akira HTB-303 User manual

Speaker
Service Manual

-2-
Model No.: HTB-303
Version: 1.0
MODEL:
HTB-303

-3-
Model No.: HTB-303
Version: 1.0
CONTENTS
SPECIFICATION..................................................................................................................................... 4
EXPLODED VIEW.................................................................................................................................. 5
PART LIST............................................................................................................................................... 7

-4-
Model No.: HTB-303
Version: 1.0
SPECIFICATION
Model Number HTB-303 CS HTB-303 FS HTB-303 SS
Cabinet Type Center Speaker Floor Standing Speaker Surround Speaker
Component 0.5 Dome tweeter 0.5 Dome tweeter 0.5 Dome tweeter
4 woofer x 2 2 woofer x 4 2 woofer x 2
Speaker System Close Bass Reflex Close
Speaker Terminals Spring clip Spring clip Spring clip
Dimension W x H x D 260 x 85 x 55 mm 85 x 1053 x 55 mm 85 x 1053 x 55 mm
Weight (net) 0.65kg/pc 2.95kg/pc 2.8kg/pc

-5-
Model No.: HTB-303
Version: 1.0
EXPLODED VIEW

-6-
Model No.: HTB-303
Version: 1.0

-7-
Model No.: HTB-303
Version: 1.0
PART LIST
HTB-303 CS
CODE DESCRIPTION QTY
38079-1 Aluminum material VISION 5C drawing no, AQ-1, 00, 011, 1
silver
1
450053 Silicon gel feet drawing no. INNO-3 (foot) 00, 002, 0 4
509092 Bracket VISION SERIES silver 1
53758 Top cover VISION 5 drawing no. AQ-1, 00, 006, 0 silver plastic 1
59414-2 Iron net VISION 5C drawing no. AQ-1, 00, 013, 2 silver 1
N200-133 Cross cover AM-21277 two way no EQ network wire clip back
board
1
T004-0131-02 Tweeter 0.5” HT-1379 13.28 core 4Ωmagnetic shielded 1
W0208-0161-004 Woofer 2” FR050FDD03424 8Ωmagnetic shielded 2
HTB-303 FS
CODE DESCRIPTION QTY
38080-1 Aluminum material VISION 5F1 drawing no. AQ-1, 00, 010, 1
silver
1
38084-1 Aluminum material down VISION 5 drawing no. AQ-1, 00, 008, 1
silver L=650mm
1
47623 Glass stand VISION 5, 00, 021, 0 ellipse with hole silver 1
450056 Copper feet distance VISION 3, 00, 006, 0 copper alloy with
chrome plated
4 set
500504 Stand connecting board VISION 5 drawing no. AQ-1, 00, 005, 0
silver plastic
1
53758 Top cover VISION 5 drawing no. AQ-1, 00, 006, 0 silver plastic 1
59415-1 Iron net VISION 5F1 drawing no. AQ-1, 00, 012, 1 silver 1
61070 Binding post vision 5/6 AQ-1; 00, 021, 0 red 1
61071 Binding post vision 5/6 AQ-1; 00, 021, 0 black 1
N201-294 Cross over filter AM-21276 two way non EQ network binding post
board
1
T004-0131-02 Tweeter 0.5” HT-1379 13.28 core 4Ωmagnetic shielded 1
W0204-0161-004 Woofer 2” WR050FDD03431 4Ωmagnetic shielded 4

-8-
Model No.: HTB-303
Version: 1.0
HTB-303 SS
CODE DESCRIPTION QTY
38083-1 Aluminum material up VISION 5SF drawing no. AQ-1, 00, 007, 1
silver
1
38115 Aluminum material drow VISION 5SFA drawing AQ-1, 00, 019 0
silver 770
1
47623 Glass stand VISION 5, 00, 021, 0 elipse with hole silver 1
450056 Cooper feet pin VISION 3, 00, 006, 0 copper alloy chrome plated 4 set
500504 Stand connecting board VISION 5 drawing AQ-1, 00, 005, 0 silver
plastic
1
53758 Top cover VISION 5 drawing no. AQ-1, 00, 006, 0 silver plastic 1
59416-2 Iron net VISION 5F2/SF drawing no. AQ-1, 00, 003, 2 silver 1
61070 Binding post vision 5/6 AQ-1; 00, 021, 0 red 1
61071 Binding post vision 5/6 AQ-1; 00, 021, 0 black 1
N201-362 Cross over filter AM-21362 Two way non EQ network binding
post back board
1
T004-0131-02 Tweeter 0.5” HT-1379 13.28 core 4Ωmagnetic shielded 1
W0208-0161-004 Woofer 2” FR050FDD03424 8Ωmagnetic shielded 2
