.com
Video Source
Selects the input video source. Choose from the following:
• Auto Switch Over - automatically selects between the SDI Input and the
Optical Input (applicable to the OG-Hi5-12G-R, OG-Hi5-12G-R-ST and
OG-Hi5-12G-TR models).
• SDI Input - selects the SDI input.
• Optical Input - selects the optical input (applicable to the OG-Hi5-12G-R,
OG-Hi5-12G-R-ST and OG-Hi5-12G-TR models).
Color Space
Selects the Input Video Color Space. Choose from the following:
• Auto - automatically selects color space based on the input video parameters
and payload ID.
• 4:2:2 YCbCr
• 4:4:4 RGB
• 4:4:4 YCbCr
Bit Depth
Selects the input video bit depth. Choose from Auto, 8-bit, 10-bit, or 12-bit.
Choosing “Auto” automatically selects the bit depth based on the input video and
the attached device’s capabilities. High frame rate (HFR) 4K/UltraHD 4:4:4 limited
to 8 bits. DVI output is limited to 8 bits.
RGB Range
Selects the Input Video Color Range when the input is RGB. Does not apply when
the input is YCbCr. Choose SMPTE or Full color range.
Switch Over Priority
Selects which input (SDI or Optical) is the preferred input. This selection is valid
only when an AJA optical SFP is installed. If and when the selected input signal is
no longer detected, the auto switchover circuit will fail over to the non-priority
input if present. Choose from Last Valid Input, SDI Input, or Optical Input.
3G-B Mode
Selects the 3G level B Video Mode. Choose from the following:
• Auto - automatically selects the format based on the input video parameters.
• Level B-DL
• B-DS Link 1 - use Link 1
• B-DS Link 2 - use Link 2
Video Format
This control can be used to force the OG-Hi5-12G's input video receiver to
interpret that incoming video signal as either Progressive, interlaced, or PsF
(Progressive Sequential Frame).
The default setting is Auto, in which the OG-Hi5-12G examines the incoming
video signal to determine which format is appropriate.

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 19 www.aja.com
Choose from Auto, Progressive, Interlaced, or PsF.
• Auto - Automatically selects the format based on the input video parameters
and the Video Payload ID (VPID).
• Progressive - Forces the OG-Hi5-12G to interpret the incoming video as
Progressive.
• Interlaced - Forces the OG-Hi5-12G to interpret the incoming video as
Interlaced.
• PsF - Forces the OG-Hi5-12G to interpret the incoming video as PsF.
Under normal circumstances you should always run in Auto mode. However,
because interlaced and PsF formats are essentially the same signal, the
OG-Hi5-12G might confuse them. For example, if you know for sure that you
receiving a PsF signal, but the OG-Hi5-12G is interpreting it as an Interlaced signal
while running in Auto mode, setting this control to PsF will force the receiver to
interpret that signal as PsF. However, if the OG-Hi5-12G is receiving a Progressive
signal and you force it to interpret it as Interlaced, an invalid output video signal
will be created.
Output Tab Screen
Click on the Output tab to view and make changes to the OG-Hi5-12G Output
settings.
Color Space
Selects the Output Video Color Space. Note that DVI output is limited to 4:4:4
RGB. Choose from the following:
• Auto - selects the video format based on the input video and the attached
device’s capabilities.
• 4:2:2 YCbCr
• 4:4:4 RGB
• 4:4:4 YCbCr
• 4:2:0 YCbCr
Bit Depth
Selects the input video bit depth. Choose from Auto, 8-bit, 10-bit, or 12-bit.
Choosing “Auto” automatically selects the bit depth based on the input video and
the attached device’s capabilities. High frame rate (HFR) 4K/UltraHD 4:4:4 limited
to 8 bits. DVI output is limited to 8 bits.

OG-Hi5-12G SDI to HDMI 2.0 Converter v1.0 20 www.aja.com
RGB Range
Selects the Output Video Color Range when the output is RGB. Does not apply
when the output is YCbCr. Choose Auto, SMPTE or Full color range.
4K/2K Crop
Choose Auto, Off, or On. Provides the option of center cutting 2048x1080
video signals to make 1920x1080, or center cutting 4096x2160 signals to make
3840x2160.
HDMI/DVI
Choose Auto, HDMI, or DVI. When DVI is selected, any audio signals present are
not passed. Choosing “Auto” automatically selects the output mode based on the
attached device’s capabilities.
When the incoming signal is 4K or UltraHD and the HDMI/DVI control is set to
"DVI," the output will be down sampled to deliver a 2048x1080 or 1920x1080
image. The down sampling is accomplished by passing only one of the 2SI
quadrants from the SDI input signal. The output will appear to be a full picture,
but is actually only one quarter of the total pixels. This feature is very helpful
when connecting to a non-4K/UltraHD preview monitor.
HDR Tab Screen
