AJA kumo 1604 Operating instructions

®
Installation and Operation Guide
Version 3.1
Published: May 23, 2014
USO RESTRITO

KUMO v3.1 www.aja.com
2
Table of Contents
Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Contacting Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
KUMO Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
KUMO Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
P/S 1 & P/S 2 Power Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
RJ45 Ethernet Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
ID and Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
REF BNC connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . 8
Video Inputs and Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Normal mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Dual and Quad modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
RS-422 DB9 Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Older Model RS-422 Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
KUMO Control and Monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Network Configuration Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Direct Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . 9
LAN Connection Using a Hub or Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Default Network Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
In This Manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Chapter 2: Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
What’s In The Box? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . 12
KUMO Chassis Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Where to Place KUMO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Physical Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Physical Equipment Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . 14
Quick Start Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Default Auto Configure KUMO Router and CP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
DHCP on an Existing Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Computer Auto Discovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Mac Configuration with Safari Browser Using Bonjour. . . . . . . . . . . . . . . . . . . . . 15
Windows 7 PC Configuration using UPnP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
KUMO Temporary Static IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Network Configuration Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Direct Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . 19
LAN Connection Using a Hub or Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Setup and Control Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Setup and Control from a Browser on Mac OSX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Safari Browser Using Bonjour . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Safari Browser: Type in KUMO Static IP Address . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Setup and Control from a Browser on Windows 7. . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Windows 7: Using UPnP (Universal Plug and Play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Windows 7: Firefox Using Bonjour . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
USO RESTRITO

KUMO v3.1 www.aja.com
3
Install Apple Bonjour Print Services for Windows. . . . . . . . . . . . . . . . . . . . . . . . . . 23
Install DNSSD for Firefox Add-On . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Accessing KUMO Devices in Firefox. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Windows 7 Browser: Type in KUMO Static IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Setup and Control from a Browser on Windows XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Windows XP using UPnP (Universal Plug and Play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Enabling UPnP Services in Windows XP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Windows XP: Firefox Using Bonjour. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Windows XP Browser: Type in KUMO Static IP Address. . . . . . . . . . . . . . . . . . . . . . . . . 29
Larger System Control Configurations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
TCP-IP Network Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Default DHCP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Static IP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Select KUMO to Control from Webpage. . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Assign KUMO CP to Control KUMO Routers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Chapter 3: KUMO Router Web Browser User Interface . . . . . . . . . . .35
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Navigation Bar Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
KUMO Home. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Control Panel Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Router Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Mode Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Button Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Network Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Firmware Updating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Unpack the Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Uploading and Installing Firmware to KUMO. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Safeboot Reset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
KUMO Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Locating a Specific KUMO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Chapter 4: KUMO Remote Control Panel . . . . . . . . . . . . . . . . . . . . . . . .43
Connectors and Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Button Key Caps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Panel Function Buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Panel Lock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Destination Lock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Router Delegation Buttons (RTR 1 - 4). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Shift/Reset Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Control Panel Browser Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Home Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Configuration Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Network Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Identify Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Appendix A: Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
KUMO SDI Router Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
KUMO CP Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
GVG Native Protocol Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
RS-422 Control Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . 50
Ethernet Control Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Appendix B: Safety & Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
USO RESTRITO

KUMO v3.1 www.aja.com
4
Federal Communications Commission (FCC) Compliance Notices . . . . . . . . . . . . . . . . . . 51
Class A Interference Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
FCC Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Canadian ICES Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . 51
European Union and European Free Trade Association (EFTA)
Regulatory Compliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Korea KCC Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Taiwan Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Japanese Compliance Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Translated Warning and Caution Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Before Operating Please Read These Instructions . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
USO RESTRITO

