Akarana Baby Weka D138 User manual

Free Direction&Orientable
Link Brake For Rear Wheels
Shocking Proof For Front Wheels
The multifunctional baby stroller instruction
To make sure how to use the stroller, please read the
instruction carefully, keep it safe for future reference. If you
do not follow instructions to use the stroller, may affect
children's safety. If you assign the stroller, please assign
this instruction together.
Detachable Front Tray
4 Position Adjustable Backrest
Super Large Basket
Portable Strap Design
Front Wheels Can Be Lockable,
Super Light Weight

ZIPPER
when close zipper,close full canopy when open zipper at middle canopy.
1
②Connect the canopy with the backrest by the plastic parts and stick on.
Handle
Parts
Rear wheel
Canopy
Front tray
Front wheel*2
frame
Instruction
& tool kit
1、Release the folding latch by fiting up. Grip the Cut the rope to release.
handle bar on each side and turn outward to open fully.
2、Lift up the handle bar and stroller automatically lock into the position.
3、①Lay the stroller on its rear legs with the front legs up (see figure).
slip the front wheel holders with the release button facing outside
onto the shaft until they click into place.
②Press in the square button located at the bottom of the wheel
holder while pulling the assembly off of the shaft.
4、Lay the stroller on its front wheels with the rear legs up (see figure).
To fit the wheels insert the end of the legs into the slots rearrear
situated in the centre of the wheel blocks.
5、Align the dining plate pegs with the holes on the dining plate
adaptors. Slide and press into until hear clicks. Push the button under
the both sides bar to take out the dining plate.
6、①Confirm the canopy is facing in the proper direction. Fully insert the
canopy holder(male) to the canopy holder(female)
until a click is heard.
23
①
②square button
456
① ②
③See Fig: Press down brackets to unfold the canopy ; Open full canopy
③

t he front wheel toward right or left back before folding.
the pad for folding fixed will lock automatically.
WARNING: Do not force to fold when fail folding. Please repeat the
operation (⑤、⑥)steps till success folding.
buckle and belts.
11、The adjustment of safety belt. Adjust the length of the safety belt. Lock
two safety buttons firmly. Press the safety button down to release the
WARNING: Use the saftey belt always! Do not use it when the belt
easy broken.
BRAKE: Push it down to lock . Life it up to unlock.
second lock
folding button
Reversible handle operation: Draw up the plunger to hold on both sides
and push the handle to opposite until a sound "click"for fixed.
WARNING: Please do not nip the child hands when operation the
reversible
handle.
Red button
7、Push the stroller forward to ensure that the brakes are properly engaged.
Push the red button lever down to lock brakes；
Push the green button lever down to unlock brakes.
9、4-position for backrest: Press the button up or down can arrive another positon.
8、To lock swivels: Lift both swivel lock levers up to fix the direction.
To unlock swivels: Push down swivel lock levers down to release the direction.
12、
13、WARNING: Unlock the front wheel oriented plastic part and put
①Lock both front swivel wheels.②Empty the basket.
③Fold the canopy by lifting up on the canopy levers.
④Place seat in the upright position.
⑥Fold the handle toward inside by both hands. The hook which under
orientation
parts
Green button 79


8
⑤
Seize the button with strength and push the lock tab to big second
And make the stroller frame incline toward back to folding. left.
Rear wheels brake using:
10 11 12

13
14 Shoulder-strap using : Strap on the shoulder after folding the stroller.
WARNING: The shoulder-strap must be put in the basket when the
stroller is using.
、
brake
10
10、Open seat,enlarge seat when pull rods,shorten seat conversely.

• This is stroller is designed for a child 6 to 36 months.
• Maximum load weight is 15KGS.
• WARNING Never leave your child unattended.
• WARNING Ensure that all the locking devices are engaged before use.
• WARNING To avoid injury ensure that your child is kept away when
unfolding and folding this product.
• WARNING Do not let your child play with this product.
• WARNING Use a harness as soon as your child can sit unaided.
• WARNING Always use the restraint system
• WARNING Check that the pram body or seat unit or car seat attachment
devices are correctly engaged before use.
• WARNING This product is not suitable for running or skating.
Do not use accessories, spare parts, or any component which is not
supplied or approved by the manufacturer.
•
• Please be sure to strictly observe the following points to avoid the
accident happens.
• When children sit in stroller never carry it up.
• Never let stroller be used in steep slope, stairs, escalators, sand
beach, uneven roads and mud.
• Never allow more than one child at a time in the stroller. And be sure
the children sit in the cart seat.
• WARNING Any load attached to the handle affects the stability of the
pram/pushchair.Any accessories which are not approved shall not be used.
• Do not overload the basket. Maximum load weight is below 3KGS.
Excessive weight may cause a hazardous unstable condition to exist.
• To fix the brakes when the stroller stop to prevent the stroller moving.
• In order to avoid baby getting injured when the handle reversible.
And don't let the child's arm to put within the scope of handle's activities.
Check carefully the handle has been fixed after it changed forward.
• Please throw away the bag immediately. it would be the danger of
suffocation . if your children wear it
• WARNING Check that the pram body or seat unit attachment devices
are correctly engaged before use.
• WARNING:Do not let your stroller near by fire.
• WARNING Do not add a mattress thicker than 10 mm.
• Clean canopy/safety belts/ fixed base and basket, scrub and wipe,
then dry. For especially dirty parts, please diluted detergent and wash it. then
wipe it dry .after that
• Wipe off the marl, and then use a damp cloth to clean the stroller
frame. wipe the stroller with a dry cloth at last. If not dry, the stroller
body will be aging black.
• Do not use bleacher. Put the cushion in the dark place to dry in the
shade. Do not use dryer to dry it.
• Do not let your stroller in direct sunlight. Otherwise, the plastic and
fabric parts will fade.
• Due to the continuous improvement of products, design and
specifications are subject to change without notice.
• The pictures in instructions are just for reference. They can not represent
the actual product.
WARNING
Maintenances
800117
