STYLE 5148 MERCURYMASTER OSCILLATING NOZZLE
INSTALLATION, OPERATING, AND MAINTENANCE INSTRUCTIONS
The following is intended to provide the basic instructions for installation, operation, and maintenance. Read and
understand these operating instructions before use.
Read and follow the operating instructions before use.
Forreghtinguseonly.

Page 2
Product Ratings
Mechanical Specifications:
Parameter US Measure Metric Measure
Maximum Flow Rate 500 GPM 1900 LPM
Maximum Pressure 150 PSI 10 Bar
Mass (includes bracket and trunnions) 11.6 Lbs. 5.3 kg
Tools Required
• Hammer
• 1/8” Punch
• 5/8” Open end wrench
• 1/4” Allen wrench
Product Warnings
• Indicatesahazardoussituationwhich,ifnotavoided,WILLresultindeathorseriousinjury.
• Indicatesahazardoussituationwhich,ifnotavoided,COULDresultindeathorseriousinjury.
• Indicatesapotentiallyhazardoussituationwhich,ifnotavoided,mayresultinminorormoderateinjury.
• Addressespracticesnotrelatedtopersonalinjury.
• Thisproductisintendedforusewiththe MercuryQuickAttackportablemonitoronly.Readandfollow
theoperatinginstructionsforthemonitorbeforeuse.
• ReadandfollowtheoperatinginstructionsforStyle5148,500gpmbeforeuse.
• Useonlyforfirefightingbytrainedoperators.
• Donotexceedthemaximumpressureorflowratingsforthemonitor.
• Makesuremonitorlegsarefullydeployed,andallthreespikesareincontactwiththegroundand
safetystrapissecurebeforeuse.
• Makesurethemonitorispointedinasafedirectionbeforeflowingthewater.
•Make sure the monitor valve is closed when advancing the monitor. Do not move or lift the monitor
whileflowing.
• TheMercuryQuickAttackmonitorissuppliedwitha2.5”ballvalve.Openandclosethevalveslowly.
Openingandclosingthevalvetooquicklymayresultindamagetootherequipment,whichcanresult
inaninjurytotheoperatororothers.
• Donotalteranycomponentsinanyway.
• Chargetheunitslowly.Rapidchargingmaycauseapressuresurgewiththepotentialtocause
injuryordamagetotheunit.

Page 3
•Atpressuresbelowtheratedpressureindicatedonthelabel,thenozzlewillhavereducedowand
  reach.Besureyouhaveenoughowandpressureforthesituation(SeeIFSTAand
NFPA manuals for guidelines).
•Atpressuresbelowtheratedpressure,theoscillatingnozzlemaynotoscillate.Obstructionstothe
  owthroughthenozzlewillalsocausethenozzletonotoscillate.
•Notforuseonelectricalres.Maycauseelectrocution.
•EnsurethethreadonthenozzleswivelismatchedtothethreadontheMercuryQuickAttackoutlet.
Do not use thread adapters between the monitor and nozzle.
•Readandfollowthetippressureandowsintheoperatinginstructionsbeforeuse.
• Before operating the oscillating nozzle, make sure the connecting rod in Figure 6 is parallel
  withthewaterway.Failuretodosomaycausetheoscillatingmechanismtobindduringoperation.
• Do not adjust oscillating angle while oscillating.
•Ifanytagsorbandsonthenozzlearewornordamagedandcannotbeeasilyread,they
should be replaced.
•Forusewithfreshwaterorstandardreghtingfoamsonly.Notrecommendedforusewithsaltwater.
  Afterusewithfoamorsaltwater,ushwithfreshwater.
• Do not over tighten the nozzle onto the mating connections.
•Thenozzleisconguredforoptimumperformance.Donotalterinanymanner.
• Your nozzle should be inspected prior to and after each use to ensure it is in good operating condition.
Periodicallyanunanticipatedincidentmayoccurwherethenozzleisusedinamannerthatisinconsistentwithstandard
operating practices from those listed in IFSTA. A partial list of potential misuses follows:
 •Operatingabovemaximumratedpressureandow.
• Not draining and allowing water to freeze inside the nozzle.
• Dropping the nozzle from a height where damage is incurred.
 •Prolongedexposuretotemperaturesabove+130degreesF,orbelow-25degreesF.
• Operating in a corrosive environment.
 •Othermisusethatmightbeuniquetoyourspecicreghtingenvironment.
Therearemany“tell-tale”signsthatindicatenozzlerepairisinordersuchas:
 •Controlsthatareeitherinoperableordifculttooperate.
• Excessive wear.
• Poor discharge performance.
• Water leaks.
Ifanyoftheabovesituationsareencounteredthenozzleshouldbetakenoutofserviceandrepairedandtestedby
qualiednozzletechnicianspriortoplacingthenozzlebackintoservice.