KUMO v3.1 www.aja.com
5
Notices
Trademarks
AJA®, KONA®, Ki Pro®, KUMO® and XENA® are registered trademarks of AJA Video, Inc.,
TruZoom™, TruScale™, Ki Pro Mini™, Io Express™, Io HD™, Io™ and “Work. Flow.” are
trademarks of AJA Video, Inc. AirPort, Apple, the Apple logo, AppleShare, AppleTalk,
FireWire, iPod, iPod Touch, Mac, and Macintosh are registered trademarks of Apple
Computer, Inc. Final Cut Pro, QuickTime and the QuickTime Logo are trademarks of Apple
Computer, Inc. Avid, Avid Media Composer and Avid DNxHD are trademarks of Avid
Technology, Inc. All other trademarks are the property of their respective holders.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC. DVI is a registered trademark of DDWG. All
other trademarks are the property of their respective holders.
Copyright
Copyright © 2014 AJA Video, Inc. All rights reserved. All information in this manual is
subject to change without notice. No part of the document may be reproduced or
transmitted in any form, or by any means, electronic or mechanical, including
photocopying or recording, without the express written permission of AJA Inc.
Contacting Support
When calling for support, have all information at hand prior to calling.
To contact AJA Video for sales or support, use any of the following methods:
Telephone: [phone]
FAX: [phone]
Web: http://www.aja.com
Support Email: [email protected]
Sales Email: [email protected]
USO RESTRITO

KUMO v3.1 www.aja.com
6
Chapter 1: Introduction
Overview
KUMO compact SDI routers are small and cost-effective, yet robust and reliable. KUMO
supports full-broadcast specifications over SDI, HD-SDI, and 3G-SDI. Additionally, KUMO
routers support SDI related protocols such as 270mb ASI and Canon 3G-SDI RAW. Kumo
routers are re-clocking, non-blocking, and ready for any broadcast, production, or post
production environment. Running Embedded Linux, KUMO routers support powerful
HTTP control and monitoring. KUMO contains an internal webserver that allows
immediate installation, configuration, and operation without requiring additional
software. It offers a powerful user interface via any standard web browser. KUMO SDI
routers are available in three configurations:
• KUMO 1604 - up to sixteen SDI inputs and four outputs
• KUMO 1616 - up to sixteen SDI inputs and sixteen outputs
• KUMO 3232 - up to thirty-two SDI inputs and thirty-two outputs
KUMO also supports dual and quad port switching modes which simplify multi port SDI
signals such as "dual link" and 4K "quad-link", or switching 2 or 4 sources at once for any
reason.
Because of their compact 1RU and 2 RU sizes, KUMO SDI routers are ideal for space-
sensitive applications such as mobile sports trucks, edit suites, corporate video
installations, or live theatrical A/V rigs.
Rear Panel 1604
Rear Panel 1616
Typical Front Panel
Control Panel Option
Rear Panel 3232
USO RESTRITO

KUMO v3.1 www.aja.com
7
KUMO Features
The KUMO routers offer the following features for ease of use in any environment:
• Support for SD-SDI, HD-SDI, 3G-SDI, SMPTE 259M/292M/424M
• KUMO v3.0 firmware supports dual and quad mode routing, allowing users to group
together inputs and outputs for multiple cable applications like Dual Link, Quad HD,
Quad split monitors, etc.
•Automaticequalization and re-clocking
• Supports all ancillary data, including embedded audio
• Reference via BNC, passive loop, PAL/NTSC color black or HD tri-sync
• 10/100/1000 Ethernet LAN
• Embedded Linux OS with internal webserver for web browser control
• HTTP Control
• Optional pushbutton remote control panel via Ethernet
• 1RU form factor for 16x16, 2 RU for 32x32
• Redundant Power (optional), isolated power inputs
KUMO Connections
Figure 1. KUMO Rear Panel Connections (3232 shown, other models similar)
P/S 1 & P/S 2 Power
Connectors
Power to the KUMO unit is supplied by a power supply brick that accepts a 110-220VAC,
50/60Hz power input and supplies +12 VDC to KUMO via connector PS/1 or PS2. Only
one power supply is required and may be connected to either of the two power
connectors. An optional second power supply provides power redundancy to help
protect against outages. For additional protection, connect the two supplies to different
AC branch circuits so that KUMO will remain on even if there is a failure or open circuit
breaker on one branch.
USO RESTRITO

