Akrobat GALLUS INGROUND User manual

INSTALLATION AND USER MANUAL
> GALLUS INGROUND
100 % made in Europe 2.5 million
jumps guarantee
62.7 % softer
bounce absorption
10ft, 12ft, 13.5ft, 14ft

2
INSTALLATION AND USER MANUAL - GALLUS INGROUND
EXTEND YOUR WARRANTY TODAY!
Register your trampoline on www.akrobat.com/registration to
get an extended warranty for your product and receive useful
information on best use of your trampoline.
Thank you for choosing Akrobat Trampoline!
Your trampoline is so much more than just another outdoor toy. It was designed to provide engaging
playtime, create fun memories and active exercise to all members of the family, no matter what age.Akrobat
trampolines are built to last. Made of best quality European materials and as a result of skilled craftmanship,
your trampoline will serve you for years to come.
Safety comes first! In order to achieve the best trampolining experience that will keep you fit and energised,
please read these assembly instructions and safety recommendations thoroughly to minimize any chances
of injuries.

3
1. WARNINGS!
Maximum user weight is defined by the size of the trampoline:
10 ft – 305 cm 100 kg
12 ft – 366 cm 130 kg
13.5 ft – 411 cm 130 kg
14 ft – 427 cm 130 kg
• Adult supervision and instruction required at all times.
• Use gloves to protect your hands from pinch points and sharp points
during assembly.
• Do not apply excessive force during assembly that will cause damage
to the product.
• The trampoline has to be assembled by an adult and cautiously
inspected before first use.
• Make sure the barrier and the enclosure poles are correctly and
securely positioned. Replace any worn, defective, or missing parts.
• Minors must be supervised by an adult person regardless of their
skills or training. Be sure to prevent access to and use of the
trampoline without proper supervision.
• Check the trampoline before each use. Regular maintenance check-
ups of the trampoline and trampoline parts are advisable to prevent
user injuries. Keeping the trampoline impeccable will prolong the
lifetime of your trampoline.
• Serious injury, paralysis or even death can occur if the trampoline is
not used properly.
• This trampoline is for outdoor use only.
• Not suitable for children under 36 months - small parts, choking
hazard.
• Wear clothing free of drawstrings, hooks, loops or anything that
could get caught while using the trampoline/enclosure and result in
entanglement. Do not attach anything to the enclosure that is not a
manufacturer-approved accessory or part of the enclosure system.
• Properly secure the trampoline/enclosure when not in use. Protect
it against unauthorized use.
• Do not allow a child or other persons under the trampoline.
• Jumping on the trampoline is not recommended during pregnancy.
• Do not use the trampoline under the influence of alcohol, drugs or
heavy medication.
• Keep all sources of heat and flames away from the product as it will
burn.
• Always close the net opening before jumping.
• No animals should be allowed on the trampoline as they can damage
both the frame pad and the jumping mat.
• The jumping mat should be kept clean and dry. Jumping on a wet
jumping mat is prohibited in order to avoid slips and falls.
• Remove footwear before jumping on the trampoline.
• Empty your pockets before using the trampoline.
• Do not eat food, sweets or chew gum when bouncing.
• Bounce in the center of the mat.
• Stop bouncing by flexing knees as feet come in contact with the
trampoline bed. Learn this skill before attempting other jumps.
• Do not jump off the mat – always walk on and off. It is dangerous
practice to jump from the trampoline to the floor or ground when
dismounting, or to jump onto the trampoline when mounting. Do
not use the trampoline as a springboard to other objects. Do not
jump from other objects, buildings, or surfaces, onto the trampoline,
or into or over the trampoline enclosure.
• Avoid bouncing too high or for too long, make regular breaks. Stay
low to control your bounce and repeat landing in the center of the
trampoline.Always control your bounce. Control is more important
than height.
• Do not attempt or allow somersaults. Landing on the head or neck
can cause serious injury, paralysis, or death, even when landing in the
middle of the bed.
• No more than one person is allowed to use the trampoline at a time.
Collision hazard: multiple jumpers increase the chances of loss of
control and this can result in serious injury.
• Misuse and abuse of the trampoline is dangerous and can result in
serious injury.
• Glasses, jewellery and similar objects should be taken off before
entering the trampoline. Empty your pockets and keep your hands
free when jumping.Always jump on the middle of the jumping mat.
• Do not sit on the trampoline safety pad and do not stand on the
edge while another person is jumping.
• Keep small children away from the trampoline while others are
bouncing on it, because the edge can move in and out vigorously.
• Trampoline should be placed on a level grass surface or soft surface
such as sand or bark. Do not use trampoline on hard surfaces as
asphalt, concrete or some other similar surfaces. Do not place
trampoline around swimming pools, swings, slides, climbing walls etc.
• Do not use the trampoline in windy weather. If you are using a safety
net, remove and store it for better weather conditions.
• Installation of this trampoline requires digging a trampoline pit.
Before installing the trampoline make sure that your ground will
drain well.We advise to get help by a professional if you are not sure
about the quality of the ground or other issues regarding the digging.
• Remove all hard objects around and under the trampoline. There
should be no objects – such as fences, roofing,tree branches,laundry
ropes,electrical cables etc.– anywhere near or above the trampoline.
Clear the surroundings for at least 2 metres in every direction.
• Ensure there is sufficient head space above the trampoline.
• Each modification made to the trampoline must be approved by the
manufacturer.
• When moving the trampoline, disassemble it in reverse order of
assembling. Move to desired location and re-assemble according to
these instructions.
• In our commitment to customer satisfaction and safety, please
check our website regularly for important customer updates and all
trampoline specifications.
• For additional information concerning the trampoline equipment,
please contact the manufacturer or regularly check our website for
important customer updates.
Read this manual carefully before assembling and using
your trampoline. Keep this manual for future reference.
The responsibility of the owner is to ensure that all users of the product are fully
informed about the proper use of this trampoline and all safety precautions.