Page 4
Bracket Installation
1. Using a hammer and a 1/8” punch remove the roll pin on the end of the handle closest to the outlet of the
  MercuryQuickAttackasshowninFigure1.
 2. RotatethehandleupwardandoutofthewaytogainaccesstothetoptrunnionasshowninFigure2.
3. Using a 5/8” open end wrench remove the top trunnion and the trunnion on the left side of the
  MercuryQuickAttack.
4. Position the bracket over the trunnion holes as shown in Figure 3.
 5. ApplyLoctite277orequivalenttoeachnewtrunnionprovidedwiththenozzle.Thetrunnionsare
  easilyinstalledbypushingdownontheoutletoftheMercuryQuickAttackwhichwillalignthetrunnionholes
  intheoutlet.Tightenusingthe¼”Allenwrench,andtightento25ft.-lbs.
 6. Whiletighteningthetrunnionsmakesuretheoutletcontinuestosmoothlyrotateupanddownandleftto
right. There should be no binding of the outlet in either plane of travel after the trunnions are tightened.
 7. Reinstallthehandlerollpinusingahammerandthe1/8”rollpin.Thenishedbracketinstallationisshown
in Figure 4.
FIGURE: 1
FIGURE: 2
Remove roll pin from this
end of the handle

Page 5
FIGURE: 3
FIGURE: 4
Elevation Lock Knob and Lower Trunnion Installation
1. When looking from the inlet towards the outlet of the monitor, using a 5/8” open end wrench remove the right
sidetrunnionfromtheelevationjoint.ApplyPermabondHH120orequalthreadlockingtothelockknob
trunnion and install the pre-assembled locking knob in its place. When tightening the lock knob trunnion
makesurethelockknobisfullyloosenedtoallowthetrunniontobecompletelytightened.
2. Usinga5/8”openendedwrenchremovethebottomtrunnionontherotationjoint.Toaccessthetrunnion
placetheoutletinthefullyraisedposition.
3. ApplyLoctite277orequaltothethreadsonthelongerlowertrunnionandinstallintotherotation
joint.Tightenusinga5/8”openendedwrenchto25ft.-lbs. The longer lower trunnion is required to limit the
lower elevation to 30 degree so the oscillating nozzle cannot be locked at an elevation lower than 30 degrees and left
unattended.
4. Operatethelockingknobtoconfirmtheelevationjointmovementisrestrictedwhenthelocking
knob is tightened.
5. Figure5showsafullyassembledMercuryQuickAttackwiththelockknobandlowertrunnioninstalled.
Fullyassembledmonitor
with bracket

Page 6
FIGURE: 5
Nozzle Installation
•EnsurethethreadonthenozzleswivelismatchedtothethreadontheMercuryQuickAttackoutlet.
•Beforeoperatingtheoscillatingnozzle,makesuretheconnectingrodingure6isparallelwiththe
   waterway.Failuretodosomaycausetheoscillatingmechanismtobindduringoperation.
 1. TightenthenozzleswiveltotheoutletoftheMercuryQuickAttack.Theswivelmustbetighttokeepthe
nozzle from loosening during operation.
 2. ThenozzlemustbeorientedasshowninFigure6toensureproperalignmentoftheconnectingrod.
 3. Followingtheoperatinginstructions,owwaterthroughthenozzleandmonitorassemblytoensurethe
oscillating mechanism does not bind during oscillation.
 4. Thenozzleisreadyforuse.
Lock Knob installed
Lower trunnion
installed