KUMO v3.1 www.aja.com
8
RJ45 Ethernet
Connector
The RJ45 Ethernet connector allows you to connect KUMO to an Ethernet 10/100/1000
Ethernet LAN using CAT5 cable as explained in the section that follows. Multiple
configurations are possible, including standalone control, a local LAN, or a WAN.
ID and Reset The ID LED lights when you use the web interface to identify the KUMO unit you are
controlling. The Reset button (pinhole) below the LED allows a safeboot reset of the unit
as explained in Chapter 3: “Safeboot Reset” on page 41.
REF BNC connector The REF BNC connector is the looping input for synchronizing the switching timing of
KUMO to your house video signals. Apply an analog NTSC, PAL, or Tri-level sync signal to
this input. Also be sure to connect a terminator to the second connector, or if you loop
from that connector to other equipment, be sure to terminate the connection at the
other equipment.
When reference is present, Kumo will switch in vertical interval with respect to the
reference input. If no reference is present, the Kumo will switch at random times.
Video Inputs and
Outputs
Depending on your KUMO model, up to 32 SDI (SMPTE 259/292/296/424) video inputs
and outputs can be connected to the video input and output BNC connectors.
Normal mode In Normal mode, BNC inputs and outputs have a one-to-one relationship with the SDI
signals being routed.
Dual and Quad modes In Dual mode, inputs and outputs use adjacent pairs of BNCs for each routed signal. In
Quad mode, four adjacent BNCs are used for each routed signal
RS-422 DB9
Connector
KUMO includes an RS-422 female DB9 connector for making serial connections to other
equipment. This control connection enables interoperability with other devices,
including those that use GVG Native Protocol.
Table 1. Dual and Quad Mode BNC Connectors and Signals
Dual Mode Quad Mode
BNC # Signal BNC # Signal BNC # Signal
1-2 117-18 91-4 1
3-4 219-20 10 5-8 2
5-6 321-22 11 9-12 3
7-8 423-24 12 13-16 4
9-10 525-26 13 17-20 5
11-12 627-28 14 21-24 6
13-14 729-30 15 25-28 7
15-16 831-32 16 29-32 8
USO RESTRITO

KUMO v3.1 www.aja.com
9
Older Model RS-422
Adapter
Older KUMO routers (serial numbers ending in -R0) needed an RS-422 adapter for proper
serial control operation. This adapter was shipped with those older model routers. Be
aware of this fact if your facility has a mixture of older and newer KUMO routers that use
RS-422 control.
Figure 2. RS-422 Adapter
NOTE: Only KUMO routers with a serial number ending in -R0 require this adapter. KUMO routers
with serial numbers ending in -R1 do NOT require the adapter.
KUMO Control and Monitoring
The KUMO router user-interface provides powerful remote setup, control, and
monitoring with:
• Zero-configuration Bonjour Protocol and support for UPnP networking protocols
• Remote web browser control interface via Ethernet
• Optional push-button remote KUMO CP control panel for control of up to four KUMO
routers
• GVG Native Protocol built-in to allow serial or LAN interconnection (one RS-422 or up to
ten Ethernet) and interoperability with other equipment. Specifically, Kumo can be
controlled by the SMS 7000 portion of the GVG Native Protocol. For details, refer to:
“GVG Native Protocol Support” on page 49. Also refer to Grass Valley documentation at:
http://www.grassvalley.jp/pdf/RoutingProductsProtocolManual_2.pdf
Network Configuration Overview
KUMO’s internal HTTP networking software supports three levels of network control:
• Closed KUMO network – uses Bonjour
• Auto Configured LAN – employs a Bonjour or UPnP enabled computer/browser to
automatically connect devices and allows KUMO web browser User Interface (UI).
• Standard TCP-IP network – employs DHCP or Static IP addressing and allows the KUMO
web-based UI and an unlimited number of KUMO routers and up to 16 KUMO CP
control panels.
Direct Connection In a direct connection, the control computer (Mac /PC) or a KUMO CP control panel
connects to a KUMO router using an Ethernet cable (cat 5) between the RJ45 connectors
on both devices.
USO RESTRITO

KUMO v3.1 www.aja.com
10
Figure 3. KUMO Router Direct Connection to KUMO CP or Mac/PC
LAN Connection
Using a Hub or
Switch
In a LAN connection, one or more KUMO routers, KUMO control panels, and web browser
equipped computers are connected to your LAN or closed network using Cat. 5 Ethernet
cable and an Ethernet hub or switch.
Figure 4. KUMO LAN with Routers, Control Panels, and Web Browser UI
Default Network
Settings
KUMO routers and control panels ship with DHCP enabled, making system operation
possible simply by connecting the KUMO device’s Ethernet cabling.
In addition, temporary default static IP addresses can be activated for initial KUMO
system configuration. See “KUMO Temporary Static IP Address” on page 16.