4
INSTALLATION AND USER MANUAL - GALLUS INGROUND
2. TRAMPOLINE PARTS
Gallus
Inground 10ft
(305 cm)
Gallus
Inground 12ft
(366 cm)
Gallus
Inground 13.5ft
(366 cm)
Gallus
Inground 14ft
(427 cm)
Part A Frame sections 8 pcs 8 pcs 8 pcs 8 pcs
Part B Jumping mat 1 pc 1 pc 1 pc 1 pc
Part C Springs 80 pcs 96 pcs 104 pcs 104 pcs
Part D Frame pad 1 pc 1 pc 1 pc 1 pc
Part E Frame pad elastics 16 pcs 16 pcs 16 pcs 16 pcs
Part F Retaining PVC panels 8 pcs 8 pcs 8 pcs 8 pcs
Part G Screws for panels 34 pcs 34 pcs 34 pcs 34 pcs
Safety net assembly parts
Part H Top frame part - short 4 pcs 4 pcs 4 pcs 4 pcs
Part I Top frame part - long 4 pcs 4 pcs 4 pcs 4 pcs
Part J Net pole with PVC
sleeve 7 pcs 7 pcs 7 pcs 7 pcs
Part K Screw for net pole 9 pcs 9 pcs 9 pcs 9 pcs
Part L Enclosure door with
safety net 1 pcs 1 pcs 1 pcs 1 pcs
Part M Elastic toggle 32 / 64 pcs 32 / 64 pcs 44 / 88 pcs 44 / 88 pcs
Part N Net rope 2 / 1 pcs 2 / 1 pcs 2 / 1 pcs 2 / 1 pcs
Part O Top PVC skirt 1 pcs 1 pcs 1 pcs 1 pcs

5
3. ASSEMBLY AND INSTALLATION
Assembling the frame
Fitting the mat and installing the springs
Lay the frame sections (Part A) into a circle
with the spring holes facing upwards. Push
all sections together until all are fully mated
together.
Lay the mat flat inside the frame. Make sure the
logo is facing upwards. In order to make the
installation of the jumping mat easier, find the
four rings in the 12, 3, 6 and 9 o’clock position
directly oposite each other and attach four
springs on these locations first.Then continue by
attaching springs to every eighth ring, followed
by every fourth and so on until all springs are
attached.
At first, it may look like the mat won’t fit, it will
however stretch to the correct size when you
finish attaching all springs.
AKROBAT HINT:
Springs can be hard to attach, you will need a little force. Help
yourself by using one spring to pull another towards the frame
holes. Do not forget to wear gloves!
We recommend at least two people to assemble the trampoline. Use gloves to protect your hands from pinch points and
sharp points during assembly. Do not apply excessive force during assembly that will cause damage to the product.
The hole should not accumulate water (in which case the drainage is necessary) and it should be possible to clean during
maintenance.
TOOLS: You will need a cross-head screwdriver for the retaining wall PVC panels.
Important:Be sure all spring hooks
are well attached to the frame.
1
2