FIGURE: 6
Operating Instructions
•Chargealllinesslowlytofacilitateacontrolledwaterpressurebuild-upduringstart-up.Openand
   closeslowly.Rapidopeningwillproduceasuddenthrust.Rapidopeningorclosingcancausewater
   hammer.Haveenoughreghtersonthelinetosafelycontrolthereactionforcecreatedbythestream
•Makesurethelegsarefullydeployedandallthreespikesareincontactwiththegroundandsafety
strap is secure before use.
•Atpressuresbelowtheratedpressure,theoscillatingnozzlemaynotoscillate.Obstructionstoow
through the nozzle will also cause the nozzle to not oscillate.
• Do not adjust oscillation angle while oscillating.
 1. Theowsettingforthisnozzleis500gpm/1900lpmwithapressureof75psi/5barattheinlettothenozzle.
 2. WiththeoscillationselectorsettotheOFFposition,selectthedesiredoscillationangleof20°or40°bypushing
the center release button on the T-handle. As shownin Figure 8.
 3. Centerthemonitorandnozzleonthetarget.Thenozzlewilloscillatesymmetricallyaboutthecenterposition.
4. Turn the lock knob inward to lock the elevation in the desired position. Releasing the lock knob will allow
vertical repositioning of the nozzle.
 5. Withwaterowing,movetheoscillationselectorfromOFFtoONtobeginoscillation,Figure7.
 6. Whileowingrotatethepatternsleevetoobtaintheidealstreamquality.
 7. Tostoposcilation,movetheselectorfromONtoOFF.
Page 7
Connecting Rod

PHONE: [phone] or 800.228.1161 I FAX: [phone] or 800.531.7335 I akronbrass.com
© Akron Brass Company. 2017 All rights reserved. No portion of this can be reproduced without the express written consent of Akron Brass Company.
revised: 04/21
WARRANTY AND DISCLAIMER: We warrant Akron Brass products for a period of five (5) years after purchase against defects in materials or workmanship. Akron Brass will repair or replace
product which fails to satisfy this warranty. Repair or replacement shall be at the discretion of Akron Brass. Products must be promptly returned to Akron Brass for warranty service.
We will not be responsible for: wear and tear; any improper installation, use, maintenance or storage; negligence of the owner or user; repair or modification after delivery; damage; failure to
follow our instructions or recommendations; or anything else beyond our control. WE MAKE NO WARRANTIES, EXPRESS OR IMPLIED, OTHER THAN THOSE INCLUDED IN THIS WARRANTY
STATEMENT, AND WE DISCLAIM ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE. Further, we will not be responsible for any consequential,
incidental or indirect damages (including, but not limited to, any loss of profits) from any cause whatsoever. No person has authority to change this warranty.
ISO 9001 REGISTERED COMPANY
FIGURE: 7
FIGURE: 8
Maintenance Instructions
• Inspect nozzle prior to and after each use to ensure it is in good operating condition.
• Undernormalconditionsperiodicallyushingthenozzlewithcleanwater,cleaninggritanddirtfromaround
exterior moving parts will allow the nozzle to operate as designed.
• Overtimethesealsmayneedtobereplaced.ThiscanbeaccomplishedbypurchasingtheappropriateAkron
repairkit.UsequaliedmaintenancemechanicsorreturnthenozzletoAkronBrassCompanyforrepair.
• Regularlycheckthebafescrewtobesureitistight.
• Use low temp Lubriplate on metal parts and Parker O-Ring lubricant on O-Rings.
T-handle locking pin. With selector
switch in the off position push center
release button to disengage. Position
at20°or40°oscillationpoint.
Elevation Lock Knob
Moveselectorswitchfrom“OFF”
to“ON”tobeginoscillation.
