42” Enhanced Denition Plasma TV PDP4206EA
Home theater experiences dened by AKAI technology.
Products styled for you, performance to enrich your life. Whether your application is simple or
demanding, Akai technology will support your lifestyle.
Stunning Visual Performance
• ATSC Digital Tuner included for off air HD broadcasts
• 3,000:1 contrast ratio provides an incredible picture with deeper blacks and brighter whites
• High brightness 1,000 cd/m2 provides a more vivid , brilliant picture in any environment
• Wide viewing angle (160 degrees) makes the unit viewable from many locations
Compatible with a wide range of multi-media components
• External HD inputs through DVI(with HDCP) or Component (Y Pb Pr) Video
• Conventional video through multiple S-video and composite video inputs
• VGA port provided for connection to PC
Audio for all reasons
• 14W (7W x 2) outputs for internal rear mounted speakers
• Enhanced sonic performance with BBE and SRS audio technologies
IP
P
ROGRESSIVE
-SCAN

AKAI ELECTRIC COMPANY JAPAN
TECHNOLOGY & IMAGINATION www.akaiusa.com
* Product's specifications subject to change.
SPECIFICATIONS
42” Enhanced Denition Plasma TV PDP4206EA
Display
Display Type: 42” Diagonal Plasma Display Panel
Screen Aspect Ratio: 16:9
Resolution: 852 (H) x 480 (V)
Pixel Pitch: 1.08 x 1.08 mm
Contrast Ratio: 3000:1
Brightness: 1000 cd/m2
Viewing Angle: 160 degrees (H) & (V)
PC Resolution Supporting: VGA, SVGA, XGA (Auto Covert to VGA)
Scan system: Progressive
Digital Comb Filter: Digital 2D
Film Mode Pull Down Conversion: Yes
Color Temperature Control: Yes
“GAMMA” Correction: Yes
Wide Mode: Zoom (Fill Screen 16:9); Normal (4:3); Panorama; TV Mode; Letter Box
Audio
Output Power: 7W + 7W Internal-Speaker Stereo System
MTS: Mono/Stereo/SAP
Sound Effect: SRS, BBE System
Tone Control: Yes
Features
Tuning System: ATSC/NTSC TV Tuner
OSD Language: English/French/Spanish/Portuguese
Closed Caption Decoder: Yes
V-Chip Parental Control: Yes
Input Terminals
Analog RGB Input: D-Sub 15 Pin x1
DVI (HDCP) Input: DVI Connector x1
RS-233 Input: D-Sub 9 Pin x1
S-Video Input: Mini Din 4 Pin x1
CVBS Input: RCA x1 set
Component Video Input: RCA x2 sets
Stereo Audio Input: RCA x5 sets
Antenna Input: F Type x1
Output Terminals
Audio Output: RCA x1
Digital Audio Ouput: Optical x1
General
Power Source: 120V, 60Hz
Power Consumption: 330w
Unit Size (W x H x D): 41.3” x 25.9” x 3.9”
Unit Weight: 80.7 lbs
Box Size (W x H x D): 46.5” x 31.8” x 12.6”
Gross Weight: 94.5 lbs
UPC Code: 827935510264