6
INSTALLATION AND USER MANUAL - GALLUS INGROUND
Digging the trampoline pit
Position the frame on the location you chose and mark the position on the ground. It’s best to mark
out a hole a bit wider than the diameter of your trampoline.
This will make it easier for you to put the frame in and find the right level. Dig the pit to the
following dimensions:
First, dig the outer hole to create a ledge for
your trampoline frame, which needs to be
25cm deep. This is the exact frame height, so
that the safety pad on top of the frame will be
just above the grass level. Continue by digging
the inner hole.
Dig out in a bowl shape to a depth of 75
cm (10ft & 12ft trampolines), or 90 cm
(13.5ft & 14ft trampolines).The inner hole
should be 40 cm narrower in diameter than
the trampoline, which leaves a 20 cm ledge all
around to place the trampoline.
TRAMPOLINE SIZE
Dimension A – Outer hole Dimension B – Inner hole Dimension C – Total depth
10 ft / cca. 305 cm 204 cm 75 cm
12ft / cca. 366 cm 264 cm 75 cm
13.5ft / cca. 411 cm 371 cm 90 cm
14ft / cca. 427 cm 387 cm 90 cm
4
Attaching the pvc retaining panels
The next step is screwing the PVC retaining
wall panels to the frame. You will need the
cross-head screwdriver and gloves. Take one
panel and place it against the outside of the
frame.You will find four holes in the frame and
four holes in the wall panel. Insert and tighten
the four screws to attach the panel tightly to
the frame. Repeat with all remaining panels.
3
AKROBAT HINT:
It’s a relatively easy task to hand dig the hole for smaller size trampolines, but it would be best to hire a
mini digger able to excavate most of the soil and leave you with the finishing touches.
Note:You will need to save some of the soil for later.

7
Placing the trampoline into the pit
Attaching the frame pad
Carefully place the trampoline on the ledge
covered with the weed barrier. Fill the
remaining free space on the outer rim with
the remaining soil, then cut the excess barrier
material off.
Check that the trampoline is well levelled.You
may want to remove the trampoline to make
any adjustments to the height that the frame
is sitting.Aim for the trampoline jump mat to
sit flush to the ground.
There should be no gap between the garden
and your trampoline.
Finally, re-lay the saved turf around the
trampoline and compact down as much as
possible.
Lay the safety pad on top of the trampoline, aligning the pad section joints with the joints of the frame and
the eyelets facing up. Feed the elastic toggles through the eyelets so the loop end of the tie faces outwards
and the toggle end is on the inside.
5
6
NOTE:
If you want to avoid grass growing under your
trampoline, weed protection cover is available as a
separate item for purchase at your seller.
Important:
The frame pad must cover the
entire frame and all springs.
Flip the frame pad over and pull the elastic
band around the frame. Insert the toggle into
the loop, then rotate the toggle inwards to
secure it. Repeat with all frame pad elastics.
7

