JVC TH-D357B User manual

Remove the Plastic Strip from the Remote Control
The unit has a pre-installed
lithium CR2025 battery. Remove
the protective tab to activate the
remote control battery.
Connections
•
Operating Your Remote Control
•
Install the battery correctly in the battery compartment. Normally the
battery’s positive polarity (+) will face up.
Soundbar Sockets Overview
•
Quick Start Guide
2.1 Ch wireless soundbar with
wireless subwoofer
TH-D357B
Thank you for purchasing your new product.
We recommend that you spend some time reading this Quick Start
Guide in order that you fully understand how to connect your
Soundbar to your TV.
Use your Soundbar instruction manual and TV instruction manual to
choose the best way to connect your Soundbar and TV together.
Unpacking
•
Remove all packaging from the unit. Retain the packaging. If you
dispose of it please do so according to any local regulations.
To get the most from this product, you may need to buy an
Optical cable.
Battery Replacement for the Remote Control
1. Gently push the tab of the battery tray in and slide it free
from the remote control.
2. Replace with a new
battery
3. Slide the battery tray back into the remote control.
Main Unit
Remote Control
(battery included)
Subwoofer
Wall Bracket × 2
Screw × 4
Dowel × 4
Mains Cable × 2
Coaxial Cable
3.5 mm to 3.5 mm
Stereo Audio Cable
Instruction Manual
Quick Start Guide
Connecting to the TV
Method 1: OPTICAL / COAXIAL Connection
Use an optical cable (not included) / coaxial cable (included)
to connect the soundbar’s OPTICAL / COAXIAL socket to the
OPTICAL OUT / COAXIAL OUT socket of the external device.
The simplest option is to connect your soundbar directly to
your TV. If you connect the soundbar to another external
device (e.g. Blu-Ray player), you will hear the sound from that
device through the soundbar.
After the connection is complete,
1. Press on the unit or remote control to switch on the unit.
2. Press SOURCE repeatedly to select Optical or Coaxial
mode to play audio from your input device.
• The unit may not be able to decode all digital audio formats
from the input source. In this case, the unit will mute. This is
NOT a defect. Ensure that the audio setting of the input source
(e.g. TV, game console, DVD player, etc.) is set to PCM with
optical input.
• Before connecting the optical cable, remove the protective cap
of the OPTICAL socket.
DO NOT connect the soundbar with the TV through its RCA sockets
or headphone socket.
Ensure the unit is disconnected from the mains socket before connecting it to other devices.
1. COAXIAL Socket
2. AC~ Socket
3. OPTICAL Socket
1
2
34
5
6
4. SERVICE ONLY Socket
5. AUX Socket
6. LINE IN Socket
3.5mm to 3.5mm stereo
audio cable (included)
Rear View of the Soundbar
3.5mm to RCA Stereo Audio
Cable (not included)
or
Blu-ray Player / DVD
Player / Recorder
Set-top Box
Satellite Receiver Game
Console
Video
Camera
MP3 Player or
Mobile Device
Connecting an External
Audio Device
Use a 3.5mm to RCA stereo audio cable
(not included) or a 3.5mm to 3.5mm stereo
audio cable (included) to connect the
soundbar’s AUX or LINE IN socket to the
headphone socket of the external devices.
After the connection is complete,
1. Press on the unit or remote control to
switch on the unit.
2. Press SOURCE repeatedly to select AUX
or LINE IN mode to play audio from
your input device.
• Ensure the colours on the cable plugs
match with the colours on the input and
output sockets.
• Do not connect the soundbar and TV by
using the AUX socket.
1
2
Optical cable (not included)
TV
Rear View of the Soundbar
Coaxial cable (included)
Blu-ray Player / DVD
Player / Recorder
Set-top Box
Satellite
Receiver
Game
Console
Video Camera
or
TH-D357B_QSG_Final180626V3.indd 1 27/6/2018 11:01 AM

•Connecting to the Mains Supply
Soundbar
Unwind the mains cable to its full length. Connect the end of
the mains cable to the AC~ socket at the rear of the soundbar
then connect the mains plug to the mains socket.
Subwoofer
Connect the other mains cable to the AC~ socket at the rear
of the subwoofer then connect the mains plug to the mains
socket.
• The mains cable is designed for this JVC soundbar only. DO NOT use the mains cable for other purposes. Connecting the unit to any other power source may
damage the unit.
• Ensure all audio connections of the unit are connected before connecting to the mains power socket.
• Make sure the mains plug is rmly inserted into the mains socket.
• To switch the unit o completely, remove the mains plug from the mains socket.
• Please turn the unit o completely to save energy when not in use.
Well done, your new soundbar is now ready to use. You will nd that there are many exciting features available. To get to know all
these features, please take some time to read the instruction manual provided with your soundbar.
(QSG-TH-D357B-180626V3)
To the mains
socket
Rear View of the Soundbar
AC~
PAIR
To the mains
socket
Rear View of the Subwoofer
•Connecting the Subwoofer
Your subwoofer will automatically pair to your soundbar when the soundbar is switched on.
1. Plug the soundbar and the subwoofer into the mains sockets.
2. Press on the unit or on the remote control to switch the unit to ON mode. The subwoofer and soundbar will automatically pair within
30 seconds.
Front view of the main unit
(while pressing BASS/TREBLE button)
AUX IN
Indicator
(Green)
BT
Indicator
(Blue)
OPTICAL
Indicator
(White)
COAXIAL
Indicator
(Orange)
Select Equaliser (EQ) Eect
Press the EQ button on the unit or the CUSTOM/MOVIE/MUSIC button on the remote control to select the preset equaliser eects.
• When CUSTOM (Default) is selected, the COAXIAL indicator will ash (Orange) once.
• When MOVIE EQ is selected, the OPTICAL indicator will ash (White) once.
• When MUSIC EQ is selected, the BT indicator will ash (Blue) once.
• While the unit is in COAXIAL, OPTICAL, or AUDIO IN mode, it will automatically switch into MOVIE EQ eect.
• While the unit is in Bluetooth mode, it will automatically switch into MUSIC EQ eect.
Adjusting the Bass/Treble Level in Custom EQ mode
1. Make sure that the EQ is set to Custom mode.
2. Press BASS/TREBLE on the remote control. The AUX IN, BT, OPTICAL and COAXIAL indicators
will ash once.
3. Press VOL+/VOL– to adjust the bass/treble level.
4. After about 5 seconds, the AUX IN, BT, OPTICAL and COAXIAL indicators will ash once again to
indicate that the unit has exited BASS/TREBLE setup.
5. You may now press VOL+/VOL– to adjust volume.
• While adjusting the bass/treble level, the status indicator ashes quickly.
• While the BASS/TREBLE reaches its maximum or minimum level, the status will ash once if
you press VOL+/VOL– again.
The table below also shows the EQ mode supporting bass/treble adjustment.
EQ Mode Adjusting Bass Level? Adjusting Treble Level?
Custom 3 3
Movie N/A N/A
Music N/A N/A
•EQ and Bass/Treble Level Settings
For general information about this appliance and
handy hints and tips, please visit:
www.TeamKnowhow.com/discover or call
UK: 0344 561 1234
Ireland: 1 890 818 575