8
INSTALLATION AND USER MANUAL - GALLUS INGROUND
Installation of the safety net
AKROBAT HINT:
If you find it too difficult to get the toggles in place, wedge a
screwdriver carefully between the frame and PVC panel to
attach the toggle. Using a flat-head screwdriver (or similar),
push the loop end between the wall panel and frame. Insert
the toggle from underneath and rotate to secure. Repeat with
all ties.
Start assembling the safety net by inserting the
enclosure pole attached to the door (Part L)
into the frame part with T-socket.
1
2
3
Continue by inserting all of the poles into the sockets,all the
way stretching the bottom edge of the net,in order to make
sure that the safety net fits tightly around the trampoline.
NOTE:
If you find the net too short/long towards
the end, adjust the entire netting starting
from the door towards the last pole.
Insert the bottom part of the door and start
unrolling the safety net around the mat. Make
sure the net is not twisted. After unrolling the
entire net, insert the final pole in the socket
next to the door - be sure to close the door
on the inside of the trampoline before inserting
the last pole.
Start inserting the first pole left from the door.
Keep the bottom edge of the net stretched
before inserting the next enclosure pole. Take
the net near the door and pull tightly towards
the first pole before inserting the pole through
the net and into the socket.
To assemble the top frame., take the shorter top
frame part with a hole in the middle (Part H).
This pole should be attached above the door and
tightened with the connector screw into the top
of the enclosure pole.
Continue by attaching two top frame parts
together, then taking a connector screw and
tightening it into the top of the enclosure pole.
Important:
There are two sizes of top frame parts
– alternate them according to the
frame legs above which the longer top
frame parts should be placed.

9
4
6
5Take the black rope and web it loosely around
the top rail and the net. Web the rope through
every 4th hole on the top edge of the net.Then
return to the beginning and tighten the rope, tying
it around the screw on the last enclosure pole.
Now hang the top edge of the net around the
connector screws. In order to come all the way
around the frame stretch the netting the same
way as while attaching the bottom part.
Next,take the protection foam and place it on the
top rail to form a full circle. Follow by covering
with the top PVC skirt, tying it with the black
rope.Attach the cord around the last screw.
Finally, attach the bottom edge of the netting
to the frame and around the spring with the
remaining toggle elastics.
7
NOTE:
If your trampoline parts set includes one
rope only, use half of the remaining elastic
toggles to attach the top edge of the net.

10
INSTALLATION AND USER MANUAL - GALLUS INGROUND
Cleaning the trampoline:
All Akrobat trampoline mats and frame pads are made of durable high-quality materials and should not be cleaned with
any aggressive cleaning products! Trampoline surfaces are best cleaned with mild soapy water and thoroughly rinsed
with water afterwards.
4. TRAMPOLINE MAINTENANCE
Check your trampoline before each season thoroughly – particularly the frame, frame pad, springs, jumping mat and
safety net. We advise regular check-ups during the season as well. In contrary, damaged parts could be overlooked,
which may result in severe accidents or injuries.
Your check list should include following points:
• All parts are well attached.
• All springs are well secured to the frame and the rings on the jumping mat.
• The trampoline has no damages, such as rips, holes, sharp, twisted or broken parts. If you notice any damage, change
the parts immediately.
• Check the safety net and the poles for potential damages and replace the safety net every 2 years.
For the best maintenance of your trampoline, also make sure no animals are allowed on the trampoline as they could
damage both the frame pad and the jumping mat.
The trampoline should be disassembled and withdrawn from use at once in case of any damage or missing parts until
the defects are repaired or parts replaced.
Extreme weather conditions can impact the trampoline materials, therefore follow these recommendations:
• Disassemble the safety net in case of strong wind and weigh the trampoline down.Store the safety net in a safe place.
• Remove the jumping mat during winter season as the weight of the snow could damage the mat.
• Protect the trampoline from direct heat, fire, sparks and fireworks.
• Protect your trampoline from heavy rain and snow as well.
The hole should not accumulate water (in which case the drainage is necessary) and it should be possible to clean
during maintenance.
PLEASE KEEP THIS MANUAL FOR LATER USE.
Remember, the trampoline should only be used by one person at the time!
Maximum user weight is defined by the size of the trampoline:
10 ft – 305 cm 100 kg
12 ft – 366 cm 130 kg
13.5 ft – 411 cm 130 kg
14 ft – 427 cm 130 kg
Your Akrobat trampoline is now ready to be used. Enjoy!
If this is your first trampoline, we advise you to start by learning the basic jumps described in this manual.
CONGRATULATIONS!

11
Akrobat trampoline weather cover
Akrobat trampoline shoe mat
Akrobat UV PVC protectant spray
Providing year-round maximum protection from damage
caused by weather and debris,Akrobat trampoline cover
will increase the lifespan of your trampoline and adds
durability for countless jumping moments. It is made of
UV-resistant high-quality PVC and available for all sizes
and shapes of Akrobat trampolines.
The shoe mat helps the child to stand comfortable, while
taking the shoes off as they prepare to climb the ladder
onto the trampoline. It also helps keeping the trampoline
nice and tidy.
All weather conditions and UV-radiation PVC trampoline protectant spray leaves an
enduring dirt resilient finish,keeping PVC surfaces clean of soil,sweat,body oils and other.
It will protect your frame pad from UV rays and extend the lifetime of PVC trampoline
parts. It is safe to use on all plastic parts, polyethylene, vinyl and clear vinyl surfaces.
5. TRAMPOLINE ACCESSORIES
Akrobat trampoline socks
Durable trampoline socks with high quality grips ensure a higher level of safety. The
traction material used on the soles of the socks provides friction that reduces sliding and
can decrease the likelihood of accidents. In case of numerous users, the socks also help
control the spreading of microbes which can be exchanged between bare feet.
Akrobat weed barrier
When installing an in-ground trampoline, it is advised to
cover the hole with a weed membrane, which will stop
the weeds from growing underneath your trampoline.
This way, you can prevent weeds to grow through the
springs and obstruct the jumping experience.

12
INSTALLATION AND USER MANUAL - GALLUS INGROUND
6. JUMPING INSTRUCTIONS
Each jumper must start by learning slow and controlled jumps. Safe landings are the base of trampoline jumping skills and are
important to learn at the beginning. Lack of these skills may result in severe injuries and/or damage.
Both jumper and instructor should keep in mind that steady balance at each jump represents the base of successful trampoline
jumping.
The stopping technique is equally important as jumping. Correct stopping represents one of the most important
safety precautions in trampoline jumping.When losing control of the jump and/or balance the jumper has to react quickly to
prevent injuries. In order to achieve this, the jumper should simply bend their knees before landing on the jumping mat.This
is the safest way to stop the jump and prevent accidents.
While learning and training trampoline jumping, it is advised four persons stand around the trampoline in order to help the
jumper if needed.Trampoline jumping is a physical strain and shouldn’t last too long.A tired jumper can easily succumb to
errors in jumping thus highly increasing risk of injury.
High trampoline jumps are considered advanced jumps and should not be allowed to inexperienced jumpers. It is extremely
important to be sure that the height of the jump corresponds to the experience of the jumper.
PLEASE NOTE:
Beginners should learn the basic body positions and practice the basic bounces described in this manual.
To learn how to balance and jump, stand in the middle of the jumping area and bounce softly up and
down to control the movement. Increase the intensity gradually, returning to the same position on the
jumping mat with each bounce.
Focus on the jumping mat when jumping, failing to do so may quickly result in losing balance and falling.
Do not perform somersaults without supervision! Somersaults should be carried out only by experienced
jumpers under supervision of an expert and using appropriate safety measurements.

13
7. BASIC TRAMPOLINE JUMPS
THE JUMPING JACK:
1. Start from a standing position with feet in shoulder
width apart, head up and eyes on the trampoline mat.
2. Swing your hands forward, above your head and back
in a circular motion.
3. Bring your feet together in mid-air and point your toes.
4. Land back on the center of the mat with your feet in
shoulder width (the same as the starting position).
THE FRONT DROP:
1. Start by softly bouncing up and down a few times.
2. Jump upwards and land with your hands and knees
forward.
3. Push yourself off with your hands and jump back to the
upright position.
THE PRAYING MANTIS:
1. Start with a low bounce.
2. Land on your knees shoulder width apart, keeping
your back straight and use your arms stretched out to
maintain balance.
3. Bounce back to the starting position by using the
bounce momentum and swinging your arms upwards.
BOTTOM BOUNCE:
1. Start with a basic starting position. Jump up, aiming to
the center of the jumping mat.
2. Land with your legs stretched in front of you, with
hands on both side of your hips and keep your back
straight
3. Push yourself up with your hands to rebound to the
starting position.

14
INSTALLATION AND USER MANUAL - GALLUS INGROUND
THE PANCAKE DROP:
1. Start off with a soft, low jump upwards.
2. Let yourself fall on your front, placing your hands on
the jumping mat in front of you.
3. Push yourself up to the starting position.
THE TURTLE DROP:
1. Start with a soft upwards jump.
2. Land on your back, keeping your chin close to your
chest and your knees bent Keep your chin towards
your chest as you land.
3. Kick your legs forward in order to jump up and land in
the starting position.
THE FLYING BALLERINA:
1. Start with the sit drop jump.
2. Jump and turn your head left or right and swing your
hands in the same direction to turn in the air.
3. Follow the motion with your hips to complete the turn.
4. Land in the sitting position to complete the jump.
You now master the basic jumps and are ready to jump even higher!
But remember to always stay in control of your jumps.
ENJOY IN PURSUING YOUR PASSION FOR JUMPING!
THE ROLLING STONE:
1. Start from the front drop position and push to the left
or right with your arms to start turning.
2. Turn your head and shoulders in the direction that
your body is turning.
3. Keep your back parallel with the jumping mat and your
head straight.
4. Return to the lying position to finish the jump, lying in
the opposite direction as at the beginning.

The purpose of inspection is identifying any obvious defects and sources of danger on the outside of the trampoline, which
are easily visible from the ground without the use of auxiliary objects.This covers cleanness, various obstacles or objects
that are close to the trampoline, missing parts, trampoline or jumping mat damages and excessive wear, etc.
Examination frequency: examinations should be performed daily before use and before each use.
DAT E HOUR Trampoline
is / is not suitable Checked by Signature Notes
REPORT OF REGULAR DAILY VISUAL TRAMPOLINE
EXAMINATION

INSTALLATION AND USER MANUAL - GALLUS INGROUND
The purpose of operational inspection is to check the trampoline in detail - it’s stability and functionality. Especially
identifying any obvious defects of wear due to vandalism and/or normal use of the trampoline. This includes surfacing,
safety distance, installation of accessories, labelling, stability and the overall level of wear of the trampoline.
In case of damaged trampoline or it’s parts, missing parts or other defects the trampoline must be removed from use until
all the defects are repaired.
Incorrect maintenance will result in discontinuing the validity of the trampoline warranty and the manufacturer’s liability
for any accidents which may occur.
Examination frequency: examinations should be performed at least once a month.
DAT E HOUR Trampoline
is / is not suitable Checked by Signature Notes
REPORT OF MONTHLY OPERATIONAL TRAMPOLINE
INSPECTION

Purpose:The main inspection shall be carried out in accordance with manufacturer’s instructions on maintenance in order
to ensure the level of safety of the trampoline, its base, supporting structure and parts of the trampoline (e.g. wear and
possible overall changes in the safety of the trampoline caused by improper changes or repair).
Failure to record regular inspections will result in discontinuing the validity of the trampoline warranty and the
manufacturer’s liability for any accidents which may occur.
Examination Period: at least once a year.
Reviewer: An authorized person by the manufacturer or an expert approved by the manufacturer.
MAIN ANNUAL INSPECTION REPORT
REVIEWED ELEMENTS YES NO
A. Trampoline base inspection
Visual inspection of the trampoline base: The trampoline is stable and on a leveLled surface.
B. Trampoline construction inspection
Visual inspection of the metal construction
Inspection of all structural elements and junctions: connecting elements, legs, rails, sockets, springs...
Conformity of the structural elements with the design check-up
Condition of PVC and textile parts: frame pad, safety net, skirt and weather cover check-up
C. Jumping mat inspection
Visual inspection of the jumping mat
D. PVC parts inspection
Visual inspection of PVC parts: frame pad, safety net, skirt and weather cover check-up
Repair or replacement of damaged parts
E. Overview of safety instructions for the trampoline
F. Remarks and observations (any defects or damages must be defined and recorded in this field)
Date and hour:
Trampoline is / is not suitable
Inspected by:
Signature

INSTALLATION AND USER MANUAL - GALLUS INGROUND

EXTEND YOUR WARRANTY TODAY!
Register your trampoline within 30 days of purchase and get a change
to win a monthly giveaway!
Register on: www.akrobat.com/registration

Crmosnjice 5b
8000 Novo mesto
Slovenia
E: [e-mail]
T: [phone]
www.akrobat.com
www.trampoline-park.eu
